E1
Reolink E1 smart home security camera captures Super HD videos in the resolution
of 2304x1296 (3 megapixels), and with 8 infrared LEDs, it can see up to 40ft in the
dark. Stay connected with what you care anytime with all-day home camera.
1. Specs
1
Daylight Sensor
2
8 IR LEDs
3
Lens
4
Status LED
5
Built-in Mic
6
Reset Button
7
Micro SD Card Slot
Advertisement
Related Manuals for Reolink E1
Summary of Contents for Reolink E1
- Page 1 Reolink E1 smart home security camera captures Super HD videos in the resolution of 2304x1296 (3 megapixels), and with 8 infrared LEDs, it can see up to 40ft in the dark. Stay connected with what you care anytime with all-day home camera.
- Page 2 LAN Port Speaker Power Status Light Status Light Camera Status Camera is starting up/ Solid Blue WiFi connection succeeded WiFi is not configured/ Blinking Blue WiFi connection failed 2. Setup and Install Set up the Camera What’s in the Box Note: The package content may vary and update with different version and platforms, please take the below information only for a reference.
- Page 3 Power Adapter*1 E1 *1 Mounting Plate *1 Quick Start Guide*1 Reset Needle*1 Surveillance Sticker*1 Pack of Screws*1 Mounting Template *1 Set up the Camera on the App There are two methods to do the initial setup of the camera: 1. with a Wi-Fi connection; 2. with a network cable connection.
- Page 4 Step 2. Scan the QR code on the camera. Step 3. Tap Choose Wi-Fi Connection to configure the Wi-Fi settings. Step 4. After you hear the voice prompts from the camera, tick “I have heard the voice played by the camera“ and tap Next.
- Page 5 Step 5. Select a WiFi network, enter the WiFi password, and tap Next. Step 6. Scan the QR code on the app with the camera lens. Tap Scan Now. The QR code will be generated and displayed on your phone. Please hold your phone in front of the camera at a distance of about 20 cm (8 inches) and have the phone face the camera lens to let the camera scan the QR code.
- Page 6 After you hear the beep sound, tick "I have heard a beep sound from the camera" and tap Next. Step 7. After you hear a voice prompt "Connection to the router succeeded" from the camera, tick "I have heard the voice prompt" and tap Next. Note: If you hear the voice prompt "Connection to the router failed", please double-check if you have entered the Wi-Fi information correctly in the previous...
- Page 7 step. Step 8. Create a login password and name your camera. Step 9. Initialization finished. Tap Finish, and you can start live viewing now. 2. With a Network Cable Connection To do the initial setup, please power on the camera with the DC adapter, connect...
- Page 8 the camera to your router's LAN port with an Ethernet cable, and follow the steps below. Step 1. If your phone, the camera, and the router are on the same network and you've enabled the Add Device Automatically option in the App Settings, you can tap and select this device on the Devices page and skip to Step 3.
- Page 9 Otherwise, you can tap the icon in the top right corner and scan the QR code on the camera to add the camera. Step 2. Tap Choose Network Cable Connection. Please make sure the camera is connected in the correct way, as shown in the diagram, and then tap Access the Camera.
- Page 10 Step 3. Create a device password and name the device. Step 4. Select the WiFi network that you want to join, enter the password of the WiFi network, and tap Save to save the configuration.
- Page 11 Step 5. Initialization finished. Tap Finish, and you can start live viewing now.
- Page 12 Install the Camera Here is a guide on how to install the camera to the ceiling. Step 1. Install the Mounting Plate. Drilling two screw holes on the wall according to the mounting hole template. Insert the two plastic anchors into the holes in the wall. ...
- Page 13 To remove it from the ceiling, turn the camera counterclockwise. In case your camera is mounted upside down, its picture shall be rotated as well. Please go to Device Settings > Display on Reolink App/Client and click Flip Vertical to adjust the image.
