Ricoh M124 Service Manual

page of 1071

/ 1071
Bookmarks

Advertisement

Quick Links

Download this manual

M124/M125

SERVICE MANUAL

Advertisement

Need help?

Need help?

Do you have a question about the M124 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh M124

Page 1 M124/M125 SERVICE MANUAL...
Page 2 It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Americas Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH AMERICAS CORPORATION.
Page 3 Ricoh Technical Training Program. Untrained uncertified users utilizing information contained in this service manual to repair or modify Ricoh equipment risk personal injury, damage to property or loss of warranty protection. Ricoh Americas Corporation...
Page 4 LEGEND COMPANY PRODUCT CODE LANIER RICOH SAVIN M124 SPC830DN Aficio SPC830DN SPC830DN M125 SPC831DN Aficio SPC831DN SPC831DN DOCUMENTATION HISTORY REV. NO. DATE COMMENTS 11/2012 Original Printing...
Page 5 M124/M125 TABLE OF CONTENTS 1. PRODUCT INFORMATION ............1-1 1.1 SPECIFICATIONS ..................1-1 1.2 PRODUCT OVERVIEW ................1-2 1.2.1 COMPONENT LAYOUT ..............1-2 1.2.2 PAPER PATH ................... 1-3 1.2.3 DRIVE LAYOUT ................1-4 1.3 MACHINE CODES AND PERIPHERALS CONFIGURATION ....1-6 1.4 GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH PREDECESSOR...
Page 6 CONTROLLER OPTIONS ..............2-58 2.11.1 OVERVIEW ................2-58 I/F Card Slots ..................2-58 SD Card Slots ..................2-58 2.11.2 SD CARD APPLI MOVE ............. 2-59 Overview .................... 2-59 Move Exec ..................2-59 Undo Exec ..................2-60 3. PREVENTIVE MAINTENANCE............. 3-1 M124/M125...
Page 7 4.5.1 CAUTION DECAL LOCATION ............4-17 4.5.2 LD SAFETY SWITCH ..............4-18 Error Messages .................. 4-18 4.5.3 LASER OPTICS HOUSING UNIT ........... 4-19 Preparing the new laser optics housing unit ........4-19 Before removing the old laser optics housing unit ......4-20 M124/M125...
Page 8 4.8.4 TEMPERATURE AND HUMIDITY SENSOR ........4-55 4.9 DRIVE UNIT ..................... 4-56 4.9.1 GEAR UNIT ..................4-57 When installing the drive unit ............. 4-62 Adjustment after replacing the gear unit ..........4-62 4.9.2 REGISTRATION MOTOR ............... 4-63 4.9.3 PAPER FEED MOTOR ..............4-64 M124/M125...
Page 9 When installing the fusing fan ............4-95 4.10.14 PAPER EXIT FAN ..............4-96 When installing the paper exit fan ............4-96 4.10.15 AC CONTROLLER BOARD FAN ..........4-97 When installing the AC controller fan ..........4-97 4.10.16 FUSING ENTRANCE THERMOPILES ........4-98 M124/M125...
Page 10 ELECTRICAL COMPONENTS ............4-123 4.13.1 BOARDS................... 4-123 Controller Box closed ............... 4-123 Behind the IOB ................. 4-124 Controller Box Open ................. 4-124 4.13.2 CONTROLLER UNIT ..............4-125 4.13.3 CONTROLLER BOX RIGHT COVER ........4-125 4.13.4 CONTROLLER BOX ..............4-126 M124/M125...
Page 11 5.1 SERVICE PROGRAM MODE ..............5-1 5.1.1 SP TABLES ..................5-1 5.1.2 ENABLING AND DISABLING SERVICE PROGRAM MODE ... 5-1 Entering SP Mode ................5-1 Exiting SP Mode ................... 5-1 5.1.3 TYPES OF SP MODES ..............5-1 SP Mode Button Summary ..............5-2 M124/M125...
Page 12 ......................5-149 5.9.2 OUTPUT CHECK TABLE ............. 5-150 Printer ....................5-150 [FIN (EUP) OUTPUT Check] (Booklet) Finisher (D636/D637) ..5-155 FIN(JAK)OUTPUT Check 4bin Mail Box (M413) ......5-156 Bridge Unit (D634)................5-156 4bin Mail Box (M413) ............... 5-156 M124/M125 viii...
Page 13 CARD SAVE FUNCTION ..............5-175 5.14.1 OVERVIEW ................5-175 Card Save: ..................5-175 5.14.2 PROCEDURE ................5-175 5.14.3 ERROR MESSAGES ..............5-178 5.15 SMC LIST CARD SAVE FUNCTION..........5-179 5.15.1 OVERVIEW ................5-179 SMC List Card Save ................. 5-179 5.15.2 PROCEDURE ................5-179 M124/M125...
Page 14 6.4 TROUBLESHOOTING GUIDE ..............6-85 6.4.1 IMAGE QUALITY ................6-85 6.4.2 LINE POSITION ADJUSTMENT ............. 6-87 Test ....................6-87 Countermeasure list for color registration errors ........ 6-87 6.4.3 STAIN ON THE OUTPUTS ............. 6-92 6.4.4 PROBLEM AT REGULAR INTERVALS.......... 6-93 M124/M125...
Page 15 7.1.2 ENERGY SAVE EFFECTIVENESS ..........7-3 7.2 PAPER SAVE .................... 7-4 7.2.1 EFFECTIVENESS OF DUPLEX/COMBINE FUNCTION ....7-4 1. Duplex: ..................... 7-4 2. Combine mode: ................7-4 3. Duplex + Combine: ................7-5 How to calculate the paper reduction ratio ........... 7-5 M124/M125...
Page 16 M124/M125...
Page 17 READ THIS FIRST Important Safety Notices Prevention of Physical Injury Before disassembling or assembling parts of the machine and peripherals, make sure that the machine power cord is unplugged. The wall outlet should be near the machine and easily accessible. If any adjustment or operation check has to be made with exterior covers off or open while the main switch is turned on, keep hands away from electrified or mechanically driven components.
Page 18 explode if replaced incorrectly. Replace only with the same or an equivalent type recommended by the manufacturer. Do not recharge or burn the batteries. Used batteries must be handled in accordance with local regulations. Safety and Ecological Notes for Disposal Do not incinerate toner bottles or used toner.
Page 19 international standard for safety. The aim of these components is to prevent the products, which are heavy in weight, from toppling as a result of people running into or leaning onto the products, which can lead to serious accidents such as persons becoming trapped under the product. (U.S.: UL60950-1, Europe: EN60950-1) Therefore, removal of such components must always be with the consent of the customer.
Page 20 [A] Short Edge Feed (SEF) [B] Long Edge Feed (LEF) Trademarks ® ® ® Microsoft , Windows , and MS-DOS are registered trademarks of Microsoft Corporation in the United States and /or other countries. ® PostScript is a registered trademark of Adobe Systems, Incorporated. ®...
Page 21 PRODUCT INFORMATION R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 23 Specifications 1. PRODUCT INFORMATION 1.1 SPECIFICATIONS See "Appendices" for the following information: General Specifications  Supported Paper Sizes  Software Accessories  Optional Equipment  M124/M125...
Page 24 4. Paper transfer roller 12. Image transfer belt cleaning unit 5. Registration roller 13. Image transfer belt unit 6. By-pass feed table 14. Toner bottle (4 colors) 7. Tray 2 15. ID sensor 8. Tray 1 16. Fusing sleeve belt unit M124/M125...
Page 25 12. Finisher upper tray (Optional) 6. Tray 2 feed 13. Finisher proof tray (Optional) 7. Tray 3: Optional paper feed unit/LCT 14. Output tray The 2000/3000-sheet (booklet) finisher requires the bridge unit and one from the two-tray paper feed unit or the LCT. M124/M125...
Page 26 Turns on/off the drive power to the by-pass pick-up, 8. By-pass feed clutch: feed and separation rollers. 9. Registration motor: Drives the registration roller. Drives the by-pass pick-up, feed and separation roller, 10. By-pass/duplex feed motor: and duplex transport rollers. M124/M125...
Page 27 12. ITB drive motor: Drives the image transfer belt unit. Drives the duplex inverter rollers and duplex transport 13. Duplex inverter motor: rollers. 14. Fusing/paper exit motor: Drives the fusing unit and paper exit section. M124/M125...
Page 28 Machine Codes and Peripherals Configuration 1.3 MACHINE CODES AND PERIPHERALS CONFIGURATION Item Machine Code Call out Remarks Mainframe M124/M125 Mail bin M413 1200-sheet LCT D631 Requires [4] or [5] 2000-sheet LCT D581 One from the two Two-tray paper feed unit...
Page 29 M344-08 (EU/AA) M416-30 Gigabit Ethernet D377 512MB Memory Option M354-03 1GB Memory Option M416-27 HDD*1 (250GB) M416-28 Data Overwrite Security, Included in the controller HDD Encryption *1 The hard disk (M416-28) is supplied with the M125 model as standard equipment. M124/M125...
Page 30 Guidance for Those Who are Familiar with Predecessor Products 1.4 GUIDANCE FOR THOSE WHO ARE FAMILIAR WITH PREDECESSOR PRODUCTS Machines M124/M125 are successor models to Machines G188/G189. If you have experience with the predecessor products, the following information will be of help when you read this manual.
Page 31 INSTALLATION R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 33 Do not leave the toner bottle in a place directly exposed to sunlight.  The toner bottle must be kept at a temperature of 35°C (95°F) or less. Be careful not to  leave the toner bottle in a hot place when transporting or storing it. M124/M125...
Page 34 Therefore, the machine must be installed in a well-ventilated room. A: Over 100 mm (3.9") B: Over 100 mm (3.9") C: Over 100 mm (3.9") D: Over 750 mm (29.5") Put the machine near the power source with the clearance shown above. M124/M125...
Page 35 120 to 127 V, 60 Hz: More than 12 A (NA) 220 V to 240 V, 50 Hz/60 Hz: 10 A (EU/AA/China) Permissible voltage fluctuation: +8.66 %/ -10 % (NA) Permissible voltage fluctuation: ± 10 % (Others) Do not put things on the power cord. M124/M125...
Page 36  before you move the machine. Otherwise, the image transfer belt and the black PCDU can be damaged. 2.2.1 POWER SOCKET FOR PERIPHERALS Rating voltage for peripherals.  Make sure to plug the cables into the correct sockets.  M124/M125...
Page 37 Put the machine on the paper tray unit or the LCT first if you install an optional paper tray unit or the optional LCT at the same time. Then install the machine and other options. M124/M125...
Page 38 Lift the machine with four people by using the handle and grips on both sides of the machine. Do not remove the tapes before placing the machine.  Lower the machine slowly and carefully, so as not to pinch your hands.  M124/M125...
Page 39 Printer Installation Push back the handle [A] into the machine. Push up the lever [C] on the right door, and then open the right door. Remove the tape [A]. Close the right door. M124/M125...
Page 40 Open the drum positioning plate [H]. 10. Remove and pull out the four tapes horizontally from all PCUs. Make sure that all tapes are removed.  11. Close the drum positioning plate. 12. Turn the green levers clockwise to lock the levers. M124/M125...
Page 41 Shake the toner bottle up and down five or six times before installing. Insert the each toner bottle into the machine with the label facing up. Close the front door. Loading Paper Pull out the tray 1 [A] of the machine. M124/M125...
Page 42 Printer Installation Remove the tape [A]. Take out the contents from tray 1. Adjust the end plate [A] to A4 LEF/Letter LEF size. Load paper in tray 1, and then close tray 1. M124/M125 2-10...
Page 43 Pull out the feeler [D] for the output-tray-full detection mechanism. Turning Power On Turn off the power switch whenever you plug in and unplug the power cord.  Make sure that the power switch is set to " " (Standby). Plug in the machine. 2-11 M124/M125...
Page 44 You do not have to do this procedure if you use English. Do this procedure if you want to  use a different language. Turn on the power switch of the machine. “Ready” shows on the panel display after the machine warms up.  Press the "User Tools" key. M124/M125 2-12...
Page 45 The test printing starts shortly after. Turn off the power switch. Settings Relevant to the Service Contract Change the necessary settings depending on the each customer's service contract. For details, refer to "Meter Click Charge" following this section. 2-13 M124/M125...
Page 46 Input the Request number which you have obtained from @Remote Center GUI, and then press the "OK" key with SP5816-202. Confirm the Request number, and then press the "EXECUTE" key with SP5816-203. Check the confirmation result with SP5816-204. M124/M125 2-14...
Page 47 Check the network condition. disabled) Proxy error (Illegal user name or Check Proxy user name and password. password) See "SP5816-208 Error Codes" below Other error this. Request number confirmation Processing… Please wait. executing 13. Exit the SP mode. 2-15 M124/M125...
Page 48 Not supported at the Service Center Error Caused -2389 Database out of service by Response -2390 Program out of service from GW URL Two registrations for the same Check the registration -2391 mainframe condition of the mainframe -2392 Parameter error M124/M125 2-16...
Page 49 Mainframe not managed Box ID for external RCG is -2395 illegal. Mainframe ID for external RCG -2396 is illegal. Check the ID2 of the -2397 Incorrect ID2 format mainframe. Incorrect request number -2398 Check the Request No. format 2-17 M124/M125...
Page 50 To check the counter, the technician must print the SMC report (SP 5-990). You must select one of the counter methods (developments/prints) in accordance with  the contract ( SP5-045-001). M124/M125 2-18...
Page 51 Specifies if the counting method Counter SP5-045-001 used in meter charge mode is “1”: Prints method based on developments or prints. A3/DLT Specifies whether the counter is “0”: Single double SP5-104-001 doubled for A3/DLT paper. counting count 2-19 M124/M125...
Page 52 The external keyboard that is available in this machine is principally for the Windows  OS. However, no compatibility check is done, and there is no warranty. Enter the SP mode and set SP5075-001 to ON (1) (USB keyboard). Exit the SP mode and turn the main power off and on. M124/M125 2-20...
Page 53 Remove all trays from the optional paper feed unit or LCT.  Remove peripherals physically attached to the main machine: Paper feed unit, LCT and  finisher. Attach the caster stands for the paper feed unit or LCT if these have been removed before  moving the machine. 2-21 M124/M125...
Page 54 To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. Make sure that the side fences in the trays are correctly positioned to prevent color  registration errors. M124/M125 2-22...
Page 55 One of the three types Output Jogger Unit Requires No. 6 or No. 7. Mail bin *: Child options (Child options require a parent option.) For details about installation procedures for the user installation options, see "Hardware  Guide" of this model. 2-23 M124/M125...
Page 56 Remarks IEEE 1284 One from No.1 and No.2 Wireless LAN Gigabit Ethernet Gigabit Ethernet Slot Option only for M124 PictBridge You can merge all applications in one IPDS Unit SD card with SP mode. ( p.2-59 SD Card for Netware Printing "SD Card Appli Move").
Page 57 1200 LCT (D631) 2.4 1200 LCT (D631) 2.4.1 COMPONENT CHECK Check the quantity and condition of the components against the following list. Description Q'ty Front Bracket Rear Bracket Stud Screw Joint Pin 2-25 M124/M125...
Page 58 Unpack the LCT and remove the tapes. Remove the stand covers [A]. Release the locks [B] of the front and rear caster stands. Remove the caster stands [C]. Remove the paper path cover [A], connector cover [B] and six hole covers [C]. M124/M125 2-26...
Page 59 Pull out the front and rear rails [A], and then hang them on each bracket [B]. Connect the LCT cable [C] to the main machine. 10. Slide the LCT [D] into the main machine. 11. Make sure that the front and rear sides of the LCT are closely attached to the main machine. 2-27 M124/M125...
Page 60 1) if the side fences are adjusted for B5 size paper. Close the right door. Turn on the main power switch, and then go into the SP mode. Input the correct paper size for the1200-sheet LCT with SP5181-018. M124/M125 2-28...
Page 61 Bridge Unit (D634) 2.5 BRIDGE UNIT (D634) 2.5.1 COMPONENT CHECK Check the quantity and condition of the components against the following list. Description Q'ty Bridge Unit Frame Cover Knob screw Long Knob Screw Holder bracket Guide 2-29 M124/M125...
Page 62 If you will install a finisher unit (D636 or D637) on the machine, install it after installing the  bridge unit (D634). Remove all tapes. If the sensor feeler [A] is out, fold it into the machine. Remove the connection cover [A] ( x 1). Remove the inner tray [A]. M124/M125 2-30...
Page 63 12. Install the optional finisher (refer to the finisher installation procedure). Holder bracket [A] is used in the installation procedure of the finisher (D636 or D637).  Do not install it yet. 13. Turn on the main power switch of the machine. Check the bridge unit operation. 2-31 M124/M125...
Page 64 Rear joint bracket Front joint bracket Ground (earth) plate Tapping screws - M4 x14 Tapping screws - M3 x 8 Tapping screws - M3 x 6 Upper output tray Support Tray Lower output tray (D637 only) Cushion (with double-sided tape) M124/M125 2-32...
Page 65 Two Tray Paper Feed Unit (D580) or LCT (D581)  Unpack the finisher and remove all tapes and packing materials from the finisher. Open the front door, and then remove all tapes and packing materials from the inside of the finisher. 2-33 M124/M125...
Page 66 Attach the cushion [B] to the finisher. Make sure that the cushion is placed within 0 to 1 mm from the edge of the cover.  Install the ground plate [C] on the finisher ( x 2; M3 x 6). M124/M125 2-34...
Page 67 Slowly push the finisher to the left side of the machine, keeping its front door open until the brackets [D] [E] go into their slots. 10. Push the lock lever [G], and then secure it ( x 1). 11. Close the front door of the finisher. 12. Connect the finisher connector [H] to the machine. 2-35 M124/M125...
Page 68 If a stacking problem occurs several times on the upper output tray [A], put the support tray [B] on the tray as shown. Keep this tray in the manual pocket if this tray does not need to be installed.  M124/M125 2-36...
Page 69 2.7.1 COMPONENT CHECK Check the quantity and condition of the components against the following list. Description Q'ty Punch-out Waste Unit Slide Drive Unit Punch Waste Hopper Wire harness: short-circuit Screws: M3 x 6 Side-to-Side Detection Unit Punching Unit 2-37 M124/M125...
Page 70 Remove the rear cover [B] ( x 2) and open the front door. At the bottom of the rear cover, make sure to disconnect the tabs that attach the  cover to the frame. Remove the guide plate [C] ( x 2). M124/M125 2-38...
Page 71 Connect the cables [B] of the finisher to the connectors (CN601 and CN602) on the punch unit board ( x 2, x 1). The cables [B] are coiled and attached to the PCB.  2-39 M124/M125...
Page 72 12. Attach the side-to-side detection unit and connect it at the rear ( x 2, x 1, x 1). 13. Pull the short connector out of the connector [B] then connect the cable of the finisher x 1). This is the 3-pin connector.  M124/M125 2-40...
Page 73 18. Remove the short connector from the connector [C]. This is the 4-pin connector.  19. Connect the cable to connector [C] and attach the punch-waste transport unit ( x 1, x 1). 2-41 M124/M125...
Page 74 20. Set the hopper [A] in its holder. 21. Reassemble the finisher, and then install it on the main machine. 22. Connect the power cord to the outlet, and then turn the main power switch on. 23. Check the punch unit operation. M124/M125 2-42...
Page 75 Output Jogger Unit (B703) 2.8 OUTPUT JOGGER UNIT (B703) 2.8.1 ACCESSORIES Check the accessories and their quantities against this list. Description Q'ty Jogger Unit Tapping Screws M3x6 2-43 M124/M125...
Page 76 Turn the main machine switch off. Disconnect the finisher from the main frame. Use the flat head of a screwdriver to remove the left upper cover [A]. Remove the cover plate [A] ( x 2). Keep the screws. M124/M125 2-44...
Page 77 [A] into the holes in the left and right side of the finisher frame. Connect connector [B] to the socket ( x 1). Attach the jogger unit [C] to the finisher ( x 2). Reattach the jogger unit cover [D] to the jogger unit ( x 2). 2-45 M124/M125...
Page 78 Check the quantity and condition of the components against the following list. Description Q'ty Tray Rear Hold Bracket Front Hold Bracket Mail Bin Right Stay Guide Plate Mail Bin Solenoid Harness Clamp (Not used) Screw: M3x8 Screw: M4x10 Screw: M3x6 Step Screw Decal Sheet M124/M125 2-46...
Page 79 Mail Bin (M413) 2.9.2 INSTALLATION PROCEDURE Open the right door. Operation panel [A] ( x 2, x 1, x 2, USB x 1) Remove the following: Screw caps [A]  2-47 M124/M125...
Page 80 Remove the paper exit cover [A] ( x 1). Remove the top right stay [B] ( x 3). Install the mail bin solenoid [A] ( x 1: M3x8). Connect the harness [B] and then clamp the harness with the four clamps. M124/M125 2-48...
Page 81 The front cover is connected to the mail bin unit with the harnesses. It is not  necessary to disconnect the harnesses from the front cover. However, take care not to break or disconnect the harnesses during this installation procedure. 2-49 M124/M125...
Page 82 Mail Bin (M413) 15. Install the mail bin unit [A] on the machine as shown above. 16. Attach the front hold bracket [A] and rear hold bracket [B] ( x 2 each). M124/M125 2-50...
Page 83 2). 23. Close the right door. 24. Install the tray [A] in each bin of the mail bin unit [B]. 25. Plug in and turn on the machine. 26. Check the operation of the mail bin unit. 2-51 M124/M125...
Page 84 Installation procedure 2.10.2 INSTALLATION PROCEDURE Unplug the machine power cord before starting the following procedure.  Do the following procedure not to damage any harnesses.  Check that any harnesses are not damaged nor pinched after installation.  M124/M125 2-52...
Page 85 Connect the connector [B] of the heater to the connector of the main machine. Install the heater [C] inside the machine ( x 1) Reassemble the machine. For installing the tray heater in D580 Rear cover [A] ( x 6) Pull out the two trays in the optional paper feed unit. 2-53 M124/M125...
Page 86 Install the tray heater [B] in the optional paper feed unit ( x 1). Remove the two securing brackets [C] ( x 1 each), and then the rear cover [D] of the optional paper feed unit ( x 2). Remove the harness cover bracket [E] ( x 1). M124/M125 2-54...
Page 87 1 in "For Installing the Tray Heater in D580"). Pull out the LCT drawer. If the right tray comes out with the left tray, push the right tray into the LCT.  Left tray [A] ( x 2) 2-55 M124/M125...
Page 88 When reinstalling the right tray, set the right tray on the guide rail and carefully push  the tray in, making sure to keep the tray level. Install the tray heater [D] in the optional LCT ( x 1). M124/M125 2-56...
Page 89 11. Route the harness [K] as shown and clamp it with four clamps ( x 4). 12. Connect the harness [K] to the connector [M] of the mainframe. 13. Reassemble the mainframe and optional LCT. 14. Reassemble the mainframe and optional paper feed unit. 2-57 M124/M125...
Page 90  SD Card Slots Slot [1] (upper) is used for optional applications (e.g.: Netware, PictBridge, IPDS unit, etc).  Slot [2] (lower) is also used for installing applications, or for service only (for example,  updating the firmware). M124/M125 2-58...
Page 91 Do not turn ON the write protect switch of the system SD card or application SD card on  the machine. If the write protect switch is ON, a download error (e.g. Error Code 44) occurs during a firmware upgrade or application merge. 2-59 M124/M125...
Page 92 Turn the main switch off. Remove the SD card from SD Card Slot 2 (lower). 10. Turn the main switch on. 11. Check that the application programs run normally. 12. Make sure that the machine can recognize the option. M124/M125 2-60...
Page 93 PREVENTIVE MAINTENANCE R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 95 Maintenance Items 3. PREVENTIVE MAINTENANCE 3.1 MAINTENANCE ITEMS See "Appendices" for the following information: Preventive Maintenance Items  Other Yield Parts  M124/M125...
Page 96 On the touch panel screen, press “[1] Touch Screen Adjust”. Use a pointed (not sharp!) tool to press the mark that appears in the upper left, lower right, lower left, center, and upper right in turns on the LCD panel. M124/M125...
Page 97 Press “[6] Touch Screen Test” on the Self Diagnostic menu. Touch the nine points circled in red in the illustration above, and make sure that each point (both x and y) is within +/- 5 dots of the original “+” displayed. M124/M125...
Page 98 Touch Screen Calibration When you are finished, press “[#] OK” on the screen. Touch “[#] Exit” on the screen to close the Self Diagnostic menu and save the calibration settings. M124/M125...
Page 99 REPLACEMENT AND ADJUSTMENT R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 101 2. Turn off the main switch and disconnect the power cord and the network cable.  Always touch a grounded surface to discharge static electricity from your hands before  you handle SD cards, printed circuit boards, or memory boards. M124/M125...
Page 102 Loop-back Connector – Parallel (item 4) requires Plug - IEEE1284 Type C (item 5).  A PC (Personal Computer) is required for creating the Encryption key file on an SD card  when replacing the controller board for a model in which HDD encryption has been enabled. M124/M125...
Page 103 Side to side (main-scan direction): 2 ± 1 mm  Paper Registration Standard The registration in both main- and sub-scan directions can change within the following tolerance. Sub-scan direction: 0 ± 9 mm  Main-scan direction: 0 ± 4 mm  M124/M125...
Page 104 Press "10 key" to display the number keys. d. Input the value, then press "OK". e. Generate a trim pattern to check the leading edge adjustment. Return the value of the setting in SP2-109-003 to "00" before completing this procedure. M124/M125...
Page 105 012 Trailing edge (Duplex, S size, Thick): 0.0 to 4.0 mm (default: 0.6 mm)  014/015 Side-to-side (Duplex, Thick): 0.0 to 1.5 mm (default: 0.3 mm)  016 Leading edge (Thin): 0.0 to 9.9 mm (default: 4.2 mm)  M124/M125...
Page 106 When you open the drum positioning plate  When you remove or replace the motors, clutches, and/or gears related to the  drum/development/transfer sections When you remove or replace the image transfer belt, image transfer belt unit or laser  optical housing unit M124/M125...
Page 107 Adjust the CMY gradation scale at the top of the chart by balancing the density of the C, M, and Y gradation scales – the CMY gray scale should change smoothly from minimum to maximum. There should be no coloration. Examine this color adjustment sheet: M124/M125...
Page 108 Press "Exit" to return the controller service mode menu. Select SP1-104 “ToneCtlValue”, then select the setting you want to adjust from 001-075. The three digits in the display (example ‘016’) indicate a position on the color calibration test sheet. M124/M125...
Page 109 Do the adjustment again if there is an anomaly (normally, repeat this procedure 3 to 5 times). 11. Do these when the adjustment results are satisfactory. 12. Use SP1-105-001 to keep the adjusted settings. You must reset the controller to keep the new settings in the controller NVRAM.  M124/M125...
Page 110 Exterior Covers 4.4 EXTERIOR COVERS 4.4.1 FRONT DOOR Open the front door [A]. Remove the two pins [A], and then remove the front cover. M124/M125 4-10...
Page 111 Exterior Covers 4.4.2 LEFT COVER Left cover [A] ( x 6) 4.4.3 REAR COVER Rear cover [A] ( x 6) 4-11 M124/M125...
Page 112 Remove the screw caps [A]. Top right cover [B] ( x 2) Top rear cover [C] ( x 2) 4.4.5 RIGHT REAR COVER Rear cover ( p.4-11) Open the right door [A]. Right rear cover [B] ( x 3) M124/M125 4-12...
Page 113 Exterior Covers 4.4.6 OPERATION PANEL Open the right door. Operation panel [A] ( x 2, x 1, x 2 USB x 1) 4-13 M124/M125...
Page 114 Exterior Covers Operation panel cover [A] ( x 3) Do the touch screen calibration after you replace the operation panel.( p.3-2 "Touch  Screen Calibration") 4.4.7 PAPER EXIT COVER Top right cover ( p.4-12) Operation panel cover ( p.4-13) M124/M125 4-14...
Page 115 Open the right door. PCDU ( p.4-28) 10. Toner cartridge cover [D] ( x 2) 11. Output tray [E] 4.4.9 OZONE FILTER Ozone filter for the charge unit Top right cover ( p.4-12) Top rear cover ( p.4-12) 4-15 M124/M125...
Page 116 Exterior Covers Ozone filter [A] Ozone filter for the AC Controller AC controller fan cover [A] (hook) Filter [B] Ozone filter [C] M124/M125 4-16...
Page 117  before beginning any disassembly or adjustment of the laser unit. This machine uses a class IIIb laser beam with a wavelength of 658 nm and an output of 9 mW. The laser can cause serious eye injuries. 4-17 M124/M125...
Page 118 Along with other switches, the LD safety switches help show error messages related to external covers. When one or more covers are open, the messages, "Cover is open." and "Close the indicated cover," show with a diagram. The diagram shows which cover is open. M124/M125 4-18...
Page 119 Preparing the new laser optics housing unit Polygon motor cover [A] of the laser optics housing unit ( x 4) Sponge padding [B] Tag [C] Reinstall the polygon motor cover [A]. 4-19 M124/M125...
Page 120 Disconnect the harness [A] of the skew correction motor. Do steps 1 to 7 of "Before removing the old laser optics housing unit". Connect the harness [A] and reinstall the harness bracket and left cover. Plug in and turn on the main power switch. M124/M125 4-20...
Page 121 Laser Optics Removing the old laser optics housing unit Left cover [A] ( x 6) Left fan bracket [A] for the laser housing optics unit ( x 4, x 4) 4-21 M124/M125...
Page 122 Push the new laser optics housing unit [A] slowly into the machine until the bracket [B] bumps against the frame of the machine. Remove the bracket [B], and then push the new laser optics housing unit fully into the machine ( x 2, All x 3). Reassemble the machine. M124/M125 4-22...
Page 123  Print the test pattern (14: 1-dot trimming pattern in the SP2-109-003).  Check that the left trim margin is within 2 ± 1 mm. If not, change the registration value for  the main scan registration adjustment. 4-23 M124/M125...
Page 124 After you replace the housing unit, do the adjustments in the following section of the manual: Image Adjustment – Registration. 4.5.4 POLYGON MIRROR MOTOR AND DRIVE BOARD Laser optics housing unit [A] ( p.4-19) Polygon mirror motor cover [A] of the laser optics housing unit ( x 4) M124/M125 4-24...
Page 125 To check if SP 2-111-1 was successful, watch the screen during the process. A message is displayed at the end. Also, you can check the result with SP 2-194-10 to -12. After you replace the motor, do the adjustments in the following section of the manual: Image Adjustment – Registration. 4-25 M124/M125...
Page 126 Laser Optics 4.5.5 AIRFLOW FANS Left cover ( p.4-11) Left fan bracket [A] for the laser housing optics unit ( x 4, x 4) Airflow fans [A] There are four airflow fans on the bracket.  M124/M125 4-26...
Page 127 Pull out the laser optics rear right thermistor gently from behind by pinching its harness ( x 1, x 1).  When reinstalling the laser optics rear right thermistor: The thermistor harness is about 25 cm long. When routing the harness, use tweezers,  and pay extra attention to avoid damaging the harness. 4-27 M124/M125...
Page 128 Lever lock [A] ( x 1) Turn the drum positioning plate lever [B] and the image transfer unit lock lever [C] counter-clockwise. Open the drum positioning plate [D]. Pull out the PCDU (hold the grip while you pull it out). M124/M125 4-28...
Page 129 If you do this, then the machine will reset the PM counter for the drum unit  automatically, after you turn the power on again. Turn the machine power off. PCDU ( p.4-28) Front cover [A] ( x 2) 4-29 M124/M125...
Page 130 Do not put too much weight on the PCDU. Otherwise, the plastic frame [B] of the  development unit may be damaged. Remove the front joint [A] ( x 2, x 1). The front joint [A] is firmly set. Remove it with a flat screwdriver.  M124/M125 4-30...
Page 131 Rotate the development roller [A] five or six times in the counterclockwise direction. This step removes developer that has stuck to the development roller, which would  cause color unevenness. If you change the development unit, do the ACC procedure. 10. Execute the drum phase adjustment with SP1902-001 twice. 4-31 M124/M125...
Page 132 Development unit ( p.4-29) Hopper cover [A] (4 hooks) Release the three hooks first in the correct order (from  Put the head of a screwdriver in the groove gap [B] as shown, and then release the hook  M124/M125 4-32...
Page 133 Keep the developer off at both ends of the development unit enclosed in red lines in  the diagram. Turn the machine power on. The machine initializes the developer and resets the PM counter for the developer. (For details of the developer initialization result, see p.6-80 "Developer Initialization Result". Do the ACC procedure. 4-33 M124/M125...
Page 134 Pull out tray 1 [B]. Open the toner collection bottle door [C]. Pull out the toner collection bottle [D]. 4.6.4 SECOND DUCT FANS Rear cover ( p.4-11) Right rear cover ( p.4-12) Open the controller box ( p.4-126) M124/M125 4-34...
