Features
• 12, 24, 36 or 48 V DC permanent magnetic motor (IC only 12/24 V DC)
• Load from 500 N - 6�800 (depending on gear ratio and spindle pitch)
• Max� speed 160 mm/sec� (depending on gear ratio and spindle pitch)
• Stroke length from 100 to 1200 mm
• Built-in endstops reached function
• Highly efficient acme thread spindle
• Heavy duty aluminium housing for harsh conditions
• Protection class: IP66 for outdoor use (dynamic)� Furthermore, the actuator can be washed down by a
high pressure cleaner (IP69K - static)
• Hand crank for manual operation
• Integrated brake with high self-lock ability
• Endplay: max� 2 mm
• Non-rotating piston rod eye
• Noise level: 76 dB (A)� Measuring method: DS/EN ISO 3746 (actuator not loaded)
Options in general
• Back fixture turnable in steps of 30 degrees
• Exchangeable cables in different lengths
• Hall effect sensor
• Analogue or digital feedback for precise positioning
• Endstop signals
• Mechanical overload protection through integrated slip clutch -Standard actuators only
• Mechanical potentiometer (not with IC)
• When ordering AISI (304 and up) piston rod eye and back fixture, stainless steel screws are automatically
included
• Special anodised housing for extreme environments -see paragraph regarding 'Special anodised housing'
• Adjustable magnetic sensors for endstop signals (code no� 1017031)
• IC options (see specific interface user manuals at the
I/O Specifications) including:
- I/O
- Ethernet/IP
- Modbus TCP/IP
- Modbus RTU
- IO-Link
- LIN bus
- CAN bus
- CANopen
• PC configuration tool (BusLink or Actuator Connect™)
• IECEx/ATEX/CCC/CCC (Ex) certified for Zone 21
TECHLINE webpage for Connection Diagrams and
