- Page 1 Sync&Async Dual Modes Sending Card Instructions Version：V2.2...
- Page 2 Dear user friend ， thanks for choosing SHENZHEN SYSOLUTION TECHNOLOGY CO.,LTD (hereinafter referred to as Sysolution) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product. We strive to be precise and reliable when writing the document，and the content may be modified...
- Page 3 Ver.2.2 Content update 2023.09.14 The document is subject to change without prior notice. Note： The Instructions fit for Sysolution Media player，including M50BS，M60BS，M70BS and M80BS ， M70BS and M80BS are async&sync media player M50BS and M60BS are pure asynchronous media player.
-
Page 4: Table Of Contents
Catalogue Hardware Connection Diagram ....................1 Parameter Contrast ...........................2 Software Operation Procedures ....................3 LedSet4.0 Setup ..........................4 Sending card setu ........................4 Smart setup ..........................6 Receiver Card Setup ....................... 13 Screen Connection ........................19 LedOK Setup System Parameters ....................24 LED Screen Width and Height Pixels ................24 LedOK Setup Network ........................ - Page 5 Button of sync&async setup ....................41 Switch schedule ........................42...
-
Page 6: Hardware Connection Diagram
Hardware Connection Diagram Synchronous connection Asynchronous connection www.sysolution.net... -
Page 7: Parameter Contrast
Parameter Contrast Model M50B-D M60B-S M70B-S M80B-S Single network Dual network Dual network Communication port,WiFi, UsB port，WiFi, USB Four network portWiFi, Methods driveoptional drive，optional port,optional 4G optional 4G On-Load Pixel 650,000 1.3 million 2.3 million Discount Max Discount Max width 7680... -
Page 8: Software Operation Procedures
Software Operation Procedures www.sysolution.net... -
Page 9: Ledset4.0 Setup
M70 IP address. Please click “refresh” button on the right top if can not detect controller IP. You can also enable “ RJ45 cable directly connect ” option and click Detect button to detect controller IP. www.sysolution.net... - Page 10 Click Terminal control and select the controller， go to Advanced parameters and input password 888 to enter setup interface. Then click the “Start Ledset4.0 configure led module” button in the bottom. www.sysolution.net...
-
Page 11: Smart Setup
Choose Sender in Ledset4.0 and make sure the card number and sending card all correct. Note: LedSet4.0 cannot detect the sending card，please close the firewall and other anti-virus software. Smart setup Choose Normal mode debug. www.sysolution.net... - Page 12 Choose Smart setup wizard and start configuration www.sysolution.net...
- Page 13 R data (In addition to the single color screen ， and the chip controlling the red ， green and blue LED lights is connected together)，then select “RGB serial”. Double clock ： No need to choose when configure normal module. Only need to www.sysolution.net...
- Page 14 D，E，F signal for second clock when configure double clock led module. ⑩Low delay scheme：Usually closed. Click“Next Step” to enter the “scan line number ” window and select the scan line according to the actual display of the current module. www.sysolution.net...
- Page 15 Click “Next Step”to enter the select color window.Select the corresponding display color according to the state mode. www.sysolution.net...
- Page 16 Note： If the LED module has no pixel flashing， the first can connect the LED module to the first group of data interface (JP1 port) of the receiving card; Second， you can select all the data line options under the list; Third，you can try to insert virtual points. 11. Click Complete to finish the smart setup. www.sysolution.net...
- Page 17 12. Click finish. www.sysolution.net...
-
Page 18: Receiver Card Setup
14. Box Design ， choose Normal design and click Modify ， then enter the box width and height pixels according to your cabinet and choose the correct cascading direction and click complete. Output mode： with symmetrical to quadruple strip outputs，It can give full play of www.sysolution.net... - Page 19 Triple strip mode：1-8，9-16，17-24，Each 8 sets of data are carried in three parts horizontally with the same width and height Quadruple strip： 1-6， 7-12， 13-18， 18-24， Each 6 sets of data are carried in four parts horizontally with the same width and height. www.sysolution.net...
- Page 20 ， flower screen and other abnormal phenomena.Generally 12.5~17.86. Duty cycle： refers to the duty cycle of the clock phase. Changing this data can make the scanning clock phase higher generally set to 50%. Line changing time/discharge time/sweeping position： mainly adjust the scan screen www.sysolution.net...
- Page 21 Note: When sending data，you can specify the network port or the specified card for sending， or reset the position of the receiving card， so that the position of all interface cards is zero and the same position is displayed. www.sysolution.net...
- Page 22 17. Observe whether the box is displayed normally. Then click the “save” button and solidify the data to the receiving card to prevent data loss from power off and restarting. www.sysolution.net...