Page 135 Image Creation Second duct [A] ( x 2, x 4, x 2) Split the second duct [A] (Hooks x 5). Second duct fans [A] [B] 4-35 M124/M125...
Page 136 Third duct [A] ( x 2,  x 1) Third duct fan [A] (3 hooks) When reinstalling the third duct fan Make sure that the third duct fan is installed with its decal facing to the upper side of the machine. M124/M125 4-36...
Page 137 Put a sheet of paper (A3/DLT) inside the machine as shown and on the floor. The sheet of paper on the floor is used in a later step.  Release the harness [A] from the clamp ( x 1 for YCM, x 2 for K) and hook, and then disconnect the harness. 4-37 M124/M125...
Page 138 This sheet of paper prevents toner and screws from falling into the laser optics housing unit through cutouts. M124/M125 4-38...
Page 139 10. Put the toner pump unit on the sheet of paper, which has been put in step 4, with its opening [A] up. 11. Keep the opening [A] of the toner supply tube up, and then clip the opening of the toner supply. 4-39 M124/M125...
Page 140 Insert the opening of the toner pump unit [A] into the opening of the toner supply tube [B] as far as possible. Connect the harness [A] to the connector of the machine. M124/M125 4-40...
Page 141 Secure the toner supply tube with the holder [C], lifting up the edge of the holder "very gently". Be careful when you lift the edge of the holder, because the holder is easily broken.  Insert the toner pump unit [A] into the rear frame of the machine ( x 2). 4-41 M124/M125...
Page 142 Rear cover ( p.4-11) Open the controller box ( p.4-126) Toner end sensor [A] ( x 1, 2 hooks each) A toner end sensor is not installed in the entrance of the toner supply tube for black.  M124/M125 4-42...
Page 143 Do not use SP3902-015 or 013 if you replace the complete ITB unit.  Turn off the main power switch. Open the front door. Open the drum positioning plate. ( p.4-28) Loosen the screw [A]. Turn the lock lever [B] clockwise Pull out the image transfer belt cleaning unit [C]. 4-43 M124/M125...
Page 144 Open the drum positioning plate. ( p.4-28) Remove the bracket [A] ( x 1). Turn the image transfer belt unit lock lever [A] counterclockwise. Image transfer belt cleaning unit ( p.4-43) Pull out the image transfer belt unit [B] halfway. M124/M125 4-44...
Page 145 Grasp the handles [A], and then pull out the image transfer belt unit fully. 4.7.3 IMAGE TRANSFER BELT Image transfer belt cleaning unit ( p.4-43) Image transfer belt unit ( p.4-44) Protective covers [A], [B], [C] ( x 6) 4-45 M124/M125...
Page 146 Turn the image transfer unit contact lever [A] counterclockwise (as seen from the rear). Gear [B] (hook x 1) Turn the gear cover [C] clockwise (as seen from the rear) ( x 1). Three stays [A] ( x 6) M124/M125 4-46...
Page 147 10. Remove the two screws and then the front holder bracket [A] (as seen from the front). 11. Put the front side of the image transfer belt unit on a corner of the table or a box as shown. 4-47 M124/M125...
Page 148 Clean all rollers with dry cloth before installing the image transfer belt.  There is a rim [A] at each edge of the transfer belt. The ends of all the rollers ([B] for example)  in the transfer belt unit must be between the two rims. M124/M125 4-48...
Page 149 Lubricant powder prevents the image transfer cleaning blade from turning up. Do not put the lubricant powder at the right side of the image transfer belt unit (the  above picture is taken from the rear). Otherwise, lubricant powder may damage the encoder sensor. 4-49 M124/M125...
Page 150 If you do this, then the machine will reset the PM counter for the paper transfer unit  automatically, after you turn the power on again. Open the right door. Release the white hook. Paper transfer roller unit [A] M124/M125 4-50...
Page 151 Turn off the main power switch. Open the duplex door [A]. Open the by-pass tray [B] Right door cover [C] ( x 4) Open the right door. Right door inner cover [A] ( x 1) 4-51 M124/M125...
Page 152 Paper Transfer Pivot bracket [A] ( x 1) Paper transfer unit [B] ( x 1, 2 springs) M124/M125 4-52...
Page 153 Open the right door. Fusing unit ( p.4-79) Image transfer belt unit ( p.4-44) ID sensor unit [A] ( x 2, x 2, x 1) ID sensor cover [A] ( x 4) ID sensor board [B] ( x 2) 4-53 M124/M125...
Page 154 Input two correction coefficients [A] for the ID sensor with SP3-362-013 and SP3-362-016 on the barcode sheet provided with the new ID sensor unit/board. For example, input "1.03" with SP3-362-013.  SP numbers other than SP3-362-013 and -016 are not required for this procedure.  Exit the SP mode. M124/M125 4-54...
Page 155 Paper Transfer 4.8.4 TEMPERATURE AND HUMIDITY SENSOR Rear cover ( p.4-11) Right rear cover ( p.4-12) Temperature and humidity sensor [A] ( x 1, x 1) 4-55 M124/M125...
Page 156 There are some motors and clutches that are not shown in the above drawing: Tray lift motor 1 and 2 Junction gate 1 motor   Duplex inverter motor Shutter motor   Duplex/By-pass Motor By-pass clutch   M124/M125 4-56...
Page 157 Image transfer belt unit ( p.4-44) Rear cover ( p.4-11) Controller box ( p.4-126) Toner sump cover [A] ( x 2) Third duct ( p.4-36) Left cover ( p.4-11) PSU bracket ( p.4-132) Remove the rear stay [A] ( x 3). 4-57 M124/M125...
Page 158 Drive Unit 10. Remove ten clamps (blue arrows). 11. Release seven clamps and turn each harness aside. 12. Disconnect four connectors (red arrows). M124/M125 4-58...
Page 159 13. Disconnect two connectors (red arrows) and put these harnesses inside the machine. 14. Disconnect each connector (red circles) from the drum/development drive motors ( x 1, x 1 each). 15. Disconnect each connector (blue circles) from the development clutches ( x 1 each). 16. Cover [A] ( x 2) 4-59 M124/M125...
Page 160 17. Disconnect eight connectors from the high voltage supply board ( x 8, x 2). 18. Release four clamps (red circles) and turn the harnesses aside. 19. Disconnect five connectors (red circles) ( x 5). 20. Toner transport motor [A] ( x 3) M124/M125 4-60...
Page 161 Drive Unit 21. Pulley [A] (timing belt) 22. Gear unit [A] ( x 8) 4-61 M124/M125...
Page 162 Do "Amplitude Control " again after checking the PCDUs and image transfer belt unit.  When the result is still "2" or "3" after checking the PCDUs and image transfer belt unit: Check that the gear unit is installed correctly.  Exit the SP mode. M124/M125 4-62...
Page 163 Rear cover ( p.4-11) Right rear cover ( p.4-12) Ventilation duct ( p.4-132) PSU bracket ( p.4-132) Fusing power supply board fan bracket [A] ( x 2, x 1) Registration motor assembly [A] ( x 3, x 1) 4-63 M124/M125...
Page 164 4.9.3 PAPER FEED MOTOR Right rear cover ( p.4-12) Paper feed motor [A] ( x 1, x 2) 4.9.4 DRUM/DEVELOPMENT MOTORS FOR M, C, AND Y Rear cover ( p.4-11) PSU bracket ( p.4-132) Open the controller box ( p.4-126). M124/M125 4-64...
Page 165 Drum/Development motors (three motors, one each for MCY) [A] ( x 4, x 1 each) 4.9.5 DRUM/DEVELOPMENT MOTOR-K Rear cover ( p.4-11) PSU bracket ( p.4-132) Controller box ( p.4-126) Third duct [A] ( x 2, x 1) Drum/Development motor-K [B] ( x 4, x 1) 4-65 M124/M125...
Page 166 Rear cover ( p.4-11) Controller box ( p.4-126) ITB drive motor [A] ( x 4, x 1) 4.9.7 FUSING/PAPER EXIT MOTOR Rear cover ( p.4-11) Controller box ( p.4-126) Fusing/paper exit motor [A] ( x 3, x 1) M124/M125 4-66...
Page 167 Drive Unit 4.9.8 IMAGE TRANSFER BELT CONTACT MOTOR Rear cover ( p.4-11) Controller box ( p.4-126) Transfer belt contact motor [A] ( x 2, x 2) 4-67 M124/M125...
Page 168 4.9.9 DUPLEX INVERTER MOTOR Open the right door. Right door cover ( p.4-112 "By-pass Bottom Tray") Duplex door [A] (2 hooks) Duplex guide plate [B] ( x 3, 2 hooks) Duplex inverter motor bracket cover [A] ( x 2, x 2) M124/M125 4-68...
Page 169 Duplex inverter motor [B] ( x 4) 4.9.10 PRESSURE ROLLER CONTACT MOTOR Rear cover ( p.4-11) Right rear cover ( p.4-12) Open the controller box ( p.4-126) Disconnect the connector [A] ( x 1). Pressure roller contact motor [A] ( x 4) 4-69 M124/M125...
Page 170 4.9.11 DUPLEX/BY-PASS MOTOR Rear cover ( p.4-11) Right rear cover ( p.4-12) Open the controller box ( p.4-126). Pressure roller contact motor ( p.4-69) Disconnect the connector [A] ( x 1, x 1) Duplex/by-pass motor bracket [A] ( x 2) M124/M125 4-70...
Page 171 Rear cover ( p.4-11) Right rear cover ( p.4-12) Open the controller box ( p.4-126). Stay [A] ( x 4) Pressure roller contact motor ( p.4-69) Duplex/by-pass motor bracket ( p.4-70) Disconnect the connector [A] ( x 1). 4-71 M124/M125...
Page 172 Drive Unit Paper transfer contact motor [A] ( x 2) NOTE: The picture below shows how to use the screwdriver to remove the screws of the paper transfer contact motor. M124/M125 4-72...
Page 173 Drive Unit 4.9.13 TONER TRANSPORT MOTOR Rear cover( p.4-11) Open the controller box ( p.4-126). Toner transport motor [A] ( x 3, x 1) 4-73 M124/M125...
Page 174 Drive Unit 4.9.14 TONER COLLECTION UNIT Gear Unit ( p.4-57) Toner collection unit [A] ( x 6, x 1) 4.9.15 PAPER FEED CLUTCHES Rear cover ( p.4-11) PSU bracket ( p.4-132) M124/M125 4-74...
Page 175 Release five clamps, and then turn the harness [A] aside. Paper feed clutch 1 bracket [A] ( x 2, x 1, x 1, x 1) Paper feed clutch 1 [A] Paper feed clutch 2 bracket [A] ( x 2, x 1, x 1) 4-75 M124/M125...
Page 176 Rear cover ( p.4-11) PSU bracket ( p.4-132) Open the controller box ( p.4-126). Toner sump cover ( p.4-57 "Gear Unit") Drum/development motor-Y ( p.4-64) Disconnect the connector [A] ( x 1). Remove the pulley and bushing [A]. M124/M125 4-76...
Page 177 Drum/development motors for M and C ( p.4-64) Disconnect the connector for each development clutch ( x 1). Turn the development clutch unit [A] counter-clockwise and then pull it out ( x 1). Development clutches for M and C [B] ( x 1) 4-77 M124/M125...
Page 178 PSU bracket ( p.4-132) Controller box ( p.4-126) Third duct ( p.4-36) Drum/development motor-K ( p.4-65) Turn the development clutch unit [A] counter-clockwise and then pull it out ( x 1). Development clutch-K [A] ( x 1) M124/M125 4-78...
Page 179 It is not necessary to clear the PM counter for the fusing unit with SP mode when you  replace the fusing unit. This is because the fusing unit has a new unit detection mechanism. Turn off the main power switch. Open the right door. 4-79 M124/M125...
Page 180 Fusing Release the lock levers [A]. Remove two transport brackets [B] if installed ( x 1 each). Hold the fusing unit handles [A], and then pull out the fusing unit. M124/M125 4-80...
Page 181 Fusing 4.10.2 FUSING EXIT SHUTTER PLATE Fusing unit ( p.4-79) Fusing exit shutter plate [A] ( x 2) 4.10.3 FUSING ENTRANCE GUIDE PLATE Fusing unit ( p.4-79) Turn over the fusing unit. 4-81 M124/M125...
Page 182 The fusing entrance guide plate requires cleaning maintenance every fusing unit maintenance interval. Clean the fusing entrance guide plate at the place shown above with a dry cloth, and then clean the fusing entrance guide plate again with a cloth moistened with alcohol. M124/M125 4-82...
Page 183 4.10.5 FUSING UNIT UPPER COVER Fusing unit ( p.4-79) Fusing exit shutter plate ( p.4-81) Right guide bracket [A] ( x 1) Springs [B] Remove the fusing unit upper cover [C] while pressing down the rollers [D] ( x 4). 4-83 M124/M125...
Page 184 The shutter plate [A] should be closed whenever the fusing unit upper cover is  reinstalled. Otherwise, the ends of the shutter plate [B] may be damaged and this will result in a problem when opening and closing the shutter. M124/M125 4-84...
Page 185 The fusing lower cover cannot be removed from the fusing main body completely  before removing the thermistors. Therefore, pay extra attention to handling the fusing lower cover when disassembling the fusing unit. Fusing unit lower cover [A] 4-85 M124/M125...
Page 186 Pressure roller contact shaft actuator [A] and pressure roller contact shaft gear [B] ( x 1, x 1) Rear bracket [C] ( x 3, bearing x 1) Remove faceplate [A] and gear [B] ( x 1, x 1) M124/M125 4-86...
Page 187 Fusing Front bracket [A] ( x 2) Detach the positioning plates [A] and [B] at the front and back ( x 2). 10. Top frame [A] ( x 6) 4-87 M124/M125...
Page 188 The oil leak in the fusing sleeve belt might occur when replacing the fusing sleeve belt. When you replace only the fusing sleeve belt, replace the oil absorber felt also. Clean the pasting positions for the oil absorber felt on fusing unit lower cover with alcohol. M124/M125 4-88...
Page 189 Peel off the release paper from the oil absorber felts [A] and stick them on the fusing unit lower cover. Push the oil absorber felts along the wall and paste as shown above. Make sure they are not pasted over the wall. 4-89 M124/M125...
Page 190 Remove the pressure roller with bearings [A]. The surface of the pressure roller is fragile, so the pressure roller must be covered  with a sheet of paper when it is placed on a table or floor. M124/M125 4-90...
Page 191 Fusing Do not wipe off the grease of the new fusing drive gear when replacing the fusing  drive gear [A]. 4-91 M124/M125...
Page 192 Cleaning Requirement The stripper plates require cleaning maintenance every fusing unit maintenance interval. Clean the stripper plates with a dry cloth, and then clean the stripper plates again with a cloth moistened with alcohol at the points shown above. M124/M125 4-92...
Page 193 1 each) 4.10.11 PRESSURE ROLLER THERMOSTATS Fusing unit ( p.4-79) Fusing unit upper cover ( p.4-83) Fusing unit lower cover ( p.4-85) Pressure roller thermostat (center) [A] and pressure roller thermostat (end) [B] ( x 2 each) 4-93 M124/M125...
Page 194 Fusing 4.10.12 NC SENSORS Fusing unit ( p.4-79) Fusing unit upper cover ( p.4-83) Fusing unit lower cover ( p.4-85) NC sensor (center) [A] and NC sensor (end) [B] (Hooks x 2 each, x 1 each) M124/M125 4-94...
Page 195 Fusing duct [A] ( x 1, x 1) Fusing fan [A] (hook x 5) When installing the fusing fan Make sure that the fusing fan is installed with its decal facing the right side of the machine. 4-95 M124/M125...
Page 196 Remove the top front cover [D]. Paper exit fan [A] ( x 1, hook x 3) When installing the paper exit fan Make sure that the paper exit fan is installed with its decal facing the rear of the machine.  M124/M125 4-96...
Page 197 AC controller fan bracket [A] ( x 2, x 1) AC controller fan [B] ( x 2) When installing the AC controller fan Make sure that the AC controller fan is installed with its decal facing the upper side of the machine. 4-97 M124/M125...
Page 198 Fusing entrance thermopiles ( x 1 each, x 1 each) When cleaning the lens of the thermopile Do this cleaning procedure after the fusing unit has completely cooled down. Otherwise,  you may get a serious burn. Fusing unit ( p.4-79) M124/M125 4-98...
Page 199 Clean with a cotton-swab dipped in alcohol. 4.10.17 PRESSURE ROLLER HP SENSOR Open the right door. Fusing unit ( p.4-79) AC controller board ( p.4-137) AC controller board bracket ( p.4-138) Pressure roller HP sensor [A] ( x 1, x 1, hooks x 3) 4-99 M124/M125...
Page 200 Pull trays 1 and 2, and the image transfer belt unit half way out. Right front cover [A] and front inner cover [B] QSU fan bracket [A] ( x 1, x 1, x 1) QSU fan ( x 2) M124/M125 4-100...
Page 201 4.10.19 FUSING UNIT SHUTTER PLATE DRIVE MOTOR AC controller board ( p.4-137) Fusing shutter plate drive motor [A] ( x 2, x 1) Do not wipe off the grease of the gear [B] on the new motor [A] when replacing it.  4-101 M124/M125...
Page 202 4.10.20 FUSING UNIT SHUTTER PLATE HOME POSITION SENSOR Open the right door. Fusing unit ( p.4-79) Fusing unit shutter plate home position sensor bracket [A] ( x 1, x 1) Fusing shutter plate home position sensor [A] (Hooks x 4) M124/M125 4-102...
Page 203 Drive shaft stay [A] (Bearing x 1) Drive cams [A] ( x 3, [B] x 1) Drive gear [C] and drive shaft [D] (Bearing x 1, x 1) 4-103 M124/M125...
Page 204 When reinstalling the fusing unit shutter plate drive mechanism: Make sure that the tension of the coil spring on the drive shaft is correct before  reinstallation. If the tension is weak, rotate the spring for one revolution on the shaft and hook it. M124/M125 4-104...
Page 205 4.11 PAPER FEED 4.11.1 PAPER FEED UNIT Rear cover ( p.4-11) Right rear cover ( p.4-12) Duplex unit ( p.4-119) Pull out tray 1 and tray 2. Paper guide plate [A] (tab x 2) Harness cover [A] ( x 1) 4-105 M124/M125...
Page 206 4.11.2 PICK-UP, FEED AND SEPARATION ROLLERS Tray 1 and Tray 2 Paper feed unit ( p.4-105) Roller holder [A] ( x 1) Pick-up roller [B] Feed roller [C] x 1) Separation roller [D] and torque limiter [E] ( M124/M125 4-106...
Page 207 Paper Feed 4.11.3 TRAY LIFT MOTOR Rear cover ( p.4-11) PSU bracket ( p.4-132) High voltage supply board bracket ( p.4-137) Tray lift motor 1 [A] or 2 [B] ( x 2, x 3, x 1 each) 4-107 M124/M125...
Page 208 Paper end feeler [B] and paper end sensor [C] (hook, x 1 each) Vertical transport sensor bracket [D] ( x 1, x 1) Vertical transport sensor [E] ( x 1, hook) Paper feed sensor bracket [F] ( x 1) Paper feed sensor [G] ( x 1, hook) M124/M125 4-108...
Page 209 Paper Feed 4.11.5 REGISTRATION SENSOR Rear cover ( p.4-11) Right rear cover ( p.4-12) Paper guide plate 1 [A] and 2 [B] ( x 2 each) Registration sensor [C] ( x 1, hook) 4-109 M124/M125...
Page 210 4.11.6 BY-PASS PAPER SIZE SENSOR AND BY-PASS PAPER LENGTH SENSOR Open the by-pass tray [A]. Move the side fences to the center. By-pass tray cover [B] ( x 4) By-pass paper size sensor [A] ( x 1). By-pass paper length sensor [B] ( x 1) M124/M125 4-110...
Page 211 Check this switch operation with SP5803-011 (By-pass paper size < Input Check). - Display on the Screen - Paper Size Display Paper Size Display A3 SEF 00001110 A5 SEF 00001011 B4 SEF 00001100 B6 SEF 00000011 A4 SEF 00001101 A6 SEF 00000111 B5 SEF 00001001 Smaller A6 SEF 00001111 4-111 M124/M125...
Page 212 Paper Feed 4.11.7 BY-PASS BOTTOM TRAY Open the right door. By-pass tray cover ( p.4-110) Open the duplex door [A]. Right door cover [B] ( x 4) Right door rear cover [A] ( x 3) M124/M125 4-112...
Page 213 Paper Feed Remove the screw at the front side ( x 1). Remove the cover [A] (2 hooks). Remove the screw at the rear side. 4-113 M124/M125...
Page 214 Release the front [A] and rear [B] arms ( x 1 each). 10. By-pass bottom tray [A] 4.11.8 BY-PASS PAPER END SENSOR Right door cover ( p.4-112) By-pass feed unit cover [A] ( x 2). By-pass paper end sensor [B] ( x 1, hook) M124/M125 4-114...
Page 215 Paper Feed 4.11.9 BY-PASS PICK-UP, FEED AND SEPARATION ROLLER, TORQUE LIMITER Right door cover ( p.4-112) By-pass pick-up roller [A] (hook) By-pass feed roller [A] ( x 1) By-pass feed unit cover ( p.4-114) 4-115 M124/M125...
Page 216 By-pass separation roller [A] ( x 1) Torque limiter [B] 4.11.10 BY-PASS FEED CLUTCH Open the right door. Right door rear cover ( p.4-112) By-pass feed clutch holder [A] ( x 2) By-pass feed clutch [B] ( x 1, x 1) M124/M125 4-116...
Page 217 Open the controller box ( p.4-126). 10. Gear cover [A] ( x 1) 11. Paper exit unit [B] ( x 2, x 2) 4.11.12 FUSING EXIT, PAPER OVERFLOW, JUNCTION PAPER JAM AND PAPER EXIT SENSOR Paper exit unit ( p.4-105) 4-117 M124/M125...
Page 218 1) Remove the junction paper jam sensor from the junction paper jam sensor bracket (hook) Paper exit sensor bracket [B] ( x 1, x 1) Remove the paper exit sensor from the paper exit sensor bracket (hook). M124/M125 4-118...
Page 219 Right rear cover ( p.4-12) Right door cover ( p.4-51) Close the right door [A]. Remove the spring [B]. Open the right door [A]. Release the front link [A] ( x 1). Keep the right door fully open. 4-119 M124/M125...
Page 220 10. Press the projection [B] to pull the right door shaft into the unit, and then remove the duplex unit [C] ( x 1, x 1, x 4, ground cable x 1). 4.12.2 DUPLEX DOOR SENSOR Right door cover ( p.4-51) Open the right door. Duplex door sensor [A] ( x 1, hook) M124/M125 4-120...
Page 221 4.12.3 DUPLEX ENTRANCE SENSOR Right door cover ( p.4-51) Open the right door. Duplex entrance guide [A] ( x1, stepped screw x 2) Duplex entrance sensor bracket [B] ( x 1, x 1) Duplex entrance sensor [C] (hook) 4-121 M124/M125...
Page 222 Duplex Unit 4.12.4 DUPLEX EXIT SENSOR Paper transfer unit ( p.4-51) Guide plate [A] (two hooks) Duplex exit sensor [B] ( x 1, hook) M124/M125 4-122...
Page 223 SD cards, printed circuit boards, or memory boards. 4.13.1 BOARDS Controller Box closed Controller Board HDD*1 High Voltage Supply Board (Behind the PSU [D] ) *1 This is optional for P3c (M124) but supplied with P3d (M125) as standard equipment. 4-123 M124/M125...
Page 224 Electrical Components Behind the IOB BB (Bridge Board) Controller Box Open ITB Power Supply Board M124/M125 4-124...
Page 225 Electrical Components 4.13.2 CONTROLLER UNIT Controller unit [A] (knob screw x 5) 4.13.3 CONTROLLER BOX RIGHT COVER Rear cover ( p.4-11) Controller box right cover [A] ( x 10) 4-125 M124/M125...
Page 226 Electrical Components 4.13.4 CONTROLLER BOX When opening the controller box Rear cover ( p.4-11) Remove six screws (red circles). Open the controller box [A]. M124/M125 4-126...
Page 227 Electrical Components When removing the controller box Rear cover ( p.4-11) Right rear cover ( p.4-12) Controller box right cover ( p.4-125) Remove the controller box stay [A] ( x 4). IOB bracket [A] ( x 4, x All) 4-127 M124/M125...
Page 228 Release all clamps on the controller box frame. Disconnect all connectors on the BB (Bridge Board) [A] and the BCU board [B]. Disconnect the connector [C] at the outer controller box and at the inner controller box. Disconnect the grounding cable ( x 1). M124/M125 4-128...
Page 229 If you do not open the controller box, the second fan duct prevents you from removing the  controller box. 4.13.5 IOB (IN/OUT BOARD) Rear cover ( p.4-11) Controller box right cover ( p.4-125) IOB [A] ( x 6, x All) 4-129 M124/M125...
Page 230 Controller box right cover ( p.4-125) IOB bracket ( p.4-126) BB [1] ( x 5, x All) 4.13.7 BCU Rear cover ( p.4-11) Controller box right cover ( p.4-125) IOB bracket ( p.4-126) BCU [A] ( x 4, x All) M124/M125 4-130...
Page 231 Make sure that the DIP-switch settings on the old BCU are the same for the new BCU.  Do not change the DIP switches on the BCU in the field. Make sure the serial number is input in the machine for the NVRAM data, if not, SC  995-001 occurs. 4-131 M124/M125...
Page 232 Electrical Components 4.13.8 PSU PSU bracket Rear cover ( p.4-11) Duct fan with the bracket [A] ( x 3, x 2). Ventilation duct [A] ( x 2) PSU bracket [B] ( x 6, x All, x All) M124/M125 4-132...
Page 233 Electrical Components PSU board Rear cover ( p.4-11) Ventilation duct ( p.4-132) PSU board [A] ( x 11, x All, x All) PSU fans Rear cover ( p.4-11) 4-133 M124/M125...
Page 234 Electrical Components PSU fan bracket [A] ( x 6, x 2) PSU fans ( x 2, each) M124/M125 4-134...
Page 235 Electrical Components 4.13.9 SHUTDOWN SWITCH PSU bracket ( p.4-132) Pull out tray 2. Tray left rail cover [A] ( x 1) Take aside the cords and ferrite core [B] ( x 2). Shutdown switch [A] ( x 2) 4-135 M124/M125...
Page 236 Top rear cover ( p.4-12) ITB power supply board [A] ( x 5, x 6, 4.13.11 HIGH VOLTAGE SUPPLY BOARD Rear cover ( p.4-11) PSU bracket ( p.4-132) High voltage supply board [A] ( x 8, x All, x 2) M124/M125 4-136...
Page 237 High voltage supply board bracket [A] ( x 3, x All, x 2) 4.13.13 AC CONTROLLER BOARD Rear cover ( p.4-11) Right rear cover ( p.4-12) Fusing duct ( p.4-95) AC controller board [A] ( x 7, x 5) 4-137 M124/M125...
Page 238 Electrical Components 4.13.14 AC CONTROLLER BOARD BRACKET AC controller board ( p.4-137) AC controller board bracket [A] ( x 3) M124/M125 4-138...
Page 239 Electrical Components 4.13.15 CONTROLLER BOARD Controller unit ( p.4-125) HDD ( p.4-141) Controller board [A] ( x 7, x 1) Interface rails [A], NV-RAM [B], RAM-DIMM [C] 4-139 M124/M125...
Page 240 HDD fan bracket [A] ( x 2) HDD fan [B] ( x 2, x 1) When installing the HDD fan Make sure that the HDD fan is installed with its decal facing the right side of the machine. M124/M125 4-140...
Page 241 Electrical Components 4.13.17 HDD The HDD is an option for the P3c (M124) model.  The HDD is a standard for the P3d (M125) model.  Controller unit ( p.4-125) Remove the HDD [A] with the bracket ( x 3, x 2).
Page 242 Pull out the toner bottle detection board [B] gently and horizontally ( x 1, x 4) The toner bottle detection board should be pulled out horizontally. If you ignore this,  the toner bottle detection terminals [A] may be damaged. M124/M125 4-142...
Page 243 If the message “SD card for restoration is required.” appears after the NVRAM  replacement, the encryption key should be restored. See “Encryption Key Restoration for NVRAM” for the restoration procedure. ( p.6-98 "Encryption Key Restoration for NVRAM") 4-143 M124/M125...
Page 244 If the message “SD card for restoration is required.” appears after the NVRAM  replacement, the encryption key should be restored. See “Encryption Key Restoration for NVRAM” for the restoration procedure. ( p.6-98 "Encryption Key Restoration for NVRAM") M124/M125 4-144...
Page 245 Electrical Components 4.13.20 TUBE COOLING FAN (1ST DUCT FAN) Rear cover ( p.4-11) Tube cooling fan bracket [A] ( x 2, x 1) Tube cooling fan (1st Duct Fan) 4-145 M124/M125...
Page 246 Boot-up from Flash Boot-up from SD card Memory Factory Use Only: Do not change the switch 2 to 8 settings. 4.14.2 BCU BOARD DIP SW No. Factory Use Only: Do not change the switch 1 and 2 settings. M124/M125 4-146...
Page 247 SYSTEM MAINTENANCE R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New 01/14/2013 Entering SP Mode Added 12/21/2012 Changed SP101-005 Bit4 from 1000 to 750. 12/21/2012 Changed SP5045-001 settings to 0 –...
Page 249 Service SP: SP modes related to the controller functions  Engine SP: SP modes related to the engine functions Select one of the Service Program modes (Service, or Engine) from the touch panel as shown in the diagram below after you access the SP mode. M124/M125...
Page 250 Press to move the highlight on the left to the previous or next selection in the list. Switch to the number key screen. For an SP that requires you to enter numbers, press "10 key" to display the number key screen, enter the number, and then press "OK" to confirm the specified value. M124/M125...
Page 251 Enter the value, and then press "OK". (The value is not registered if you enter a number  that is out of range.) Press "Exit" to exit from the setting.  Press "Exit" twice to return to the user screen. Exiting Service Mode Press the Exit key on the touch-panel. M124/M125...
Page 252 "CTL" show which NVRAM contains the data. ENG: NVRAM on the BCU board  CTL: NVRAM on the controller board  The settings of each SP mode are explained in the right-hand column of the SP table in the M124/M125...
Page 253 SP mode shows on the screen using alphanumeric characters instead of only numbers. However, the settings in the bracket in the SP mode table are explained by using only the numbers. SSP: This denotes a "Special Service Program" mode setting. M124/M125...
Page 254 [PCL5e/c,PS]: PDL Auto Switching Enable Disable: The MFPs ability to change the PDL processor mid-job. Some host systems submit jobs that contain both PS and PCL5e/c. If Auto PDL switching is disabled, these jobs will not be printed properly. bit 4 M124/M125...
Page 255 If enabled, the simplex pages of IPDS jobs will be printed on the front side because of printing on the back side of the page. This might reduce printing speed. bit 4 bit 5 bit 6 bit 7 IPDS support tools Enable Disable Enable: Enables the port for IPDS support tools. M124/M125...
Page 256 Enable: Changes the maximum number of jobs that can be stored on the HDD via Job Type settings to 750. The default is 100. bit 5 bit 6 Method for determining the image Disable Enable rotation for the edge to bind on. M124/M125...
Page 257 Not having to switch paper paths increases the print speed slightly. bit 1 bit 2 bit 3 bit 4 bit 5 bit 6 bit 7 1001 [Bit Switch] 008 Bit Switch 8 bit 0 bit 1 bit 2 M124/M125...
Page 258 - Job submission via USB or Parallel Port - Spool printing (WIM >Configuration > Device Settings > System) bit 3 bit 4 Timing of the PJL Status ReadBack (JOB Enable END) when printing multiple collated Disable copies. M124/M125 5-10...
Page 259 Queue is Queue locked after locked after AJP If this is 1, then after a job is stored using Auto Job Promotion, new jobs cannot be added to the queue until the stored job has been completely printed. 5-11 M124/M125...
Page 260 2 bit 3 bit 4 bit 5 bit 6 bit 7 1001 [Bit Switch] 012 Bit Switch C bit 0 bit 1 bit 2 bit 3 bit 4 bit 5 bit 6 bit 7 M124/M125 5-12...
Page 261 Recalls a set of gamma settings. This can be either a) the factory setting, b) 1101 the previous setting, or c) the current setting. 001 Factory *CTL 002 Previous *CTL [ - / - / - ] 003 Current *CTL [Execute] 004 ACC *CTL 5-13 M124/M125...
Page 262 [0 to 30 / 15 / 1/step ] 003 Black: Middle 004 Black: IDmax 005 Black 006 Black 007 Black 008 Black 009 Black 010 Black 011 Black 012 Black 013 Black 014 Black 015 Black 016 Black M124/M125 5-14...
Page 263 050 Magenta 051 Magenta 052 Magenta 053 Magenta 054 Magenta 055 Magenta 056 Magenta 061 Yellow: Highlight 062 Yellow: Shadow [0 to 30 / 15 / 1/step ] 063 Yellow: Middle 064 Yellow: IDmax 065 Yellow 066 Yellow 5-15 M124/M125...
