Dimplex Quantum Quick Start Manual page 2

Step 3:
Set the timer mode
There are four timer modes which decide when the
heater will be active ("Heating on"):
1) User timer: Select your desired timeframes (four
periods)
2) Out all day: 7.5 hours heating per day in two periods
(morning and evening)
3) Home All Day: 13 hours of heating per day, for
people who need heat throughout the day.
4) Away: Allows you to reduce the heating while you
are away. Set the number of days you are away from
home and the desired temperature for this period.
To choose a timer mode, press
to highlight 'Modes' and press the
can then select 'Timer Mode' or 'Frost Protect'. Choosing
'Frost Protect' will maintain a room temperature of 7°C.
Select 'Timer Mode' by rotating and pressing the
a list of Timer Modes will be shown. Their default settings
are shown in the table below (the factory setting on your
heater may vary from the example shown).
Period 1
06.30
User timer
-09.30
08.00
Home all day
-21.00
06.00
Out all day
-08.30
You can then choose to 'Select', 'Preview' or 'Modify'
the timer mode. Pressing 'Select' will choose this timer
option. You can view the times currently set with
'Preview' without risking accidental changes. If the pre-
set time periods don't suit you, 'Modify' allows you to
customise them.
Advance button
If the heater is in "Heating o
heat earlier, pressing advance will turn the heater to
"Heating on", bringing forward the start of the next
time period. This will use heat already stored in the
heater and so can leave less stored heat available for
later in the day, so use this setting sparingly. Pressing
and rotate the
menu
to select. You
dial
dial
Period 2 Period 3 Period 4
11.00 15.00 18.00
-13.00 -17.00
00.00 00.00 00.00
-00.00 -00.00
17.00 00.00 00.00
-22.00 -00.00
" mode but you need
advance when "Heating on" is showing will turn the
heater o until the next heating period. Advance can
be useful if you are in and out of home at di
times to those set on the timer.
Boost
The boost option (found by pressing menu) switches on
a booster heating element. You can choose the target
temperature and the duration of the boost (in minutes).
Once the boost has run for the selected time it will
automatically switch o
Note that the boost option uses the expensive rate of
electricity, and should be avoided except for emergencies
(for example, unusually cold weather), and that an 'auto
boost' option may be on.
dial
New models of the Dimplex Quantum can be
controlled remotely via a Dimplex app
dimplex.co.uk/remo-app).
and
Sometimes watching a video is the best way to learn
about using Quantum heaters.
There are some excellent short guides in this Dimplex
playlist (http://bit.ly/3YFc5vT)
And here are instructions for using the Dimplex
Quantum:
https://youtu.be/ImFAPhASICU
-22.00
-00.00
Remember to leave a gap of 30cm in front of
your heater to prevent a fire hazard.
-00.00
