CSO SL9800 Instructions For Use Manual

Slit lamp
Hide thumbs Also See for SL9800:

Advertisement

Quick Links

Download this manual
COSTRUZIONE STRUMENTI OFTALMICI
SLIT LAMP
INSTRUCTIONS FOR USE
SL9800 / SL9900 / SL9900 ELITE
COSTRUZIONE STRUMENTI OFTALMICI
Via degli Stagnacci 12/E | 50018 Scandicci (FI) | ITALY
Phone: +39 055 722191 | Fax: +39 055 721557
cso@csoitalia.it | www.csoitalia.it
IFU305EN02.07 - 10/2023
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the SL9800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CSO SL9800

Summary of Contents for CSO SL9800

  • Page 1 COSTRUZIONE STRUMENTI OFTALMICI SLIT LAMP INSTRUCTIONS FOR USE SL9800 / SL9900 / SL9900 ELITE COSTRUZIONE STRUMENTI OFTALMICI Via degli Stagnacci 12/E | 50018 Scandicci (FI) | ITALY Phone: +39 055 722191 | Fax: +39 055 721557 cso@csoitalia.it | www.csoitalia.it IFU305EN02.07 - 10/2023...
  • Page 3 ANUFACTURER ECLARATIONS 2.9.1 Electromagnetic emissions ................. 18 DEVICE DESCRIPTION ................21 ..................21 UPPLY DESCRIPTION 3.1.1 SL9800 device ..................... 25 3.1.1 Device SL9900 and SL9900 ELITE ................ 27 3.1.2 Power supply unit ....................29 3.1.3 Chin rest ......................30 3.1.4 Ophthalmic table ....................
  • Page 4 OW TO INSTALL THE ACCESSORIES 4.12.1 How to install the video camera (Xx-D) .............. 60 4.12.2 How to install the illuminator (SL9800) .............. 61 4.12.3 How install the illuminator (SL9900 and SL9900 ELITE) ........62 4.12.4 How to install the additional light diffusion filter (SL9900 and SL9900 ELITE) ..63 4.12.5...
  • Page 5 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 INTRODUCTION The slit lamp is the result of a long research period, carried out by experts in the sector in order to give the product technical innovation, quality and design. SYMBOLS Within the instructions for use, on the package or on the device, the following symbols...
  • Page 6 TILTING OF THE LIGHTING ASSEMBLY. THE DEVICE SL9900 ELITE IS ALSO EQUIPPED WITH ILLUMINATOR. THE DEVICES SL9800 AND SL9900 ARE AVAILABLE IN THE XX AND XX-D MODELS. THE DEVICE SL9900 ELITE DEVICE IS AVAILABLE IN THE XX-D MODEL. THE CODING "XX" IDENTIFIES THE TYPE OF MICROSCOPE SUPPLIED WITH THE DEVICE AND INSTALLED ON THE OBSERVATION UNIT.
  • Page 7 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Keep the original packaging, as free assistance does not cover failures caused by improper packaging of the device when this is shipped to an authorized Service Centre. Before using the device, check that there is no sign of damages due to transport or an incorrect storage, that could compromise the correct functioning of the device.
  • Page 8 MANUFACTURER IDENTIFICATION C.S.O. SRL Costruzione Strumenti Oftalmici Via degli Stagnacci, 12/E 50018 - Scandicci (FI) - ITALY phone: +39-055-722191 - fax +39-055-721557 cso@csoitalia.it www.csoitalia.it This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 8/80 8/80...
  • Page 9 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 SAFETY SAFETY WARNINGS DANGER Danger of electric shock. Do not let water fall on the device. Do not immerse the device in water or other liquids. DANGER Danger of electric shock. If the power cables are damaged, have them replaced at an authorized Service Centre, in order to prevent any risk.
  • Page 10 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 CAUTION The power grid shall have a residual-current device (IΔn=30mA) and circuit breaker (Vn=230V) to protect the device. Place the device so that the power socket is easily accessible. It is forbidden to carry out any maintenance operation on the device not mentioned in the instructions for use.
  • Page 11 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 DEVICE IDENTIFICATION 2.2.1 REGISTRATION DATA IN THE LIST OF MEDICAL DEVICES The device registration data can be verified on the Italian Ministry of Health website at this page: Ministero della Salute - Ricerca dispositivi 2.2.2...