Page 264 [0 to 999 / 75 / 1 /step ] 006 Mode2:Line *CTL [0 to 999 / 50 / 1 /step ] 007 Mode1:Paint *CTL [0 to 999 / 75 / 1 /step ] 008 Mode2:Paint *CTL [0 to 999 / 50 / 1 /step ] M124/M125 5-16...
Page 265 [All Jobs Delete Mode] This switch determines whether all SCS jobs in progress are included in the 1111 SMC report when SP5990 is executed. 0:excluding New Job *CTL [0 or 1 / 1 / 1/step] 1:including New Job 5-17 M124/M125...
Page 266 025 Duplex: Thick 1:1200 *ENG 026 Tray: Thin *ENG 027 By-pass: Thin *ENG 028 Duplex: Thin *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm/step] 029 Tray: Thin: 1200 *ENG 030 By-pass: Thin: 1200 *ENG 031 Duplex: Thin: 1200 *ENG M124/M125 5-18...
Page 267 [-9 to 5 / 0 / 1 mm/step] 024 Tray 2/3/4/5LCT: Mid:1200 *ENG 025 By-pass: Plain:1200 *ENG 026 By-pass: Middle Thick:1200 *ENG 027 Paper Tray1: Thick1:1200 *ENG Paper Tray2/3/4/5/LCT: Thick [-9 to 5 / -2 / 1 mm/step] *ENG 1:1200 5-19 M124/M125...
Page 268 1105 roller Paper Type Plain, Thin, Thick, OHP, Middle Thick, Special, Postcard [100 to 180 / P3c:158(NA,TA),160(EU,ASIA,CHN) Plain1:FC:Center *ENG P3d:161(NA,TA),163(EU,ASIA) / 1 deg/step] Specifies the fusing sleeve belt target temperature for the ready condition in full color printing. M124/M125 5-20...
Page 269 [100 to 180 / 158 / 1 deg/step] 025 Thick3:FC:Center *ENG [100 to 180 / 163 / 1 deg/step] 027 Thick3:BW:Center *ENG [100 to 180 / 163 / 1 deg/step] [100 to 180 / P3c:163(NA,TW),165(EU,ASIA,CHN), 029 Special1:FC:Center *ENG P3d:166(NA,TW),168(EU,ASIA) / 1 deg/step] 5-21 M124/M125...
Page 270 [100 to 180 / 138 / 1 deg/step] 127 Plain2:Glossy:Center *ENG [100 to 180 / 143 / 1 deg/step] 129 M-thick:Glossy:Center *ENG [100 to 180 / 148 / 1 deg/step] 131 OHP:Center *ENG [100 to 180 / 158 / 1 deg/step] M124/M125 5-22...
Page 271 [0 to 2 / 0 / 1 /step] Execute Pattern *ENG 0: Off, 1: On (No Decurl), 2: On Selects the curl correction type. Humidity:Threshold:M-humid *ENG [0 to 100 / 1 / 1 %/step] Specifies the threshold between low and middle humidity. 5-23 M124/M125...
Page 272 [0 to 100 / 65 / 1 %/step] Specifies the CPM ratio against of the no decurl control to the normal operation in high humidity. [Voltage Detection] 1133 Detects AC power voltage. 001 Voltage Detection *ENG [0 to 350 / 1 / 1 V/step] M124/M125 5-24...
Page 273 *ENG issued. [-50 to 300 / - / 1 deg/step] Displays the temperature at the end of the pressure roller when an SC was 154 Press Roller:End Det2 *ENG issued. [-50 to 300 / - / 1 deg/step] 5-25 M124/M125...
Page 274 [-10 to 100 / 0 / 1/step] Select [Switch Rotation Start/Stop] 1154 Heater On Timing From *ENG [0 to 250 / 50 / 10msec/step] Motor ON [0 to 250 / Overshoot Prevent P3c:157(NA,TW),159(EU,ASIA,CHN), *ENG Temp. Abnormal Case P3d:160(NA,TW),162(EU,ASIA,CHN) / 1/step] M124/M125 5-26...
Page 275 [-4.0 to 4.0 / 0.0 / 0.1 %/step] Duplex CCW:Middle *ENG Thick:high 023 Duplex CCW:Thick1:Mid *ENG Reverse *ENG [-4.0 to 4.0 / -0.5 / 0.1%/step] CW:Normal:High Reverse CW:Middle *ENG [-4.0 to 4.0 / 0.0 / 0.1 %/step] Thick:Mid 5-27 M124/M125...
Page 276 [-4.00 to 4.00 / 0.10 / 0.01 %/step] 077 TransferMot:Low *ENG 078 TonerMot *ENG [-30 to 30 / 10 / 5 %/step] 079 Fusing: 1200 *ENG [-4.00 to 4.00 / -0.60 / 0.01 %/step] 080 Fusing:Thin:600 *ENG [-4.00 to 4.00 / -0.60 / 0.01 %/step] M124/M125 5-28...
Page 277 007 Paper Exit Fan *ENG 008 PSU Fan *ENG 009 QSU Heater Cooling Fan *ENG [0.0 to 120.0 / 0.0 / 0.1 min./step] AC Control board *ENG Cooling Fan 011 Second Duct Fan *ENG Toner Supply Cooling *ENG 5-29 M124/M125...
Page 278 *ENG Main Mag.: High Speed: *ENG Main Mag.: Medium *ENG [0 to 560 / 280 / 1 /step] Speed: M Main Mag.: Low Speed: *ENG Main Mag.: High Speed: *ENG [0 to 560 / 280 / 1 /step] M124/M125 5-30...
Page 279 [0.0 to 4.0 / 0.8 / 0.1 mm/step] Size:Thick Duplex Trail. S *ENG [0.0 to 4.0 / 0.6 / 0.1 mm/step] Size:Thick 014 Duplex Left Edge:Thick *ENG [0.0 to 1.5 / 0.3 / 0.1 mm/step] 015 Duplex Right Edge:Thick *ENG 5-31 M124/M125...
Page 280 21: Grayscale Horizontal Margin 10: Argyle Pattern Large 23: Full Dot Pattern Specifies the color for the test pattern. [1 to 4 / 1 / 1/step] 005 Color Selection 1: All colors, 2: Magenta, 3: Yellow, 4: Cyan M124/M125 5-32...
Page 281 [TM/ID Sensor Check] ID Sensor Check FA 2112 [0 or 1 / 0 / 1 /step] This SP is used to check the ID sensors 001 Execute at the factory. The results of this SP are displayed in SP2140 to SP2145. 5-33 M124/M125...
Page 282 [-50 to 50 / - / 1 pulse/step] 003 Y *ENG [Thick Paper Skew Adj] 2120 001 On/Off *ENG [0 or 1 / 1 / 1 /step] [Skew Adjust Coefficient] 2121 001 Coefficient *ENG [0 to 2 / 0 / 1 /step] M124/M125 5-34...
Page 283 [0 to 999999 / - / 1 times/step] 009 Number of Failure *ENG [0 to 999999 / - / 1 times/step] 010 Error Result: M *ENG [0 to 9 / - / 1 /step] 011 Error Result: C *ENG 0: Not done 5-35 M124/M125...
Page 284 [0 to 99999999 / - / 1/mm] 003 45 < TS [0 to 99999999 / - / 1/mm] [0 or 1 / 0 / 1/step] 004 Log Clear 1: Clear [OPC Drum Refresh Mode] 2982 [- / - / -] 001 Manual Execution Execution M124/M125 5-36...
Page 285 Troubleshooting: Process Control Error Conditions" for details. 001 History: Latest *ENG 002 Result: Latest 1 *ENG 003 Result: Latest 2 *ENG [1111 to 99999999 / - / 1/step] 004 Result: Latest 3 *ENG 005 Result: Latest 4 *ENG 006 Result: Latest 5 *ENG 5-37 M124/M125...
Page 286 [Forced Toner Supply: Execute] Forced Toner Supply ([Color]) 3015 001 Execution: ALL 002 Execution: COL Executes the manual toner supply to 003 Execution: Bk the development unit. 004 Execution: M [-/ - / -] 005 Execution: C Execute 006 Execution: Y M124/M125 5-38...
Page 287 *ENG [0 or 1/ 0 / 1 /step] 006 Execution Flag: M *ENG 0: Flag OFF, 1: Flag ON 007 Execution Flag: C *ENG This flag is cleared after executing TD 008 Execution Flag: Y *ENG sensor initialization. 5-39 M124/M125...
Page 288 [0 to 4 / 4 / 1/step] Alphanumeric 002 M *ENG 0: FIXED (with the supply rates stored 003 C *ENG with SP 3401) 1: PID (Vtref_Fixed) 2: PID (Vtref_Control) 004 Y *ENG 3: Not used 4: MBD (Vtref_Control) M124/M125 5-40...
Page 289 *ENG [Vtref: Display/Set] 3222 Displays or adjusts the current Vtref value for each color. 001 Current: Bk *ENG 002 Current: M *ENG [0 to 5.5 / 3.00 / 0.01 V/step] 003 Current: C *ENG 004 Current: Y *ENG 5-41 M124/M125...
Page 290 011 Average M: C *ENG 012 Average M: Y *ENG Displays the average coverage of each color for the Vtref correction. 013-016 "Average L" is defined when the number of developed pages does not reach the number specified with SP3-251-019. M124/M125 5-42...
Page 291 010 Vsg TM (Rear) *ENG [Vsg Adjustment Result:Ifsg] 3323 Displays the result value of the Vsg adjustment for each sensor. 005 Ifsg: TM(Front) *ENG 006 Ifsg: TM(Center) *ENG [0.0 to 50.0 / - / 0.1 mA/step] 007 Ifsg: TM(Rear) *ENG 5-43 M124/M125...
Page 292 [Toner Supply Carry Over:Disp] 001 Bk *ENG Displays the toner supply time carried 002 M *ENG over from a previous toner supply 003 C *ENG mode for each color. 004 Y *ENG [0 to 10000 / 0 / 1 msec/step] M124/M125 5-44...
Page 293 *ENG [1 to 12 / - / 1/step] 003 Date *ENG [1 to 31 / - / 1/step] 004 Hour *ENG [0 to 23 / - / 1/step] 005 Minute *ENG [0 to 59 / - / 1/step] 5-45 M124/M125...
Page 294 *ENG Dev. Motor Rotation: Dis: *ENG 006 Pixel Coverage Sum: Bk *ENG 007 Pixel Coverage Sum: M *ENG [0 to 65535 / - / 1 cm^2/step] 008 Pixel Coverage Sum: C *ENG 009 Pixel Coverage Sum: Y *ENG M124/M125 5-46...
Page 295 [0.00 to 5.00 / - / 0.01 mg/cm /kV /step] 004 Y (Current) *ENG [Vk Display] 3612 Displays Vk for each color. 001 Bk *ENG 002 M *ENG [-300 to 300 / - / 1 V/step] 003 C *ENG 004 Y *ENG 5-47 M124/M125...
Page 296 008 Thick 1: Y *ENG 009 Thick 2 & FINE: Bk *ENG 010 Thick 2 & FINE: M *ENG [0 to 2000 / - / 1 -V/step] 011 Thick 2 & FINE: C *ENG 012 Thick 2 & FINE: Y *ENG M124/M125 5-48...
Page 297 TD Sensor: Toner Concentration Control Setting 3710 Selects the toner concentration control method by HST memory, which is in the TD sensor. Control Method: [0 or 1 / 1 / 1 /step] *ENG Selection 0: Not Use, 1: Use 5-49 M124/M125...
Page 298 013 Adjustment: Vtcnt *ENG [0.00 to 5.00 / - / 0.01 V/step] /kV /step] 014 Adjustment: Gamma *ENG [0.00 to 2.55 / - / 0.01 mg/cm 015 Adjustment: Vcnt Result *ENG [0 to 9 / - / 1 /step] M124/M125 5-50...
Page 299 013 Adjustment: Vtcnt *ENG [0.00 to 5.00 / - / 0.01 V/step] 014 Adjustment: Gamma *ENG [0.00 to 2.55 / - / 0.01 mg/cm /kV /step] 015 Adjustment: Vcnt Result *ENG [0 to 9 / - / 1 /step] 5-51 M124/M125...
Page 300 Sleeve Belt" in this manual. 020 Toner Supply Unit: Bk *ENG 021 Toner Supply Unit: M *ENG [0 or 1 / 0 / 1 /step] 022 Toner Supply Unit: C *ENG 0: OFF, 1: ON 023 Toner Supply Unit: Y *ENG M124/M125 5-52...
Page 301 [0 or 1 / 0 / 1 /step] Alphanumeric 001 - *CTL 0: ON 1: OFF [Display IP Address] 5055 Display or does not display the IP address on the LCD. [0 or 1 / 0 / 1 /step] 001 - *CTL 0: OFF 1: ON 5-53 M124/M125...
Page 302 018 Fusing Roller *CTL 019 Pressure Roller *CTL [PM Parts Display] 5066 Display or does not display the “PM parts” button on the LCD. [0 or 1 / 0 / 1 /step] 001 - *CTL 0: Not display, 1: Display M124/M125 5-54...
Page 303 Paper Transfer Roller *CTL [0: Service] or [1: User] Unit 017 Waste Toner bottle *CTL [0: Service] or [1: User] 018 Fusing Roller *CTL [0: Service] or [1: User] 019 Pressure Roller *CTL [0: Service] or [1: User] 5-55 M124/M125...
Page 304 001 Double Count *CTL [0 or 1 / 0 / 1/step] Bypass Custom Paper *CTL [0 or 1 / 0 / 1/step] Size 5112 [Non-Standard Paper Selection] 001 0:OFF 1:ON *CTL [0 or 1 / 1 / -] M124/M125 5-56...
Page 305 [0 or 1 / P3c 0(EU, ASIA, CHN,TW), P3d 004 TRAY 2: 3 *ENG 1(NA) / 1 /step] 0: B4, 1: LG [0 or 1 / P3c 0(EU, ASIA, CHN,TW), P3d 005 TRAY 2: 4 *ENG 1(NA) / 1 /step] 0: B5 LEF, 1: Exe LEF 5-57 M124/M125...
Page 306 [0 or 1 / P3c 0(EU, ASIA, CHN,TW), P3d 017 TRAY 5: 4 *ENG 1(NA) / 1 /step] [0 or 1 / P3c 0(EU, ASIA, CHN,TW), P3d 018 LCT *ENG 1(NA) / 1 /step] 0: A4LEF, 1: LTLEF, 2: B5LEF M124/M125 5-58...
Page 307 [0 to 10 / 0 / 1/step] 0: No external controller installed 1: EFI 001 - 2: Ratio 3: Egret 4: GJ 5: Creo 6: QX-100 7: Kurofune 8 to 10: Reserved 5-59 M124/M125...
Page 308 NA and EUR: 1, ASIA: 0 Enables or disables the summer time mode. Make sure that both SP5-307-3 and -4 are correctly set. Otherwise,  this SP is not activated even if this SP is set to "1". 003 Rule Set (Start) *CTL M124/M125 5-60...
Page 309 9999) x 1000 > PM counter [0 or 1 / 0 / 1 /step] 0: No alarm sounds 002 Original Count Alarm *CTL 1: Alarm sounds after the number of originals passing through the ARDF > 10,000 5-61 M124/M125...
Page 310 Supply Alarm 0: Off 1: On [0 or 1 / 1 / 1 /step] 007 Tensya Supply Alarm 0: Off 1: On [0 or 1 / 1 / 1 /step] 008 Fuser Supply Alarm 0: Off 1: On M124/M125 5-62...
Page 311 Continuous Count Sets the number of consecutive paper jams required to initiate a call. This setting is enabled only when SP5508-004 is set to "1". Door Open: Time *CTL [3 to 30 / 10 / 1 /step] Length 5-63 M124/M125...
Page 312 SP parts reaches its yield. Disable/Enable Setting [0 or 1 / 1 / - ] *CTL (0: Not send, 1: Send) 0: Not send, 1: Send Percent yield for *CTL [1 to 255 / 75 / 1 %/step] triggering PM alert M124/M125 5-64...
Page 313 [- / - / - ] Option: [Unique] 101 Import Crypt config: [Encryption] Encryption key (if selected) [Execute] Export Result Print [ - / - / - ] (SP) [Execute] Import Result Print [ - / - / - ] (SP) [Execute] 5-65 M124/M125...
Page 314 System Setting except for setting of Energy Saver  I/F Setup (I/O Buffer and I/O Timeout)  PCL Menu [ - / - / - ] Web Service [Execute] Deletes the network file application management files and thumbnails, and initializes the job login ID. M124/M125 5-66...
Page 315 Initializes the ECS settings. 021 ECS [- / - / -] [Execute] [ - / - / - ] websys [Execute] [Input Check] 5803 p.5-141). See "Input Check Table" ( [Output Check] 5804 See "Output Check Table" ( p.5-150). 5-67 M124/M125...
Page 316 Counter List. This can be up to 20 characters (both numbers and alphabetic characters can be input). Supply *CTL Use this to input the telephone number of your supplier for consumables. Enter the number and press #. M124/M125 5-68...
Page 317 NRS. Successful return will be in the range 0 to 99. [ - / - / - ] Device Information Call [Execute] This SP issues a call to notify the NRS device information to the call center. Successful return will be in the range 0 to 99. 5-69 M124/M125...
Page 318 1: Installation completed This SP displays the RCG-N installation end flag. [0 or 1 / 0 / 1 /step] Connect Type (N/M) *CTL 0: Internet connection 1: Dial-up connection This SP displays and selects the RCG-N connection method. M124/M125 5-70...
Page 319 This SP sets the HTTP proxy certification password. The length of the password is limited to 31 characters. Any character  beyond the 31st character is ignored. This name is customer information and is not printed in the SMC  report. 5-71 M124/M125...
Page 320 Displays a number code that describes the reason for the request for update of the certification. Normal. There is no request for certification update in progress. Request for certification update in progress. The current certification has expired. An SSL error notification has been issued. Issued after the certification has expired. M124/M125 5-72...
Page 321 Displays the common name of the issuer of the @Remote certification. CN = the following 30 bytes. Asteriskes (****)indicate that no DESS exists. CERT: Valid Start Displays the start time of the period for which the current @Remote certification is enabled. 5-73 M124/M125...
Page 322 Letter Number *CTL Allows entry of the number of the request needed for the RCG-N device. Confirm Execute Executes the inquiry request to the @Remote GW URL. 204 Confirm Result [0 to 255 / 0 / 1 /step] M124/M125 5-74...
Page 323 [-2147483647 to 2147483647 / 0 / - ] Displays a number that describes the error code that was issued when either SP5816-204 or SP5816-207 was executed. Cause Code Meaning -11001 Chat parameter error -11002 Chat execution error Illegal Modem -11003 Unexpected error Parameter -11004 -11005 5-75 M124/M125...
Page 324 -2394 Device not managed -2395 Box ID for Basil is illegal -2396 Device ID for Basil is illegal -2397 Incorrect ID2 format -2398 Incorrect request number format 209 Instal Clear Releases the machine from its embedded RCG setup M124/M125 5-76...
Page 325 IPv4 Address *CTL address for Ethernet and wireless LAN (Ethernet/IEEE 802.11) (802.11): aaa.bbb.ccc.ddd This SP allows you to check and reset the IPv4 IPv4 Subnet Mask *CTL subnet mask for Ethernet and wireless LAN (Ethernet/IEEE 802.11) (802.11): aaa.bbb.ccc.ddd 5-77 M124/M125...
Page 326 This SP determines whether the job interrupted at power off is resumed at the next power on. This SP operates only when SP5828-065 is set to "1". [0 to 1 / 1 / 1 /step] 069 Job Spooling (Protocol) *CTL 0: No spooling 1: Spooling enabled M124/M125 5-78...
Page 327 5) referenced on the Ethernet or wireless LAN Active IPv6 Stateless (802.11b) in the format: Address 2 "Status Address" + "Prefix Length" Active IPv6 Stateless The IPv6 address consists of a total 128 bits Address 3 configured in 8 blocks of 16 bits each. 5-79 M124/M125...
Page 328 Web shopping link *CTL 0: Not display visible 1:Display Displays or does not display the link to Net RICOH on the top page and link page of the web system. [0 to 1 / 1 / 1 /step] Web supplies Link *CTL...
Page 329 001 HDD Formatting (ALL) 002 HDD Formatting (IMH) Initializes the hard disk. Use this SP HDD Formatting mode only if there is a hard disk error. (Thumbnail) [ - / - / - ] HDD Formatting (Job [Execute] Log) 5-81 M124/M125...
Page 330 HDD Formatting (Ridoc I/F) 5840 [IEEE 802.11] Range: DOM 1-14 NA/CHN/TW 1-11 EU 1-13 006 Channel MAX *CTL Default: DOM 14 NA/CHN/TW 11 EU 13 Range: DOM 1-14 007 Channel MIN *CTL NA/CHN/TW 1-11 EU 1-13 Default: 1 M124/M125 5-82...
Page 331 [1 to 3 / 3 / 1/step] 1: Info WPA Debug Lvl *CTL 2: warning 3: error Selects the debug level for WPA authentication application. This SP is displayed only when the IEEE802.11 card is installed. 5841 [Supply Name Setting] 5-83 M124/M125...
Page 332 PnP Model Name *CTL (up to 20 characters allowed). This SP sets the model name to be used by the USB PnP when "Function Enable (Level 2) is set so the USB Serial No. can have a common name (SP5844-5). M124/M125 5-84...
Page 333 [Delivery Server Setting] 5845 Provides items for delivery server settings. [0 or 1 / 1 / 1 /step] Rapid Sending Control *CTL 0: Disable 1: Enable Enables or disables the prevention function for the continuous data sending error. 5-85 M124/M125...
Page 334 Initialize Local Addr [- / - / -] Book [Execute] Clears the local address book information, including the user code. Initialize LDAP Addr [- / - / -] Book [Execute] Clears the LDAP address book information, except the user code. M124/M125 5-86...
Page 335 This SP does not normally require adjustment.  This SP is enabled only after the system administrator has set up a  group password policy to control access to the address book. 5-87 M124/M125...
Page 336 *CTL 4bits) 210 Setting: LogType: Job1 *CTL 211 Setting: LogType: Job2 *CTL Setting: LogType: *CTL Access 213 Setting: Primary Srv *CTL 214 Setting: Secondary Srv *CTL 215 Setting: StartTime *CTL 216 Setting: IntervalTime *CTL 217 Setting: Timing *CTL M124/M125 5-88...
Page 337 [Save Debug Log] [0 or 1 / 0 / 1 /step] On/Off (1:ON 0:OFF) *CTL 0: OFF 1: ON Switches the debug log feature on and off. The debug log cannot be captured until this feature is switched on. 5-89 M124/M125...
Page 338 Erases all debug logs on the SD Card. If the card contains only debugging files generated by an event specified by SP5858, the files are erased when SP5857 010 or 011 is executed. To enable this SP, the machine must be cycled off and on. M124/M125 5-90...
Page 339 These SPs allow you to set up to 10 keys for log files for functions that use 5859 common memory on the controller board. 001 Key 1 *CTL [–9999999 to 9999999 / 0 / 1 /step] 002 Key 2 *CTL 5-91 M124/M125...
Page 340 Selects the MIME header type of an E-mail sent by S/MIME. 5869 [RAM Disk Setting] Mail Function *CTL [0 or 1 / 0 / 1 /step] Writes to flash ROM the common proof for validating the device for @Remote specifications. M124/M125 5-92...
Page 341 1: Automatic reboot Selects the reboot method for SC. 5878 [Option Setup] [- / - / -] Data Overwrite Security [Execute] Enables the Data Overwrite Security unit. Press "EXECUTE" on the operation panel. Then turn the machine off and on. 5-93 M124/M125...
Page 342 Protect 1: No authentication, Protected logs (only an administrator can see the logs) Selects the protection level for logs. [SDK Application Counter] 5893 Displays the counter name of each SDK application. 001 SDK-1 002 SDK-2 003 SDK-3 M124/M125 5-94...
Page 343 [0 or 1 / 1 / 1 /step] 010 PCU *ENG 0:OFF 1:ON [0 or 1 / 1 / 1 /step] 014 Mid Trans Unit *ENG 0:OFF 1:ON [0 or 1 / 0 / 1 /step] 016 Fusing Unit *ENG 0:OFF 1:ON 5-95 M124/M125...
Page 344 002 SP (Mode Data List) 003 User Program 004 Logging Data Press “Execute” key to start exporting 005 Diagnostic Report the SMC data in the SP mode display. 006 Non-Default 007 NIB Summary 008 Capture Log 021 Copier User Program M124/M125 5-96...
Page 345 026 Printer SP mode [Fusing Cont mode] Fusing Control Mode 5998 Turns the silent fusing warm-up mode on or off. [0 or 1 / 1 / 1 /step ] 001 fast/silent *ENG 0: Silent (less noise) 1: Fast (less time) 5-97 M124/M125...
Page 346 Adjusts the paper buckle for each paper size. 001 A3T 002 B4T 003 A4T 004 A4Y 005 B5T 006 B5Y *ENG [-5.0 to 5.0 / 0 / 0.2 mm/step] 007 DLT-T 008 LG-T 009 LT-T 010 LT-Y 011 12*18 012 Other M124/M125 5-98...
Page 347 Adjusts the staple position for each finisher (D636/D637). 6133 + Value: Moves the staple position to the rear side. - Value: Moves the staple position to the front side. 001 Finisher1 *ENG [-3.5 to 3.5 / 0 / 0.5/step] 5-99 M124/M125...
Page 348 005 DLT-T the crease. 006 LG-T *ENG 007 LT-T 008 12*18 009 Other 6136 [Folding Number] *ENG [1 to 30 / 2 / 1 time/step] Sets the number of times that folding is done in the Booklet Finisher D637. M124/M125 5-100...
Page 349 You may need to adjust this setting or switch it off when feeding thick  or slick paper. [INPUT Check] Displays the signals received from sensors and switches of the bridge unit 6150 (D634) ( p.5-141 "Input and Output Check"). 6151 [OUTPUT Check] 5-101 M124/M125...
Page 350 [1 to 3 / 3 / 1 sheet/step] Sheet Conversion (Thick 1: 1 Sheet Paper) 2: 2 Sheets 3: 3 Sheets Permits punching, including tab sheets. Note: Do not change this setting. 6810 [1 to 3 / 3 / 1/step] M124/M125 5-102...
Page 351 [0 to 50 / 0 / 1/step] than booklet stapling 002 2 Booklet stapling *CTL [0 to 50 / 0 / 1/step] 6890 Shading Control ON/OFF [0 or 1 / 0 / 1/step] Enables or disables the shading adjustment for DF mode. 5-103 M124/M125...
Page 352 [0 to 65535 / - / 1/step ] [Total Original Jam] 7503 Displays the total number of original jams. 001 Original Jam counter *CTL [0 to 9999 / - / 1 original/step ] [Paper Jam Loc] 7504 ON: On check, OFF: Off Check M124/M125 5-104...
Page 353 053 Vertical Trans. 3: Off *CTL 054 Vertical Trans. 4: Off *CTL 057 Registration Sensor: Off *CTL For details, see “Jam Detection” in the 058 LCT Feed Sensor : Off *CTL "Main Chapters: 6. Troubleshooting". 060 Paper Exit Off *CTL 5-105 M124/M125...
Page 354 *CTL Finisher Stapler Exit: *CTL For details, see “Jam Detection” in the 195 Finisher Exit: EUP *CTL "Main Chapters: 6. Troubleshooting". 198 Finisher Folder: EUP *CTL Finisher Tray Motor: *CTL Finisher Jogger Motor: *CTL Finisher Shift Motor: *CTL M124/M125 5-106...
Page 355 014 B5 LEF *CTL [0 to 9999 / - / 1 sheet/step ] 038 LT LEF *CTL 044 HLT LEF *CTL 132 A3 SEF *CTL [0 to 9999 / - / 1 sheet/step ] 133 A4 SEF *CTL 5-107 M124/M125...
Page 356 007 Latest 6 *CTL 008 Latest 7 *CTL 009 Latest 8 *CTL 010 Latest 9 *CTL [Part Replacement Operation ON/OFF] 7624 Selects the PM maintenance for each part. 001 Drum unit: Bk *CTL [0 or 1 / 1 / -] M124/M125 5-108...
Page 357 Displays all versions and ROM numbers in the machine. 102 Engine 107 Finisher [- / - / -] 111 MailBox Lists ROM No. and Firmware versions on ROM No./ Firmware the display. Version [- / - / -] 5-109 M124/M125...
Page 358 014 Page: Image Transfer 015 Page: Cleaning Unit 016 Page: Fusing Unit [ 0 to 9999999 / - / 1 page/step ] Page: Paper Transfer Unit Page: Toner Collection Bottle 019 Page: Fusing Belt Unit 020 Page: Pressure Roller M124/M125 5-110...
Page 359 Unit: Bk Rotation: Development Unit: M Rotation: Development Unit: C Rotation: Development Unit: Y Rotation: Developer: [ 0 to 999999999 / - / 1 mm/step ] 040 Rotation: Developer: M 041 Rotation: Developer: C 042 Rotation: Developer: Y 5-111 M124/M125...
Page 360 R (%) counter is still less than 100%. 061 Rotation (%): PCU: Bk 062 Rotation (%): PCU: M 063 Rotation (%): PCU:C [0 to 255 / - / 1 %/step] 064 Rotation (%): PCU:Y 079) Rotation (%): Development Unit: Bk M124/M125 5-112...
Page 361 If the revolution count lifetime is reached first, the machine also enters the end condition, even though the Run Time (%) counter is still less than 100%. Run Time(%):Toner [0 to 255 / - / 1 %/step] Supply Unit: Bk 5-113 M124/M125...
Page 362 Page (%): Developer: 101 Page (%): Developer: C 102 Page (%): Developer: Y [0 to 255 / - / 1 %/step] Page (%): Image 091) Transfer Page (%): Cleaning Unit 105 Page (%): Fusing Unit Page (%): Paper Transfer Unit M124/M125 5-114...
Page 363 PM counter value in SP7-906 (PM Counter - Previous) and reset the value of the current PM counter (SP7-803) to “0”. [- / - / -] 001 PM Counter Reset [Execute] 002 PCU: Bk [- / - / -] 003 PCU: M [Execute] 004 PCU: C 5-115 M124/M125...
Page 364 This SP doesn’t delete either jam histories or SC code histories.  [ - / - / - ] 001 SC/Jam Clear [Execute] [Self-Diagnose Result Display] 7832 Displays the result of the diagnostics. 001 Diag. Result *CTL [ - / - / - ] M124/M125 5-116...
Page 365 017 Toner Collection Bottle 018 Fusing Belt Unit 019 Pressure Roller 020 Toner Supply Unit: Bk 021 Toner Supply Unit: M [0 to 255 / - / 1 /step] 022 Toner Supply Unit: C 023 Toner Supply Unit: Y 5-117 M124/M125...
Page 366 Displays the number of sheets printed with the previous maintenance units. 001 Page: PCU: Bk 002 Page: PCU: M 003 Page: PCU: C [0 to 9999999 / - / 1 page/step] 004 Page: PCU: Y Page: Development Unit: Bk M124/M125 5-118...
Page 367 Displays the number of revolutions for motors or clutches in the previous maintenance units. ( 031 - 046) 031 Rotation: PCU: Bk 032 Rotation: PCU: M 033 Rotation: PCU: C [0 to 999999999 / - / 1 mm/step] 034 Rotation: PCU: Y 019) Rotation: Development Unit: Bk 5-119 M124/M125...
Page 368 Displays the running time of the previous pump unit Run Time: Toner Supply Unit: Bk Run Time: Toner Supply Unit: M [0 to 999999999 / - / 1 msec/step] Run Time: Toner Supply Unit: C Run Time: Toner Supply Unit: Y M124/M125 5-120...
Page 369 Rotation %: Developer: Rotation %: Image Transfer Belt [0 to 255 / - / 1 %/step] Rotation %: Cleaning Unit 075 Rotation %: Fusing Unit Rotation %: Paper Transfer Unit Measurement %: Toner Collection bottle Rotation (%): Fusing Belt Unit 5-121 M124/M125...
Page 370 094 Page %: PCU: Y Page %: Development Unit: Bk Page %: Development [0 to 255 / - / 1 %/step] Unit: M Page %: Development Unit: C Page %: Development Unit: Y 099 Page %: Developer: Bk M124/M125 5-122...
Page 371 015 Scanner [ - / - / - ] 016 IDU 1 [ - / - / - ] 017 IDU 2 [ - / - / - ] 018 NIB [ - / - / - ] 5-123 M124/M125...
Page 372 210 MIB [ - / - / - ] 211 WebSystem [ - / - / - ] 212 WebDocBox [ - / - / - ] [Firmware Version] 7911 001 Engine [ - / - / - ] M124/M125 5-124...
Page 373 [ - / - / - ] 181 FONT1 [ - / - / - ] 182 FONT2 [ - / - / - ] 183 FONT3 [ - / - / - ] 200 Factory [ - / - / - ] 5-125 M124/M125...
