Summary of Contents for SYSOLUTION Y50
- Page 1 Y50 Universal Instructions Version：Ver.1.0...
- Page 2 Statement Dear user friend，thanks for choosing SSHENZHEN SYSOLUTION TECHNOLOGY CO.,LTD (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product. We strive to be precise and reliable when writing the document，...
- Page 3 Update Record Version Details Date Ver.1.0 Initial 2022.07.18 The document is subject to change without prior notice.
-
Page 4: Table Of Contents
Catalogue Overview ..............................1 Functions &Features ..........................2 Interfaces ..............................4 Technical Parameters ..........................5 Hardware Connection Diagram ......................8 Software Operation Procedures ......................9 LedSet4.0 Basic Setting ........................10 Sending card configuration ...................... 10 Smart Setup ...........................12 Receiver Card Setup ........................22 Screen Connection ........................ - Page 5 Advanced Program ........................43 Send Program ..........................49...
-
Page 6: Overview
Overview Sysolution Y50 is a type of product that allows users to publish programs and control through PC, cell phone, Pad and other user terminals; it supports wireless transmission to eliminating wiring troubles, like a router for wireless network configuration;... -
Page 7: Functions &Features
10. support for secondary development, support for remote cluster control on the cloud platform. 11. Built-in Web Sever, support local web production, support PC, cell phone, Pad and other user terminals program release and display control, cluster remote program release and display control, cluster remote monitoring screen status. www.sysolution.net... - Page 8 1080P video hard decoding, 1GB running memory. 13. 16.8GB of internal storage space, 4GB available to users. 14. User terminal connects to Y50 WiFi hotspot, default SSID is "SN number", default password is "12345678". 15. Support GPS timing/time alignment.
-
Page 9: Interfaces
Interfaces Y50 Interfaces www.sysolution.net... -
Page 10: Technical Parameters
Technical Parameters Features Description Type Y50-WIFI（ no 4G）/Y50-NA、Y50-EU、Y50-LA、Y50-G、Y50-J Pixel Y50：920,000 pixels，resolution 1280（w）*720（h） Communication Ethernet port、WiFi、USB mode Cortex-A35 4 core main frequency1.5GHz Mali-G31MP2 OpenGL ES3.2, Vulkan 1.0, OpenCL 2.0 Dvalin-2EE System memory 8GB Emmc+1GB LPDDR3 Operating syste Android 9 WiFi IEEE 802.11b/g/n 2.4G... - Page 11 -China（China/India） FDD-LTE：B1/3/5/8 TDD-LTE：B38/39/40/41 Compulsory Certification： SRRC/ Y50-CH TDSCDMA：B34/39 NAL/ CCC WCDMA：B1/8 Others ：WHQL CDMA 1X/EVDO：BC0 GSM：B3/5/8 Operator certification：AT&T/ T-Mobile/Rogers/ TelusVerizon/AT&T -North America (FirstNet)/T-Mobile/U.S. Y50-NA FDD-LTE：B2/4/5/7/12/13/17 Cellular/Rogers/ Telus WCDMA： B2/4/5 Mandatory / conformance certification：FCC/ IC/ PTCRB Others ：WHQL -Eurasia Operator certification：...
- Page 12 -Latin America （LA/AU/Newsland） Compulsory Certification：GCF/ FDD-LTE：B1/3/5/7/8/28 Y50-LA FCC/ Anatel/ NCC/RCM TDD-LTE：B40 Others：WHQL WCDMA：B1/2/5/8 GSM：B2/3/5/8 Operator certification：Deutsche Telekom/ Verizon/ AT&T/ -Global Sprint/U.S. Cellular/ Telus FDD-LTE：B1/2/3/4/5/7/8/12/13/ Mandatory / conformance 18/19/20/25/26/28 certification：GCF/ CE/ FCC/ Y50-G TDD-LTE：B38/39/40/41 PTCRB/ IC/ Anatel/IFETEL/ WCDMA：B1/2/4/5/8/6/19 SRRC/ NAL/ CCC/ KC/ NCC/ GSM：4 frequencies...
