- Page 1 E2X Series Screen Configuration And TAXIHUB Platform Instructions Version：V.1.1...
- Page 2 Statement Dear user friend, thanks for choosing Shanghai Xixun Electronic Technology Co., Ltd. (hereinafter referred to as Xixun Technology) as your LED advertising equipment control system. The main purpose of this document is to help you quickly understand and use the product.
-
Page 3: Table Of Contents
Catalog Overview ................................1 Functions And Features ............................ 2 Interfaces Description ............................3 Technical Parameters ............................5 Hardware Connection Diagram ........................7 Software Operation Procedures ........................8 LED Display Smart Setup ..........................9 1. Software Connection ..........................9 2. Network Configuration ........................9 3. - Page 4 Update Record Version Details Date Ver.1.0 Initial 2020.09.08 Ver.1.1 Content change 2020.12.16 Note: The document is subject to change without prior notice.
-
Page 5: Overview
WiFi or 4G internet, also require to operate by smart phone. Shanghai Xixun SYSOLUTION designed E2X for all those requirements, which will lead the development of led vehicle signs market and make users to accessing in a simple way. -
Page 6: Functions And Features
Build in Web server, support editing local web page, also allow to editing and sending programs from laptop, iPhone, android phone, with offline LEDOK express software to send programs within local network； Support RGB module with1-32 scanning and static types； Industrial on board Flash：8GB. www.sysolution.net... -
Page 7: Interfaces Description
Interfaces Description E22 interfaces & description www.sysolution.net... - Page 8 E24 interfaces & description E26 interfaces & description www.sysolution.net...
-
Page 9: Technical Parameters
Communication type 4G full Netcom、WiFi、USB Quad-core A7（32bit）four cores 1.1GHz A307 409.6MHz 8GB Emmc+1GB LPDDR3 Operation system Android 5.1 WiFi IEEE 802.11b/g/n 2.4G GNSS GPS/Beidou/Glonass Bluetooth Bluetooth BT4.1 -China FDD-LTE:B1/3 TDD-LTE:B38/39/40/41 3G/4G frequency TDSCDMA:B34/39 （optional） WCDMA:B1/8 CDMA 1X/EVDO:BC0 GSM:B3/5/8 www.sysolution.net... - Page 10 Audio support Camera support Weather forecast support Readback display support content Software Easyboard www.sysolution.net...
-
Page 11: Hardware Connection Diagram
Hardware Connection Diagram www.sysolution.net... -
Page 12: Software Operation Procedures
Procedures www.sysolution.net... -
Page 13: Led Display Smart Setup
(EXX-XX-XXXXX) released by the control card, click "Connect" and enter the password (the default password is 12345678). 2. Network Configuration Click "System network server configuration" on the main interface of EasyBoard to configure the cloud platform account and network. www.sysolution.net... -
Page 14: Cloud Platform Account Binding
The server address in China is：www.taxihub.cn The foreign server address is：www.ledaips.com 4. WiFi Configuration (1) Enable “WiFi switch” , waiting for 3 seconds, and click “Scanning WiFi”, select the WiFi name and write down the WiFi password. Click “Save”. www.sysolution.net... - Page 15 If could not scanning the WiFi, please try to turn on/turn off Software or WiFi Switch. If controller can’t get access to internet through WiFi, please double check the steps below: WiFi antenna plug correctly; WiFi password is correct or not; www.sysolution.net...
-
Page 16: G/4G Configuration
(1) Enable 3G/4G option, Choose correct country code, 460 is Chinese code for example (If do not know your country code, please click Network status detection button and check IMSI number, the first 3 numbers are the country code). (2) Select the Operator name and input or auto-recognize the APN, then click “Save”. www.sysolution.net... - Page 17 Y/M series controller, make sure the LAN cable removed. APN is correct or not? SIM card has activate? SIM card has enough money and 4G data service? Check 4G signal at least 13 and above？Click Network status detection to check 4G signal. www.sysolution.net...
-
Page 18: Platform Release Program
Platform Release Program 1. Add AD (1) Enter the "Release By Grouping" interface, and click to add a program. (2) Edit "Campaign Name". (3) Open the "Media Library", select an existing material or upload a local material, and then click www.sysolution.net... - Page 19 (4) Select "Duration", the image can choose the existing time long or a custom duration. (Unit is second, video animation automatic identification time) (5) Select the vehicle terminal group that plays the advertisement, and click www.sysolution.net...
-
Page 20: Release Advertisement
(6) Click to complete the ad addition. 2. Release Advertisement (1) Go back to the "Campaign List" unreleased page. www.sysolution.net... - Page 21 (3) Click “OK”, there will be a window indicating whether the operation is successful. (4) You can see the newly launched advertisement on the "Released" screen. (5) Click "Stop" to set the advertising playing period, when the time will automatically www.sysolution.net...
- Page 22 (6) In "Stop Ads Result", click "Details" to view the terminal that has downloaded and played the AD. (7) If you need to add more ads, click to add them again. www.sysolution.net...
-
Page 23: End Of Page
If necessary, the online customer service will communicate with you in time. The industry experience will definitely give you a satisfactory answer, Shanghai Xixun sincerely looks forward to the follow-up cooperation with you! Sincerely with our best wishes Shanghai XiXun Electronics Co.,Ltd. 2022/04 www.sysolution.net...