  • Page 12 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 SL9800 device, Xx and Xx-D model Fig. 3 - Data plate for the Xx model Fig. 4 - Data plate for the Xx-D model SL9900 device, Xx and Xx-D model Fig.
  • Page 13 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 2.2.4 POWER SUPPLY UNIT DATA PLATE Fig. 9 - Data plate of the power supply unit INTENDED USE The device is characterized by an innovative design of the optical observation unit which adopts a multilayer anti-reflective treatment system.
  • Page 14 SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Illumination (device SL9800) The device is equipped with a professional LED illuminator placed in the lower part of the device. The LED illumination allows a high-quality observation and a perfect comfort for the patient.
  • Page 15 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Video camera The new digital video camera has been designed for ophthalmological purposes. The video camera is based on a high performance CCD sensor, characterized by an excellent colour rendering. The increasing in resolution and in speed (doubled in the progressive live mode) make tiny details really sharp and displaying very flowing.
  • Page 16 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 ELECTROMEDICAL DEVICE CLASSIFICATION Classification based on the IEC 60601-1:2005 + A1:2012 technical standard Technical data Value Type of protection against direct and indirect Class II contacts Applied parts Type B Protection degree against humidity IP20 (no protection against infiltration by liquids) Sterilisation or disinfection method...
  • Page 17 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 DISPOSAL AT THE END OF THE USEFUL LIFE Warnings for the correct disposal of the device in accordance with Directive 2012/19/EU and Directive 2011/65/EU relating to the reduction of the use of hazardous substances in electrical and electronic equipment, as well as waste disposal.
  • Page 18 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 MANUFACTURER DECLARATIONS 2.9.1 ELECTROMAGNETIC EMISSIONS The device is designed to be used in a room with the following electromagnetic characteristics: Emission test Compliance Electromagnetic environment The device uses radio frequency energy only for its internal functioning.
  • Page 19 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 IEC 60601-1-2 Immunity test Compliance level Electromagnetic environment Proof level ±6 kV on contact ±6 kV on contact Floors shall be wood, concrete or Electrostatic ceramic tile. If the floors are covered discharge.
  • Page 20 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 (1) Portable and mobile RF communication equipment should be used no closer to any part of the device, including cables, than the recommended separation distance (d) calculated from the equation applicable to the frequency of the transmitter. d=1.167*sqrt (P) d=1.167*sqrt (P) 80 MHz to 800 MHz d=2.333*sqrt (P) 800 MHz to 2.5 GHz...
  • Page 21 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 DEVICE DESCRIPTION SUPPLY DESCRIPTION SL9800 device Fig. 10 - Supply description This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 21/80...
  • Page 22 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Name Description Chin rest Optional (*) Adjustable height. Adjustable distance between chin and forehead. Fixation point included. Wheel cover Protection against accidental crushing of fingers. Power supply unit Optional (*) A cable is provided with the power supply unit.
  • Page 23 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Device SL9900 and SL9900 ELITE Fig. 11 - Supply description This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 23/80...
  • Page 24 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Name Description Chin rest Optional (*) Adjustable height. Adjustable distance between chin and forehead. Fixation point included. Wheel cover Protection against accidental crushing of fingers. Power supply unit Optional (*) A cable is provided with the power supply unit.
  • Page 25 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 3.1.1 SL9800 DEVICE Fig. 12 - Device SL9800 - left side Name Description Yellow filter insertion rod Light diffusing filter Prism-holder head Calibration testing tool Dial with rotation indicator To adjust the slit rotation...
  • Page 26 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Fig. 13 - Device SL9800 - right side Name Description Locking/unlocking knob for the binoculars or the video camera Joystick Microscope selector To select magnifications Illuminator LED illuminator (Optional)
  • Page 27 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 3.1.1 DEVICE SL9900 AND SL9900 ELITE Fig. 14 - Device SL9900 and SL9900 ELITE - left side Name Description Lighting unit LED illumination Illuminator LED illuminator (*) Calibration testing tool Lighting assembly arm...
  • Page 28 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Fig. 15 - Device SL9900 and SL9900 ELITE - right side Pos Name Description Filter selector Slit height adjustment knob Locking/unlocking knob for the binoculars or the video camera Horizontal tilting setting knob Slit width adjustment knob Joystick...
