Page 28
Important Safety Instructions 6. For INDOOR household use ONLY. Do not use the Appliance in outdoor, commercial or industrial environments. IMPORTANT SAFETY INSTRUCTIONS 7. Use only the original rechargeable battery and Charging Dock provided with the Appliance from the manufacturer. Non-rechargeable batteries are prohibited.
Page 29
28. When not using the Charging Dock for a long period of time, please unplug it. 29. The Appliance must be used in accordance with the directions in this Instruction Manual. Ecovacs Robotics Co.,Ltd. cannot be held liable or responsible for any damages or injuries caused by improper use.
Page 30
For indoor use only Direct current Alternating current This product conforms to the applicable EC Directives. Before charging, read the instructions. CLASS 1 LASER PRODUCT. EN∣30...
Page 31
1. PACKAGE CONTENTS 1.1 Package content Robot Charging Dock Washable Mopping Pad Mopping Pad Plate Y1 *1 Y1 PRO *4 取扱説明書/Instruction Manual Side Brush Adapter Instruction Manual Screw Bag * Note: Figures and illustrations are for reference only and may differ from actual product appearance. Product design and speci cations are subject to changes without notice.
Page 32
1.2 PRODUCT DIAGRAM Robot 2 in 1 Module Top Cover Dust Box TrueMapping Dust Box Buckle Distance Sensor Filling Opening 2 in 1 Module Release Button START Button Short Press: Reservior Start/Pause Long Press Power On/Off Filter Filter Sponge Charging Button: Filter Net Short Press: Go To Charge Long Press: Reset...
Page 33
Bottom View Charging Dock Anti-drop Sensors Carpet Detection Sensor Universal Wheel Charging Contacts Anti-drop Sensors Adapter Interface Charging Contacts Side Brush Main Brush Release Button Driving Wheels Main Brush Installation Port For Mopping Pad Module 33∣EN...
Page 34
TrueMapping Distance Sensor Name Functional Description With Laser Ranging-measuring the distance between the device and surroundings through the TrueMapping Distance Sensor time difference of re ection, it can map according to the objects around while the device is moving. Detection of 8m. With Infrared Ranging-detecting the distance between the bottom of the device and ground by Infrared Sensor at the bottom, the device will not move forward when there are stairs in front Anti-drop Sensor...
Page 35
2. Operations 2.1 Notes Before Cleaning Tidy up the area to be cleaned by putting furniture, such as chairs, in During the rst use, make sure each room door is open to help Robot their proper place. fully explore your house. Put away objects including cables, cloths and slippers, etc.
Page 36
Scan the QR code on the Robot or Instruction Manual to download the App. * Before using the product, please take the screwdriver and Method 2: Search the ECOVACS HOME to download the App. screws out of the screw pack for installation. EN∣36...
Page 37
Privacy Policy and User Agreement, some of the aforementioned intelligent functions cannot be realized through ECOVACS HOME App, but you can still use the basic functions of this product for manual operation. 37∣EN...
Page 38
Place the Charging Dock Power ON Long press the START Button for 3 seconds to turn on the Robot. The Charging Dock should be placed against a wall on a at ground, and no items should be placed with in a range of (0.5m to left and right sides) (1.5m to the...
Page 39
Charging Short press the Charging button to make Robot return for charging. * It is recommended that Robot start cleaning from the Charging Dock. Do not move the Charging Dock while cleaning. 39∣EN...
Page 40
2.5 Start Cleaning Pause When Robot is in working, shot press to pause. Create a map When creating a map for the rst time, please follow Robot to help eliminate some minor issues. For example, the Robot may get stuck under low furniture. Take following solutions for reference.
Page 41
Install Mopping Pad and Mopping Pad Module Charging Stick the white side of the Mopping Pad onto the velcro of the Shot press to pause, Robot goes to charge. Mopping Pad Plate. Insert the protruded part of the Mopping Pad Plate into the installation port.
Page 42
6-12 months every week Filter every week every 3-6 months TrueMapping Distance Sensor Universal Wheel Anti-drop Sensors every week Bumper Charging Contacts Warm note: If you want to buy accessories, please visit ECOVACS HOME App store or https://www.ecovacs.com/global EN∣42...
Page 43
3.2 Maintain Dust Box Note: Do not use nger or brush to clean the lter. Note: Completely dry the lter before use. Explore more accessories at ECOVACS HOME App or at https://www.ecovacs.com/global. 43∣EN...
Page 44
3.3 Maintain Main Brush and Side Brush Side Brush Main Brush EN∣44...
Page 45
3.4 Maintain Other Parts Anti-drop Sensor Bumper Charging Contacts TrueMapping Distance Sensor Wheels Note: Note: Wipe the components with a clean, dry cloth. Avoid using Do not clean Charging Contacts with wet cloths. cleaning sprays or detergents. 45∣EN...
Page 46
Robot can't be charged when the power is turned off. • If the battery is over-discharged or not used for a long time, the Robot may not be charged. Please contact ECOVACS for help. Do not disassemble by yourself. EN∣46...
Page 47
The Robot doesn't support 5G network at present. Please Not use 2.4GHz or 2.4/5GHz network. choose 2.4GHz or 2.4/5GHz. Please scan the code or download the ECOVACS HOME Download the wrong APP. App in store. Try to recover by moving the Robot into Charging Dock.
Page 48
Malfunction Possible Causes Solutions The Robot doesn't start working from The Robot must start cleaning from Charging Dock. Charging Dock. Can't creat maps in APP. Move the Robot when it is working. Don't move the Robot when it is working. Allow the Robot return to Charging Dock when it nishes Cleaning is not nished.
Page 49
Robot gets stuck while working and stops. Robot might be stuck under furniture with Please set a physical barrier, or set a Virtual Boundary in an entrance of similar height. the ECOVACS HOME App. 49∣EN...
Page 50
Malfunction Possible Causes Solutions Please tidy up the scattered objects on the ground such The wires, slippers and other objects placed as wires, slippers before cleaning. If there is any area on the ground affect the normal work of the missing, Robot will clean the missing area by itself, Robot.
Page 51
Malfunction Possible Causes Solutions Please rotate and press the driving wheels to check whether there is any foreign object wrapped or stuck. If Driving wheels are blocked. Driving wheels are blocked by foreign objects. there is any foreign object, please clean it in time. If this problem persists, please contact Customer Care for help.
Page 52
Rated output CH2331 Charing Dock Laser Lidar 200 mA 940 nm Output power of the Wi-Fi module is less than 100mW. Note: Technical and design speci cations may be changed for continuous product improvement. Explore more accessories at https://www.ecovacs.com/global. 52∣EN...
Page 53
Ecovacs Robotics Co.,Ltd. No.518 Songwei Road, Wusongjiang Industry Park, Guoxiang Street, Wuzhong District, Suzhou, Jiangsu, China.