-
Page 13: Hardware Connection Diagram
Hardware Connection Diagram www.sysolution.net... -
Page 14: Software Operation Procedures
Software Operation Procedures www.sysolution.net... -
Page 15: Ledset4.0 Basic Setting
2. Then click Terminal Control, select Control Card, open Advanced Settings, and enter the password (888) to enter the Advanced Settings screen. www.sysolution.net... - Page 16 3. Click Use LedSet4.0 to configure the LED module at the bottom of the Advanced Settings screen to open the LedSet4.0 software interface. 4. In the LedSet 4.0 interface, open the transmitter card and make sure that the transmitter and receiver cards are connected properly and communication is established with the software. www.sysolution.net...
-
Page 17: Smart Setup
Note: LedSet3.0 cannot detect the sending card, please close the firewall and other anti-virus software. Smart Setup Choose Normal mode debug. www.sysolution.net... - Page 18 Choose Smart setup wizard and start configuration. www.sysolution.net...
- Page 19 RGB，then the module data group is 2). Card type ： type of receiving card currently used for debugging which can directly view according to the identity on the receiving card. Blanking polarity： low/high effective，normally use the default one. www.sysolution.net...
- Page 20 R data (In addition to the single color screen， and the chip controlling the red， green and blue LED lights is connected together)，then select “RGB serial”. Double clock： No need to choose when configure normal module. Only need to choose D，E，F signal for second clock when configure double clock led module. www.sysolution.net...
- Page 21 Click Next step and enter choose of Data polarity，please choose correct according to screen changes. www.sysolution.net...
- Page 22 Click “ Next Step ” to enter the ” OE polarity selection window ” .Select the corresponding state according to the actual display of the current module. www.sysolution.net...
- Page 23 10. Click “Next Step” to enter the “scan line number” window and select the scan line according to the actual display of the current module. www.sysolution.net...
- Page 24 11. Click “Next Step”to enter the select color window.Select the corresponding display color according to the state mode. www.sysolution.net...
- Page 25 12. Click “ Next step ” to enter the “ intelligent Settings ” window and do the walk-points according to the actual display of the module. www.sysolution.net...
- Page 26 13. Click Complete to finish the smart setup. 14. Click finish. www.sysolution.net...
-
Page 27: Receiver Card Setup
Receiver Card Setup 15. It can be configured by means of “smart setting” or by default “option modules” (applicable to receiving cards D90-75) to load module file or by “open box file” after loading preservation cabinet file. www.sysolution.net... - Page 28 Normal output： 1 to 24 sets of data are loaded from top to bottom. Symmetrical：The data of the receiving card (1-12) group is equipped with the left half lamp board，and the data of (12-24) group is equipped with the right half lamp www.sysolution.net...
- Page 29 17. The System will auto calculate the performance configuration parameters after done box design，you can also adjust some options to make display effect better. Refresh rate ： an important indicator of the Led screen.Increasing the refresh frequency can improve the water ripple when using the camera to take pictures. www.sysolution.net...
- Page 30 50%. Line changing time/discharge time/sweeping position： mainly adjust the scan screen afterglow， the newline value time can be increased if serious ，generally take the default values. Min OE width ： Min response time. When the refresh cannot be improved www.sysolution.net...
- Page 31 18. Click the”send data” button to send the program to the receiving card. www.sysolution.net...
- Page 32 19. Observe whether the box is displayed normally. Then click the “save” button and solidify the data to the receiving card to prevent data loss from power off and restarting. www.sysolution.net...
- Page 33 20. Finanlly click Save Box Config button and save the configuration file to laptop. www.sysolution.net...
-
Page 34: Screen Connection
Load：load the saved screen configuration file. Save to file：save the display configuration information to the computer in (.* dcc ) format. Send ： send screen configuration information to the sending and receiving cards. www.sysolution.net... - Page 35 Ethernet port 1 of sending card has connected 1 receiving card，while Ethernet port 2 of sending card no receiving card. Switching sending card ： if there are more than one sending cards in the same network，can switch to the correct sending card when sending parameters. www.sysolution.net...