Page 374 [0 or 99999999 / - / 1 /step] Counter 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG [0 or 1 / - / 1 /step] 021 End Date *ENG 7932 [Toner Bottle M] M124/M125 5-126...
Page 375 002 Cartridge Ver *ENG 003 Brand ID *ENG 004 Area ID *ENG 005 Product ID *ENG [0 to 255 / - / 1 /step] 006 Color ID *ENG 007 Maintenance ID *ENG New Product *ENG Information 009 Recycle Counter *ENG 5-127 M124/M125...
Page 376 *ENG 014 End History *ENG [0 or 1 / 0 / 1 /step] 015 Refill Information *ENG Attachment: Total *ENG Counter Attachment: Color [0 or 99999999 / 0 / 1 /step] *ENG Counter 018 End: Total Counter *ENG M124/M125 5-128...
Page 377 [0 or 1 / - / 1 /step] 041 to Displays the toner bottle information log 5 for Bk. 041 Serial No. [0 or 1 / - / 1 /step] 042 Attachment Date [0 or 1 / - / 1 /step] 5-129 M124/M125...
Page 378 [0 or 1 / - / 1 /step] 041 to Displays the toner bottle information log 5 for M. 041 Serial No. [0 or 1 / - / 1 /step] 042 Attachment Date [0 or 1 / - / 1 /step] M124/M125 5-130...
Page 379 [0 or 1 / - / 1 /step] 041 to Displays the toner bottle information log 5 for C. 041 Serial No. [0 or 1 / - / 1 /step] 042 Attachment Date [0 or 1 / - / 1 /step] 5-131 M124/M125...
Page 380 [0 or 1 / - / 1 /step] 041 to Displays the toner bottle information log 5 for Y. 041 Serial No. [0 or 1 / - / 1 /step] 042 Attachment Date [0 or 1 / - / 1 /step] M124/M125 5-132...
Page 381 Unit: Bk Page: Development Unit: M [0 to 255 / 255 / 1 day/step] Page: Development Unit: C Page: Development Unit: Y 009 Page: Developer: Bk [0 to 255 / 255 / 1 day/step] 010 Page: Developer: M 5-133 M124/M125...
Page 382 039 Rotation: Developer: Bk 040 Rotation: Developer: M [0 to 255 / 255 / 1 day/step] 041 Rotation: Developer: C 042 Rotation: Developer: Y Rotation: Image Transfer [0 to 255 / 255 / 1 day/step] 044 Rotation: Cleaning Unit M124/M125 5-134...
Page 383 For toner collection bottle, this SP is not Unit: Y displayed because its Remaining Day Minimum: Developer: Counters is calculated with its weights only. 110 Minimum: Developer: M 111 Minimum: Developer: C 112 Minimum: Developer: Y Minimum: Image Transfer 5-135 M124/M125...
Page 384 [0 to 999999999 / 52083000 / 1000 Supply Unit: M msec/step] Run Time: Toner [0 to 999999999 / 52083000 / 1000 Supply Unit: C msec/step] Run Time: Toner [0 to 999999999 / 52083000 / 1000 Supply Unit: Y msec/step] M124/M125 5-136...
Page 385 Adjusts the threshold day for the near Transfer Belt end for each PM unit. Day Threshold: [1 to 30 / 15 / 1 day/step] Cleaning Unit These threshold days are used for Day Threshold: Fusing @Remote alarms. Unit 5-137 M124/M125...
Page 386 Unit: Y 058 Page: Developer: Bk 059 Page: Developer: M [0 to 999999 / 0 / 1 sheet/step] 060 Page: Developer: C 061 Page: Developer: Y Day Threshold:Toner [1 to 30 / 15 / 1 day/step] Supply Unit: Bk M124/M125 5-138...
Page 387 [0 to 99999999 / - / 1 mm/step] 016 25<=T<30:80<=H<=100 017 30<=T<35:0<=H<30 018 30<=T<35:30<=H<55 019 30<=T<35:55<=H<80 020 30<=T<35:80<=H<=100 021 35 <= T [Operation Env. Log Clear] 7954 Clears the operation environment log. Operation Env. Log [- / - / -] Clear [Execute] 5-139 M124/M125...
Page 388 180473000 / 1 mm/step] Displays the threshold distance for the fusing sleeve belt near end. [0 to 999999999 / P3c: 168518000, P3d: End: Rotation 187283000 / 1 mm/step] Displays the threshold distance for the fusing sleeve belt end. M124/M125 5-140...
Page 389 014 1st Paper Feed Sensor 015 2nd Paper Feed Sensor 016 Exit Sensor 017 Tray Full Exit Sensor 018 Fusing Exit Sensor 019 Fusing Entrance Sensor 020 1st Feed Sensor 021 2nd Feed Sensor 022 Duplex Exit Sensor 023 Registration Sensor 5-141 M124/M125...
Page 390 057 AC Control board Cooling Fan: Lock 058 Airflow Fan: Middle 1: Lock 059 Airflow Fan:Middle 2:Lock 060 ITB Contact Motor Position Paper Transfer Contact Motor Position 062 Toner Relay Motor: Lock 063 ITB Drive Motor:Lock K Drum/Development Drive Motor: Lock M124/M125 5-142...
Page 391 092 Fusing Pressue Release Sensor 094 GAVD Open/Close Detection 110 IOB Version Table 1: Paper Height Sensor 0: Deactivated, 1: Activated (actuator inside sensor) Remaining paper Paper height sensor 1 Paper height sensor 2 Full Nearly full Near end Almost empty 5-143 M124/M125...
Page 392 *3: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP 5-181-002. *4: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of SP 5-181-005. M124/M125 5-144...
Page 393 A5 LEF LT/LG SEF* A4 SEF LT/LG SEF* A5 LEF DLT SEF A3 SEF LT LEF A4 LEF DLT SEF A3 SEF LT LEF A4 LEF *1: The paper size (LT or LG) can be selected with SP1-007-001. 5-145 M124/M125...
Page 394 024 Punch Registration HP Sensor Punch Registration Detection Sensor 026 Punch Chad Full Sensor 027 Punch HP 028 Punch Selection DIPSW 1 See * 029 Punch Selection DIPSW See * Junction Gate Open/Close HP Sensor 031 Leading Edge Detection Sensor M124/M125 5-146...
Page 395 *1: Combination of DIP SW 1 and SW 2 DIP SW 1 DIP SW 2 Punch Type Japan Europe North America North Europe *2: Please refer to "Lower Tray (D637 Only)" in the Service Manual for the "2000/3000 (Booklet) Finisher". 5-147 M124/M125...
Page 396 010 Paper Sensor 1 011 Door Sensor Bridge Unit (D634) Reading 6150 Description 001 Bridge/Left: Exit Sensor 002 Bridge/Left: Feed Sensor 003 Bridge/Left/Shift: Set Detection 004 Bridge/Left: Exit Cover Detection 005 Bridge/Left: Feed Cover Detection 006 Left:Left Exit Sensor M124/M125 5-148...
Page 397 002 Bank: Tray4: Feed Sensor 003 Bank: Tray5: Feed Sensor 004 Bank: Tray3: Vertical Feed Sensor 005 Bank: Tray4: Vertical Feed Sensor 006 Bank: Tray5: Vertical Feed Sensor 007 Bank: Feed Cover Detection 011 Bank: LCT: Paper Replenishment 012 Bank: LCT: Slide 5-149 M124/M125...
Page 398 Exit the SP mode or turn off the power switch. Undo the step 1. If the main power switch is turned off, turn the switch back on. 037 Toner Relay Motor Image Transfer Motor: HighSpeed Image Transfer Motor: MiddleSpeed M124/M125 5-150...
Page 399 Duplex Reverse Motor: CW: MiddleSpeed Duplex Reverse Motor: CW: LowSpeed Duplex Reverse Motor: CCW: HighSpeed Duplex Reverse Motor: CCW: MiddleSpeed Duplex Reverse Motor: CCW:LowSpeed 095 ITB Contact Motor 096 Paper Transfer Contact Motor 097 1st Tray Lift Motor: Up 5-151 M124/M125...
Page 400 137 Toner Supply Pump: Y 138 1st Paper Feed Clutch 139 2nd Paper Feed Clutch 140 Bypass Feed Clutch 141 Bypass Pickup Solenoid 143 TM Sensor Shutter Solonoid 144 Exit Junction Solenoid 145 1st Feed Pickup Solenoid 146 2nd Feed Pickup Solenoid M124/M125 5-152...
Page 401 182 ChargeAC: Y: MiddleSpeed 183 ChargeAC: Y: LowSpeed 186 PP: Development: K 187 PP: Development: M 188 PP: Development: C 189 PP: Development: Y 190 PP:Separation 216 LD1: K 217 LD2: K 218 LD1: Ma 219 LD2: Ma 220 LD1: Cy 5-153 M124/M125...
Page 402 238 PP: ChargeDC: K: MiddleSpeed 239 PP: ChargeDC: K: LowSpeed 244 PP: ChargeDC: M: HighSpeed 245 PP: ChargeDC: M: MiddleSpeed 246 PP: ChargeDC: M: LowSpeed 251 PP: ChargeDC: M: HighSpeed 252 PP: ChargeDC: M: MiddleSpeed 253 PP: ChargeDC: M: LowSpeed M124/M125 5-154...
Page 403 Booklet Stapler EH185R: Rear Rear 024 Folder Plate Motor Fold Plate Motor 025 Folder Roller Motor Fold Roller Motor 026 Drive Roller Oscillating Motor Positioning Roller Motor 027 Punch Motor Punch Drive Motor 028 Punch Moving Motor Punch Movement Motor 5-155 M124/M125...
Page 404 002 Bridge/Left: Feed Motor: Reset 003 Bridge/Left: Feed Motor: Enable Bridge/Left: Feed Motor: HighSpeed Bridge/Left: Feed Motor: MiddleSpeed Bridge/Left: Feed Motor: LowSpeed 011 Bridge/Left: Junction Solenoid 4bin Mail Box (M413) 6157 Display Description 001 4 bin: Junction Solenoid M124/M125 5-156...
Page 405 Bank2: Feed Motor: LowSpeed/Fan Bank2: Feed Motor: LowIncreaseSpeed/Fan 030 Bank: Tray3: PU Solenoid 031 Bank: Tray4: PU Solenoid 032 Bank: Tray5: PU Solenoid 035 Bank: Tray3: Feed Clutch 036 Bank: Tray4: Feed Clutch 037 Bank: Tray5: Feed Clutch 5-157 M124/M125...
Page 406 Flash ROM on the language controller board (PCL) Flash ROM on the PictBridge PictBridge control PictBridge controller board MediaPrint: Flash ROM on the MediaPrint: MediaPrint control JPEG/TIFF controller board JPEG/TIFF Summary Flash ROM on the Summary fonts Font Font controller board M124/M125 5-158...
Page 407 To select an item on the LCD, touch the appropriate button on the soft touch-screen of the  LCD. Disconnect the Ethernet interface cable, Gigabit Ethernet cable, IEEE1284 interface cable  and remove the Wireless LAN interface board before you start the firmware update procedure. 5-159 M124/M125...
Page 408 The first line is the module number, the second line the version name. Tells you the number of the module and name version on the SD NEW: card. The first line is the module number, the second line the version name. M124/M125 5-160...
Page 409 If firmware update fails, an error code appears. The following example (E36) reports that the program which you wish to update is not in the machine or the data in the machine you wish to update does not correspond to the data in the card. 5-161 M124/M125...
Page 410 When the updating is completed, the Home key is lit off and the Simple Screen key lights. 11. Switch the machine main power switch off and remove the SD card. Then switch the machine M124/M125 5-162...
Page 411 Acquire correct machine update data then install again. SD update data is incorrect. The data on the SD Cannot write module – card is for another machine. Acquire correct Cause other than E34, E35 update data then install again. 5-163 M124/M125...
Page 412 Controller module download SD card and tray again, or replace controller failed board. SD update data is incorrect. The data on the SD Electronic confirmation card is for another machine. Acquire correct check failed update data then install again. M124/M125 5-164...
Page 413 In order to prevent an error during the download, be sure to mark the SD card that holds the uploaded data with the number of the machine from which the data was uploaded. You can upload NVRAM data from more than one machine to the same SD card.  5-165 M124/M125...
Page 414 The serial number of the file on the SD card must match the serial number of the  machine for the NVRAM data to download successfully. The download fails if the serial numbers do not match. This procedure does not download the following data to the NVRAM: Total Count  C/O, P/O Count  M124/M125 5-166...
Page 415 If the capacity of SD card is not enough to store the local user information, an error  message is displayed. Carefully handle the SD card, which contains user information. Do not take it back to  your location. 5-167 M124/M125...
Page 416 The counter in the user code information is initialized after uploading.  The information of an administrator and supervisor cannot be downloaded nor uploaded.  If there is no data of address book information in the SD card, an error message is  displayed. M124/M125 5-168...
Page 417 Press "10 key" to display the number keys. Enter "1", then press "OK". This switches the Save Debug Log feature on. The default setting is “0” (OFF). This feature must be switched on in order for the  debug information to be saved. 5-169 M124/M125...
Page 418 Engine SC Error generated. Saves debug data when a controller-related SC Controller SC Error Code is generated. Saves data only for the SC code that you Any SC Error specify by entering code number. Saves data for jams. M124/M125 5-170...
Page 419 Under “5859” press the necessary key item for the module that you want to record. Enter the appropriate 4-digit number. Then press "OK". Refer to the two tables below for the 4-digit numbers to enter for each key.  The example below shows “Key 1” with “2222” entered. 5-171 M124/M125...
Page 420 Net File Application GW Print Service Printer Design Language GW Print Service – Print GSP-PM Print Server Module Image Memory Handler System Control Service System Resource Memory Control Service Management Web Document Box Network Control Service WebDB (Document Server) M124/M125 5-172...
Page 421 SD card. Use a card reader to copy the file and send it for analysis to your local Ricoh representative by email. You can also send the SD card by regular mail if you want.
Page 422 SD card for the log file, the data only needs to be recorded; a new log file does not require creation. To create a new log file, do SP5857-012 to delete the debug log data from the SD card. Then do SP5857-017. M124/M125 5-174...
Page 423 In addition they will cause the Card Save to fail. 5.14.2 PROCEDURE Turn the main power switch OFF. Insert the SD card into slot 2. Then turn the power ON. Enter SP mode. Select “Service". Select SP-1001 "Bit Switch”. 5-175 M124/M125...
Page 424 "OK” button to register the change. The result should look like: 00010000. By doing this, Card Save option will appear in the “List/Test Print” menu. Press “Exit” to exit SP Mode. Press the “User Tools” button. Select “Printer Features”. M124/M125 5-176...
Page 425 11. Press “OK” and then exit the “User Tools” menu. 12. Press the “Printer” button. 13. Card Save should be displayed in the top left of the display panel. 14. Send a job to the printer. The Communicating light should start blinking as shown below. 5-177 M124/M125...
Page 426 No memory: Insufficient working memory to process the job.  Write error: Failed to write to the card.  Other error: An unknown error occurred.  If an error occurs, pressing “OK” will cause the device to discard the job and return to the ready state. M124/M125 5-178...
Page 427 Detail No. SMC Categories to Save 001 All (Data List) 002 SP (Mode Data List) 003 User Program 004 Logging Data 005 Diagnostic Report 006 Non-Default 007 NIB Summary 024 SDK/J Summary 025 SDK/J Application Info 026 Printer SP 5-179 M124/M125...
Page 428 SMC List Card Save Function Press [EXECUTE]. Press [EXECUTE] again to start. Press [CANCEL] to cancel the saving. “It is executing it” is shown on the screen while executing. 10. Wait for 2 to 3 minutes until “Completed” is shown. M124/M125 5-180...
Page 429 A folder named by the machine serial number will be created on the SD card when this  function is executed. This function can save the SMC list data only to an SD card inserted into the operation  panel SD card slot. 5-181 M124/M125...
Page 430 5.15.4 ERROR MESSAGES SMC List Card Save error message:  Failed: FACTOR: Read-only file system, No space left on device. If an error occurs, pressing “Exit” will cause the device to discard the job and return to the ready state. M124/M125 5-182...
Page 431 TROUBLESHOOTING R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 433 You can reset the machine by turning the Turn the operation switch or operation switch or main main power switch off and on. switch off and on. If the error occurs again, the same SC code is displayed. M124/M125...
Page 434 440 - Around drum 460 - Unit 480 - Others 500 - Paper feed Paper feed / Fusing 515 - Duplex 520 - Paper transport 530 - Fan motor Paper feed / Fusing 540 - Fusing 560 - Others M124/M125...
Page 435 720 - Two-tray finisher 740 - Booklet finisher 800 - Error after ready condition 820 - Diagnostics error Controller 860 - Hard disk 880 - Unique for a specific model 900 - Counter Others 920 - Memory 990 - Others M124/M125...
Page 436 The polygon motor drive pulse is not released correctly.  The XSCRDY signal cannot be monitored.  Turn the main power switch off and then back on.  Replace the laser optics housing unit.  Replace the I/F harness.  Replace the BCU.  M124/M125...
Page 437 Disconnected or defective harness to polygon motor driver board  Defective polygon motor  Defective polygon motor driver board  Turn the main power switch off and on.  Replace the laser optics housing unit.  Replace the I/F harness.  Replace the BCU.  M124/M125...
Page 438 Disconnected or defective I/F harness to laser synchronizing  detection unit. Defective laser synchronizing detection unit.  The laser fails to reach the photo detector.  Defective GAVD  Defective LD board or driver  Defective BCU  M124/M125...
Page 439 The laser fails to reach the photo detector.  Defective GAVD  Defective LD driver  Defective LDB  Defective BCU  Turn the main power switch off and on.  Replace the laser optics housing unit.  Replace the BCU.  M124/M125...
Page 440 MUSIC for end position [K], [C], [M], [Y]. The PFGATE ON signal still asserts when the next job starts.  Defective ASIC  Defective GAVD  Turn the main power switch off and on.  Replace the BCU.  Replace the controller board.  M124/M125...
Page 441 On startup, Read/Write performed for the same register does not match. Defective GAVD  Defective eSOC  Defective BCU  Defective harness  Turn the main power switch off and on.  Replace the laser optics-housing unit.  Replace the BCU.  M124/M125...
Page 442 Check and reinstall the image transfer belt unit and PCDUs.  Check if each toner bottle has enough toner.  Replace the TD sensor.  Replace the image transfer belt unit.  Replace the PCDU(s).  Replace the laser optics housing unit.  M124/M125 6-10...
Page 443 Disconnected or broken PCU  Defective HVPS (C/B)  Loose connection  Broken harness  Reinstall or replace the harnesses of the HVPS.  Reinstall or replace the PCU.  Replace the HVPS (C/B).  Reconnect the connector.  6-11 M124/M125...
Page 444 (default: 5.0V) with SP3-020-001. A TD sensor-related part is faulty.  A TD sensor-related part's connection is loose.  Toner density error  Turn the main power switch off and then back on.  Replace the AIT (development unit).  M124/M125 6-12...
Page 445 The ID/TD sensor's optical path is dirty.  ID/TD sensor detection surface dirty  Replace the ID/TD sensor.  Replace the IOB.  Check the connection.  Clean the sensor parts.  Replace/repair the image transfer unit.  6-13 M124/M125...
Page 446  Shorted 24 V fuse on the PSU  Defective interlock system  Replace the motor.  Reconnect the connector.  Replace the harness.  Shorted 24 V fuse on the PSU.  Repair the interlock system.  M124/M125 6-14...
Page 447 Shorted 24 V fuse on the PSU  Defective interlock system  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Shorted 24 V fuse on the PSU.  Replace the interlock switch.  Replace the IOB.  6-15 M124/M125...
Page 448 Shorted 24 V fuse on the PSU  Defective interlock system  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Shorted 24 V fuse on the PSU.  Repair the interlock system.  Replace the IOB.  M124/M125 6-16...
Page 449 100 ms. If the High status occurs 20 times consecutively, the machine judges that the motor is not rotating correctly. Defective motor  Loose connection  Broken harness  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  6-17 M124/M125...
Page 450 Defective high voltage supply unit  Turn the main power switch off and on.  Reattach/replace the harness and parts on the high voltage power  supply route. Replace/reinstall the high-voltage supply unit.  Replace the high voltage supply unit.  M124/M125 6-18...
Page 451 * However, if the power is switched off and then back on, the machine resumes its attempt to use the sensor. Loose connection/Disconnected connector  Defective sensor  Clean/Replace the sensor.  Reconnect the connector.  Check the harness.  6-19 M124/M125...
Page 452 * If the thermal sensor or humidity sensor remains capable of normal operation even after the SC is issued, the capable sensor will keep operating. Loose connection/harness disconnected  Defective sensor  Clean/replace the sensor.  Reconnect to the connector.  Check the harness.  M124/M125 6-20...
Page 453 Too much paper in the tray  Paper or other material is jammed in the parts between the tray  and motor. Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  6-21 M124/M125...
Page 454 Defective end fence home position sensor or connector  disconnection Defective tray lift motor or connector disconnection  Defective upper limit sensor or connector disconnection  Pickup SOL error/disconnection  Right tray sensor error/disconnection  Turn the main power switch off and on. M124/M125 6-22...
Page 455 A registration error is detected 50 times consecutively at intervals of 10 Motor overload  Defective motor  Loose connection  Broken harness  Defective IOB  Defective encoder  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  6-23 M124/M125...
Page 456 Motor overload  Defective motor  Loose connection  Disconnected harness  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  M124/M125 6-24...
Page 457 Motor overload  Defective motor  Loose connection  Broken harness  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  6-25 M124/M125...
Page 458 Motor overload  Defective motor  Loose connection  Broken harness  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  M124/M125 6-26...
Page 459 If the retrieval of the lock signal fails 100 times consecutively, it is determined as a failure to rotate properly. Defective motor  Loose connection  Disconnected harness  Defective IOB  Replace the motor.  Reconnect the connector.  Replace the harness.  Replace the IOB.  6-27 M124/M125...
Page 460  Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Fusing sleeve belt thermopile error The temperature detected by the fusing sleeve belt thermopile does not reach -50°C for 0.1 seconds. Defective thermopile  Defective thermistor  Loose connection  M124/M125 6-28...
Page 461 Details (Symptom, Possible Cause, Troubleshooting Procedures) Fusing sleeve belt overheat: Center (software error) The detected fusing temperature stays at 240°C for 1 second for 10 consecutive times. The triac switch has shorted out.  Defective IOB.  Defective BCU.  6-29 M124/M125...
Page 462 Details (Symptom, Possible Cause, Troubleshooting Procedures) Fusing Heater error: Center The fusing heater keeps full power for 9 seconds or more. Defective thermistors  Broken heater cables  This is determined after the device for preventing excessive  temperature rise operates. M124/M125 6-30...
Page 463 Fusing sleeve belt thermistor error The temperature at the end of the fusing sleeve belt measured by the fusing sleeve belt thermistor does not reach -50°C for 0.1 seconds. Defective thermopile  Defective thermistor  Loose connection  6-31 M124/M125...
Page 464 Fusing sleeve belt overheat: End (software error) The detected fusing sleeve belt temperature stays at 240°C or more for 1 second for 10 consecutive times. The triac switch has shorted out.  Defective IOB  Defective BCU  M124/M125 6-32...
Page 465 After replacing fusing unit, to set SP5-810-2 is necessary to reset  this SC. Type Details (Symptom, Possible Cause, Troubleshooting Procedures) Fusing Heater error: End The fusing heater keeps full power for 9 seconds or more. Defective thermistors  Broken heater cables  6-33 M124/M125...
Page 466 Details (Symptom, Possible Cause, Troubleshooting Procedures) Pressure roller thermistor error: End The temperature at the end of the pressure roller measured by the thermistor does not reach 0°C for 20 seconds. Defective thermopile  Defective thermistor  Loose connection  M124/M125 6-34...
Page 467 Details (Symptom, Possible Cause, Troubleshooting Procedures) Pressure roller overheat: End (software error) The detected pressure roller temperature stays at 230°C or more for 1 second for 10 consecutive times. The triac has shorted out.  Defective IOB  Defective BCU  6-35 M124/M125...
Page 468 Pressure roller contact sensor does not detect the pressure roller position three times. Broken or defective pressure roller contact motor  Deformed or broken pressure roller contact sensor feeler  Defective fusing unit  Turn the main power switch off and on. M124/M125 6-36...
Page 469 Details (Symptom, Possible Cause, Troubleshooting Procedures) Pressure roller thermistor warm-up error: Center The center temperature of the pressure roller measured by the thermistor does not reach 41°C within 8 seconds after the heater turns Dirty thermopile lenses  Deformed thermistor  6-37 M124/M125...
Page 470 After this SC occurs, the counter reset of the fusing unit should be  done manually using SP3-902-014 because the counter reset is not done automatically. After replacing fusing unit, to set SP5-810-2 is necessary to reset  this SC. M124/M125 6-38...
Page 471 Defective thermistor  Loose connection  Type Details (Symptom, Possible Cause, Troubleshooting Procedures) NC sensor broken: End The sensor detects -17°C or less for 6 seconds. Broken cables of thermopile  Broken cables of thermistor  Loose connection  6-39 M124/M125...
Page 472 2nd Paper Bank communication error An error code is issued from the paper bank unit. Loose connection  Defective paper bank  Reconnect the connector.  Replace the paper bank.  Turn the main power switch off and on.  M124/M125 6-40...
Page 473 Create the usercode files with the User Setting Tool "IDissuer.exe" and store the files in the root folder of the SD card. Note: Make sure the eccm.mod file is in the root folder of the SD card. 6-41 M124/M125...
Page 474 Dial up fails due to an incorrect modem setting. SP5-816-160: Check if the AT command is appropriate, when the SP above is appropriate, it is caused by a software bug. Communication error of the remote service modem (3) M124/M125 6-42...
Page 475 SCs. The modem board is installed even though the setting at @Remote or the wired/wireless LAN is not working normally. Uninstall the modem board if it is installed.  Check that the wired/wireless LAN is working properly.  6-43 M124/M125...
Page 476 The character string is not 17 characters long.  Unprintable characters are included.  It contains spaces only.  It is blank.  Replace the NVRAM  Clear the current @Remote setting, write the common certificate,  and then retry the installation. M124/M125 6-44...
Page 477 Device detection error: Channel error Device detection error: Device error Device detection error: Communication failed error Device detection error: Timeout error Device detection error: Communication suspended error Device detection error: Buffer full error Device detection error: No error code 6-45 M124/M125...
Page 478 The engine board fails to start up.  The engine board was reset at an inappropriate time.  Check the connection/contact between the engine board and  controller board. Replace the engine board.  Replace the controller board or the relay board.  M124/M125 6-46...
Page 479 Device ID is not identified: C Device ID is not identified: Y Channel error: K Channel error: M Channel error: C Channel error: Y Device error: K Device error: M Device error: C Device error: Y Communication interruption (an error during communication): K 6-47 M124/M125...
Page 480 No memory chip on the toner cartridge 16-9, 21-24, 26-39  Caused by noise 31-34, 36-39  Software problem Replace the toner bottle detection board.  Replace the toner cartridge.  Turn the main power switch off and on.  M124/M125 6-48...
Page 481 The requested buffer is full: Y No error code: K No error code: M No error code: C No error code: Y Retry of memory chip communication fails three times after the machine has detected the memory chip communication error. 6-49 M124/M125...
Page 482 (for each command) cannot be received. The image data cannot be prepared at the controller due to a  problem. Communication error  An error has occurred inside the controller.  Turn the main power switch off and on. M124/M125 6-50...
Page 483 The 1st failure issues an original jam message, and the 2nd failure issues this SC code. Jogger HP sensor disconnected, defective  Jogger motor disconnected, defective  Jogger motor overloaded due to obstruction  Finisher main board and jogger motor  Turn the main power switch off and on. 6-51 M124/M125...
Page 484 The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Defective stapler rotation motor  Loose connection of the finisher corner stapler rotation motor  Overload to the stapler rotation motor  Turn the main power switch off and on. M124/M125 6-52...
Page 485 The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Motor harness disconnected, loose, defective  Motor overload  Defective motor  Turn the main power switch off and on. 6-53 M124/M125...
Page 486 Staple jam  Defective motor  Loose connection  An overload has occurred due to staples applied to sheets  exceeding the maximum number. Defective home position sensor  Turn the main power switch off and on. M124/M125 6-54...
Page 487 The upper tray paper height sensor does not change its status with the specified time after the tray raises or lowers. Defective motor  Loose connection  Motor overload  Defective upper tray paper height sensor  Turn the main power switch off and on. 6-55 M124/M125...
Page 488 The 1st detection failure causes a jam error, and the 2nd failure causes this SC code. Exit jogger motor sensor disconnected, defective  Exit jogger motor is disconnected, defective  Exit jogger motor overloaded due to obstruction  Turn the main power switch off and on. M124/M125 6-56...
Page 489 The 1st detection failure issues a jam error, and the 2nd failure issues this SC code. Defective motor  Motor harness disconnected, loose, defective  Motor overloaded  Turn the main power switch off and on. 6-57 M124/M125...
Page 490 Bridge unit error The machine recognizes the finisher, but does not recognize the bridge unit. The bridge unit is not installed.  Defective bridge unit  Re-install the bridge unit.  Turn the main power switch off and on.  M124/M125 6-58...
Page 491 The finisher's connection is faulty.  The finisher is not attached to a device equipped with the bridge  unit. Defective finisher  Reconnect the finisher or bridge unit, and then turn the main power switch off and then back on. 6-59 M124/M125...
Page 492 Read () error write () error Communication error in writing retry Communication error in writing retry Communication error in writing retry Communication error in reading retry Communication error in reading retry Read () error Sub-system error Sub-system error Sub-system error M124/M125 6-60...
Page 493 Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error Sub-system error 6-61 M124/M125...
Page 494 OS Flash ROM, or the items on the SD card in the controller slot are false or corrupted. OS Flash ROM data defective  SD card data defective  Change the controller firmware.  Use another SD card.  M124/M125 6-62...
Page 495 The Bluetooth interface unit was installed while the machine was turned on. Turn off the main power switch, and then confirm that the Bluetooth interface unit was installed correctly. And then, turn on the main power switch again. 6-63 M124/M125...
Page 496 Details (Symptom, Possible Cause, Troubleshooting Procedures) USB IF error USB I/F cannot be used due to a driver problem. An error has occurred to the USB driver.  Make sure that the USB connection is good.  Replace the controller board.  M124/M125 6-64...
Page 497 A recoverable error has occurred before starting data conversion. Defective NVRAM Turn the main switch off and on.  If the error reoccurs, replace the controller board.  A serious error occurs while the data is encrypted. Same as SC991 Same as SC991 6-65 M124/M125...
Page 498 HDD startup error at main power on HDD is connected but a driver error is detected. The driver does not respond with the HDD within 30 seconds. HDD not initialized  Label data is corrupted  Defective HDD  Initialize the HDD with SP5-832-001. M124/M125 6-66...
Page 499 Turn the main switch off and on.  Replace the HDD.  Type Details (Symptom, Possible Cause, Troubleshooting Procedures) SD card authentication error A correct license is not found in the SD card. SD-card data is corrupted. Store correct data in the SD card. 6-67 M124/M125...
Page 500 Device setting: The hard disk is installed, but the area for storing the address book cannot be used. Device setting: Inconsistencies have occurred in the NVRAM area where settings required for forming the address book are stored. M124/M125 6-68...
Page 501 Encryption setting: While changing the encryption settings, an attempt to move a file has failed. Encryption setting: While changing the encryption settings, an attempt to delete a directory has failed. Encryption setting: While changing the encryption settings, lack of resources has been detected. 6-69 M124/M125...
Page 502 A hard disk error is detected while switching the device on Defective HDD  The device was switched off while the hard disk was being  accessed. Perform SP5832-007 to format the hard disk.  Replace the HDD.  M124/M125 6-70...
Page 503 The log data is not encrypted, even though the log encryption  setting is set to active. Initialize the HDD with SP5-832-004. Log Data Error 5 An error was detected in the handling of the log data at power on or during the machine operation. 6-71 M124/M125...
Page 504 Incorrect operating of the USB flash.  Replace the board. USB Flash error An error has occurred in the file system in the USB flash drive. The file system of the USB flash drive is damaged. Replace the controller board. TPM error M124/M125 6-72...
Page 505 Authentication area error This detects a problem with the software. This is issued due to the accumulation of abnormal authentication  data in the software. This is issued during authentication.  Turn the main power switch off and on. 6-73 M124/M125...
Page 506 An error is detected in the printer application program and operation cannot continue. Defective software  Unexpected hardware resource (e.g., memory shortage)  Turn the main power switch off and on.  Add memory.  Cannot start-up the filtering process M124/M125 6-74...
Page 507 Turn the main power switch off and on.  Initialize the NetFile partition on the HDD (SP5-832-002).  Initialize all partition on the HDD (SP5-832-001).  Replace the HDD.  Here is a list of HDD status codes: 6-75 M124/M125...
