A world of expertise
11285-8
Rev. 13F/11F
Operating Instructions
IMPORTANT
These instructions should be read carefully and retained for
future use.
Note also the information presented on the appliance.
Quantum Heater
Models:
QM050
Boost
Output
230/240V~:
353/385W
Storage
Element
Rating
230/240V~:
936/1020W
Rated
Charge
Period:
7.7 - 7 Hours
Energy
Cells:
12
Installed
Weight:
67kg
kWh:
7.2kWh
QM070
QM100
567/630W
792/880W
1435/1560W
2042/2220W
18
24
91kg
115kg
10.9kWh
15.5kWh
QM125
QM150
1017/1130W
1242/1380W
2540/2760W
3024/3300W
30
36
142kg
165kg
19.3kWh
23.1kWh
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Quantum QM100 and is the answer not in the manual?

Questions and answers

Related Manuals for Dimplex Quantum QM100

Summary of Contents for Dimplex Quantum QM100

  • Page 1 Operating Instructions A world of expertise IMPORTANT These instructions should be read carefully and retained for future use. Note also the information presented on the appliance. Quantum Heater Models: QM050 QM070 QM100 QM125 QM150 Boost Output 230/240V~: 353/385W 567/630W 792/880W 1017/1130W 1242/1380W Storage...
  • Page 2 fi tted around the heater, as is normal with heating appliances in similar circumstances. A range of guards specially designed for Dimplex heaters is available. If you require further information on these guards, please see contact details on back page of these instructions.
  • Page 3 CAUTION: DO NOT COVER SURFACES OF THE HEATER AND DO NOT OBSTRUCT AIR OUTLET GRILLES. • Surfaces of the heater should not be covered or obstructed as this can cause excessive temperatures that can be hazardous and may cause safety cut-outs to operate. This will stop the heater from working.

  • Page 4: The Benefi Ts Of Quantum

    The benefi ts of Quantum Quantum is designed to be a responsive heating system that meets your comfort requirements while optimising energy use. The heater releases heat in two ways: A small amount of heat is dispersed by ‘natural’ convection and radiation from the heater case. The vast majority of heat is released using the built- in fan that pushes hot air out from the heat outlet grille at the bottom of the product.
  • Page 5 Function Compared with traditional storage heaters the amount of energy released from the outer case of the heater is signifi cantly reduced, resulting in lower surface UE TO THE LOW ENERGY LOSSES FROM temperatures. This allows more effi cient running because the Quantum is heating the room only when THE CASING OF THE HEATER THE SURFACE you want it to.

  • Page 6: Operation

    Operation The user controls are located on the top right of the heater. The heater is fi tted with an adjustable electronic temperature controller and three buttons. Programmable timer Display screen ‘ Menu’ b utton ‘ Back’ button Comfort status ‘Selector Dial’...

  • Page 7: Control Functions

    Control Functions The heater controls can easily be adjusted by using a combination of the three buttons and the selector dial, which can be rotated and pressed. 1. The DISPLAY SCREEN shows the options available at each stage of the adjustment. 2.

  • Page 8: Setting The Date And Time

    Setting the Date and Time Your Quantum controller incorporates a real time clock with calendar function. The time clock has a battery backup that will keep the clock running in the event of a mains power outage. To adjust the time or date follow the steps below. Note - the display screen will return to standard display after a period of 20 seconds of inactivity.

  • Page 9: Choosing And Setting A Timer Mode

    Main Screen After 20 seconds the heater will default back to the Main Screen. Here the chosen temperature is displayed along with Comfort On or Comfort Off, which tells you whether you are in a timed heating period or not. Any use of the Advance function will be displayed here, and pressing the Selector Dial will show the Timer Mode etc.
  • Page 10 To choose a Timer Mode press Menu and rotate the Selector Dial to select ‘Timer Mode’ and press Selector Main Menu Dial. Date / Time Timer Mode Boost Options Select the mode required, again by rotating and pressing the Selector Dial. Timer Mode For options Out All Day and Home All Day, three Out All Day...
  • Page 11 In Holiday mode the number of days that the room will be unoccupied can be adjusted together with the Holiday required room temperature. Active Days Rotate the Selector Dial to choose a holiday period Temperature between 1 and 255 days, then press the Selector Dial. Rotate the Selector Dial to choose a temperture between 7°C (frost protection) and 26°C (comfort) to be maintained during this period and press the Selector...
  • Page 12 Boost A supplemental heating (boost) element controlled by the electronic thermostat is provided for occasions when a brief increase in heating is required. This will operate Boost Menu No Boost only by selecting ‘Menu’, then ‘Boost’ and then selecting 1 Hour 2 Hours a boost period of 1 hour, 2 hours, 3 hours, 4 hours or 3 Hours...

  • Page 13: Child Lock

    Options The Options menu allows you two choices; Report - This option presents information helpful in the Options event of a fault with the unit. Report DST rule DST Rule - The heater clock will automatically adjust for daylight saving (British Summer Time as it is often referred to).

  • Page 14: User Information

    User Information Press and hold the Selector Dial to display the User Information menu, three choices are available; SP Range - enables adjustment of the temperature User Info range available. Maximum range 7°C to 30°C. SP Range Factory - return all settings to the factory presets - Yes or No. Factory Extra Charge - forces an extra charge of up to four Extra Charge...
  • Page 15 (such as soot, cigarette smoke or incense generated from the burning of candles, etc.). A suitable shelf (available from Dimplex) may be fi tted to limit the extent of any wall discolouration.

  • Page 16: After-Sale Service

    If this product appears damaged when fi rst received or does not function correctly contact us by e-mail at aftersales@dimplex.co.uk or call 0844 879 35 88 and we will be able to help. For ROI please call 01 842 4833.
