EVB624 User Manual
All rights reserved! Any company or individual person shall not copy or backup this user manual in any
format (electronic, mechanical, photocopying, recording or other formats) without written permission
from Launch Tech Co., Ltd (hereinafter referred to as "Launch"). The manual is for the use of the
products manufactured by Launch, which shall not assume any responsibility for the consequences
arising from the use of it to guide the operations of other equipment.
Launch and its branches will not bear any liability for the fees and expenses incurred by equipment
damage or loss due to accidents caused by users or third parties, misuses and abuses, unauthorized
modifications and repairs, or operations and services not following launch's instructions.
Launch assumes no responsibility for device damages or problems resulted from the usage of other
parts or consumables, rather than original products of launch or products approved by the company.
Official statement: the mentioning of the names of other products in this manual is to illustrate how to
use the device, with the ownership of the registered trademarks belonging to the owners.
The device is intended for the use of professional technicians or maintenance and repair personnel.
Registered Trademark
Launch has registered its trademark in china and several other countries, and the logo is
.
Other trademarks, service marks, dot names, icons, company names of launch mentioned in the user
manual all belong to launch and its subsidiaries. In those countries where trademarks, service marks,
dot names, icons, company names of launch have not been registered yet, launch declaims the right for
its unregistered trademarks, service marks, dot names, icons, and company names. Trademarks of
other products and company names mentioned in this manual are still owned by the original registered
companies. Without written agreement from the owner, no person is allowed to use the trademarks,
service marks, domain names, icons and company names of Launch or of other mentioned companies.
You can visit https://www.cnlaunch.com, or write to Customer Service Center of Launch Tech Co., Ltd at
Launch Industrial Park, North of Wuhe Road,Bantian Street,Longgang District,Shenzhen City,
Guangdong Province, P.R.China, to get contact with Launch for the written agreement on the usage of
the user manual.
Disclaimer of Warranties and Limitation of Liabilities
All information, illustrations, and specifications in this manual are based on the latest information
available at the time of publication.
The right is reserved to make changes at any time without notice. We shall not be liable for any direct,
special, incidental, indirect damages or any economic consequential damages (including the loss of
profits) due to the use of the document.
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the EVB624 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Launch EVB624

  • Page 1 (electronic, mechanical, photocopying, recording or other formats) without written permission from Launch Tech Co., Ltd (hereinafter referred to as "Launch"). The manual is for the use of the products manufactured by Launch, which shall not assume any responsibility for the consequences arising from the use of it to guide the operations of other equipment.
  • Page 2 EVB624 User Manual...
  • Page 3 EVB624 User Manual Contents 1. Product Overview ................................1 2. Precautions for Safe Use ..............................1 3. Packing list ..................................1 4. Technical Features ................................1 5. Operating Instructions ..............................3 5.1 Panel Description ................................3 5.2 Device Connection ................................. 5 5.3 Main Unit Operation ...............................
  • Page 4 EVB624 User Manual...
  • Page 5 EVB624 Battery Pack Module Wireless Equaliser is a split equalization maintenance device developed by Launch, which is designed based on the charge and discharge characteristics of lithium batteries. It can effectively repair the problem of battery performance degradation, which caused by excessive pressure difference of single battery.
  • Page 6 EVB624 User Manual Data communication Wi-Fi; Bluetooth Data Storage Data dump U disk Over voltage, Under voltage, Over current, Power-down, Over Main unit protection temperature, Reverse connection protection Cooling Operating temperature range: -10-50 ℃; Temperature storage temperature: -20~70℃ Environment Humidity...
  • Page 7 EVB624 User Manual 5. Operating Instructions 5.1 Panel Description Charger: Name Description Antenna Used to communication and networking. Screen 10.1-inch touch screen. Power indicator: ①In the equilibrium mode---the cell discharging , the red light always on. ②In the equilibrium mode---the cell charging, the POWER red light flashes.
  • Page 8 EVB624 User Manual Wireless Discharge module: Name Description Power indicator: ①After the device is turned on, the red light always POWER ② The red light flashes when power supply is below 30%. Communication indicator: ①After the device turned on, the blue light not on.
  • Page 9 EVB624 User Manual 5.2 Device Connection Step1: First, connect the plug of DC high-voltage output cable into the high-voltage output port of the charger, and then connect the positive and negative output cable of DC high-voltage cable to the positive and negative terminals of the battery pack respectively (the red cable is the positive, the black cable is the negative).
  • Page 10 EVB624 User Manual 5.3 Main Unit Operation 5.3.1 Main Menu After charger is turned on, enter to the main interface. The main interface functions include Balanced, Data Analysis and Export Data. 5.3.2 Balanced Maintenance Click “Balanced” on main interface to enter Balanced interface.
  • Page 11 EVB624 User Manual Click “ ” button in the upper right corner of balanced interface to enter the device pairing interface, which can connect with optional devices. “ ” button in the upper right corner of device pairing interface is the clear device pairing button, which deletes all current devices when clicked. If you need to delete a single paired device, long press on the device serial number to delete the device.
  • Page 12 EVB624 User Manual Click “Setup” to set parameter and tap “ ” to save the current parameter. In addition, due to the unit end of charger does not participate in the discharge test process in discharge mode, number of cells does not need to be set.
  • Page 13 EVB624 User Manual Click “Start” button to enter balanced interface which displays real-time information of each channel such as voltage, current, status, discharge capacity, etc. Then wait for working mode to complete.During working mode, tap “Stop” to end working mode.
  • Page 14 EVB624 User Manual 5.3.4 Data Export Click "Data Export" on the main interface to enter the data export interface, select a battery pack in the data list, insert the U disk into the I/O port on the panel, and click “Export to USB” to transfer the...
  • Page 15 EVB624 User Manual 5.3.5 System Setting Click “ ” button on the main interface to enter the system setup interface, which includes Wi-Fi connection, Bluetooth, Data&Time, Language Setting, Data Storage Interval, Software Upgrade and About. Wi-Fi: Used to connect to Wi-Fi and check the IP address.
  • Page 16 EVB624 User Manual Bluetooth:Open or close the bluetooth. Data & Time: Used to set data and time.
  • Page 17 EVB624 User Manual Language Setting:Used to select language. Data Storage Interval:Used to set the data storage interval.
  • Page 18 EVB624 User Manual Software Upgrade: Used for software upgrade, including App upgrade and Firmware upgrade. 1. Tap “APP Upgrade”, you can can be upgraded online by connecting to Wi-Fi or locally by inserting a USB stick. 2. Tap “Firmware Upgrade”, you can can be upgraded online by connecting to Wi-Fi or locally by inserting a USB stick.
  • Page 19 EVB624 User Manual About: Used to view device model,APP version, system update, etc.
  • Page 20 If the device needs to be repaired, please send it back to Launch, and attach the Warranty Card, Product Qualification Certificate, Purchase Invoice and problem description. Launch will maintain and repair the device for free when it is within warranty period. If it is out of warranty, Launch will charge the repair cost and return freight.
