- Page 1 Android Control Card Y50 Instructions Version：Ver.1.1...
- Page 2 Statement Dear user friend ， thanks for choosing SHENZHEN SYSOLUTION TECHNOLOGY CO.,LTD (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product. We strive to be precise and reliable when writing the document，and the content may be modified or changed at any time without notice.
- Page 3 Update Record Version Details Date Ver.1.0 Initial 2020.09.27 Ver.1.1 Update content 2024.08.29...
- Page 4 Catalogue Overview ..............................1 Functional Features ..........................3 Interfaces ..............................5 Technical Parameters ..........................6 Hardware Connection Diagram ......................9 Ledset4.0 Configuration ........................10 Smart Setting ........................13 Receiver Configuration .......................18 LEDOK Upload /Publish Program ....................20 Network Configuration ........................25 Wired Ethernet Configuration ..................25 WiFi Configuration ......................
- Page 5 The Y50 control card is a high-performance control card that can operate stably in extremely harsh environments such as high and low temperatures. The performance configuration series uses an industrial grade quad core processor with a main frequency of 1.5GHz, and supports 1GB+8GB of memory (compatible with 2GB+16GB and requires...
- Page 6 6. The software and platform are designed to run stably and maintain efficiently. 7. Apply UV three proof adhesive, with a national standard of double 85 protection level, dust-proof, moisture-proof, anti-static, and salt spray resistant. www.sysolution.net...
- Page 7 Please provide the country of use for shipment; Support switching between AP mode and Station mode. AP mode: Y50 emits hotspots that are found by other devices; Station mode: Y50 does not emit hotspots, but connects www.sysolution.net...
- Page 8 The user terminal connects to the AP hotspot that comes with Y50, with a default SSID of "SN number" and a default password of "12345678"; 10. Supports USB cameras; 11. Supports timing/synchronization, precise automatic...
- Page 9 Interfaces www.sysolution.net...
- Page 10 Technical Parameters Features Description Type Y50-WIFI（ no 4G）/Y50-NA、Y50-EU、Y50-LA、Y50-G、Y50-J Y50：1300,000 pixels，resolution 1920 (W)or1920 (H) , custom Pixel resolution support Communication Ethernet port、WiFi、USB mode Cortex-A35 4 core main frequency1.5GHz Mali-G31MP2 OpenGL ES3.2, Vulkan 1.0, OpenCL 2.0 Dvalin-2EE System memory 8GB Emmc+1GB LPDDR3...
- Page 11 -China（China/India） FDD-LTE：B1/3/5/8 TDD-LTE：B38/39/40/41 Compulsory Certification： SRRC/ Y50-CH TDSCDMA：B34/39 NAL/ CCC WCDMA：B1/8 Others ：WHQL CDMA 1X/EVDO：BC0 GSM：B3/5/8 Operator certification：AT&T/ T-Mobile/Rogers/ TelusVerizon/AT&T -North America (FirstNet)/T-Mobile/U.S. Y50-NA FDD-LTE：B2/4/5/7/12/13/17 Cellular/Rogers/ Telus WCDMA： B2/4/5 Mandatory / conformance certification：FCC/ IC/ PTCRB Others ：WHQL -Eurasia Operator certification：...
- Page 12 -Latin America （LA/AU/Newsland） Compulsory Certification：GCF/ FDD-LTE：B1/3/5/7/8/28 Y50-LA FCC/ Anatel/ NCC/RCM TDD-LTE：B40 Others：WHQL WCDMA：B1/2/5/8 GSM：B2/3/5/8 Operator certification：Deutsche Telekom/ Verizon/ AT&T/ -Global Sprint/U.S. Cellular/ Telus FDD-LTE：B1/2/3/4/5/7/8/12/13/ Mandatory / conformance 18/19/20/25/26/28 certification：GCF/ CE/ FCC/ Y50-G TDD-LTE：B38/39/40/41 PTCRB/ IC/ Anatel/IFETEL/ WCDMA：B1/2/4/5/8/6/19 SRRC/ NAL/ CCC/ KC/ NCC/ GSM：4 frequencies...
- Page 13 Hardware Connection Diagram www.sysolution.net...
- Page 14 How to find Ledset4.0: Please open Ledok Express software, Click ‘Terminal Control, Click ’Advanced’, Enter password 888 Click ‘start Leset4.0’. Note: Please make sure to install the display apk when using ledset 4.0. Step 1: Tick the card, click ‘Firmware management’. www.sysolution.net...
- Page 15 Step 2: Check whether display is running, click com.xixun.display, click ‘check running state. If the state is running, you can use Ledset4. 0 normally. If the state is not running, follow the steps below to install display： 1. Click ‘Select Online APK’, Choos ‘display’, click ‘ok’ www.sysolution.net...
- Page 16 2. Click ‘Upgrade’ .When the status is ‘Install success’ , the display has been installed. www.sysolution.net...