- Page 23 18. Finanlly click Save Box Config button and save the configuration file to laptop. www.sysolution.net...
-
Page 24: Screen Connection
(usually receiving card number) is consistent with the number ofthe connected，if not consistent，please check the hardware connection ， whenconnecting several sending cards please switch to find the correspondingsending card for debugging. www.sysolution.net... - Page 25 Switching sending card： if there are more than one sending cards in the same network，can switch to the correct sending card when sending parameters. www.sysolution.net...
- Page 26 Choose the “Connect HUB” option; Select the sending card Ethernet port and setup the“hub address” ; Choose “hub address”and do screen connection; Quick connect ： the entire screen is loaded with only one network cable and the www.sysolution.net...
- Page 27 Revert ALL： will revert all setup for all network ports. 21. Click send and choose “as the main sender” and save to device; or choose “As the backup sender”to save to backup sender device. For double sender backup only work for synchronous controller. www.sysolution.net...
- Page 28 www.sysolution.net...
-
Page 29: Ledok Setup System Parameters
LedOK Setup System Parameters LED Screen Width and Height Pixels LedOK Express software， advanced parameters and enter screen width and height pixels， then click save. www.sysolution.net... -
Page 30: Ledok Setup Network
Network configuration，first is Wire，can setup the controller IP address. NOTES： Controller will get access to internet by wire as first priority. Must remove the LAN cable from controller if choose WIFI or 3G internet and choose automatically acquisition IP. www.sysolution.net... -
Page 31: Wifi Configuration
If controller can’t get access to internet through WiFi，please double check the steps below： A.WiFi antenna plug correctly. B.WiFi password is correct or not. C.If the Wireless router being accessed too many terminals? D.E series controller switch on WIFI mode? www.sysolution.net... -
Page 32: 3G/4G Setup
“ Internet” light will flashing fast for dialing up then flashing regularly means get online success. NOTES： If controller can’t get online success，please checking following things： A.3G antenna has plugged correctly? B.Y/M series controller，make sure the LAN cable removed. www.sysolution.net... - Page 33 C.APN is correct or not？ D.SIM card has activate? SIM card has enough money and 3G data service? E.Check 3G signal at least 13 and above? Click Network status detection to check 3G signal. www.sysolution.net...
-
Page 34: Aips Cloud Platform Register
AIPS Cloud Platform Register Register For AIPS Platform Visit www.ledaips.com and choose Register to starting input related information，click done and verified the link sent by email，finish the register. Oversea address：www.ledaips.com www.sysolution.net... - Page 35 www.sysolution.net...
-
Page 36: Aips Cloud Programing
Click “add simple program” button and set correct screen width and height pixels and click OK. Input program name and select the material from left side，here are 3 zones including material in the left side，program editing in the middle and preview window in the right side. www.sysolution.net... - Page 37 Choose materials and set program name，can check preview in the right window. Can set the display duration time here，see screenshot in below： www.sysolution.net...
-
Page 38: Advanced Program
Will see program in the list after save. Advanced Program Advanced program including image，video，clock，text，audio and support more layers. Clcik “add advanced program” button and set correct screen width and height pixels， click ok. www.sysolution.net... - Page 39 Here are 4 zones including media group，time panel，preview and program property. Click “New layer” button and select media file then add to the time panel， for example： select video file and add to time panel. www.sysolution.net...
- Page 40 Can set the program parameters，start and end time， www.sysolution.net...
- Page 41 Save and quit after setup all parameters and program name. Then jump to program list interface，you can click green button of create task quickly and then select controller and send. www.sysolution.net...
- Page 42 Use the “Edit” button to modify the existing program. Add multi-line text，click the text (single or muti-text)and add to the time panel www.sysolution.net...
- Page 43 Setup parameters for text，including the start and end time. Setup the text color，font size and add more pages，please pay attention to our TIPS message in below，save and quit after finish. www.sysolution.net...
-
Page 44: Send Program
Send Program Click “ create task quickly ” button in the program list interface and will jump to the terminal interface directly. Select the controller and send program www.sysolution.net... - Page 45 In the bottom part of terminal interface，will see program task then choose the program task and click send. www.sysolution.net...
-
Page 46: Synchronous And Asynchronous Setup
Async: means the M70 work without laptop or other extra device，it will accept the programs from the LEDAIPS platform and display. Manual or schedule. Also can click read back button to know controller current mode. www.sysolution.net... - Page 47 Switch schedule In schedule setup interface，can add schedule tasks according to customer requests，default status is displaying asynchronous content. After finishing setup，click apply. Can also export the schedule task from software to computer，or you can import the schedule tasks into software. www.sysolution.net...