  • Page 29 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 3.1.2 POWER SUPPLY UNIT Fig. 16 - Power supply unit Description Data plate Power supply unit Power indicator light Power switch Power cable connector of the fixation point Connector of the device power supply cable...
  • Page 30 SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 3.1.3 CHIN REST Fig. 17 - Chin rest for SL9900 and SL9900 ELITE device (left) and for SL9800 device (right) Description Power cable of the fixation point Chin rest support Chin rest handle...
  • Page 31 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 3.1.4 OPHTHALMIC TABLE Different table models are available based on the customer's choice. The table is composed of a table top on which the cogged guides for the device compartment are installed. The table has one or two motorised telescopic columns that permit the height adjustment of the table top.
  • Page 32 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Fig. 19 - Personal Computer The PC shall comply with standard IEC 60950-1 Information technology equipment - Safety - Part 1: General requirements. If the PC is installed in the patient area it is necessary to install an isolation transformer compliant with the directive IEC 60601-1:2005 + A1:2012- "Medical electrical equipment - Part 1: General requirements for basic safety and essential performance".
  • Page 33 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 TECHNICAL DATA 3.2.1 SL9800 DEVICE Technical data Value Supply voltage 120-230 V ±10% 50/60 Hz 1 A Size (HxWxD) 440 x 313 x 335 mm Device weight 7.4 kg Base movement (x, y, z)
  • Page 34 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Chin rest Technical data Value Fixation point Red light adjustable Chinrest stroke 70 mm ±1 3.2.2 DEVICE SL9900 AND SL9900 ELITE Technical data Value Supply voltage 120-230 V ±10% 50/60 Hz 1 A Size (HxWxD) 675 x 313 x 335 mm Device weight (Xx, Xx-D)
  • Page 35 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Technical data Value Light intensity 284000 Lux Chin rest Technical data Value Fixation point Red light adjustable Chinrest stroke 70 mm ±1 To request spare parts, specify the code given in the paragraph "Spare parts and accessories list"...
  • Page 36 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Technical data Value Interpupillary distance From 50 mm to 80 mm Barrier filter Yellow Microscope 5x Technical data Value Galilean convergent with magnification change system - Type 5 positions Ocular convergence angle 6°...
  • Page 37 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 DEVICE USE HOW TO INSTALL THE DEVICE CAUTION Danger of falling device. The device must be installed on a horizontal and stable surface. Place the ophthalmic table in the room. The table shall be lifted by two people.
  • Page 38 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Verify the position of the sticker relative to the central axis (A). Remove the protective film. Place the sticker pad between the two guides and the sliding plate. Respect the indicated distances while placing the sticker pad on the table top. Fig.
  • Page 39 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 39/80...
  • Page 40 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Place the device on the table top and align the cogwheels on the guide rails. Install the two wheel covers on the guides on the table top. Fig. 25 - Place the device Fig.
  • Page 41 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 If the eye level indicator does not reach the required height, adjust the chin rest. Loosen the 4 locking grub screws placed on the chin rest support. Slide the chin rest rods until reaching the required height of 380 mm. Tighten the previously loosened locking grub screws.
  • Page 42 SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 HOW TO CONNECT THE DEVICE SL9800 device Fig. 31 - Connecting the device SL9800 Name Connection cable between the base and the lighting unit Power cable of the fixation point Power supply cable of the power supply unit...
  • Page 43 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Device SL9900 and SL9900 ELITE Fig. 32 - Connection of the device SL9900 and SL9900 ELITE Name Connection cable between the base and the lighting unit Power cable of the fixation point...
  • Page 44 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 HOW TO PLACE THE ELECTRIC CABLES CAUTION Danger of falling device. Do not leave free cables in a place where people could walk. CAUTION Danger of stumbling and falling. Do not leave loose cables which may represent an obstacle or danger for the patient or operator.
  • Page 45 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 INDICATIONS GIVEN BY THE FUNCTIONING INDICATORS For monitoring the device functioning it is necessary to verify the status of the operation indicator on the device base. Status of the operation indicator on the base Meaning Indicator on.
  • Page 46 Verify the correct eyes position respectively to the shooting channel. Fig. 33 - Patient position on the chin rest Fig. 34 - Patient position on the chin rest SL9800 SL9900 - SL9900 ELITE Turn the knob to lift or lower the chin cup.