- Page 17 (1) Click on the main menu of the software 'Normal' icon, enter the receiver card configuration. click "Refresh" button and will see the cards information and receiving card number, then click on the 'Smart setting' button, according to the current LED module actual situation enter the corresponding parameters. www.sysolution.net...
- Page 18 '; if the module only one color signal data or only one R data (except monochrome screen, and control the red, green and blue LED chips are connected in series), then select ' RGB serial '. www.sysolution.net...
- Page 19 （4） Click ‘Next’ to enter the Scan Lines window. Number of rows between two bright lines plus 1 row. Select the scanning lines according to the actual display of the current module, if the led module 32scan, then choose 32; if it is 8scan module, then choose 8. www.sysolution.net...
- Page 20 (if the module does not have pixel point blinking, please connect the LED module to the first data interface of the receiver card or change the data cable to all interfaces, or try to insert the virtual point to try). www.sysolution.net...
- Page 21 （7）Smart settings will be prompted after the completion of the window, and then click the 'trace complete' button, and then send the data to the screen www.sysolution.net...
- Page 22 Jump back to Receiver settings and then change the box design first, choose Refresh rate first and other parameters keep default, then click the Send button in the bottom, and then click Save button to solidify the parameters , www.sysolution.net...
- Page 23 Notes ：Refer to the LedSet4.0 operating manual for more details. www.sysolution.net...
- Page 24 As shown in the figure, the top is the type of material that can be added, you can add video, pictures, text, digital clocks, analog clocks, etc., according to the need to choose, this article to pictures and videos as an example. www.sysolution.net...
- Page 25 The default playback time of the added photo material is 10s, if you need to change the playback time, you can change it in the widget properties. www.sysolution.net...
- Page 26 Click the ‘+’at the top left to add a second material and the ‘X’ to delete the material page. When the program is finished, you can click ‘Play/Stop’ on the top to preview the program. You can close the preview by clicking the right mouse button. www.sysolution.net...
- Page 27 Click publish button after done all setup, and select the controller id and click send, 100% means send success. www.sysolution.net...
- Page 28 The finished program will present in the solution management. At this time, you can check the program and click "Edit" to enter the program page again to modify the program, and then follow the above steps to send the program. www.sysolution.net...
- Page 29 Network configuration，first is Wire，can setup the controller IP address. NOTES： Controller will get access to internet by wire as first priority. Must remove the LAN cable from controller if choose WIFI or 3G internet and choose automatically acquisition IP. www.sysolution.net...
- Page 30 Wait for about 3 minutes，controller will come online. Please watch the“Internet”light， if it flashing regularly means online success ， go to AIPS platform (www.ledaips.com) and check it. NOTES： If could not scanning the WiFi， please try to turn on/turn off Software or WiFi Switch. www.sysolution.net...
- Page 31 If the ‘internet’ light does not flash, check whether the APN is set correctly.If there is no error, you can reboot the controller and wait for it to go online. www.sysolution.net...
- Page 32 NOTES： If controller can’t get online success，please checking following things： 4G antenna has plugged correctly? Y/M series controller，make sure the LAN cable removed. APN is correct or not？ (Consult with the carrier" available) SIM card has activate? SIM card has enough money and 4Gdata service? www.sysolution.net...
- Page 33 AIPS Cloud Platform Register Register For AIPS Platform Visit www.ledaips.com and choose Register to starting input related information，click done and verified the link sent by email，finish the register. Oversea address：www.ledaips.com www.sysolution.net...
- Page 34 www.sysolution.net...
- Page 35 Click “add simple program” button and set correct screen width and height pixels and click OK. Input program name and select the material from left side ， here are 3 zones including material in the left side ， program editing in the middle and preview window in the right side. www.sysolution.net...
- Page 36 Choose materials and set program name，can check preview in the right window. Can set the display duration time here，see screenshot in below： www.sysolution.net...
- Page 37 Will see program in the list after save. Advanced Program Advanced program including image， video， clock， text， audio and support more layers. Clcik “add advanced program” button and set correct screen width and height pixels，click ok. www.sysolution.net...
- Page 38 Here are 4 zones including media group，time panel，preview and program property. Click “New layer ” button and select media file then add to the time panel，for example： select video file and add to time panel. www.sysolution.net...
- Page 39 Can set the program parameters，start and end time， www.sysolution.net...
- Page 40 Save and quit after setup all parameters and program name. Then jump to program list interface ， you can click green button of create task quickly and then select controller and send. www.sysolution.net...
- Page 41 Use the “Edit” button to modify the existing program. Add multi-line text，click the text (single or muti-text)and add to the time panel www.sysolution.net...
- Page 42 Setup parameters for text，including the start and end time. Setup the text color，font size and add more pages，please pay attention to our TIPS message in below，save and quit after finish. www.sysolution.net...
- Page 43 Send Program Click “create task quickly” button in the program list interface and will jump to the terminal interface directly. Select the controller and send program www.sysolution.net...
- Page 44 In the bottom part of terminal interface ， will see program task then choose the program task and click send. www.sysolution.net...
