- Page 1 S40 Video Processor Instructions Version：Ver.1.1 www.ledok.cn 第 1 页...
- Page 2 Statement Dear user friend ， thanks for choosing Shanghai Xixun Electronic Technology Co. ， Ltd. (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product.
- Page 3 Update Record Version Details Date Ver.1.0 Initial 2020.12.14 Ver.1.1 2th version 2024.10.22 The document is subject to change without prior notice.
- Page 4 Catalogue Interface definition ............................1 Hardware connection Diagram ........................5 Operation Menu ..............................6 Main Interface .............................6 Main Menu .................................10 Output ................................. 10 Output Resolution Setting ......................10 Custom Resolution .......................... 12 Image ................................13 Image Scaling ............................13 Input interception（Capturing） ....................14 Image Properties ..........................14 Scenarios ..............................
- Page 5 Version Information ........................23 Language ............................23 Time Settings ............................ 24 Key Lock ..............................24 Factory Settings ..........................24 Upgrade Processor .......................... 24...
- Page 6 Return/ cancel the current menu or action. SCALE Full screen zoon shortcht key Enter the source key introduction ：HDMI1 input source Input button, which is reused as” ” when the usb flash www.sysolution.net...
- Page 7 The long light indicates that the source is connected and in use. The indicator light flashes to indicate that the interface is in use but there is no signal source. The indicator light is off to indicate that the signal source is not in use. www.sysolution.net...
- Page 8 AUDIO IN 3.5mm Audio Interface. 1×USB 2.0 Interface，connecting to the U-disk，it supports 1080p@30fps Video files。 The U-Disk File System Supports NTFS、FAT32 and FAT16 ， but the exFAT （ FAT64 ） is not supported. Image Formats：jpg、jpeg、png and bmp。 www.sysolution.net...
- Page 9 3.5mm Audio Port AUDIO It supports the audio channel ： 3.5mm audio channel、 HDMI、USB Control Ports Ports Unit Illustrations USB-B USB debug port 100 megabit communication network port RS232 Debug Series Connection Port WIFI Wireless Router WIFI antenna (custom) antenna www.sysolution.net...
- Page 10 Hardware connection Diagram Software download and Installation : LEDOK express Download link: https://drive.google.com/file/d/1TOiJ_-raeULoJmh1D4fqEjmZ7tB6Jl0T/view?usp=sharing Ledset4.0 Download link: https://drive.google.com/file/d/1EjLo0ZHwKfAcyQEM6DvN6xmqyrjIdvfr/view?usp=drive_link www.sysolution.net...
- Page 11 Illustration Real Time Current display interface The input resolution of the currently selected input signal source;: No signal! Sending card image capture resolution Number: indicates the serial number of the network port ：Indicates that the receiving card is connected www.sysolution.net...
- Page 12 ：Indicates that the receiving card is not connected Function Status Icon Illustration Real-time temperature monitoring of equipment Real-time power monitoring of equipment Processor brightness value Timing brightness on 6、7 FULL SCREEN DISPLAY 1:1 Pixel to Pixel Display Screen freezes off Screen freezes on www.sysolution.net...
- Page 13 U disk is connected U disk is not connected The keys are not locked The Keys are locked Stop play Pause playback Previous Play www.sysolution.net...
- Page 14 Next Input Signal Source ：Blue background indicates selected ：Gray background means not selected www.sysolution.net...
- Page 15 In the main interface, press the knob to enter the menu operation interface, press the knob to enter the sub menu, and press ESC to return to the previous level. Output Output Resolution Setting Enter the "Output" menu, as shown in the figure below: www.sysolution.net...
- Page 16 First of all, the interface of each hardware device is normal and the input and output connections are correct. I will not introduce it in detail here. The first step is to set the output resolution, the specific operation: main www.sysolution.net...
- Page 17 When the output resolution that meets our needs is not available in the common output resolutions, such as 1920X1280 size, then the resolution must be customized. The specific operation: main menu-"output display"-"custom resolution", set the screen width Set it to 1920, screen height 1280, refresh rate 60, and application. www.sysolution.net...
- Page 18 LED screen. It will be reduced or enlarged, just adjust the horizontal start, vertical start, horizontal width, and vertical height to the image size we need. www.sysolution.net...
- Page 19 Turn on the interception function. The screen parameters we will intercept are such as "horizontal start, vertical" Start, image width, image height" are set. Image Properties Enter the "Image Properties" menu, as shown in the figure below： www.sysolution.net...
- Page 20 50, 0-100 Can be set. Sharpness adjust the sharpness value of the output image, the system default is 20, 0-64 can be set. adjust the tone value of the output image, the system default is 50, 0-128 can be set. www.sysolution.net...
- Page 21 Here, we can save and load the parameters set by the video processor, including the input signal, input resolution, output resolution, position offset, zoom, interception and other information to save as a template, which is convenient for next use. The system has 8 templates for users to save. www.sysolution.net...
- Page 22 There are 10 function settings in the advanced settings: "LED, EDID management, VGA correction, volume, freeze, switching effect, test mode, black screen, timing brightness, automatic brightness", which are introduced below. Enter the "LED" menu, as shown in the figure below： Select the network port arrangement mode "1X2, 2X1". www.sysolution.net...
- Page 23 Status: On means to turn on the timing switching function; Off means to turn off the timing switching function. Port: Switch the input signal source. d. Time: Set the switching time. Times: Switch times within the set time period. www.sysolution.net...
- Page 24 Switch: On means to turn on the timing switching function; off means to turn off the timing switching function. Brightness: switch the brightness value Time: set the switching time Times: switch times within the set time period EDID Management Enter the "EDID Management" menu, as shown below： www.sysolution.net...
- Page 25 Enter the sub-menu, select the common EDID "1366x768_60HZ, 1440x900_60HZ, DVI_1080P, HDMI_1080P" to quickly se. Custom EDID Enter the sub-menu, you can set "EDID type, image width, image height, refresh rate", the application takes effect VGA Calibration Enter the "VGA Calibration" menu, as shown in the figure below： www.sysolution.net...
- Page 26 Phase is to improve the output to the LED screen when there is an abnormal display (such as flash point, blurry), and the value can be adjusted from 0 to 2500.。 Switching Effects Special effects for switching between input signals, the default "fade in and fade out" effect, you can switch the "seamless switching" effect. www.sysolution.net...
- Page 27 "USB" signal switch button on the front panel to enter the U disk signal state. At this time, we enter the "U disk playback" from the main menu. If a U disk is inserted into the processor without pressing the "USB" signal switch button www.sysolution.net...
- Page 28 DVI, VGA, CVBS" signal switching function is invalid, press "Esc" to exit the U disk playback operation. System Version Information That is the version information of the current video processor system program. Language The default system language is "Chinese", you can switch to "English" language, press OK www.sysolution.net...
- Page 29 (Confirm/Return)"; press the OK key to confirm, and press the Esc key to return. Upgrade Processor Put the V56 upgrade program into the U disk, insert the USB port, select "Upgrade Processor" until the upgrade automatically restarts and enter the status interface, at which www.sysolution.net...
- Page 30 www.sysolution.net...