  • Page 47 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 HOW TO VISUALIZE THE IMAGE (SL9800) Move towards the patient's eye with the device. d=68 mm with prisma holder head d=80 mm with split head Move the joystick and place the device with the shooting channel near the patient's eye.
  • Page 48 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Bring the image into focus by rotating the eyepieces for the refractive error correction. Fig. 40 - Refractive error correction Turn the ferrule (A) to select diaphragm diameter and slit height. Turn the filter selector (B) to select the filters.
  • Page 49 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Perform some micro movements with the joystick to obtain the best image quality. Use the turning locking/unlocking knob to change the microscope position. Fig. 43 - Placing the device Fig. 44 - Microscope position adjustment Use the locking/unlocking knob to change the position of the lighting assembly.
  • Page 50 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 During the examination, adjust the slit width. If necessary, change the image magnification. Fig. 47 - Slit width adjustment Fig. 48 - Microscope magnification change If necessary, readjust the slit rotation by checking the value on the dial with rotation indicator (A).
  • Page 51 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 HOW TO VIEW THE IMAGE (SL9900 AND SL9900 ELITE) Move towards the patient's eye with the device. Move the joystick and place the device with the shooting channel near the patient's eye.
  • Page 52 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Bring the image into focus by rotating the eyepieces for the refractive error correction. Fig. 54 - Refractive error correction Adjust the slit width. Insert the yellow filter by lifting the rod on the microscope. Fig.
  • Page 53 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Perform some micro movements with the joystick to obtain the best image quality. Use the turning locking/unlocking knob to change the microscope position. Fig. 57 - Placing the device Fig. 58 - Microscope position adjustment Use the locking/unlocking knob to change the position of the lighting assembly.
  • Page 54 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 During the examination, adjust the slit height. If necessary, change the microscope magnification. Fig. 61 - Adjust the slit height Fig. 62 - Microscope magnification change Adjust the slit rotation by checking the value on the dial with rotation indicator (A) to place the lighting unit correctly.
  • Page 55 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Loosen the knob (A) to carry out horizontal tilting. Tighten the knob to lock. Fig. 64 - Locking/unlocking knob Fig. 65 - Horizontal tilting This document is the property of C.S.O. SRL.
  • Page 56 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 To tilt vertically press the locking lever (C). The lamp can be inclined following the twitches of the blocking lever. Fig. 66 - Locking lever for vertical tilting Fig. 67 - Vertical tilting This document is the property of C.S.O.
  • Page 57 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 HOW TO ACQUIRE THE IMAGE (XX-D) If the device is equipped with a video camera, it is possible to acquire images by means of the management application software and then analyse the acquired images.
  • Page 58 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.10 HOW TO CHANGE CHIN CUP PAPERS At the end of the examination, remove and replace the chin cup paper so that it is always new and hygienic for the next patient. The device is provided with a package of chin cup papers.
  • Page 59 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 4.11 HOW TO TURN OFF THE DEVICE CAUTION Do not turn off the PC or disconnect the connection cable between the PC and the device when the program is in use (Xx-D).
  • Page 60 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.12 HOW TO INSTALL THE ACCESSORIES The accessories described may be optional and vary depending on the device model. 4.12.1 HOW TO INSTALL THE VIDEO CAMERA (XX-D) The 2x microscope does not support the video camera installation. Support the binocular (A).
  • Page 61 Fig. 75 - Installing the binoculars Fig. 76 - Connecting the video camera 4.12.2 HOW TO INSTALL THE ILLUMINATOR (SL9800) Place the illuminator (A) next to the lighting assembly. Tighten the screw (B) to fasten the illuminator. Connect the connection cable (D) to the connector (E) on the circuit board of the lighting unit.
  • Page 62 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.12.3 HOW INSTALL THE ILLUMINATOR (SL9900 AND SL9900 ELITE) Turn the slit width adjustment knob in order to lower the rod (E). Manually lift the component (D) and hold it up. Insert the flat ring (I) on the rod (E).
  • Page 63 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 4.12.4 HOW TO INSTALL THE ADDITIONAL LIGHT DIFFUSION FILTER (SL9900 AND SL9900 ELITE) To install the additional light diffusion filter: Insert the light diffusion filter (B) on the rod (D). Use the opening (A) on the light diffusion filter and the profile (C) on the rod.