- Page 36 Configure button after choose. If choose 2 means LED screen is double sides， you need do screen connection one by one. Starting location：LED display interception position of input signal source.The default state is (0，0)，which means that the LED display starts at the point (0，0) of the video source. www.sysolution.net...
- Page 37 Hidden connection line：When checking the hidden connection line box，the display wire knowledge will be hidden. Revert：cancel the lastest operation Reset Netport：will revert all setup for current Ethernet port. Revert ALL： will revert all setup for all network ports. www.sysolution.net...
- Page 38 23. Click send and choose “as the main sender” and save to device; or choose “As the backup sender”to save to backup sender device. For double sender backup only work for synchronous controller. www.sysolution.net...
- Page 39 www.sysolution.net...
-
Page 40: Ledok Setup System Parameters
LedOK Setup System Parameters LED Screen Width And Height Pixels LedOK Express software，advanced parameters and enter screen width and height pixels， then click save. www.sysolution.net... -
Page 41: Ledok Setup Network
Controller will get access to internet by wire as first priority. Must remove the LAN cable from controller if choose WIFI or 3G internet and choose automatically acquisition IP. WiFi Configuration Turn on WIFI and scanning WIFI hotspot，then enter wifi password and click save. www.sysolution.net... - Page 42 A.WiFi antenna plug correctly. B.WiFi password is correct or not. C.If the Wireless router being accessed too many terminals? D.E series controller switch on WIFI mode? E.Try another WIFI hot spot. F.Y/M series controller，please make sure the LAN cable removed. www.sysolution.net...
-
Page 43: 3G/4G Setup
B.Y/M series controller，make sure the LAN cable removed. C.APN is correct or not？ D.SIM card has activate? SIM card has enough money and 3G data service? E.Check 3G signal at least 13 and above? Click Network status detection to check 3G signal. www.sysolution.net... -
Page 44: Aips Cloud Platform Register
AIPS Cloud Platform Register Register For AIPS Platform Visit www.ledaips.com and choose Register to starting input related information，click done and verified the link sent by email，finish the register. Oversea address：www.ledaips.com www.sysolution.net... - Page 45 www.sysolution.net...
-
Page 46: Aips Cloud Programing
Click “add simple program” button and set correct screen width and height pixels and click OK. Input program name and select the material from left side ， here are 3 zones including material in the left side ， program editing in the middle and preview window in the right side. www.sysolution.net... - Page 47 Choose materials and set program name，can check preview in the right window. Can set the display duration time here，see screenshot in below： www.sysolution.net...
- Page 48 Will see program in the list after save. Advanced Program Advanced program including image， video， clock， text， audio and support more layers. Clcik “add advanced program” button and set correct screen width and height pixels，click ok. www.sysolution.net...
- Page 49 Here are 4 zones including media group，time panel，preview and program property. Click “New layer ” button and select media file then add to the time panel，for example： select video file and add to time panel. www.sysolution.net...
- Page 50 Can set the program parameters，start and end time， www.sysolution.net...
- Page 51 Save and quit after setup all parameters and program name. Then jump to program list interface ， you can click green button of create task quickly and then select controller and send. www.sysolution.net...
- Page 52 Use the “Edit” button to modify the existing program. Add multi-line text，click the text (single or muti-text)and add to the time panel www.sysolution.net...
- Page 53 Setup parameters for text，including the start and end time. Setup the text color，font size and add more pages，please pay attention to our TIPS message in below，save and quit after finish. www.sysolution.net...
- Page 54 Send Program Click “create task quickly” button in the program list interface and will jump to the terminal interface directly. Select the controller and send program www.sysolution.net...
- Page 55 In the bottom part of terminal interface ， will see program task then choose the program task and click send. www.sysolution.net...