Page 508 Go into the User Tools mode and do "Delivery Settings" to print all received fax documents that are scheduled for delivery. Then erase them. In the User Tools mode, do Document Management> Batch Delete Transfer Documents. Do SP5832-011, then turn the machine power off and on. M124/M125 6-76...
Page 509 Details (Symptom, Possible Cause, Troubleshooting Procedures) Undefined error If an SC not managed by the system is issued In cases such as using a tool for the previous model  Software problem  Turn the main power switch off and on. 6-77 M124/M125...
Page 510 The application selected by the operation panel key works abnormally (No response, abnormal ending). Defective software Check the devices (e.g., RAM, DIMM and board) necessary for  the application programs. Check that downloaded application programs are correctly  configured. M124/M125 6-78...
Page 511  Printer driver settings used when the problem occurs  All data displayed on the screen (SC code, error code, and program address where the  problem is logged.) Image file which causes the problem, if possible  6-79 M124/M125...
Page 512 Defective TD sensor target ±0.2V. Make sure that the heat seal on the development unit is not removed Vcnt is less than Vcnt error 3 Defective TD sensor 4.7V. Vt target settings are not correct. Toner density error M124/M125 6-80...
Page 513 Replace the IOB board. coefficient Not enough data can Solid image is O.K.  (K5) detection be sampled. Replace the ID sensors. error Replace the IOB board. ID sensor is dirty:  Clean the ID sensors. Retry the process control. 6-81 M124/M125...
Page 514 ID sensor pattern density is too high  error during be sampled during or low. gamma the gamma Hardware defective  correction correction. Same as 53 Unexpected Power Failure  Process control fails. error Check the power source. M124/M125 6-82...
Page 515 Poor connection  is more than Defective IOB  Adjustment "Voffset Replace the ID sensor. error Threshold" Check the connection. (SP3-324-004) Replace the IOB board. Vsg adjustment Other cases  Adjustment has not been Retry SP3-321-010. error completed. 6-83 M124/M125...
Page 516 ID sensors have correctly detected the patterns adjustment for line position adjustment, but a shift of See Note range patterns is out of adjustable range. Not used For details, see the "Troubleshooting Guide - Line Position Adjustment" section.  M124/M125 6-84...
Page 517 Troubleshooting Guide 6.4 TROUBLESHOOTING GUIDE 6.4.1 IMAGE QUALITY The following work-flow shows the basic troubleshooting steps for the image quality problems on this product. 6-85 M124/M125...
Page 518 Troubleshooting Guide M124/M125 6-86...
Page 519 Low density of test pattern  Defective BB  White image, Abnormal image, Replace the shutter motor. Low density Replace the high voltage power supply unit. Do the forced process control (SP3-011-001) or supply some toner (SP3-015-xxx). Replace the BB. 6-87 M124/M125...
Page 520 Defective laser optics housing unit  The skew for Y, M, C is more Defective BB  than ±0.75 mm from the main Reinstall or replace the PCDU. scan registration of K Replace the laser optics housing unit. Replace the BB. M124/M125 6-88...
Page 521 Defective ID sensor  Defective BB  Replace the ID sensor shutter solenoid. Replace the ID sensor. Replace the BB. After Executing SP2-111-001 Result: "1" in SP2-194-007  Result: "5" (Out of adjustable range) in SP2-194-010, -011, -012  6-89 M124/M125...
Page 522 Reinstall or replace the PCDU. Replace the laser optics housing unit. Replace the BB. Others Skew correction upper limit error  Defective BB  Defective laser optics housing unit  Replace the BB. Replace the laser optics housing unit. After Executing SP2-111-001 M124/M125 6-90...
Page 523 Defective laser optics housing unit  M, C are shifted. Defective ID sensor  Defective BB  Incorrect SP value  Replace the laser optics housing unit. Replace the ID sensor. Replace the BB. Adjust the value with SP2-182-004 to -021. 6-91 M124/M125...
Page 524 If a stain appears at the edge of the output, do the following procedure. Execute the fusing cleaning mode with SP1123-002. It takes 160 seconds to complete the fusing cleaning mode.  Make a sample copy, and then check if a stain appears on the output. M124/M125 6-92...
Page 525 Check the machine referring to the flow chart for the toner end recovery error. After a new toner bottle has been installed in the machine  When a displayed color toner bottle still has toner inside  6-93 M124/M125...
Page 526 Troubleshooting Guide Flow Chart for the Toner End Recovery Error M124/M125 6-94...
Page 527 Replace the toner bottle detection board ( p.4-142).  When replacing the toner bottle detection board, be sure not to deform the toner bottle  detection terminals. This error does not occur if the toner bottles are replaced correctly. 6-95 M124/M125...
Page 528 Return the setting of the SP which you have changed in step 2 before.  Execute SP3-015-xxx (Forced Toner Supply: Execute) twice. Chose a target color SP number from -003 (Bk), -004 (Magenta), -005 (Cyan) and -006  (Yellow). M124/M125 6-96...
Page 529 Set the setting of SP3-516-025 (Refresh Mode; Job End Area Coefficient) to "0.5".  6.4.8 FAULTY CLEANING Black or color lines (2-3mm) Possible Cause: Wear of the cleaning blade at a specific point by image creation in the same place many times. Solution: Replace the drum unit. 6-97 M124/M125...
Page 530 Using a PC, create a folder in the SD card and name it "restore_key". Create a folder in the “restore_key” folder and name it the same as machine’s serial number, “xxxxxxxxxxx” (11 digits). Create a text file called "key_xxxxxxxxxxx.txt" and save it in the "xxxxxxxxxxx“ folder. Write M124/M125 6-98...
Page 531 It is judged that a forced start has been selected when the content of "nvclear" is  executed and the machine shifts to the alternate system (forced start). Confirm that a message is displayed on the LCD telling to insert the SD card that contains the encryption key. 6-99 M124/M125...
Page 532 Test the machine using the flow chart below, to determine which parts are causing the problem. Countermeasure list for the error The following table shows what to do in each case: For example, if only the controller and HDD were found to be defective, then it is No 4 in the table below. M124/M125 6-100...
Page 533 HDD is automatically formatted. Replace CTL, then restore the old encryption key, then replace SD card. Replace CTL, then restore the old encryption key. Replace HDD / SD card / NVRAM. Replace HDD / SD card / NVRAM. 6-101 M124/M125...
Page 534 Replace SD card / NVRAM. Replace SD card. (legends) - : Not defective parts R: Defective parts, must replace (R): Not defective parts but must be replaced *1: Data Overwrite Security (ON/OFF) does not affect the combination table. M124/M125 6-102...
Page 535 Paper is not fed from the by-pass tray. (Bypath) Registration Sn:On 7504 9 Paper is jammed at the duplex unit. (Duplex) 7504 10 Vertical transport sensor 1 does not 7504 11 Vertical Trans. 1: On detect paper from tray 1. 6-103 M124/M125...
Page 536 7504 26 (In) paper. Duplex entrance sensor does not detect Duplex Entrance: ON 7504 27 paper again after paper has passed this (Out) sensor. 7504 28 Vertical transport sensor 1 does not turn 7504 51 Vertical Trans. 1:Off off. M124/M125 6-104...
Page 537 R1-R4 EUP (D637/D636) sensor. Finisher Shift Tray Paper does not reach the upper tray 7504 193 Exit: EUP exit sensor or stays at the upper tray R1-R4 (D637/D636) exit sensor. 6-105 M124/M125...
Page 538 Jogger fence HP sensor does not turn on/off after the jogger motor has turned Finisher Jogger 7504 200 Motor: EUP R8-R12 Stack feed out belt HP sensor does not D637/D636) turn on/off after the feed out belt motor has turned on. M124/M125 6-106...
Page 539 Fold bottom fence HP sensor does not turn on/off after the fold unit bottom fence lift motor has turned on. Stack junction gate HP sensor does not turn on/off after the stack junction gate motor has turned on. 7504 205 6-107 M124/M125...
Page 540 The finisher does not respond even 7504 230 Fin Exit R1-R3 after the sheet delivery has completed. The finisher does not accept sheets due 7504 231 Insufficient Data to an error concerning the data/commands from the machine. M124/M125 6-108...
Page 541 Paper Size Code Size Code Paper Size Size Code Paper Size A4 LEF B4 SEF A5 LEF B5 SEF B5 LEF DLT SEF LT LEF LG SEF HLT LEF LT SEF A3 SEF HLT SEF A4 SEF Others A5 SEF 6-109 M124/M125...
Page 542 Jam Detection Sensor Locations M124/M125 6-110...
Page 543 Drum Gear Position Open/ CN222/ A5 SC390-02/SC396-02 Sensor-C Shorted Drum Gear Position Open/ CN222/ A8 SC390-03/SC396-03 Sensor-M Shorted Drum Gear Position Open/ CN222/ A11 SC390-04/SC396-04 Sensor-Y Shorted Toner End Sensor - CN207/B14 Toner end cannot be Open CN207/B3 detected. 6-111 M124/M125...
Page 544 Tray 2 Paper Feed Open/ CN230/B4 Jam A, B Sensor Shorted Tray 1 is not detected Open when tray 1 is set. Tray 1 Set Switch CN224/A9 Tray 1 is detected Shorted when tray 1 is not set. M124/M125 6-112...
Page 545 CN204/12 Shorted Jam C (Jam 1) Waste toner near full Open indicated when it is not near full. Waste Toner Sensor CN224/A5 Waste toner near full cannot be detected Shorted when the waste toner bottle is nearly full. 6-113 M124/M125...
Page 546 Junction Paper Jam Open/ CN204/6 Jam C (Jam 24/64) Sensor Shorted NC Sensor Center, Open/ CN212/14,9 SC581, SC591 Edge Shorted Paper overflow message is not Paper Overflow CN204/15 Open displayed when the Sensor paper overflow condition still remains. M124/M125 6-114...
Page 547 24VS power to the IOB is not supplied. 8A/250V 8A/250V 24V power to the IOB and BB are not supplied. FU10 8A/250V 8A/250V Not used. 24V power to the PFU or LCT and finisher are FU11 8A/250V 8A/250V not supplied. 6-115 M124/M125...
Page 548 FU2*1 1A/250V 1A/250V No Voltage detection For continued protection against risk of fire, replace only with same type and rating of  fuse. *1 Replace the whole board or unit if this fuse blows, because it is soldered. M124/M125 6-116...
Page 549 ENERGY SAVING R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 551 Saver timer, the machine goes immediately to Off mode when the Auto Off timer expires. It skips the Energy Saver mode. Example Low power: 15 min.  Auto Off: 1 min.  The machine goes to Off mode after 1 minute. Low Power mode is not used.  M124/M125...
Page 552 240 minutes has expired after the last job. This means that after the customer has finished using the machine for the day, energy will be consumed that could otherwise be saved. If you change the settings, the energy consumed can be measured using SP8941, as  explained below. M124/M125...
Page 553 At the end of the measurement period, read the values of SP8941 001 to 005 again.  Find the amount of time spent in each mode (subtract the earlier measurement from the later  measurement). Multiply this by the power consumption spec for each mode.  Convert the result to kWh (kilowatt hours)  M124/M125...
Page 554 Duplexing and the combine functions reduce the amount of paper used. This means that less energy overall is used for paper production, which improves the environment. 1. Duplex: Reduce paper volume in half! 2. Combine mode: Reduce paper volume in half! M124/M125...
Page 555 A = ((2) + (3) + (4))/2 + (5) + (6) x 3/2 Number of printed original images: B  = Total counter6 + Number of pages in Single-sided with combine mode + Number of pages in Duplex with combine mode B = (1) + (5) + (6) M124/M125...
Page 556 (3) Double-sided with duplex mode: SP 8421 002 (pages)  (4) Book with duplex mode: SP 8421 003 (pages)  (5) Single-sided with combine mode: SP 8421 004 (pages)  (6) Duplex with combine mode: SP 8421 005 (pages)   M124/M125...
Page 557 M124/M125 SERVICE MANUAL APPENDICES...
Page 559 M124/M125 APPENDICES TABLE OF CONTENTS 1. APPENDIX: GENERAL SPECIFICATIONS ......... 1-1 1.1 GENERAL SPECIFICATIONS ..............1-1 1.1.1 MAIN FRAME ................... 1-1 1.1.2 PRINTER ..................1-3 1.2 SUPPORTED PAPER SIZES ..............1-5 1.2.1 PAPER FEED ................... 1-5 North America ..................1-5 Europe/ Asia ..................
Page 560 3.10.1 SP8-XXX (DATA LOG2) ............3-278 3.11 INPUT AND OUTPUT CHECK ............3-300 3.11.1 INPUT CHECK TABLE ............3-300 Copier....................3-300 Table 1: Paper Height Sensor ............3-302 Table 2: Paper Size Switch (Tray 2) ..........3-302 M124/M125 SM Appendix...
Page 561 Bridge Unit (D386)/ Side Tray (D542) ..........3-317 Shift Tray (D388) ................3-317 1 Bin Tray (D536) ................3-317 - ......................3-317 Two-Tray Paper Feed Unit (D537)/ LCT 2000 (D538)/ LCT 1200 (D539)3-317 3.12 TEST PATTERN PRINTING ............3-319 SM Appendix M124/M125...
Page 563 APPENDIX: SPECIFICATIONS R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 565 (Refer to "Supported Paper Sizes".) Minimum Maximum Tray 1 A4 (LEF) / LT (LEF) Print Paper Size: A3 / DLT / Tray 2 A5 (LEF) 11" x 17" By-pass 90 x 148 mm 305 x 1260 mm SM Appendix M124/M125...
Page 566 Printer: 670 x 684 x 640 mm (26.4" x 26.9" x 25.2") or less Printer + PFU or LCT* : 670 x 766 x 902 mm (26.4" x 30.2" x 35.5") or less (*1) with the two tray paper feed unit with the stabilizers M124/M125 SM Appendix...
Page 567 Fast (1 bit), Standard (2 bits), Fine (4 bits) 1200 x 1200 dpi (1 bit)  P3c: 45 ppm (color / black and white, A4/LT LEF) Printing speed: P3d: 55 ppm (color / black and white, A4/LT LEF) SM Appendix M124/M125...
Page 568  Ethernet (100 Base-TX/10 Base-T)  SD and USB2.0 Type A (Operation panel)  Host Interfaces: Optional: Gigabit Ethernet (1000 Base-T)  IEEE1284 parallel x 1  IEEE802.11a/b/g (Wireless LAN)  Network Protocols: TCP/IP (IPv4, IPv6), IPX/SPX(Optional) M124/M125 SM Appendix...
Page 569 Legal SEF 8.5" x 14" Government 8.25" x 14" Legal SEF Half Letter 5.5" x 8.5" Executive 7.25" x 10.5" Executive 10.5" x 7.25" F SEF 8" x 13" Foolscap 8.5" x 13" Folio SEF 8.25" x 13" SM Appendix M124/M125...
Page 570 12" x 18" A3 SEF 297 x 420mm A4 SEF 210 x 297mm A4 LEF 297 x 210mm A5 SEF 148 x 210mm A5 LEF 210 x 148mm A6 SEF 105 x 148mm B4 SEF 257 x 364mm M124/M125 SM Appendix...
Page 571 267 x 195mm Custom Com10 Env. 4.125" x 9.5" Monarch 3.875" x 7.5" Env. C6 Env. 114 x 162mm C5 Env. 162 x 229mm DL Env. 110 x 220mm Remarks: Supported: the sensor detects the paper size. SM Appendix M124/M125...
Page 572 A6 SEF 148 mm 257 x B4 SEF 364 mm 182 x B5 SEF 257 mm 257 x B5 LEF 182 mm 128 x B6 SEF 182 mm Ledger 11" x 17" 8.5" x Letter SEF 11" M124/M125 SM Appendix...
Page 573 390 mm 195 x 16K SEF 267 mm 267 x 16K LEF 195 mm Custom 4.125" x Com10 Env. 9.5" Monarch 3.875" x Env. 7.5" 114 x C6 Env. 162 mm 162 x C5 Env. 229 mm SM Appendix M124/M125...
Page 574 Longer paper (feed length) than DLT (432 mm) is not guaranteed in this mode.  *3: Minimum 100 mm for 2P, 230 mm for 3P, 255 mm for 4P, 125 mm for N4P *4: Corner stapling is not available in this mode. M124/M125 1-10 SM Appendix...
Page 575 Smart Device Monitor for Admin A printer management utility for network (XP / Vista / 7 / Server 2003 / administrators. NIB setup utilities are also available. 2003R2 / 2008 / 2008R2) This is provided on the CD-ROM SM Appendix 1-11 M124/M125...
Page 576 Printer Utility for Mac TCP This software provides several convenient (Mac) functions for printing from Macintosh clients. This is provided on the scanner drivers CD-ROM Remote Communication Gate S Used to control devices connected to the same network. M124/M125 1-12 SM Appendix...
Page 577 Tray Capacity: 2,000 sheets (80 g/m , 20lb.) 5 steps (100%, 70%, 30%, 10%, Empty): Right Tray Remaining Paper Detection: 4 steps (100%, 70%, 30%, Empty): Left Tray Power Source: DC 24 V, 5 V (from copier/printer) SM Appendix 1-13 M124/M125...
Page 578 Paper Size 5.5" x 8.5"-11" x 17" SEF, 12" x 18" SEF Paper Weight 52 g/m – 256 g/m (14 lb. - 68 lb.) Shift Tray Stack Capacity 3,000 sheets A4 LEF, 8.5" x 11" LEF M124/M125 1-14 SM Appendix...
Page 579 2 - 30 pages 50 set (mixed sizes) LEF & 11" x 17" SEF 1.4.6 2000-SHEET BOOKLET FINISHER (D637) Finisher Dimension W x D x H 657 mm x 613 mm x 960 mm (25.9 x 24.1 x 37.8") SM Appendix 1-15 M124/M125...
Page 580 A4 SEF, A3 SEF, B5 SEF, B4 SEF Booklet Stapling 15 sheets 8.5" x 11" SEF, 8.5" x 14" SEF, 11" x 17" SEF, 12" x 18" SEF 5,000 staples per Staple Replenishment Corner staple cartridge M124/M125 1-16 SM Appendix...
Page 581 A5 to A3, 5.5" x 8.5" to 11" x 17" Sizes EU 2-holes A5 to A4, 5.5" x 8.5", 8.5" x 11" A3, B4, 11"x17" EU 4-holes A4, B5, 8.5" x 11" Scandinavia A5 to A3, 5.5" x 8.5" to 11" x 17" SM Appendix 1-17 M124/M125...
Page 582 Size (W x D x H): 1.4.10 OUTPUT JOGGER UNIT (B703) Paper Size: Paper Weight: Tray Capacity: 250 sheets (80 g/m , 20 lb., A4 / LT) Power Source: Power Consumption: Weight: Size (W x D x H): M124/M125 1-18 SM Appendix...
Page 583 Optional Equipment SM Appendix 1-19 M124/M125...
Page 585 APPENDIX: PM TABLES R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 587 Filter, Ozone Filter) Toner Collection Bottle Service Maintenance Item 150K 300K Remarks PCDU (Bk) PCDU (C, M, Y) Replace when the Toner Collection Bottle waste toner bottle full message appears. Image Transfer Belt-cleaning Unit Image Transfer Belt SM Appendix M124/M125...
Page 588 Damp cloth Duplex Entrance Blower brush or dry Sensor cloth Blower brush or dry Duplex Exit Sensor cloth Duplex Exit Roller Damp cloth Ozone Filter (Charge Unit) Ozone Filter (AC Controller) Exhaust Filter (AC Controller) Dust Glass M124/M125 SM Appendix...
Page 589 Damp cloth 2000-sheet LCT (D581) Item Remarks Feed Roller Dry cloth Separation Roller Dry cloth Pick-up Roller Dry cloth Paper Feed Sensor Dry cloth Relay Sensor Dry cloth Relay Roller Damp cloth Bottom Plate Pad Damp cloth SM Appendix M124/M125...
Page 590 2000/3000-Sheet (Booklet) Finisher Punch Unit (D570) Items Remarks Punch Chads Discard chads. Bridge Unit (D634) Items Remarks Rollers Damp cloth Shift Tray (D633) Items Remarks Tray Damp cloth Side tray (D635) Items Remarks Rollers Damp cloth Sensors Blower brush Mail Box (M413) M124/M125 SM Appendix...
Page 591 PM parts but as yield parts (EM parts). Mainframe Item 300K 1500K 2000K Remarks Tonner Suplpy Unit - K Tonner Suplpy Unit - Y Tonner Suplpy Unit - C Tonner Suplpy Unit - M Toner Scatter proof Filter SM Appendix M124/M125...
Page 593 APPENDIX: SERVICE PROGRAM MODE TABLES R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New 01/14/2013 Entering SP Modes Added 12/21/2012 Changed SP101-005 Bit4 from 1000 to 750. 12/21/2012 Changed SP5045-001 settings to 0 –...
Page 595 "Card Save Function" in the "Main chapters: 5. System Maintenance". bit 5 bit 6 bit 7 Enable [RPCS,PCL]: Printable area frame border Disable Enable: The machine prints all RPCS and PCL jobs with a border on the edges of the printable area. SM Appendix M124/M125...
Page 596 Enable: Uses the same left margin as older HP models such as HP4000/HP8000. In other words, the left margin defined in the job (usually "<ESC>*r0A") will be changed to "<ESC>*r1A" bit 3 bit 4 bit 5 bit 6 bit 7 M124/M125 SM Appendix...
Page 597 Using this BitSw, the device can be configured to print all copies even if a paper mismatch occurs. bit 2 Prevent SDK applications from altering Disable Enable the contents of a job. SM Appendix M124/M125...
Page 598 Disable: Simplex pages or the last page of an odd-paged duplex job, are not routed through the duplex unit. This could result in problems with letterhead/pre-printed pages. Only affects pages specified as Letterhead paper. 1001 [Bit Switch] 006 Bit Switch 6 DFU M124/M125 SM Appendix...
Page 599 Color jobs will not be printed without a valid user code. bit 4 Enable Disable PCL edge to edge printing setting (Standard) (BMS) Switches the edge to edge printing setting for custom-made machines (BMS). bit 5 bit 6 Disable Enable bit 7 Disable Enable SM Appendix M124/M125...
Page 600 UTF-8 characters cannot be displayed in the operation panel. For example, job names are sometimes stored in the MIB using UTF-8 encoded characters. When these are displayed on the operation panel, they will be garbled unless this switch is enabled (=0). M124/M125 SM Appendix...
Page 601 ECD If this is 0, Auto Job Promotion will be automatically disabled if an external charge device is connected. Note: We do not officially support enabling this switch (1). Use it at your own risk. bit 7 SM Appendix M124/M125...
Page 602 5 bit 6 bit 7 1003 [Clear Setting] [- / - / -] Initialize System *CTL [Execute] Initializes settings in the "System" menu of the user mode. [- / - / -] 003 Delete Program *CTL [Execute] M124/M125 SM Appendix...
Page 603 Recalls a set of gamma settings. This can be either a) the factory setting, b) 1101 the previous setting, or c) the current setting. 001 Factory *CTL 002 Previous *CTL [ - / - / - ] 003 Current *CTL [Execute] 004 ACC *CTL SM Appendix M124/M125...
Page 604 007 Black 008 Black 009 Black 010 Black [0 to 30 / 15 / 1/step ] 011 Black 012 Black 013 Black 014 Black [0 to 30 / 15 / 1/step ] 015 Black 016 Black M124/M125 3-10 SM Appendix...
Page 605 055 Magenta 056 Magenta 061 Yellow: Highlight 062 Yellow: Shadow [0 to 30 / 15 / 1/step ] 063 Yellow: Middle 064 Yellow: IDmax 065 Yellow [0 to 30 / 15 / 1/step ] 066 Yellow SM Appendix 3-11 M124/M125...
Page 606 006 Mode2:Line *CTL [0 to 999 / 50 / 1 /step ] 007 Mode1:Paint *CTL [0 to 999 / 75 / 1 /step ] 008 Mode2:Paint *CTL [0 to 999 / 50 / 1 /step ] M124/M125 3-12 SM Appendix...
Page 607 [All Jobs Delete Mode] This switch determines whether all SCS jobs in progress are included in the 1111 SMC report when SP5990 is executed. 0:excluding New Job *CTL [0 or 1 / 1 / 1/step] 1:including New Job SM Appendix 3-13 M124/M125...
Page 608 *ENG 026 Tray: Thin *ENG 027 By-pass: Thin *ENG 028 Duplex: Thin *ENG [-9.0 to 9.0 / 0.0 / 0.1 mm/step] 029 Tray: Thin: 1200 *ENG 030 By-pass: Thin: 1200 *ENG 031 Duplex: Thin: 1200 *ENG M124/M125 3-14 SM Appendix...
Page 609 [-9 to 5 / 0 / 1 mm/step] 024 Tray 2/3/4/5LCT: Mid:1200 *ENG 025 By-pass: Plain:1200 *ENG 026 By-pass: Middle Thick:1200 *ENG 027 Paper Tray1: Thick1:1200 *ENG Paper Tray2/3/4/5/LCT: Thick [-9 to 5 / -2 / 1 mm/step] *ENG 1:1200 SM Appendix 3-15 M124/M125...
Page 610 007 Forced Reload Time :Cold *ENG sec/step] [Reload Permit Setting] Specifies the settings of the reload permit for low power mode temperature in 1101 color mode. Temp.:Delta:Low Power *ENG [0 to 200 / 5 / 1 deg/step] Mode:Center M124/M125 3-16 SM Appendix...
Page 611 [0 to 100 / P3c: 15, P3d: 20 / 1 *ENG Time:Cold:BW sec/step] [Flicker Control] 1101 Enables or disables the Flicker Control. [0 to 1 / 0 / 1/step] 030 Flicker Control *ENG 0: Disable 1: Enable SM Appendix 3-17 M124/M125...
Page 612 [Reload Permit Setting] 1101 Specifies the settings of the reload permit for cold temperature. Temp .:Delta:Cold:Center: *ENG [0 to 200 / 5 / 1 deg/step] FIN-less/ADF-less Temp .:Delta:Cold:End: *ENG [0 to 200 / 5 / 1 deg/step] FIN-less/ADF-less M124/M125 3-18 SM Appendix...
Page 613 [0 to 200 / 5 / 1 deg/step] Delta:Center:Sp.1 Temp.:Lower *ENG [0 to 200 / 5 / 1 deg/step] Delta:End:Sp.1 Temp.:Upper *ENG [0 to 200 / 30 / 1 deg/step] Delta:Center:Sp.1 Temp.:Upper *ENG [0 to 200 / 30 / 1 deg/step] Delta:End:Sp.1 SM Appendix 3-19 M124/M125...
Page 614 [100 to 180 / P3c:158(NA,TW),160(EU,ASIA,CHN) Plain1:BW:Center *ENG P3d:161(NA,TW),163(EU,ASIA) / 1 deg/step] Specifies the heating roller target temperature for the ready condition in BW printing. 004 Plain1:BW:Press *ENG [0 to 200 / 120 / 1 deg/step] M124/M125 3-20 SM Appendix...
Page 615 *ENG [0 to 200 / 120 / 1 deg/step] [100 to 180 / P3c: 170, P3d: 173 / 1 013 M-thick:FC:Center *ENG deg/step] [0 to 200 / P3c:120(NA,TW), 014 M-thick:FC:Press *ENG 150(EU,ASIA,CHN), P3d:150 / 1 deg/step] SM Appendix 3-21 M124/M125...
Page 616 [0 to 200 / 120 / 1 deg/step] 037 Special3:FC:Center *ENG [100 to 180 / 158 / 1 deg/step] 038 Special3:FC:Press *ENG [0 to 200 / 120 / 1 deg/step] 039 Special3:BW:Center *ENG [100 to 180 / 158 / 1 deg/step] M124/M125 3-22 SM Appendix...
Page 617 [0 to 200 / 120 / 1 deg/step] Speed Thick1:BW:Center:Low *ENG [100 to 180 / 148 / 1 deg/step] Speed Thick1:BW:Press:Low *ENG [0 to 200 / 120 / 1 deg/step] Speed Special1:FC:Center:Low *ENG [100 to 180 / 123 / 1 deg/step] Speed SM Appendix 3-23 M124/M125...
Page 618 [100 to 180 / 168 / 1 deg/step] 140 Thick4:FC:Press *ENG [0 to 200 / 120 / 1 deg/step] 141 Thick4:BW:Center *ENG [100 to 180 / 168 / 1 deg/step] 142 Thick4:BW:Press *ENG [0 to 200 / 120 / 1 deg/step] M124/M125 3-24 SM Appendix...
Page 619 P3d:166(NA,TW),168(EU,ASIA) / 1 deg/step] Specifies the temperature of the heating roller after re-load or job. Press *ENG [0 to 200 / 120 / 1 deg/step] Specifies the temperature of the pressure roller after re-load or job. SM Appendix 3-25 M124/M125...
Page 620 Job Low Temp. *ENG [0 to 100 / 10.0 / 0.1 deg/step] Correction:Sp. Job High Temp. *ENG [-5.0 to 100.0 / 0.0 / 0.1 deg/step] Correction:Sp. Standard Environment *ENG [10 to 30 / 23 / 1 deg/step] Temp. M124/M125 3-26 SM Appendix...
Page 621 Temp.:Delta:Press:H-humid Specifies the threshold temperature for the curl control in high humidity. Permit Temp.:Delta:Press:M-humid:No *ENG [0 to 200 / 30 / 1 deg/step] Decurl Specifies the threshold temperature for the no curl control in middle humidity. SM Appendix 3-27 M124/M125...
Page 622 0: OFF, 1: ON: BW, 2: ON: BW/FC Selects the heat storage FB control mode. Usage Limitation: Use "0: OFF" or "1: ON: BW" only. 011 Time out *ENG [0 to 500 / 10 / 1 sec/step] M124/M125 3-28 SM Appendix...
Page 623 016 Temp.:End:2:DLT *ENG [-30 to 30 / -5 / 1 deg/step] 021 Control Time 1:B4 *ENG [0 to 300 / 0 / 1 sec/step] 022 Control Time 2:B4 *ENG [0 to 300 / 30 / 1 sec/step] SM Appendix 3-29 M124/M125...
Page 624 [-30 to 30 / -5 / 1 deg/step] 074 Temp.:End:1:DLT:M-thick *ENG [-30 to 30 / -5 / 1 deg/step] 075 Temp.:Center:2:DLT:M-thick *ENG [-30 to 30 / -10 / 1 deg/step] 076 Temp.:End:2:DLT:M-thick *ENG [-30 to 30 / -10 / 1 deg/step] M124/M125 3-30 SM Appendix...
Page 625 006 Temp.:End:DLT *ENG [-30 to 30 / 0 / 1 deg/step] [Aging Temp. Correction] 1119 001 Page(%) *ENG [0 to 100 / 10 / 1 %/step] 002 Rotation(%) *ENG [0 to 100 / 10 / 1 %/step] SM Appendix 3-31 M124/M125...
Page 626 Temp.:FC:A5:Press *ENG [0 to 250 / 150 / 1 deg/step] Center Uniform End Temp.:FC:B6:Press *ENG [0 to 250 / 155 / 1 deg/step] Center Time:After Main Switch *ENG [0 to 100 / 60 / 1 sec/step] M124/M125 3-32 SM Appendix...
Page 627 [10 to 100 / 80 / 1 %/step] Specifies the 1st CPM down ration against the normal CPM in the low temperature condition. 004 Low :2nd CPM *ENG [10 to 100 / 65 / 1 %/step] SM Appendix 3-33 M124/M125...
Page 628 Specifies the pressure roller temperature for 1st CPM down of B4 paper size. High:2nd CPM Down *ENG [100 to 250 / 130 / 1 deg/step] Temp.:B4:Press End Specifies the pressure roller temperature for 2nd CPM down of B4 paper size. M124/M125 3-34 SM Appendix...
Page 629 [100 to 250 / 195 / 1 deg/step] Temp .:A5:Press End Specifies the pressure roller temperature for 2nd CPM down of A5 paper size. High :3rd CPM Down *ENG [100 to 250 / 200 / 1 deg/step] Temp .:A5:Press End SM Appendix 3-35 M124/M125...
Page 630 High :2nd CPM:Down *ENG [0 to 10000 / 10000 / 1 sec/step] Time:DLT Specifies the pressure roller temperature for 2nd CPM down of DLT. High :3rd CPM:Down *ENG [0 to 10000 / 10000 / 1 sec/step] Time:DLT M124/M125 3-36 SM Appendix...
Page 631 Specifies the pressure roller temperature for 2nd CPM down of B5 paper size. High :3rd CPM:Down *ENG [0 to 10000 / 10000 / 1 sec/step] Time:B5 Specifies the pressure roller temperature for 3rd CPM down of B5 paper size. SM Appendix 3-37 M124/M125...
Page 632 [0 to 10000 / 10000 / 1 sec/step] Time:A3:Low Speed Specifies the pressure roller temperature for 3rd CPM down of A3 paper size. High :1st CPM:Down *ENG [0 to 10000 / 10000 / 1 sec/step] Time:DLT:Low Speed M124/M125 3-38 SM Appendix...