  • Page 64 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.12.5 HOW TO INSTALL THE SINGLE OR DOUBLE OUTPUT SPLITTER (XX-D) The 2x microscope does not support the video camera installation. Support the binocular (A). Loosen the locking/unlocking knob on the microscope (B). Remove the binocular.
  • Page 65 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 4.12.6 HOW TO INSTALL THE VIDEO CAMERA FITTING (XX-D) Before installing the accessory, install the separator. Remove the lid (C) installed on the separator (B). Install the video camera fitting (A) on its seat on the splitter. Align the plug (D) of the video camera fitting with the plug (E) on the splitter.
  • Page 66 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.12.7 HOW TO INSTALL THE CAMERA FITTING (XX-D) Before installing the accessory, install the separator. Remove the lid (C) installed on the separator (B). Install the camera connector (A) on its seat on the separator. Align the plug (D) of the camera connector with the socket (E) on seat of the separator.
  • Page 67 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 4.12.8 HOW TO INSTALL THE OCULAR FOR THE SECOND OPERATOR Before installing the accessory, install the separator. Remove the lid (D) installed on the separator (B). Lift the locking/unlocking knob on the microscope (C) on the ocular for the second operator (A).
  • Page 68 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 4.12.9 HOW TO REPLACE EYEPIECES FOR THE BINOCULAR Remove the eyepieces installed on the binoculars. Slightly press the new eyepieces on the binocular to install them. Check that the eyepieces are inserted properly. Fig.
  • Page 69 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 ORDINARY MAINTENANCE SAFETY WARNINGS DANGER Danger of electric shock. Unplug the power supply cable from the power socket before disinfecting or cleaning the device and before any maintenance operation. CAUTION The device does not contain any part requiring user intervention. Do not remove any part of the device.
  • Page 70 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 5.2.1 RECOMMENDED PRODUCTS FOR CLEANING AND DISINFECTION CAUTION Danger of material damage. Do not use solvents, acidic or basic solutions (pH <4,5 or >8,0), abrasive or caustic substances, chlorine- based and chlorine-derived products.
  • Page 71 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 5.2.2 CLASSIFICATION OF THE CRITICALITY OF THE DEVICE CAUTION The device is supplied non-sterile and it shall not be sterilized prior to use. This device is classified as "non-critical" since it only comes into contact with intact skin and therefore has a low infectious risk.
  • Page 72 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 5.2.4 CLEANING THE APPLIED PARTS CAUTION Danger of material damage. Only use detergent and disinfectant products specifically approved for medical devices or medical- surgical devices. Applied parts that come into direct contact with the patient during the examination shall be thoroughly cleaned after each use with a disinfectant approved for the purpose.
  • Page 73 SPARE PARTS AND ACCESSORIES LIST Code Description 100257720 SL9900 LED table top chin rest 100258700 SL9800 LED table top chin rest 103301800 Table top 45x90 cm, with rails and drawer 330259900 Connecting power cable - lamp base, length 80 cm per LED 330259901...
  • Page 74 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 TROUBLESHOOTING Issue Cause Solution Note If the device is powered trough the auxiliary Connect the power cable of power supply of the Power cable not the device to the power The device does not table, check the connected to the power...
  • Page 75 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 Issue Cause Solution Note The PC does not have the Make sure the PC The application Follow the application minimum features features are equivalent software does not software installation required for the...
  • Page 76 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 Issue Cause Solution Note Some colours and materials of the table Missing Missing installation of the top may not reflect the acknowledgement sticker pad under the Install the sticker pad under infrared light.
  • Page 77 SL9800-SL9900-SL9900 ELITE INSTRUCTIONS FOR USE IFU305EN02.07 - 10/2023 This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 77/80...
  • Page 78 INSTRUCTIONS FOR USE SL 9800-SL 9900-SL 9900 ELITE IFU305EN02.07 - 10/2023 This document is the property of C.S.O. SRL. Any reproduction, even partial, it is prohibited. 78/80 78/80...
  • Page 80 COSTRUZIONE STRUMENTI OFTALMICI Via degli Stagnacci 12/E | 50018 Scandicci (FI) | ITALY Phone: +39 055 722191 | Fax: +39 055 721557 cso@csoitalia.it | www.csoitalia.it SL9800-SL9900-SL9900 ELITE | IFU305EN02.07- 10/2023...