Page 633 Specifies the pressure roller temperature for 3rd CPM down of A4 paper size. High :1st CPM:Down *ENG [0 to 10000 / 10000 / 1 sec/step] Time:B5:Low Speed Specifies the pressure roller temperature for 1st CPM down of B5 paper size. SM Appendix 3-39 M124/M125...
Page 634 *ENG [0 to 10000 / 10000 / 1 sec/step] Time:A6:Low Speed Specifies the pressure roller temperature for 3rd CPM down of A6 paper size. [CPM Down Setting] 1125 Specifies the settings for the CPM down mode. M124/M125 3-40 SM Appendix...
Page 635 Specifies the pressure roller temperature for 3rd CPM down of A3 Small paper size. [0 to 100 / High :1st P3c:80(NA,TW),74(EU,ASIA,CHN), CPM:DLT:Large *ENG P3d:80(NA,TW),77(EU,ASIA,CHN) / Size:Normal Speed 1 %/step] Specifies the pressure roller temperature for 1st CPM down of DLT Large paper size. SM Appendix 3-41 M124/M125...
Page 636 *ENG Size:Normal Speed P3d:70(NA,TW),60(EU,ASIA,CHN) / 1 %/step] Specifies the pressure roller temperature for 1st CPM down of B4 Large paper size. [0 to 100 / High :2nd CPM:B4:Large P3c:50(NA,TW),61(EU,ASIA,CHN), *ENG Size:Normal Speed P3d:50(NA,TW),40(EU,ASIA,CHN) / 1 %/step] M124/M125 3-42 SM Appendix...
Page 637 Specifies the pressure roller temperature for 1st CPM down of LT Small paper size. High :2nd CPM:LT:Small *ENG [0 to 100 / 50 / 1 %/step] Size:Normal Speed Specifies the pressure roller temperature for 2nd CPM down of LT Small paper size. SM Appendix 3-43 M124/M125...
Page 638 [0 to 100 / 50 / 1 %/step] Size:Normal Speed Specifies the pressure roller temperature for 2nd CPM down of B5 Large paper size. High :3rd CPM:B5:Large *ENG [0 to 100 / 30 / 1 %/step] Size:Normal Speed M124/M125 3-44 SM Appendix...
Page 639 Specifies the pressure roller temperature for 2nd CPM down of B6 paper size. High :3rd *ENG [0 to 100 / 30 / 1 %/step] CPM:B6:Normal Speed Specifies the pressure roller temperature for 3rd CPM down of B6 paper size. SM Appendix 3-45 M124/M125...
Page 640 Specifies the pressure roller temperature for 1st CPM down of DLT Large paper size. High :2nd CPM:DLT:Large *ENG [0 to 100 / 50 / 1 %/step] Size:Middle Speed Specifies the pressure roller temperature for 2nd CPM down of DLT Large paper size. M124/M125 3-46 SM Appendix...
Page 641 Specifies the pressure roller temperature for 2nd CPM down of LT Large paper size. High :1st CPM:LT:Small *ENG [0 to 100 / 80 / 1 %/step] Size:Middle Speed Specifies the pressure roller temperature for 1st CPM down of LT Small paper size. SM Appendix 3-47 M124/M125...
Page 642 [0 to 100 / 50 / 1 %/step] Size:Middle Speed Specifies the pressure roller temperature for 2nd CPM down of B5 Small paper size. High :1st CPM:A5:Middle *ENG [0 to 100 / 80 / 1 %/step] Speed M124/M125 3-48 SM Appendix...
Page 643 Specifies the pressure roller temperature for 1st CPM down of DLT Small paper size. High :1st CPM:B4:Large *ENG [0 to 100 / 80 / 1 %/step] Size:Low Speed Specifies the pressure roller temperature for 1st CPM down of B4 Large paper size. SM Appendix 3-49 M124/M125...
Page 644 Specifies the pressure roller temperature for 1st CPM down of B6 paper size. High :1st CPM:A6:Low *ENG [0 to 100 / 80 / 1 %/step] Speed Specifies the pressure roller temperature for 1st CPM down of A6 paper size. M124/M125 3-50 SM Appendix...
Page 645 [-50 to 300 / - / 1 deg/step] Displays the temperature at the center of the pressure roller when an SC was 103 Press Roller:Ctr Det1 *ENG issued. [-50 to 300 / - / 1 deg/step] SM Appendix 3-51 M124/M125...
Page 646 [-50 to 300 / - / 1 deg/step] Displays the temperature at the end of the pressure roller when an SC was 204 Press Roller:End Det3 *ENG issued. [-50 to 300 / - / 1 deg/step] 1142 [Fusing Jam Detection] M124/M125 3-52 SM Appendix...
Page 647 Sets the default pressure position of the fusing unit for each paper type in normal speed. 0: Depression position (no pressure) 1: Position 1 (less pressure) 2: Position 2 3: Position 3 (strongest pressure) 102 Pressure:Thin *ENG [0 to 3 / 3 / 1 /step] SM Appendix 3-53 M124/M125...
Page 648 Sets the default pressure position of the fusing unit for thick 4 paper. 0: Depression position (no pressure) 1: Position 1 (less pressure) 2: Position 2 3: Position 3 (strongest pressure) 162 Pressure:Postcard *ENG [0 to 3 / 3 / 1 /step] M124/M125 3-54 SM Appendix...
Page 649 [-10 to 100 / 15 / 1 deg/step] 003 Temp. : Target *ENG [0 to 100 / 100 / 1 deg/step] Temp. :Rotation *ENG [-10 to 100 / 30 / 1/step] Threshold Value [Switch Rotation Start/Stop] 1154 SM Appendix 3-55 M124/M125...
Page 650 P3c:1(NA,TW),0(EU,ASIA,CHN), 003 Warm Up Heater Switch *ENG P3d:1(NA,TW),0(EU,ASIA,CHN) / 1/step] Feed Permit *ENG [0 to 200 / 5 / 1 deg/step] Temp. :Delta:Center Feed Permit *ENG [0 to 200 / 5 / 1 deg/step] Temp. :Delta:End M124/M125 3-56 SM Appendix...
Page 651 [-2.0 to 2.0 / -1.1 / 0.1 %/step] 002 Registration:Plain:High *ENG [-2.0 to 2.0 / -0.1 / 0.1 %/step] Registration:Middle *ENG [-2.0 to 2.0 / -1.1 / 0.1 %/step] Thick:Low Registration:Middle *ENG [-2.0 to 2.0 / -0.1 / 0.1 %/step] Thick:Mid SM Appendix 3-57 M124/M125...
Page 652 [-4.0 to 4.0 / 0.0 / 0.1 %/step] Reverse CCW:Middle *ENG Thick:High 033 Reverse CCW:Thick1:Mid *ENG 034 Feed:Plain:Low *ENG [-2.0 to 2.0 / -1.1 / 0.1 %/step] 035 Feed:Plain:High *ENG [-2.0 to 2.0 / -0.1 / 0.1 %/step] M124/M125 3-58 SM Appendix...
Page 653 *ENG P3c: [-10 to 10 / 0 / 1 /step] 102 COpcDevMot:High *ENG P3d: [-8 to 8 / 0 / 1 /step] 103 YOpcDevMot:High *ENG 104 MOpcDevMot:Mid *ENG [-7 to 7 / 0 / 1 /step] SM Appendix 3-59 M124/M125...
Page 654 *ENG [-4.00 to 4.00 / 0.10 / 0.01 %/step] 136 Long:Fusing:Thick 2:Low *ENG [-4.00 to 4.00 / 0.10 / 0.01 %/step] 137 Long:Fusing:Thick 3:Low *ENG [-4.00 to 4.00 / 0.10 / 0.01 %/step] 1802 [CPM Setting] M124/M125 3-60 SM Appendix...
Page 655 *ENG [-10 to 10 / 0 / 1 mm/step] 014 Feed Clutch ON: Thick *ENG [-10 to 10 / 0 / 1 mm/step] 015 Re-Feed Stop Position *ENG [-10 to 10 / 0 / 1 mm/step] SM Appendix 3-61 M124/M125...
Page 656 002 Fusing Exit Fan *ENG [0 to 900 / 120 / 1 sec/step] 006 Main Suction Fan *ENG [0 to 900 / 120 / 1 sec/step] 007 Paper Exit Fan *ENG [0 to 900 / 120 / 1 sec/step] M124/M125 3-62 SM Appendix...
Page 657 Enables or disenables the control of extra fan execution control. [Fan Control] 1955 Configures the settings of fan execution switching. Execution Temp. *ENG [20.0 to 70.0 / 34.6 / 0.1 deg/step] Threshold Cancellation Temp. *ENG [0.1 to 20.0 / 1.8 / 0.1 deg/step] Threshold SM Appendix 3-63 M124/M125...
Page 658 [-100 to 100 / P3c:25, P3d: 24 / 1 016 HVP:Plain *ENG -V/step] 017 HVP:Thick 1 *ENG [-100 to 100 / 20 / 1 -V/step] 018 HVP: Thick 2&FINE *ENG [-100 to 100 / 29 / 1 -V/step] M124/M125 3-64 SM Appendix...
Page 659 004 Environmental Target: Y *ENG 0.01 mA/step] [Charge AC Current: ML] Charge Roller AC Current Adjustment for MM (Color) 2008 Displays/sets the AC current target of the charge roller for ML environment (Meddle temperature and Low humidity). SM Appendix 3-65 M124/M125...
Page 660 [0.00 to 3.00 / P3c:0.99, P3d: 1.46 / 003 Environmental Target: C *ENG 0.01 mA/step] [0.00 to 3.00 / P3c:1.01, P3d: 1.48 / 004 Environmental Target: Y *ENG 0.01 mA/step] [Charge AC Current: HH] 2011 Charge Roller AC Current Adjustment for HH (Color) M124/M125 3-66 SM Appendix...
Page 661 0: The environmental condition is determined automatically. 1: LL, 2: ML, 3: MM, 4: MH, 5: HH Changes the humidity threshold Absolute Humidity: *ENG between LL and ML. Threshold 1 [0.00 to 100.00 / 3.00 / 0.01 g/m /step] SM Appendix 3-67 M124/M125...
Page 662 008 RH Threshold M *ENG [0 to 99 / 25 / 1 %RH/step] 009 AH Threshold *ENG [0 to 99 / 6 / 1 g/m /step] 010 Temp Threshold S *ENG [0.0 to 20.0 / 1.0 / 0.1 deg/step] M124/M125 3-68 SM Appendix...
Page 663 [0 to 90 / 10 / 10 V/step] 007 Setting1:C *ENG 008 Setting1:Y *ENG 009 Setting2:K *ENG 010 Setting2:M *ENG [0 to 90 / 20 / 10 V/step] 011 Setting2:C *ENG 012 Setting2:Y *ENG 2018 [Charge R Running Par] SM Appendix 3-69 M124/M125...
Page 664 "Laser Optics Housing Unit" in the "Main chapters: 4. Replacement and Adjustment: Laser Optics". The value should be provided with the new laser optics housing unit. 001 Main Dot: Bk *ENG [-512 to 511 / 0 / 1 dot/step] M124/M125 3-70 SM Appendix...
Page 665 Main Mag.: High Speed: *ENG Main Mag.: Medium *ENG [0 to 560 / 280 / 1 /step] Speed: Y Main Mag.: Low Speed: *ENG 013 Offset: Mag Bk1-2 *ENG [-256 to 255 / 0 / 1 sub-dot/step] SM Appendix 3-71 M124/M125...
Page 666 [50 to 120 / 100 / 1%/step] 002 High Speed: Ma *ENG Decreasing a value makes lines thinner 003 High Speed: Cy *ENG on the output. Increasing a value makes lines thicker 004 High Speed: Ye *ENG on the output. M124/M125 3-72 SM Appendix...
Page 667 [0 or 1 / 1 / 1 /step] 001 Image Gamma Flag Sets the image gamma flag ON/OFF. [0 or 1 / 1 / 1 /step] 002 Shading Correction Flag *ENG Sets shading correction ON/OFF. 2109 [Test Pattern] SM Appendix 3-73 M124/M125...
Page 668 1: All colors, 2: Magenta, 3: Yellow, 4: Cyan 006 Density: Bk Specifies the color density for the test 007 Density: Ma pattern. 008 Density: Cy [0 to 15 / 15 / 1 /step] 0: Lightest density 009 Density: Ye 15: Darkest density M124/M125 3-74 SM Appendix...
Page 669 002 Pulse: C *ENG [-50 to 50 / 0 / 1 pulse/step] 003 Pulse: Y *ENG 2118 [Skew Adjustment] 001 Execute: M Changes the current skew adjustment 002 Execute: C values to the values specified with SM Appendix 3-75 M124/M125...
Page 670 [0 to 1024 / - / 1 /step] 003 C *ENG 004 Y *ENG 2140 [TM Sensor Check Result] 005 Front *ENG 006 Center *ENG [0 to 1024 / - / 1 /step] 007 Rear *ENG 2141 [ID Sensor Check Result] M124/M125 3-76 SM Appendix...
Page 671 [0.00 to 5.50 / - / 0.01 V/step] 003 Minimum: C *ENG 004 Minimum: Y *ENG 2143 [TM Sensor Check Result] 005 Minimum: Front *ENG 006 Minimum: Center *ENG [0.00 to 5.50 / - / 0.01 V/step] 007 Minimum: Rear *ENG SM Appendix 3-77 M124/M125...
Page 672 [-255 to 255 / 0 / 1sub-dot/step] 028 Area 1: Bk *ENG 029 Area 2: Bk *ENG Adjusts the area magnification for LD 0. 030 Area 3: Bk *ENG [-255 to 255 / 0 / 1 sub-dot/step] 031 Area 4: Bk *ENG M124/M125 3-78 SM Appendix...
Page 673 [-255 to 255 / 0 / 1 sub-dot/step] 184 Area 1: Ye *ENG Adjusts the area magnification for LD 0. 185 Area 2: Ye *ENG [-255 to 255 / 0 / 1 sub-dot/step] 186 Area 3: Ye *ENG SM Appendix 3-79 M124/M125...
Page 674 *ENG 013 Area 12: Bk *ENG 014 Area 13: Bk *ENG 015 Area 14: Bk *ENG This is out of the image area. 016 Area 15: Bk *ENG [50 to 150 / 100 / 1 %/step] M124/M125 3-80 SM Appendix...
Page 675 *ENG 077 Area 12: Cy *ENG 078 Area 13: Cy *ENG 079 Area 14: Cy *ENG This is out of the image area. 080 Area 15: Cy *ENG [50 to 150 / 100 / 1 %/step] SM Appendix 3-81 M124/M125...
Page 676 [10 to 15 / 15 / 1 /step] Dot:Bk 1200dpi:Independent *ENG [10 to 15 / 15 / 1 /step] Dot:Bk 2180 [Line Pos. Adj. Clear] 001 Color Regist. [- / - / -] Main Scan Length [Execute] Detection M124/M125 3-82 SM Appendix...
Page 677 *ENG M. Right Mag.: Subdot: *ENG 017 S. Cor.: 600 Line: M *ENG [-16384 to 16383 / - / 1 line/step] 018 S. Cor.: 600 Sub: M *ENG [-1.000 to 1.000 / - / 0.001 line/step] SM Appendix 3-83 M124/M125...
Page 678 [-16384 to 16383 / - / 1 line/step] 054 S. Cor.: 600 Sub: Y *ENG [-1.000 to 1.000 / - / 0.001 line/step] 055 S. Cor.: 1200 Line: Y *ENG [-16384 to 16383 / - / 1 line/step] M124/M125 3-84 SM Appendix...
Page 679 [-15 to 15 / 0 / 1 pulse/step] 022 S. Scan: High: Line: M *ENG [-16384 to 16383 / 0 / 1 line/step] S. Scan: High: Subline: *ENG [-1.000 to 1.000 / 0.000 / 0.001 /line] SM Appendix 3-85 M124/M125...
Page 680 005 Execute: Medium: M 006 Execute: Low: M 007 Execute: High: C 008 Execute: Medium: C 009 Execute: Low: V [- / - / -] 010 Execute: High: Y [Execute] 011 Execute: Medium: Y 012 Execute: Low: Y M124/M125 3-86 SM Appendix...
Page 681 [0 to 999 / 1 / 1 sec/step] [Line Position Adj.] 2190 Paper Int. Mag.: Subdot: *ENG Paper Int. Mag.: Subdot: *ENG [0 or 1 / 1 / 1 /step] Paper Int. Mag.: Subdot: *ENG Paper Int. Mag.: Subdot: *ENG SM Appendix 3-87 M124/M125...
Page 682 [-131071 to 131071 / 77 / 1 bit/step] 025 ch 2: Filter: Front: b2 [-131071 to 131071 / 39 / 1 bit/step] 026 ch 2: Filter: Rear: a1 [-131071 to 131071 / 128596 / 1 bit/step] M124/M125 3-88 SM Appendix...
Page 683 Adjusts the threshold of the line position adjustment for BW and color printing mode during job. Page: Interrupt: FC *ENG [0 to 999 / 200 / 1 page/step] Adjusts the threshold of the line position adjustment for color printing mode during jobs. SM Appendix 3-89 M124/M125...
Page 684 The line position adjustment is done when the number of outputs in BW and color printing mode reaches the value specified with this SP and the condition of SP2-193-008 or SP2-193-009 is satisfied. 2194 [MUSIC Execution Result] Line Position Adjustment: Execution Result M124/M125 3-90 SM Appendix...
Page 685 [Music A/D Interval] 2198 ADC Trigger Counter 001 ADC Trigger Counter *ENG [7.5 to 20.0 / 10.0 / 0.1 s/step] 2199 [MUSIC Error Time Setting] 001 Error Detection Counter *ENG [0.5 to 3.0 / 2.5 / 0.1 sec/step] SM Appendix 3-91 M124/M125...
Page 686 *ENG 002 Plain: M *ENG 003 Plain: C *ENG 004 Plain: Y *ENG [0 to 800 / 550 / 10 -V/step] 005 Thick 1: Bk *ENG 006 Thick 1: M *ENG 007 Thick 1: C *ENG M124/M125 3-92 SM Appendix...
Page 687 [0 to 99999999 / - / 1/mm] [0 or 1 / 0 / 1/step] 004 Log Clear 1: Clear [Environmental Correction: Transfer] 2302 Environmental Correction: Image Transfer Belt Unit Current Environmental Displays the current environment Display condition. SM Appendix 3-93 M124/M125...
Page 688 Threshold 2 ≤ paper ≤ Threshold 1: 002 Threshold 2 *ENG Paper is detected as "S2" size. [0 to 350 / 210 / 1 mm/step] Threshold 3 ≤ paper ≤ Threshold 2: 003 Threshold 3 *ENG Paper is detected as "S3" size. M124/M125 3-94 SM Appendix...
Page 689 Adjusts the current for the image transfer belt in B/W mode for thick 1 paper. ITB unit: Thick 2 & FINE *ENG [0 to 80 / 12 / 1 Adjusts the current for the image transfer belt in B/W mode for thick 2 paper or FINE mode. SM Appendix 3-95 M124/M125...
Page 690 Thick 2 and fine. ITB unit: Thick 2 & FINE: *ENG [0 to 80 / 11 / 1 Adjusts the current for the image transfer belt for Cyan in full color mode for Thick 2 and fine. M124/M125 3-96 SM Appendix...
Page 691 [0 to 4000 / 2200 / 10 -V/step] 2nd Side [Plain: Bias: BW] Adjusts the current for the paper transfer roller for plain paper in 2403 black-and-white mode. Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed SM Appendix 3-97 M124/M125...
Page 692 S1 size > 297 mm (Paper width) *ENG 1st Side: S1 Paper Transfer: 1200: *ENG 2nd Side: S1 [100 to 600 / 105 / 5%/step] Paper Transfer: Plain: *ENG 297 mm > S2 size > 275 mm (Paper 1st Side: S2 width) M124/M125 3-98 SM Appendix...
Page 693 [100 to 600 / 300 / 5%/step] *ENG 1st Side: S5 148 mm > S5 size (Paper width) Paper Transfer: 1200: *ENG [100 to 600 / 400 / 5%/step] 2nd Side: S5 2421 [Plain: Leading Edge Correction] Plain Paper: Leading Edge Correction SM Appendix 3-99 M124/M125...
Page 694 Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed Paper Transfer: Plain: *ENG 1st Side Paper Transfer: Plain: *ENG 2nd Side [0 to 50 / 0 / 2 mm/step] Paper Transfer: 1200: *ENG 1st Side Paper Transfer: 1200: *ENG 2nd side M124/M125 3-100 SM Appendix...
Page 695 Adjusts the bias/voltage switch timing of the paper transfer roller/discharge plate at the paper trailing edge between the erase margin area and the image 2424 area. Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed SM Appendix 3-101 M124/M125...
Page 696 [1 to 60 / 22 / 1 /step] Side Separation DC: 1200: *ENG [1 to 60 / 29 / 1 /step] 2nd Side Paper Transfer: 1200: *ENG [1 to 60 / 11 / 1 /step] BW: 1st Side M124/M125 3-102 SM Appendix...
Page 697 Adjusts the current for the paper transfer roller for thin paper in full color mode. 2457 Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed Paper Transfer: Plain: [0 to 250 / P3c:40, P3d:50 / 1 - A *ENG 1st Side /step] SM Appendix 3-103 M124/M125...
Page 698 Adjusts the correction to the paper transfer roller current at the paper leading edge in each mode. SP2453 and SP2457 are multiplied by these SP values. 2471 Plain: High speed, 1200: Low speed  The paper leading edge area can be adjusted with SP2472. M124/M125 3-104 SM Appendix...
Page 699 Paper Transfer: Plain: *ENG 2nd Side Paper Transfer: 1200: *ENG 1st Side [0 to 50 / 0 / 2 mm/step] Paper Transfer: 1200: *ENG 2nd Side Separation DC: Plain: 1st *ENG Side Separation DC: Plain: *ENG 2nd Side SM Appendix 3-105 M124/M125...
Page 700 2474 area. Plain: High speed, 1200: Low speed Paper Transfer: Plain: *ENG 1st Side [0 to 50 / 0 / 2 mm/step] Paper Transfer: Plain: *ENG 2nd Side M124/M125 3-106 SM Appendix...
Page 701 Paper Transfer: 1200: *ENG BW: 1st Side [1 to 60 / 11 / 1 /step] Paper Transfer: 1200: *ENG BW: 2nd Side Paper Transfer: 1200: *ENG [1 to 60 / 1 / 1 /step] FC: 1st Side SM Appendix 3-107 M124/M125...
Page 702 [0 to 400 / 100 / 5%/step]] 2486 [Plain: Switch Timing: Lead. Edge] 001 Paper Transfer: 1st Side *ENG [0 to 50 / 0 / 2 mm/step] 005 Separation DC: 1st Side *ENG 2487 [Plain: Trailing Edge Correction] M124/M125 3-108 SM Appendix...
Page 703 [0 to 250 / 24 / 1 - A /step] Paper Transfer: Plain: *ENG 2nd Side Separation DC: 1200: 1st *ENG [0 to 250 / 12 / 1 - A /step] Side 2507 [Thick 1: Bias: FC] SM Appendix 3-109 M124/M125...
Page 704 275 mm > S3 size > 210 mm (Paper 2nd Side: S3 width) [100 to 600 / 140 / 5%/step] Paper Transfer: 1200: *ENG 275 mm > S3 size > 210 mm (Paper 1st Side: S3 width) M124/M125 3-110 SM Appendix...
Page 705 Separation DC: Plain: 1st *ENG Side [0 to 400 / 100 / 5%/step] Separation DC: Plain: *ENG 2nd Side Separation DC: 1200: 1st *ENG [0 to 400 / 100 / 5%/step] Side 2522 [Thick 1: Switch Timing: Lead. Edge] SM Appendix 3-111 M124/M125...
Page 706 Paper Transfer: 1200: *ENG 1st Side Separation DC: Plain: 1st *ENG Side Separation DC: Plain: *ENG 2nd Side [0 to 400 / 100 / 5%/step] Separation DC: 1200: 1st *ENG Side 2524 [Thick 1: Sw Timing: Trail. Edge] M124/M125 3-112 SM Appendix...
Page 707 [1 to 60 / 22 / 1 /step] Side Paper Transfer: 1200: *ENG [1 to 60 / 11 / 1 /step] BW: 1st Side Paper Transfer: 1200: *ENG [1 to 60 / 1 / 1 /step] FC: 1st Side SM Appendix 3-113 M124/M125...
Page 708 Paper Transfer: 1st Side: *ENG 275 mm > S3 size > 210 mm (Paper width) [100 to 600 / 240 / 5 %/step] Paper Transfer: 2nd *ENG 275 mm > S3 size > 210 mm (Paper Side: S3 width) M124/M125 3-114 SM Appendix...
Page 709 002 Paper Transfer: 2nd Side *ENG [0 to 50 / 0 / 2 mm/step] 003 Separation DC: 1st Side *ENG 004 Separation DC: 2nd Side *ENG 2573 [Thick 2: Trail. Edge Correction] Thick 2 Paper: Trailing Edge Correction SM Appendix 3-115 M124/M125...
Page 710 [0 to 4000 / 2200 / 10 -V/step] [OHP: Bias: BW] 2603 Adjusts the current for the paper transfer roller for OHP in black-and-white mode. 001 Paper Transfer *ENG [0 to 250 / 12 / 1 - A /step] M124/M125 3-116 SM Appendix...
Page 711 [0 to 400 / 100 / 5%/step] [OHP: Switch Timing: Leading Edge] Adjusts the bias/ voltage switch timing of the paper transfer roller/ discharge 2622 plate at the paper leading edge between the erase margin area and the image area. SM Appendix 3-117 M124/M125...
Page 712 002 Paper Transfer: 2nd Side *ENG [0 to 250 / 12 / 1 - A /step] [Thick3: Bias: FC] 2652 Adjusts the current for the paper transfer roller for thick paper 3 in full color mode. M124/M125 3-118 SM Appendix...
Page 713 210 mm > S4 size > 148 mm (Paper Side: S4 width) Paper Transfer: 2nd [100 to 600 / 600 / 5%/step] *ENG Side: S5 148 mm > S5 size (Paper width) 2654 [Thick 3: Leading Edge Correction] Thick 3 Paper: Leading Edge Correction SM Appendix 3-119 M124/M125...
Page 714 2657 plate at the paper trailing edge between the erase margin area and the image area. 001 Paper Transfer: 1st Side *ENG [0 to 50 / 0 / 2 mm/step] 002 Paper Transfer: 2nd Side *ENG M124/M125 3-120 SM Appendix...
Page 715 Adjusts the current for the paper transfer roller for thick paper 4 in full color mode. Paper Transfer: 1st *ENG [0 to 250 / 15 / 1 - A /step] Side Paper Transfer: 2nd *ENG [0 to 250 / 15 / 1 - A /step] Side SM Appendix 3-121 M124/M125...
Page 716 SP2671 and SP2672 are multiplied by these SP values.  The paper leading edge area can be adjusted with SP2675. 001 Paper Transfer: 1st Side *ENG [0 to 400 / 100 / 5%/step] 002 Separation DC: 1st Side *ENG M124/M125 3-122 SM Appendix...
Page 717 002 Paper Transfer: 2nd Side *ENG [0 to 50 / 0 / 2 mm/step] 003 Separation DC: 1st Side *ENG 004 Separation DC: 2nd Side *ENG [Thick 4: Environment Correction] Thick 4 Paper: MM Environment 2680 Coefficient Adjustment SM Appendix 3-123 M124/M125...
Page 718 Adjusts the current for the paper transfer roller for special paper 1 in 2753 black-and-white mode. Plain: High speed Paper Transfer: Plain: *ENG 1st Side [0 to 250 / P3c: 30, P3d: 38 / 1 - A Paper Transfer: Plain: /step] *ENG 2nd Side M124/M125 3-124 SM Appendix...
Page 719 [100 to 600 / 160 / 5%/step] Paper Transfer: 2nd *ENG 210 mm > S4 size > 148 mm (Paper Side: S4 width) Paper Transfer: 1st Side: [100 to 600 / 180 / 5%/step] *ENG 148 mm > S5 size (Paper width) SM Appendix 3-125 M124/M125...
Page 720 Plain: High speed, 1200: Low speed Paper Transfer: Plain: *ENG 1st Side [0 to 50 / 0 / 2 mm/step] Paper Transfer: Plain: *ENG 2nd Side Paper Transfer: 1200: *ENG [0 to 50 / 0 / 1 mm/step] 1st Side M124/M125 3-126 SM Appendix...
Page 721 Plain: High speed, 1200: Low speed Paper Transfer: Plain: *ENG 1st Side Paper Transfer: Plain: *ENG [0 to 50 / 0 / 2 mm/step] 2nd Side Paper Transfer: 1200: *ENG 1st Side SM Appendix 3-127 M124/M125...
Page 722 Adjusts the DC voltage of the discharge plate for special paper 2. 2801 Plain: High speed, 1200: Low speed Separation DC: Plain: 1st *ENG Side Separation DC: Plain: *ENG [0 to 4000 / 2200 / 10 -V/step] 2nd Side Separation DC: 1200: 1st *ENG Side M124/M125 3-128 SM Appendix...
Page 723 Paper Transfer: 2nd *ENG 297 mm > S2 size > 275 mm (Paper Side: S2 width) [100 to 600 / 140 / 5%/step] Paper Transfer: 1st Side: *ENG 275 mm > S3 size > 210 mm (Paper width) SM Appendix 3-129 M124/M125...
Page 724 2821  The paper leading edge area can be adjusted with SP2822. Separation DC: Plain: 1st *ENG Side Separation DC: Plain: *ENG [0 to 400 / 100 / 5%/step] 2nd Side Separation DC: 12001st *ENG Side M124/M125 3-130 SM Appendix...
Page 725 Paper Transfer: 1200: *ENG 1st Side [0 to 400 / 100 / 5%/step] Separation DC: Plain: 1st *ENG Side Separation DC: Plain: *ENG 2nd Side Separation DC: 1200: 1st *ENG Side 2824 [Special 2: Sw Timing: Trail. Edge] SM Appendix 3-131 M124/M125...
Page 726 [1 to 60 / 22 / 1 /step] Side Paper Transfer: 1200: *ENG [1 to 60 / 11 / 1 /step] BW: 1st Side Paper Transfer: 1200: *ENG [1 to 60 / 1 / 1 /step] FC: 1st Side M124/M125 3-132 SM Appendix...
Page 727 Adjusts the size correction coefficient for the paper transfer roller current for 2861 each paper size. SP2852 and SP2857 are multiplied by these SP values. Paper Transfer: 1st Side: [100 to 600 / 100 / 5%/step] *ENG S1 size > 297 mm (Paper width) SM Appendix 3-133 M124/M125...
Page 728  The paper leading edge area can be adjusted with SP2872. Paper Transfer: Plain: 1st *ENG Side Paper Transfer: Plain: *ENG [0 to 400 / 100 / 5%/step] 2nd Side Paper Transfer: 1200: 1st *ENG Side M124/M125 3-134 SM Appendix...
Page 729 SP2852 and SP2857 are multiplied by these SP values. 2873 Plain: High speed, 1200: Low speed  The paper trailing edge area can be adjusted with SP2874. Paper Transfer: Plain: *ENG [0 to 400 / 100 / 5%/step] 1st Side SM Appendix 3-135 M124/M125...
Page 730 [1 to 60 / 22 / 1 /step] 1st Side Separation DC: Plain: *ENG [1 to 60 / 29 / 1 /step] 2nd Side Paper Transfer: Plain: *ENG [1 to 60 / 11 / 1 /step] BW: 1st Side M124/M125 3-136 SM Appendix...
Page 731 [Image Transfer Reverse Time] Adjusts the time for how long the image transfer belt motor reverses after job 2904 end. 001 All *ENG [0 to 200 / 40 / 10 msec/step] 2905 [Dev Rvs Time] Development Roller Reverse Time SM Appendix 3-137 M124/M125...
Page 732 SP after consecutive full color image printouts in the full color mode. If this SP is set to "0", the image transfer belt does not move away. 001 Continuous Bk Pages *ENG [0 to 10 / 0 / 1 sheet/step] M124/M125 3-138 SM Appendix...
Page 733 If SC443 occurs and machine does not recover, change this setting to "1". SC443-00 Count *ENG [0 to 3 / 0 / 1 /step] Displays the number of the ITB encodre error. SC443 is displayed if this counter counts to "3". SM Appendix 3-139 M124/M125...
Page 734 001 Standard Speed *ENG [0 to 1250 / 197 / 1 msec/step] 002 Medium Speed *ENG [0 to 1500 / 146 / 1 msec/step] 003 Low Speed *ENG [0 to 2600 / 0 / 1 msec/step] M124/M125 3-140 SM Appendix...
Page 735 [300 to 20000 / 500 / 10 msec/step] Duty Control ITB Stop Time: No Duty *ENG [300 to 20000 / 500 / 10 msec/step] Control Forced CPM Down *ENG [0 to 5000 / 4 / 1 page/step] Thresh: Duty Control SM Appendix 3-141 M124/M125...
Page 736 Cancellation Temp. *ENG cancellation temperature. Threshold [ 0.1 to 20.0 / 0.1 / 0.1/step] Turns duty control off or on. 013 ON/OFF Setting *ENG [0 or 1 / 1 / 1 /step] 0: OFF 1: ON M124/M125 3-142 SM Appendix...
Page 737 001 History: Latest *ENG 002 Result: Latest 1 *ENG 003 Result: Latest 2 *ENG [1111 to 99999999 / - / 1/step] 004 Result: Latest 3 *ENG 005 Result: Latest 4 *ENG 006 Result: Latest 5 *ENG SM Appendix 3-143 M124/M125...
Page 738 Specifies the manual toner supply time for each color. 001 Supply Time: Bk *ENG 002 Supply Time: M *ENG [0 to 30 / 4 / 1 sec/step] 003 Supply Time: C *ENG 004 Supply Time: Y *ENG M124/M125 3-144 SM Appendix...
Page 739 This flag is cleared after executing TD 008 Execution Flag: Y *ENG sensor initialization. Enables or disables developer initialization. 009 Set Prohibition *ENG [0 or 1/ 0 / 1 /step] 0: Enable 1: Disable [Tonner Replenishment Mode] 3022 SM Appendix 3-145 M124/M125...
Page 740 Enables or disables the automatic process control prohibition. [0 to 3 / 2 / 1/step] 0: Not Executed Pre-ACC Process *ENG 1: Process Control Control 2: TC Control (TD Adjustment) 3: Not used Selects the process control mode that is done before ACC. M124/M125 3-146 SM Appendix...
Page 741 5: Repeat three times (Toner is supplied only when the toner density is too low, and toner is consumed only when the toner density is too dark.) 6 to 9: Disabled 004 Repeat Number: ACC *ENG [0 to 9 / 3 / 1 time/step] SM Appendix 3-147 M124/M125...
Page 742 Consumption pattern: Y *ENG [0 to 255 / 5 / 1 time/step] Specifies the belt mark generating time for checking the yellow toner density when toner density is detected to be low at the toner density adjustment. M124/M125 3-148 SM Appendix...
Page 743 Adjusts the LD duty for the toner consumption mode at the toner density adjustment. In toner consumption mode, toner is discharged when the detected development gamma values (SP3611-004) exceed the target values (SP3611-008) by more than the specified thresholds (SP3239-009). SM Appendix 3-149 M124/M125...
Page 744 [1 to 600 / 400 / 1 g/step] 004 Toner Replenishment: Y *ENG [Toner End/Near End] 3101 Displays the consumed amount of each color toner. 005 Toner Consumption: Bk *ENG [0.000 to 3000.000 / 0.000 / 0.001 006 Toner Consumption: M *ENG g/step] M124/M125 3-150 SM Appendix...
Page 745 Displays the total delta Vt (Vt-Vtref) value for each color. These are calculated by pixel counting. 022 Delta Vt Sum: Bk *ENG 023 Delta Vt Sum: M *ENG [0.00 to 655.00 / 0.00 / 0.01 V/step] 024 Delta Vt Sum: C *ENG SM Appendix 3-151 M124/M125...
Page 746 [Toner End/Near End] 3101 Adjusts the threshold of the remaining toner for the toner near-end detection. 046 Mohno Off Time: Bk *ENG [0 to 0xFFFFFFFF / 0 / 1 /step] 047 Mohno Off Time: M *ENG M124/M125 3-152 SM Appendix...
Page 747 0.01 V/step] [0.00 to 5.00 / P3c: 0.11 P3d: 0.41 / 003 Thick 1 Shift: C *ENG 0.01 V/step] [0.00 to 5.00 / P3c: 0.17 P3d: 0.46 / 004 Thick 1 Shift: Y *ENG 0.01 V/step] SM Appendix 3-153 M124/M125...
Page 748 001 Current: Bk *ENG 002 Current: M *ENG [0 to 5.5 / 3.00 / 0.01 V/step] 003 Current: C *ENG 004 Current: Y *ENG Displays or adjusts the Vtref value for each color at developer initialization. 005-008 M124/M125 3-154 SM Appendix...
Page 749 [0.200 to 0.440 / 0.440 / 0.001 V/wt%/step] 012 Upper Sensitivity *ENG Adjusts the upper limit of the TD sensor sensitivity. [0.200 to 0.500 / 0.209 / 0.001 V/wt%/step] 013 Lower Sensitivity *ENG Adjusts the lower limit of the TD sensor sensitivity. SM Appendix 3-155 M124/M125...
Page 750 [0.0 to 5.0 / 0.3 / 0.1 /step] High Coverage *ENG Coefficient: C High Coverage *ENG Coefficient: Y [0.0 to 20.0 / 3.0 / 0.1 %/step] Low Coverage *ENG Adjusts the threshold of the low Threshold coverage. M124/M125 3-156 SM Appendix...
Page 751 Upper Max Correction: *ENG [TonerSupply_MBD] 3230 001 ADD_TIME *ENG [0 to 1000 / 200 / 10 msec/step] 002 ADD_K *ENG 003 ADD_M *ENG [0.00 to 2.00 / 1.00 / 0.01 /step] 004 ADD_C *ENG 005 ADD_Y *ENG SM Appendix 3-157 M124/M125...
Page 752 0.01 /step] 071 AWPUP_LowSpd *ENG [0.00 to 100.00 / 1.00 / 0.01 /step] 090 SMITH_K *ENG 091 SMITH_M *ENG [0.00 to 2.00 / P3c: 0.09, P3d: 0.07 / 092 SMITH_C *ENG 0.01 /step] 093 SMITH_Y *ENG M124/M125 3-158 SM Appendix...
Page 753 [0.00 to 5.00 / 1.00 / 0.01 /step] 180 ANCLA_K *ENG 181 ANCLA_M *ENG [0.000 to 1.000 / P3c: 0.160, P3d: 182 ANCLA_C *ENG 0.210 / 0.001 /step] 183 ANCLA_Y *ENG 184 ANCLB_K *ENG [0.000 to 1.000 / P3c: 0.210, P3d: SM Appendix 3-159 M124/M125...
Page 754 235 PID_I_LIM2_MidSpd *ENG [0.000 to 1.000 / 0.068 / 0.001 /step] 236 PID_I_LIM2_LowSpd *ENG [0.000 to 1.000 / 0.036 / 0.001 /step] [0.000 to 1.000 / P3c: 0.093, P3d: 237 PID_P_LIM1_Std *ENG 0.113 / 0.001 /step] M124/M125 3-160 SM Appendix...
Page 755 003 Vt Proportion: C *ENG 004 Vt Proportion: Y *ENG 005 Pixel Proportion: Bk *ENG 006 Pixel Proportion: M *ENG [0.00 to 2.55 / 0.47 / 0.01 /step] 007 Pixel Proportion: C *ENG 008 Pixel Proportion: Y *ENG SM Appendix 3-161 M124/M125...
Page 756 009 Vt Integral Value: Bk *ENG 010 Vt Integral Value: M *ENG [-255.00 to 255.00 / 0.00 / 0.01 /step] 011 Vt Integral Value: C *ENG 012 Vt Integral Value: Y *ENG 3236 [Toner Supply Consumption:Disp] M124/M125 3-162 SM Appendix...
Page 757 [-1.00 to 0.00 / -0.20 / 0.01 V/step] 014 T Rank 2 Threshold *ENG [0.00 to 1.00 / 0.20 / 0.01 V/step] 021-028 Sets the correction coefficient of the Vtref correction. Correction Coefficient *ENG [0.0 to 1.0 / 0.5 / 0.1/step] 1: Bk SM Appendix 3-163 M124/M125...
Page 758 Adjusts the coefficient for LD power control value at the process control. 001 StdSpd:Coefficient: Bk *ENG 002 StdSpd:Coefficient: M *ENG [-1000 to 1000 / 142 / 1 /step] 003 StdSpd:Coefficient: C *ENG 004 StdSpd:Coefficient: Y *ENG M124/M125 3-164 SM Appendix...
Page 759 011 LowSpd:Coef:C *ENG [0.50 to 1.50 / 0.96 / 0.01 /step] 012 LowSpd:Coef:Y *ENG 013 LowSpd:offset:Bk *ENG [-128 to 127 / 0 / 1 V/step] 014 LowSpd:offset:M *ENG [-128 to 127 / -20 / 1 V/step] SM Appendix 3-165 M124/M125...
Page 760 [1 to 999 / 50 / 1 sheet/step] 020-023 Adjusts the threshold for SP3-251-024 to -027. 020 Total Page Setting: S2 *ENG [1 to 100 / 40 / 1 sheet/step] Total Page Setting: *ENG [1 to 500 / 10 / 1 sheet/step] M124/M125 3-166 SM Appendix...
Page 761 001 Vsg reg: Bk *ENG 002 Vsg reg: M *ENG 003 Vsg reg: C *ENG [0.00 to 5.50 / - / 0.01 V/step] 004 Vsg reg: Y *ENG 005 Vsg dif: M *ENG 006 Vsg dif: C *ENG SM Appendix 3-167 M124/M125...
Page 762 3: Offset voltage error 006 Result: Latest 5 *ENG 2: Vsg adjustment value error 007 Result: Latest 6 *ENG 1: O.K 008 Result: Latest 7 *ENG 009 Result: Latest 8 *ENG 010 Result: Latest 9 *ENG M124/M125 3-168 SM Appendix...
Page 763 [0.000 to 1.000 / 0.250 / 0.001 /step] 018 K2: Check: Y *ENG [0.000 to 1.000 / 0.250 / 0.001 /step] [ID Pattern Timing] 3363 001 Scan: YCMBk *ENG [-50.0 to 50.0 / 0.0 / 0.1 mm/step] SM Appendix 3-169 M124/M125...
Page 764 Adjusts the toner supply rate during 002 Upper Limit: M *ENG printing. 003 Upper Limit: C *ENG [0 to 100 / 100 / 1%/step] 004 Upper Limit: Y *ENG Minimum Supply Time: Adjusts the minimum toner supply *ENG time. M124/M125 3-170 SM Appendix...
Page 765 *ENG 003 Power ON: BW *ENG 004 Power ON: FC *ENG [0 to 2000 / - / 1 page/step] 005 MUSIC: BW *ENG 006 MUSIC: FC *ENG 007 Vsg Adj. *ENG 008 Charge AC Control *ENG SM Appendix 3-171 M124/M125...
Page 766 Correction Coef 1: JE: *ENG [0.00 to 1.00 / 0.50 / 0.01/step] Correction Coef 2: JE: *ENG [0.00 to 1.00 / 1.00 / 0.01/step] 026 Cor Coef 1: Interrupt: BW *ENG [0.00 to 1.00 / 0.10 / 0.01/step] M124/M125 3-172 SM Appendix...
Page 767 These are the results after considering all the conditions. Job End: Pot Control: *ENG [0 to 2000 / - / 1 page/step] 002 Job End: Pot Control: FC *ENG [0 to 2000 / - / 1 page/step] SM Appendix 3-173 M124/M125...
Page 768 [0 to 255 / 34 / 1 cm^2/m/step] 016 Refresh Threshold: C *ENG 017 Refresh Threshold: Y *ENG Pattern Generation *ENG Number: Bk Pattern Generation *ENG [0 to 255 / 0 / 1 time/step] Number: M Pattern Generation *ENG Number: C M124/M125 3-174 SM Appendix...
Page 769 0: OFF 008 MUSIC *ENG 1: ON (once) 2: ON (twice) MUSIC (Skew *ENG Correction) [0 or 1 / 0 / 1 /step] 010 Charge AC Control *ENG 0: OFF 1: ON Blade Damage *ENG Prevention SM Appendix 3-175 M124/M125...
Page 770 When the current condition has changed by more than the values of these 3522 SPs when compared with the conditions at the previous operation, the process control at power on is executed. 002 Non-use Time Setting *ENG [0 to 1440 / 360 / 1 minute/step] M124/M125 3-176 SM Appendix...
Page 771 010 M (Standard Target Set) *ENG /step] [0.00 to 5.00 / 0.83 / 0.01 mg/cm 011 C (Standard Target Set) *ENG /step] [0.00 to 5.00 / 0.79 / 0.01 mg/cm 012 Y (Standard Target Set) *ENG /step] SM Appendix 3-177 M124/M125...
Page 772 001 Plain: Bk *ENG 002 Plain: M *ENG [0 to 800 / - / 1 -V/step] 003 Plain: C *ENG 004 Plain: Y *ENG 005 Thick 1: Bk *ENG [0 to 800 / - / 1 -V/step] M124/M125 3-178 SM Appendix...
Page 773 012 Thick 2 & FINE: Y *ENG [Charge AC Control: Display] Plain: High speed 3641 Displays the charge AC voltage adjusted with the process control for each color. 001 Plain: Bk *ENG [0.00 to 3.00 / - / 0.01 kV/step] SM Appendix 3-179 M124/M125...
Page 774 007 Without Developer *ENG [0.0 to 5.0 / - / 0.1 V/step] 008 With Developer *ENG [0.0 to 5.0 / - / 0.1 V/step] 009 Serial Number 1 *ENG [0 to 255 / - / 1 /step] M124/M125 3-180 SM Appendix...
Page 775 [0.0 to 5.0 / - / 0.1 V/step] 009 Serial Number 1 *ENG [0 to 255 / - / 1 /step] 010 Serial Number 2 *ENG 011 Adjustment: Vt *ENG [0.0 to 5.0 / - / 0.1 V/step] SM Appendix 3-181 M124/M125...
Page 776 Full Displays the pixel counter after Pixel Count After *ENG replacement of toner collection bottle. Replacement [0 to 200000 / - / 1 cm /step] 008 Coefficient *ENG [0.1 to 1.5 / 1.0 / 0.1 /step] M124/M125 3-182 SM Appendix...
Page 777 3 (Replacement and Adjustment). 001 Development Unit: Bk *ENG 002 Development Unit: Y *ENG [0 or 1 / 0 / 1 /step] 003 Development Unit: C *ENG 0: OFF, 1: ON 004 Development Unit: M *ENG SM Appendix 3-183 M124/M125...
Page 778 020 Toner Supply Unit: Bk *ENG 021 Toner Supply Unit: M *ENG [0 or 1 / 0 / 1 /step] 022 Toner Supply Unit: C *ENG 0: OFF, 1: ON 023 Toner Supply Unit: Y *ENG M124/M125 3-184 SM Appendix...
Page 779 Engine SP Tables-4 3.6 ENGINE SP TABLES-4 3.6.1 SP4-XXX (SCANNER) There are no Group 4 SP modes for this machine. SM Appendix 3-185 M124/M125...
Page 780 001 - *CTL 0: ON 1: OFF [Display IP Address] 5055 Display or does not display the IP address on the LCD. [0 or 1 / 0 / 1 /step] 001 - *CTL 0: OFF 1: ON M124/M125 3-186 SM Appendix...
Page 781 Sets the application that appears when the home key is pressed. Home Screen Login *CTL [FFh / 0x0 / 1hex /step ] Setting [0 to 2 / 0 / 1/step ] (0:OFF 1:SDK 0: Function disable *CTL 2:Reserve) 1: SDK application 2: Legacy application (reserved) SM Appendix 3-187 M124/M125...
Page 782 AB system (0), the LT system (1), and the AF system (2). [0 to 2 / P3c:1(NA), 2 (EU, ASIA, CHN, 001 - *ENG TW), P3d:1(NA), 2(EU, ASIA,TW) / 1 / step] *CTL [0: OFF/ 1: ON] 5148 [Size Detection Off] M124/M125 3-188 SM Appendix...
Page 783 005 TRAY 2: 4 *ENG 1(NA) / 1 /step] 0: B5 LEF, 1: Exe LEF [0 or 1 / P3c 0(EU, ASIA, CHN,TW), P3d 006 TRAY 3/T-LCT: 1 *ENG 1(NA) / 1 /step] 0: A4 LEF, 1: LT LEF SM Appendix 3-189 M124/M125...
Page 784 Enables or disables the prevention for RK4 (accounting device) disconnection. 5186 If the RK4 is disconnected for 10 seconds when this SP is set to "1 (Enable)", the machine automatically jams a sheet of paper and stops. M124/M125 3-190 SM Appendix...
Page 785 *CTL [-1440 to 1440 / -300 / 1 min./step] 5307 [Summer Time] [ 0 to 1 / NA, EU, ASIA / 1 /step] 0: Disabled 001 Setting *CTL 1: Enabled NA and EUR: 1, ASIA: 0 SM Appendix 3-191 M124/M125...
Page 786 2: Edit/Delete 3: Full control 104 Authentication Time *CTL [0 to 255 / 0 / 1sec/step] 162 ExtAuth Detail *CTL [ - / 0x00 / 0x01/step] 200 SDK1 UniqueID *CTL [0 to 0xffffffff / 0 / 1/step] M124/M125 3-192 SM Appendix...
Page 787 [Access Control] 101 SDKJ1 Limit Setting *CTL [ / 0x00 / 0x01/step] 102 SDKJ2 Limit Setting *CTL bit0: SDKJ Authentication 103 SDKJ3 Limit Setting *CTL -0: Panel Type 104 SDKJ4 Limit Setting *CTL -1: Remote Type SM Appendix 3-193 M124/M125...
Page 788 -0: OFF, 1: ON 111 SDKJ11 Limit Setting *CTL [ / 0x00 / 0x01/step] 112 SDKJ12 Limit Setting *CTL bit0: SDKJ Authentication 113 SDKJ13 Limit Setting *CTL -0: Panel Type 114 SDKJ14 Limit Setting *CTL -1: Remote Type M124/M125 3-194 SM Appendix...
Page 789 -0: OFF, 1: ON 121 SDKJ21 Limit Setting *CTL [ / 0x00 / 0x01/step] 122 SDKJ22 Limit Setting *CTL bit0: SDKJ Authentication 123 SDKJ23 Limit Setting *CTL -0: Panel Type 124 SDKJ24 Limit Setting *CTL -1: Remote Type SM Appendix 3-195 M124/M125...
Page 790 Not used bit7: Using extended function J limit users -0: OFF, 1: ON 141 SDKJ1 ProductID *CTL 142 SDKJ2 ProductID *CTL [0 to 0xffffffff / 0 / 1/step] 143 SDKJ3 ProductID *CTL 144 SDKJ4 ProductID *CTL M124/M125 3-196 SM Appendix...
Page 791 1: Password NULL permitted. This SP is referenced only when SP5411-4 is set to "1" (On). Detail Option *CTL 0: OFF, 1: ON Determines whether LDAP option (anonymous certification) is turned on or off. 5412 [Krb-Certification] SM Appendix 3-197 M124/M125...
Page 792 [0 to 60 / 15 / 1 min./step] Sets the length of time for excluding continuous access for identical user IDs and passwords. 5415 [Password Attack] 001 Permissible Number *CTL [0 to 100 / 30 / 1 attempt/step] M124/M125 3-198 SM Appendix...
Page 793 [User Authentication] These settings should be done with the System Administrator. 5420 Note: These functions are enabled only after the user access feature has been enabled. SM Appendix 3-199 M124/M125...
Page 794 Determines whether certification is required before a user can use the SDK application. [0 or 1 / 0 / 1] SDK2 *CTL 0: ON. 1: OFF Determines whether certification is required before a user can use the SDK application. M124/M125 3-200 SM Appendix...
Page 795 9999) x 1000 > PM counter [0 or 1 / 0 / 1 /step] 0: No alarm sounds 002 Original Count Alarm *CTL 1: Alarm sounds after the number of originals passing through the ARDF > 10,000 5504 [Jam Alarm Interval] SM Appendix 3-201 M124/M125...
Page 796 0: Off 1: On [0 or 1 / 1 / 1 /step] 007 Tensya Supply Alarm *CTL 0: Off 1: On [0 or 1 / 1 / 1 /step] 008 Fuser Supply Alarm *CTL 0: Off 1: On M124/M125 3-202 SM Appendix...
Page 797 Sets the number of consecutive paper jams required to initiate a call. This setting is enabled only when SP5508-004 is set to "1". Door Open: Time *CTL [3 to 30 / 10 / 1 /step] Length SM Appendix 3-203 M124/M125...
Page 798 (0: Not send, 1: Send) 0: Not send, 1: Send Percent yield for *CTL [1 to 255 / 75 / 1 %/step] triggering PM alert 5730 [Extended Function Setting] Expiration Prior Alarm *CTL [0 to 999 / 20 / 1days/step] M124/M125 3-204 SM Appendix...
Page 799 Option: [Unique] 101 Import Crypt config: [Encryption] Encryption key (if selected) [Execute] Export Result Print [ - / - / - ] (SP) [Execute] Import Result Print [ - / - / - ] (SP) [Execute] SM Appendix 3-205 M124/M125...
Page 800 Gamma settings (User & Service)  Toner Limit The following user settings:  Tray Priority  Menu Protect  System Setting except for setting of Energy Saver  I/F Setup (I/O Buffer and I/O Timeout) PCL Menu M124/M125 3-206 SM Appendix...
Page 801 [ - / - / - ] LCS Memory Clr [Execute] Initializes the LCS settings. Initializes the ECS settings. 021 ECS [- / - / -] [Execute] [ - / - / - ] websys [Execute] 5802 [FreeRun] SM Appendix 3-207 M124/M125...
Page 802 5811 Machine Serial Number Display Display *ENG [0 to 255 / 0 / 1/step] Displays the machine serial number. [0 to 255 / 0 / 1/step] Inputs Novita [0 to 255 / 0 / 1/step] Inputs M124/M125 3-208 SM Appendix...
Page 803 *CTL 0: Start of the service 1: End of the service Performs the CE Call at the start or end of the service.  This SP is activated only when SP 5816-001 is set to “2”. SM Appendix 3-209 M124/M125...
Page 804 RFU Timing *CTL 0: Any status of a target machine 1: Sleep or panel off mode only Selects the timing for the remote firmware updating. 014 RCG Error Cause [0 or 1 / 0 / 1 /step] M124/M125 3-210 SM Appendix...
Page 805 RCG-N and the gateway. This setting is necessary to set up the embedded RC Gate-N.  This port number is customer information and is not printed in the SMC report. 065 Proxy User Name *CTL SM Appendix 3-211 M124/M125...
Page 806 The certification has been stored, and the GW URL is being notified of the successful completion of this event. The storing of the certification has failed, and the GW URL is being notified of the failure of this event. M124/M125 3-212 SM Appendix...
Page 807 Allows the service technician to confirm the size of the firmware data files during the firmware update execution. CERT: Macro Ver. Displays the macro version of the @Remote certification. CERT: PAC Ver. Displays the PAC version of the @Remote certification. 089 CERT: ID2 Code SM Appendix 3-213 M124/M125...
Page 808 If the execution succeeded, SP5816-153 will display the result for confirmation and SP5816-154 will display the telephone number for the connection to the outside line. Manual Polling Executes the manual polling. 201 Regist Status [0 to 4 / 0 / 1 /step] M124/M125 3-214 SM Appendix...
Page 809 Displays the result of the notification sent to the device from the GW URL in answer to the inquiry request. Displayed only when the result is registered at the GW URL. Register Execute Executes "Embedded RCG Registration". 207 Register Result [0 to 255 / 0 / 1 /step] SM Appendix 3-215 M124/M125...
Page 810 A confirmation request was made after -12006 the confirmation had been already completed. Operation Error, The request number used at Incorrect Setting -12007 registration was different from the one used at confirmation. Update certification failed because -12008 mainframe was in use. M124/M125 3-216 SM Appendix...
Page 811 [0 to 16 characters / /RCG/services/ / - RCG URL Path *CTL /step] Sets the URL path of the RCG (Remote Communication Gate) destination for call processing at the remote service center. 5824 [NV-RAM Data Upload] SM Appendix 3-217 M124/M125...
Page 812 Mask started up with DHCP. This SP allows you to check the IPv4 default Active IPv4 Gateway gateway setting that was used when the machine Address started up with DHCP. M124/M125 3-218 SM Appendix...
Page 813 This SP determines whether job spooling is enabled or disabled for each protocol. This is an 8-bit setting. BMLinks (Japan Only) FTP (Not Used) DIPRINT Reserved (Not Used) Reserved (Not Used) 087 Protocol Usingage *CTL [0 or 1 / 0x00000000 / 1/step] SM Appendix 3-219 M124/M125...
Page 814 (802.11b) in the format: Address 3 "Status Address" + "Prefix Length" The IPv6 address consists of a total 128 bits Active IPv6 Stateless Address 4 configured in 8 blocks of 16 bits each. Active IPv6 Stateless Address 5 M124/M125 3-220 SM Appendix...
Page 815 Web shopping link *CTL 0: Not display visible 1:Display Displays or does not display the link to Net RICOH on the top page and link page of the web system. [0 to 1 / 1 / 1 /step] Web supplies Link *CTL...
Page 816 Initializes the hard disk. Use this SP HDD Formatting (Job mode only if there is a hard disk error. Log) [ - / - / - ] HDD Formatting [Execute] (Printer Fonts) HDD Formatting (User Info1) M124/M125 3-222 SM Appendix...
Page 817 HDD Formatting (Ridoc I/F) 5840 [IEEE 802.11] Range: DOM 1-14 NA/CHN/TW 1-11 EU 1-13 006 Channel MAX *CTL Default: DOM 14 NA/CHN/TW 11 EU 13 Range: DOM 1-14 007 Channel MIN *CTL NA/CHN/TW 1-11 EU 1-13 Default: 1 SM Appendix 3-223 M124/M125...
Page 818 [1 to 3 / 3 / 1/step] 1: Info WPA Debug Lvl *CTL 2: warning 3: error Selects the debug level for WPA authentication application. This SP is displayed only when the IEEE802.11 card is installed. 5841 [Supply Name Setting] M124/M125 3-224 SM Appendix...
Page 819 5bit: output related(print, FAX, and delivery) group 6bit: repository, F0,etc. document related group 7bit: debug log level suppression Default: 00000000 – do not change Netfiles: Jobs to be printed from the document server using a PC and the DeskTopBinder software SM Appendix 3-225 M124/M125...
Page 820 SP code.  At times other than initialization, the value set for this SP code is used. [0 to 1 / 1 / 1 /step] 100 Notify Unsupport *CTL 0: Function enable 1: Function disable M124/M125 3-226 SM Appendix...
Page 821 5. However, at this point the address book can be accessed by only the system administrator or key operator. 6. Enter the SP mode and do SP5846-041. After this SP executes successfully, any user can access the address book. SM Appendix 3-227 M124/M125...
Page 822 After you do this SP, go out of the SP mode, and then turn the power off.  Do not remove the SD card until the Power LED stops flashing. 060 Search option *CTL [0x00 to 0xff / 0x0f / 1 /step] M124/M125 3-228 SM Appendix...
Page 823 4 bits) Switches access control on and off. Access Ctrl: Job Ctrl [0000 or 0001 / 0000 / 1/step] *CTL (Lower 4 bits) 0000: No access control Access Ctrl: 0001: Access control Devicemanagement *CTL (Lower 4bits) SM Appendix 3-229 M124/M125...
Page 824 [0 or 1 / 0 / 1 /step] On/Off (1:ON 0:OFF) *CTL 0: OFF 1: ON Switches the debug log feature on and off. The debug log cannot be captured until this feature is switched on. M124/M125 3-230 SM Appendix...
Page 825 Erases all debug logs on the SD Card. If the card contains only debugging files generated by an event specified by SP5858, the files are erased when SP5857 010 or 011 is executed. To enable this SP, the machine must be cycled off and on. SM Appendix 3-231 M124/M125...
Page 826 5859 These SPs allow you to set up to 10 keys for log files for functions that use common memory on the controller board. 001 Key 1 *CTL [–9999999 to 9999999 / 0 / 1 /step] M124/M125 3-232 SM Appendix...
Page 827 1: Internet Draft standard 2: RFC standard Selects the MIME header type of an E-mail sent by S/MIME. 5866 [E-Mail Report] [0 to 1 / 0 / 1/step] Report Validity 0: Enable, 1: Disable Enables/disables each function. SM Appendix 3-233 M124/M125...
Page 828 Then turn the machine off and on. 5881 [Fixed Phrase Block Erasing] Fixed Phase Block [- / - / -] Erasing [Execute] Deletes the fixed phrase. [Line Speed Selection] 5883 Selects the line speed for middle thick paper. M124/M125 3-234 SM Appendix...
Page 829 Displays the counter name of each SDK application. 001 SDK-1 002 SDK-2 003 SDK-3 004 SDK-4 005 SDK-5 006 SDK-6 [External Counter Setting] 5894 Test Name1_1 001 Switch Charge Mode *ENG [0 to 2 / 0 / 1/step] SM Appendix 3-235 M124/M125...
Page 830 SP is set to "2".Even though you can change the initial settings of those network applications, the settings do not work. [0 or 1 / 0 / 1/step] 002 On Board USB 0: Disable, 1: Enable M124/M125 3-236 SM Appendix...
Page 831 021 Copier User Program 022 Scanner SP 023 Scanner User Program 024 SDK/J Summary 025 SDK/J Application Info 026 Printer SP mode [Fusing Cont mode] Fusing Control Mode 5998 Turns the silent fusing warm-up mode on or off. SM Appendix 3-237 M124/M125...
Page 832 Engine SP Tables-5 [0 or 1 / 1 / 1 /step ] 001 fast/silent *ENG 0: Silent (less noise) 1: Fast (less time) M124/M125 3-238 SM Appendix...
Page 833 Adjusts the paper buckle for each paper size. 001 A3T 002 B4T 003 A4T 004 A4Y 005 B5T 006 B5Y *ENG [-5.0 to 5.0 / 0 / 0.2 mm/step] 007 DLT-T 008 LG-T 009 LT-T 010 LT-Y 011 12*18 012 Other SM Appendix 3-239 M124/M125...
Page 834 Adjusts the staple position for each finisher (B408/B804/B805). 6133 + Value: Moves the staple position to the rear side. - Value: Moves the staple position to the front side. 001 Finisher1 *ENG [-3.5 to 3.5 / 0 / 0.5/step] M124/M125 3-240 SM Appendix...
Page 835 [1 to 30 / 2 / 1 time/step] Sets the number of times that folding is done in the Booklet Finisher B804. [Fin. Free Run] 6137 Sets the finisher free run on/off. 001 Free Run1 [0 or 1 / 0 / 1 /step] SM Appendix 3-241 M124/M125...
Page 836 [-1.5 to 1.5 / 0.0 / 0.5mm/step] 006 A5Y *ENG [-1.5 to 1.5 / 0.0 / 0.5mm/step] 007 DLT-T *ENG [-1.5 to 1.5 / 0.0 / 0.5mm/step] 008 LG-T *ENG [-1.5 to 1.5 / 0.0 / 0.5mm/step] M124/M125 3-242 SM Appendix...
Page 837 6154 Displays the signals received from sensors and switches of the 1 bin tray (D536) See “Input Check” ( p.448). 6155 [OUTPUT Check] [0 or 1 / 0 / 1/step] 001 1 bin: Junction Solenoid On/Off SM Appendix 3-243 M124/M125...
Page 838 Staple positions other *CTL [0 to 50 / 0 / 1/step] than booklet stapling 002 2 Booklet stapling *CTL [0 to 50 / 0 / 1/step] M124/M125 3-244 SM Appendix...
Page 839 SC code logs. 001 Latest *CTL 002 Latest 1 *CTL 003 Latest 2 *CTL 004 Latest 3 *CTL [- / - / -] 005 Latest 4 *CTL 006 Latest 5 *CTL 007 Latest 6 *CTL SM Appendix 3-245 M124/M125...
Page 840 Registration Sn: On *CTL (Tray) For details, see “Jam Detection” in the 018 Fusing Entrance: On *CTL "Main Chapters: 6. Troubleshooting". 019 Fusing Exit: On *CTL 020 Paper Exit: On *CTL 021 Bridge Tray Exit: On *CTL M124/M125 3-246 SM Appendix...
Page 841 103 Finisher Exit: KIN *CTL Finisher Tray Lift Motor: *CTL Finisher Jogger Motor: *CTL For details, see “Jam Detection” in the "Main Chapters: 6. Troubleshooting". Finisher Shift Motor: *CTL Finisher Staple Motor: *CTL 109 Finisher Exit Motor: KIN *CTL SM Appendix 3-247 M124/M125...
Page 842 132 A3 SEF *CTL 133 A4 SEF *CTL 134 A5 SEF *CTL 141 B4 SEF *CTL [0 to 9999 / - / 1 sheet/step ] 142 B5 SEF *CTL 160 DLT SEF *CTL 164 LG SEF *CTL M124/M125 3-248 SM Appendix...
Page 843 102 Engine 107 Finisher [- / - / -] 111 MailBox Lists ROM No. and Firmware versions on ROM No./ Firmware the display. Version [- / - / -] 7803 [PM Counter Display] (Page, Unit, [Color]) SM Appendix 3-249 M124/M125...
Page 844 014 Page: Image Transfer 015 Page: Cleaning Unit 016 Page: Fusing Unit [ 0 to 9999999 / - / 1 page/step ] Page: Paper Transfer Unit Page: Toner Collection Bottle 019 Page: Fusing Belt Unit 020 Page: Pressure Roller M124/M125 3-250 SM Appendix...
Page 845 Rotation: Development Unit: M Rotation: Development Unit: C Rotation: Development Unit: Y Rotation: Developer: [ 0 to 999999999 / - / 1 mm/step ] 040 Rotation: Developer: M 041 Rotation: Developer: C 042 Rotation: Developer: Y SM Appendix 3-251 M124/M125...
Page 846 R (%) counter is still less than 100%. 061 Rotation (%): PCU: Bk 062 Rotation (%): PCU: M 063 Rotation (%): PCU:C [0 to 255 / - / 1 %/step] 064 Rotation (%): PCU:Y 079) Rotation (%): Development Unit: Bk M124/M125 3-252 SM Appendix...
Page 847 If the revolution count lifetime is reached first, the machine also enters the end condition, even though the Run Time (%) counter is still less than 100%. Run Time(%):Toner [0 to 255 / - / 1 %/step] Supply Unit: Bk SM Appendix 3-253 M124/M125...
Page 848 101 Page (%): Developer: C 102 Page (%): Developer: Y [0 to 255 / - / 1 %/step] Page (%): Image 091) Transfer Page (%): Cleaning Unit 105 Page (%): Fusing Unit Page (%): Paper Transfer Unit M124/M125 3-254 SM Appendix...
Page 849 PM counter value in SP7-906 (PM Counter - Previous) and reset the value of the current PM counter (SP7-803) to “0”. [- / - / -] 001 PM Counter Reset [Execute] 002 PCU: Bk [- / - / -] 003 PCU: M [Execute] 004 PCU: C SM Appendix 3-255 M124/M125...
Page 850 This SP doesn’t delete either jam histories or SC code histories. [ - / - / - ] 001 SC/Jam Clear [Execute] [Self-Diagnose Result Display] 7832 Displays the result of the diagnostics. 001 Diag. Result *CTL [ - / - / - ] M124/M125 3-256 SM Appendix...
Page 851 018 Fusing Belt Unit 019 Pressure Roller 020 Toner Supply Unit: Bk 021 Toner Supply Unit: M [0 to 255 / - / 1 /step] 022 Toner Supply Unit: C 023 Toner Supply Unit: Y 7855 [Coverage Range] SM Appendix 3-257 M124/M125...
Page 852 (Page or Rotations, Unit, [Color]), Dev.: Development Unit 001 to Displays the number of sheets printed with the previous maintenance units. 001 Page: PCU: Bk [0 to 9999999 / - / 1 page/step] 002 Page: PCU: M M124/M125 3-258 SM Appendix...
Page 853 Displays the number of revolutions for motors or clutches in the previous maintenance units. ( 031 - 046) 031 Rotation: PCU: Bk [0 to 999999999 / - / 1 mm/step] 032 Rotation: PCU: M 019) 033 Rotation: PCU: C SM Appendix 3-259 M124/M125...
Page 854 Displays the running time of the previous pump unit Run Time: Toner Supply Unit: Bk Run Time: Toner Supply Unit: M [0 to 999999999 / - / 1 msec/step] Run Time: Toner Supply Unit: C Run Time: Toner Supply Unit: Y M124/M125 3-260 SM Appendix...
Page 855 Rotation %: Image Transfer Belt [0 to 255 / - / 1 %/step] Rotation %: Cleaning Unit 075 Rotation %: Fusing Unit Rotation %: Paper Transfer Unit Measurement %: Tonner Collection bottle Rotation (%): Fusing Belt Unit SM Appendix 3-261 M124/M125...
Page 856 094 Page %: PCU: Y Page %: Development Unit: Bk Page %: Development [0 to 255 / - / 1 %/step] Unit: M Page %: Development Unit: C Page %: Development Unit: Y 099 Page %: Developer: Bk M124/M125 3-262 SM Appendix...
Page 857 [0 or 1 / - / 1 /step] 011 Serial No. *ENG 012 Toner Remaining *ENG [0 to 100 / - / 1 %/step] 013 EDP Code *ENG [0 or 1 / - / 1 /step] SM Appendix 3-263 M124/M125...
Page 858 *ENG [0 to 99999999 / - / 1 /step] Counter 018 End: Total Counter *ENG 019 End: Color Counter *ENG 020 Attachment Date *ENG [0 or 1 / - / 1 /step] 021 End Date *ENG M124/M125 3-264 SM Appendix...
Page 859 002 Cartridge Ver *ENG 003 Brand ID *ENG 004 Area ID *ENG 005 Product ID *ENG [0 to 255 / - / 1 /step] 006 Color ID *ENG 007 Maintenance ID *ENG New Product *ENG Information SM Appendix 3-265 M124/M125...
Page 860 [0 or 1 / - / 1 /step] 022 Attachment Date [0 or 1 / - / 1 /step] Attachment: Total [0 to 99999999 / - / 1 /step] Counter 024 Refill Information *ENG [0 or 1 / - / 1 /step] M124/M125 3-266 SM Appendix...
Page 861 [0 or 1 / - / 1 /step] 022 Attachment Date [0 or 1 / - / 1 /step] Attachment: Total [0 to 99999999 / - / 1 /step] Counter 024 Refill Information *ENG [0 or 1 / - / 1 /step] SM Appendix 3-267 M124/M125...
Page 862 [0 or 1 / - / 1 /step] 022 Attachment Date [0 or 1 / - / 1 /step] Attachment: Total [0 to 99999999 / - / 1 /step] Counter 024 Refill Information *ENG [0 or 1 / - / 1 /step] M124/M125 3-268 SM Appendix...
Page 863 [0 or 1 / - / 1 /step] 022 Attachment Date [0 or 1 / - / 1 /step] Attachment: Total [0 to 99999999 / - / 1 /step] Counter 024 Refill Information *ENG [0 or 1 / - / 1 /step] SM Appendix 3-269 M124/M125...
Page 864 015 Toner Supply Unit: Y *ENG [Remaining Day Counter] 7951 Displays the remaining unit life of each PM unit. 001 Page: PCU: Bk 002 Page: PCU: M [0 to 255 / 255 / 1 day/step] 003 Page: PCU: C M124/M125 3-270 SM Appendix...
Page 865 032 Rotation: PCU: M [0 to 255 / 255 / 1 day/step] 033 Rotation: PCU: C 034 Rotation: PCU: Y Rotation: Development Unit: Bk [0 to 255 / 255 / 1 day/step] Rotation: Development Unit: M SM Appendix 3-271 M124/M125...
Page 866 Minimum: Development [0 to 255 / 255 / 1 day/step] Unit: Bk For toner collection bottle, this SP is not Minimum: Development displayed because its Remaining Day Unit: M Counters is calculated with its weights M124/M125 3-272 SM Appendix...
Page 867 [0 to 999999999 / 303401000 / 1 Transfer Belt mm/step] [0 to 999999999 / 151701000 / 1 002 Rotation: Cleaning Unit mm/step] [0 to 999999999 / P3c: 153198000, P3d: 003 Rotation: Fusing Unit 170257000 / 1 mm/step] SM Appendix 3-273 M124/M125...
Page 868 Development Unit: M [1 to 30 / 15 / 1 day/step] Day Threshold: These threshold days are used for Development Unit: C @Remote alarms. Day Threshold: Development Unit: Y Day Threshold: Developer: Bk Day Threshold: Developer: M M124/M125 3-274 SM Appendix...
Page 869 051 Page: PCU: M [0 to 999999 / 0 / 1 sheet/step] 052 Page: PCU: C 053 Page: PCU: Y Page: Development Unit: Bk [0 to 999999 / 0 / 1 sheet/step] Page: Development Unit: M SM Appendix 3-275 M124/M125...
Page 870 [0 to 99999999 / - / 1 mm/step] 006 5<T<15:30<=H<55 007 5<T<15:55<=H<80 008 5<T<15:80<=H<=100 009 15<=T<25:0<=H<30 010 15<=T<25:30<=H<55 011 15<=T<25:55<=H<80 012 15<=T<25:80<=H<=100 013 25<=T<30:0<=H<30 014 25<=T<30:30<=H<55 [0 to 99999999 / - / 1 mm/step] 015 25<=T<30:55<=H<80 016 25<=T<30:80<=H<=100 017 30<=T<35:0<=H<30 M124/M125 3-276 SM Appendix...
Page 871 180473000 / 1 mm/step] Displays the threshold distance for the heating roller near end. [0 to 999999999 / P3c: 168518000, P3d: End: Rotation 187283000 / 1 mm/step] Displays the threshold distance for the heating roller end. SM Appendix 3-277 M124/M125...
Page 872 SP that you do not understand. Key for Abbreviations Abbreviation What it means "By", e.g. "T:Jobs/Apl" = Total Jobs "by" Application > More (2> "2 or more", 4> "4 or more" M124/M125 3-278 SM Appendix...
Page 873 Local Storage. Refers to the document server. LSize Large (paper) Size Magnification One color (monochrome) New Remote Service, which allows a service center to monitor machines remotely. "NRS" is used overseas, "CSS" is used in Japan. Original for scanning OrgJam Original Jam SM Appendix 3-279 M124/M125...
Page 874 All of the Group 8 SPs are able to reset by “SP5 801 1 Memory All Clear”. These SPs count the number of times T:Total Jobs *CTL 8001 each application is used to do a job. M124/M125 3-280 SM Appendix...
Page 875 Number of jobs started out of Sort mode. 806x 3 Staple Number of jobs started in Staple mode. Number of jobs started in Booklet mode. If the 806x 4 Booklet machine is in staple mode, the Staple counter also increments. SM Appendix 3-281 M124/M125...
Page 876 If the finisher runs out of staples during a print and staple job, then the job is counted at the time the error occurs.  When printing the first page of a job from within the document server screen, the page is counted. M124/M125 3-282 SM Appendix...
Page 877 This SP counts the amount of paper (front/back counted as 1 page) used for 8411 Prints/Duplex *CTL duplex printing. Last pages printed only on one side are not counted. [0 to 99999999 / 0 / 1] SM Appendix 3-283 M124/M125...
Page 878 ISO standards for the reduction of paper consumption.  Pages that are only partially printed with the n-Up functions are counted as 1 page.  Here is a summary of how the counters work for Booklet and Magazine modes: Booklet Magazine M124/M125 3-284 SM Appendix...
Page 879 These SPs count by print paper size the number of pages printed by the printer application. O:PrtPGS/Ppr Size *CTL [0 to 99999999 / 0 / 1] 8447 These SPs count by print paper size the number of pages printed by Other applications. SM Appendix 3-285 M124/M125...
Page 880 *CTL Currently not used. 014 Tray 13 *CTL Currently not used. 015 Tray 14 *CTL Currently not used. 016 Tray 15 *CTL Currently not used. 8461 T:PrtPGS/Ppr Type *CTL [0 to 99999999 / 0 / 1] M124/M125 3-286 SM Appendix...
Page 881 Magnification adjustments done for adjustments after they have been stored on the document server are not counted.  Magnification adjustments performed automatically during Auto Reduce/Enlarge copying are counted.  The magnification rates of blank cover sheets, slip sheets, etc. are automatically assigned a SM Appendix 3-287 M124/M125...
Page 882 8 51x 6 GL/GL2 8 51x 7 R55 8 51x 8 RTIFF 8 51x 9 PDF 8 51x 10 PCL5e/5c 8 51x 11 PCL XL 8 51x 12 IPDL-C 8 51x 13 BM-Links Japan Only 8 51x 14 Other M124/M125 3-288 SM Appendix...
Page 883 The counts for staple finishing are based on output to the staple tray, so jam recoveries are counted. This SP counts the amount of staples 8531 Staples *CTL used by the machine. [0 to 9999999 / 0 / 1] 8551 T:FIN Books 001 Perfect-Bind *CTL Not used SM Appendix 3-289 M124/M125...
Page 884 [0 to 99999999 / 0 / 1] 005 Development: K *CTL 008 Print: Color *CTL 009 Print: B/W *CTL 010 Total: Color *CTL 011 Total: B/W *CTL [0 to 99999999 / 0 / 1] 012 Full Color: A3 *CTL M124/M125 3-290 SM Appendix...
Page 885 These SPs count the totals for A3/DLT paper use, number of duplex pages 8591 printed, and the number of staples used. These totals are for Other (O:) applications only. 001 A3/DLT *CTL [0 to 99999999 / 0 / 1] 002 Duplex *CTL 8601 T: Coverage Counter SM Appendix 3-291 M124/M125...
Page 886 [0 to 99999999 / 0 / 1] 004 SDK-4 *CTL 005 SDK-5 *CTL 006 SDK-6 *CTL Func Use Counter 8621 001 Function-001 *CTL 002 Function-002 *CTL [0 to 99999999 / 0 / 1] 003 Function-003 *CTL 004 Function-004 *CTL M124/M125 3-292 SM Appendix...
Page 887 *CTL [0 to 99999999 / 0 / 1] 036 Function-036 *CTL 037 Function-037 *CTL 038 Function-038 *CTL 039 Function-039 *CTL 040 Function-040 *CTL 041 Function-041 *CTL [0 to 99999999 / 0 / 1] 042 Function-042 *CTL SM Appendix 3-293 M124/M125...
Page 888 These SPs display the number of already replaced toner bottles. 8781 NOTE: Currently, the data in SP7-833-011 through 014 and the data in SP8-781-001 through 004 are the same. 001 Toner: BK The number of black-toner bottles 002 Toner: Y The number of yellow-toner bottles M124/M125 3-294 SM Appendix...
Page 889 105 Combine:Last *CTL 106 Color(%):Last *CTL 107 Full Color (%):Last *CTL 108 Duplex (%):Last *CTL [0 to 100 / 0 / 1% /step] 109 Combine (%):Last *CTL 110 Paper Cut (%):Last *CTL 8851 Cvr Cnt: 0-10% SM Appendix 3-295 M124/M125...
Page 890 [0 to 99999999 / 0 / 1] 003 M *ENG 004 C *ENG CVr Cnt: 31%- 8881 These SPs display the number of scanned sheets on which the coverage of each color is 31% or higher. M124/M125 3-296 SM Appendix...
Page 891 011 Coverage /P: Bk *CTL 012 Coverage /P: Y *CTL [0 to 99999999 / 0 / 1] 013 Coverage /P: M *CTL 014 Coverage /P: C *CTL 031 Coverage(%):Eco BK *CTL [0 to 2147483647 / 0 / 1% /step] SM Appendix 3-297 M124/M125...
Page 892 Total time when original jams have been staying 008 OrgJam during scanning. 009 Supply PM Unit End Total time when toner end has been staying Electricity Status 8961 001 Ctrl Standby Time *CTL [0 to 99999999 / 0 / 1] M124/M125 3-298 SM Appendix...
Page 893 [0 to 99999999 / 0 / 1] 009 Printer: Two Color 012 A3/DLT 013 Duplex 026 Printer: Full Color(%) 027 Printer: BW(%) [0 to 2147483647 / 0 / 1] 028 Printer: Single Color(%) 029 Printer: Two Color(%) SM Appendix 3-299 M124/M125...
Page 894 015 2nd Paper Feed Sensor 016 Exit Sensor 017 Tray Full Exit Sensor 018 Fusing Exit Sensor 019 Fusing Entrance Sensor 020 1st Feed Sensor 021 2nd Feed Sensor 022 Duplex Exit Sensor 023 Registration Sensor M124/M125 3-300 SM Appendix...
Page 895 057 AC Control board Cooling Fan: Lock 058 Airflow Fan: Middle 1: Lock 059 Airflow Fan:Middle 2:Lock 060 ITB Contact Motor Position Paper Transfer Contact Motor Position 062 Tonner Relay Motor: Lock 063 ITB Drive Motor:Lock K Drum/Devlopment Drive Motor: Lock SM Appendix 3-301 M124/M125...
Page 896 Near end Almost empty Table 2: Paper Size Switch (Tray 2) Switch 1 is used for tray set detection. 0: Pushed, 1: Not pushed Models Switch Location North America Europe/Asia 4 (bit0) 3 (bit1) 2 (bit2) M124/M125 3-302 SM Appendix...
Page 897 HLT SEF A5 SEF HLT SEF A5 SEF LT/LG SEF* A4 SEF LT/LG SEF* A5 LEF LT/LG SEF* A4 SEF LT/LG SEF* A5 LEF DLT SEF A3 SEF LT LEF A4 LEF DLT SEF A3 SEF SM Appendix 3-303 M124/M125...
Page 898 021 Shift Exit Sensor 022 Proof Exit Sensor 023 Exit Guide Plate HP Sensor 024 Proof Full Sensor 025 Upper Cover Sensor 026 Door SW 027 Clincher Timing Sensor 028 Clincher HP Sensor 029 Driver Timing Sensor M124/M125 3-304 SM Appendix...
Page 899 010 Staple READY Detection 011 Exit Guide Plate HP 012 Shift HP Sensor 013 Paper Sensor 014 Tray Lower Sensor 015 Proof Full Sensor [FIN (EUP) INPUT Check] Finisher (B804/B805) Reading 6140 Description 001 Entrance Sensor SM Appendix 3-305 M124/M125...
Page 900 Junction Gate Open/Close HP Sensor 031 Leading Edge Detection Sensor 032 Drive Roller HP Sensor 033 Arrival Sensor 034 Rear Edge Fence HP Sensor 035 Folder Cam HP Sensor 036 Folder Plate HP Sensor 037 Folder Pass Sensor M124/M125 3-306 SM Appendix...
Page 901 [FIN (ELB) INPUT Check] Finisher (B804/B805) Reading 6141 Description 001 Entrance Sensor 002 Hitroll HP Sensor 003 Front Jogger HP Sensor 004 Rear Jogger HP Sensor 005 Staple Tray Paper Sensor 006 Staple Moving HP Sensor SM Appendix 3-307 M124/M125...
Page 902 Bridge Unit (D386) / Side Tray (D542) Reading 6150 Description 001 Bridge/Left: Exit Sensor 002 Bridge/Left: Feed Sensor 003 Bridge/Left/Shift: Set Detection 004 Bridge/Left: Exit Cover Detection 005 Bridge/Left: Feed Cover Detection 006 Left:Left Exit Sensor M124/M125 3-308 SM Appendix...
Page 903 006 Bank: Tray5: Vertical Feed Sensor 007 Bank: Feed Cover Detection 011 Bank: LCT: Paper Replenishment 012 Bank: LCT: Slide 3.11.2 OUTPUT CHECK TABLE Copier 5804 Display Description 003 Drum/Dev Motor:K: HighSpeed 004 Drum/Dev Motor:K: MiddleSpeed SM Appendix 3-309 M124/M125...
Page 904 060 Regist Motor: HighSpeed 061 Regist Motor: MiddleSpeed 062 Regist Motor: LowSpeed Duplex Feed Motor: CW: HighSpeed Duplex Feed Motor: CW: MiddleSpeed Duplex Feed Motor: CW: LowSpeed Duplex Feed Motor: CCW: HighSpeed Duplex Feed Motor: CCW: MiddleSpeed M124/M125 3-310 SM Appendix...
Page 905 114 PSU Cooling Fan 115 2nd Duct Fan1 117 3rd Duct Fan 119 Paper Exit Fan 121 QSU Heater Cooling Fan 122 AC Control board Cooling Fan 126 Development Clutch: Bk 127 Development Clutch: M 128 Development Clutch: C SM Appendix 3-311 M124/M125...
Page 906 166 HST Sensor:Bk 167 HST Sensor:M 168 HST Sensor:C 169 HST Sensor:Y 170 Toner End Sensor: K 171 Toner End Sensor: M 172 Toner End Sensor: C 173 Toner End Sensor: Y 174 TM Sensor:F 175 TM Sensor:C M124/M125 3-312 SM Appendix...
Page 907 237 PP: ChargeDC: K: HighSpeed 238 PP: ChargeDC: K: MiddleSpeed 239 PP: ChargeDC: K: LowSpeed 244 PP: ChargeDC: M: HighSpeed 245 PP: ChargeDC: M: MiddleSpeed 246 PP: ChargeDC: M: LowSpeed 251 PP: ChargeDC: M: HighSpeed 252 PP: ChargeDC: M: MiddleSpeed SM Appendix 3-313 M124/M125...
Page 908 020 Jogger Motor Punch Registration Moving Motor 022 Punch Motor 023 Punch Moving Motor [FIN (KIN) OUTPUT Check] 6143 Display Description 001 Relay Up Motor 002 Relay Down Motor 003 Exit Motor 004 Proof Junction Gate SOL M124/M125 3-314 SM Appendix...
Page 909 018 Trailing Edge Hold Solenoid Positioning Roller Solenoid 019 Saddle Stitch Hold Solonoid Booklet Pressure Roller Solenoid Stack Junction Gate Stack Junction Gate Motor Open/Close Motor Trailing Edge Fence Moving Fold Unit Bottom Fence Lift Motor Motor SM Appendix 3-315 M124/M125...
Page 910 005 Staple Moving Motor 006 Stack Feed-out Motor 007 Tray Motor 008 Staple Motor 009 Stopper Solenoid 013 Exit Guide Plate Motor FIN(JAK)OUTPUT Check 6147 Display Description 001 Feed Motor 002 Solenoid 1 003 Solenoid 2 004 Solenoid 3 M124/M125 3-316 SM Appendix...
Page 911 Display Description 001 ShiftTray: Motor 1 Bin Tray (D536) 6155 Display Description 001 1 bin: Junction Solenoid 6157 Display Description 001 4 bin: Junction Solenoid Two-Tray Paper Feed Unit (D537)/ LCT 2000 (D538)/ LCT 1200 (D539) SM Appendix 3-317 M124/M125...
Page 912 Bank2: Feed Motor: LowSpeed/Fan Bank2: Feed Motor: LowIncreaseSpeed/Fan 030 Bank: Tray3: PU Solenoid 031 Bank: Tray4: PU Solenoid 032 Bank: Tray5: PU Solenoid 035 Bank: Tray3: Feed Clutch 036 Bank: Tray4: Feed Clutch 037 Bank: Tray5: Feed Clutch M124/M125 3-318 SM Appendix...
Page 913 D386/D634 BRIDGE UNIT BU3030/BU3060 R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New None...
Page 915 BRIDGE UNIT BU3030/BU3060 (D386/D634) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 BRIDGE UNIT CONTROL BOARD ..............1 1.2 BRIDGE UNIT DRIVE MOTOR ..............2 1.3 TRAY EXIT SENSOR ..................3 1.4 RELAY SENSOR ................... 4 2. DETAILS ..................5 2.1 MECHANICAL COMPONENT LAYOUT ............
Page 917 READ THIS FIRST Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the  replacement procedures in this manual. When taking apart the bridge unit, first take the unit out of the copier. Symbols Used in this Manual This manual uses the following symbols.
Page 919 Bridge Unit Control Board 1. REPLACEMENT AND ADJUSTMENT 1.1 BRIDGE UNIT CONTROL BOARD 1. Bridge unit ( "Installation Procedure" in the base copier manual) 2. Rear cover [A] ( x 2) 3. Bridge unit control board [B] ( x 3,  x 4) D386/D634...
Page 920 Bridge Unit Drive Motor 1.2 BRIDGE UNIT DRIVE MOTOR 1. Bridge unit ( "Installation Procedure" in the base copier manual) 2. Rear cover ( "Bridge Unit Control Board") 3. Bracket [A] ( x 3,  x 2) 4. Bridge unit drive motor [B] ( x 4,  x 1) D386/D634...
Page 921 Tray Exit Sensor 1.3 TRAY EXIT SENSOR 1. Bridge unit ( "Installation Procedure" in the base copier manual) 2. Rear cover ( "Bridge Unit Control Board") 3. Paper tray [A] 4. Exit guide [B] ( x 1) 5. Tray exit sensor [C] ( x 1) D386/D634...
Page 922 Relay Sensor 1.4 RELAY SENSOR 1. Bridge unit ( "Installation Procedure" in the base copier manual) 2. Paper tray [A] 3. Relay sensor [B] ( x 1) D386/D634...
Page 923 Mechanical Component Layout 2. DETAILS 2.1 MECHANICAL COMPONENT LAYOUT 1. Upper Exit Roller 5. Relay Sensor 2. Tray Exit Sensor 6. 2nd Transport Roller 3. Junction Gate 7. Left Exit Roller 4. 1st Transport Roller 8. Paper Tray D386/D634...
Page 924 Drive Layout 2.2 DRIVE LAYOUT 1. Left Exit Roller 2. 2nd Transport Roller 3. 1st Transport Roller 4. Upper Exit Roller 5. Bridge Unit Drive Motor D386/D634...
Page 925 Electrical Component Layout 2.3 ELECTRICAL COMPONENT LAYOUT 1. Left Guide Switch 2. Right Guide Switch 3. Junction Gate Solenoid 4. Tray Exit Sensor 5. Bridge Unit Control Board 6. Bridge Unit Drive Motor 7. Relay Sensor D386/D634...
Page 926 Electrical Component Description 2.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Drive Motor Drives the bridge unit. Sensors Tray Exit Checks for misfeeds. Relay Checks for misfeeds. Switches Right Guide Detects when the right guide is opened. Left Guide Detects when the left guide is opened.
Page 927 Junction Gate Mechanism 2.5 JUNCTION GATE MECHANISM The junction gate [A] directs any paper reaching the bridge unit to either the upper tray (on top of the bridge unit) or to the finisher, depending on which has been selected. If the junction gate solenoid has been activated, the junction gate [A] points downward and directs the paper to the upper tray [B] (dotted line path in illustration).
Page 928 PB3110(D537)/PB3130(D580) PAPER FEED UNIT R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New None...
Page 930 PAPER FEED UNIT (D537/D580) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 EXTERIOR COVER ..................1 1.1.1 REAR COVER ..................1 1.2 ELECTRICAL COMPONENTS ..............2 1.2.1 LIFT MOTORS ..................2 1.2.2 UPPER AND LOWER PAPER FEED CLUTCHES ....... 3 1.2.3 PAPER FEED MOTOR .................
Page 932 Exterior Cover 1. REPLACEMENT AND ADJUSTMENT 1.1 EXTERIOR COVER 1.1.1 REAR COVER 1. Securing brackets [A] ( x 1 each) 2. Rear cover [B] ( x 2) D537/D580...
Page 933 Electrical Components 1.2 ELECTRICAL COMPONENTS 1.2.1 LIFT MOTORS 1. Rear cover ( "Rear Cover") 2. Lift motors [A][B] ( x 2, x 1 each) D537/D580...
Page 934 Electrical Components 1.2.2 UPPER AND LOWER PAPER FEED CLUTCHES 1. Rear cover ( "Rear Cover") 2. Upper paper feed gear unit [A] ( x 3, x 1) 3. Upper paper feed clutch bracket [B] ( x 1, x 2, bushing x 1) 4.
Page 935 Electrical Components 1.2.3 PAPER FEED MOTOR 1. Rear cover ( "Rear Cover") 2. Paper feed motor [A] ( x 1, x 2) When installing the paper feed motor, make sure that the gear of the paper feed  motor holds the timing belt [B]. 1.2.4 MAIN BOARD 1.
Page 936 Feed 1.3 FEED 1.3.1 PAPER FEED UNIT 1. Right cover [A] ( x 2) 2. Vertical transport guide [B] of the paper feed unit 3. Pull the tray 3 (or 4). 4. Paper guide [C] 5. Paper feed unit [D] ( x 2, x 1, x 2)
Page 937 Feed 1.3.2 PICK-UP, PAPER FEED AND SEPARATION ROLLERS 1. Paper feed unit ( "Paper Feed Unit) 2. Roller holder [A] ( x 1) 3. Pick-up roller [B] 4. Paper feed roller [C] 5. Separation roller [D] ( x 1) D537/D580...
Page 938 Feed 1.3.3 LIFT, PAPER END, AND RELAY SENSORS 1. Paper feed unit ( "Paper Feed Unit") 2. Vertical transport sensor bracket [A] ( x 1) 3. Vertical transport sensor [B] ( x 1) 4. Paper feed sensor bracket [C] ( x 1) 5.
Page 939 PB3110(D538)/PB3140(D581) LARGE CAPACITY TRAY R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New None...
Page 941 LARGE CAPACITY TRAY (D538/D581) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 EXTERIOR COVER ..................1 1.1.1 LEFT AND RIGHT TRAY ..............1 1.1.2 CHANGING THE TRAY SIZE ............... 2 1.2 ELECTRICAL COMPONENTS ..............3 1.2.1 PAPER HEIGHT SENSORS ON PAPER STORAGE SIDE ....3 1.2.2 END FENCE HP SENSOR/PAPER END SENSOR 2 ......
Page 943 Exterior Cover 1. REPLACEMENT AND ADJUSTMENT 1.1 EXTERIOR COVER 1.1.1 LEFT AND RIGHT TRAY 1. Pull the LCT drawer. If the right tray comes up with the left tray, push the right tray into the LCT.  2. Left tray [A] ( x 2) 3.
Page 944 Exterior Cover 1.1.2 CHANGING THE TRAY SIZE 1. Remove the fence screws ( x 5). 2. Change the position of the fences. Before fastening the screws, set paper in the tray.  D538/D581...
Page 945 Electrical Components 1.2 ELECTRICAL COMPONENTS 1.2.1 PAPER HEIGHT SENSORS ON PAPER STORAGE SIDE 1. Tray ( "Left and Right Tray") 2. Rear fence [A] ( x 1) 3. Rear fence bracket [B] ( x 2) 4. Paper height sensors [C] ( x 1 each) 1.2.2 END FENCE HP SENSOR/PAPER END SENSOR 2 1.
Page 946 Electrical Components 1.2.3 TRAY LIFT MOTOR 1. Securing brackets [A] ( x 1 each) 2. Rear cover [B] ( x 2) 3. Tray lift motor [C] ( x 1, x 3) D538/D581...
Page 947 Electrical Components 1.2.4 TRAY MOTOR 1. Rear cover ( "Tray Lift Motor") 2. Tray motor [A] ( x 1, x 2) When installing the tray motor, make sure that the gear of the tray motor holds the  timing belt [B]. 1.2.5 MAIN BOARD 1.
Page 948 Electrical Components 1.2.6 STACK TRANSPORT CLUTCH 1. Rear cover ( "Tray Lift Motor") 2. Stack transport clutch [A] ( x 1, x 1) D538/D581...
Page 949 Feed 1.3 FEED 1.3.1 PAPER FEED UNIT 1. Right cover [A] 2. Open the vertical guide plate [B] 3. Guide plate [C] 4. Pull the LCT drawer [D]. 5. Paper feed unit [E] ( x 1) D538/D581...
Page 950 Feed 1.3.2 PICK-UP, FEED AND SEPARATION ROLLERS 1. Paper feed unit ( "Paper Feed Unit") 2. Separation roller [A] ( x 1) 3. Roller holder [B] ( x 1) 4. Feed roller [C] and pick-up roller [D] D538/D581...
Page 951 Feed 1.3.3 PAPER FEED, PAPER END, LIFT AND RELAY SENSORS 1. Paper feed unit ( "Paper Feed Unit") 2. Vertical transport sensor bracket [A] ( x 1, x 1) 3. Relay sensor [B] 4. Paper feed sensor bracket [C] 5. Paper feed sensor [D] 6.
Page 952 D579 PAPER FEED UNIT PB3120 R E V I S I O N H I S T O RY Pag e Date Ad d ed / Upd ated / New None...
Page 954 PAPER FEED UNIT PB3120 (D579) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ..........1 1.1 REAR COVER ....................1 1.2 MOTORS, CLUTCH AND MAIN BOARD ............1 1.2.1 LIFT MOTOR ..................1 1.2.2 PAPER FEED CLUTCH ............... 2 1.2.3 PAPER FEED MOTOR ................ 3 1.2.4 MAIN BOARD ..................
Page 956 READ THIS FIRST Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the  replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...
Page 958 Rear Cover 1. REPLACEMENT AND ADJUSTMENT 1.1 REAR COVER Securing brackets [A] ( x 1 each) Rear cover [B] ( x 2) 1.2 MOTORS, CLUTCH AND MAIN BOARD 1.2.1 LIFT MOTOR Rear cover ( p.1 "Rear Cover") Lift motor [A] ( x 3, x 1) D579...
Page 959 Motors, Clutch and Main Board 1.2.2 PAPER FEED CLUTCH Rear cover ( p.1 "Rear Cover") Paper feed gear unit [A] ( x 3, x 1) Paper feed clutch bracket [A] ( x 1, x 2, bushing x 1) Paper feed clutch [B] D579...
Page 960 Motors, Clutch and Main Board 1.2.3 PAPER FEED MOTOR Rear cover ( p.1 "Rear Cover") Paper feed motor [A] ( x 1, x 2) When installing the paper feed motor, make sure that the gear of the paper feed  motor holds the timing belt [B].
Page 961 Motors, Clutch and Main Board 1.2.4 MAIN BOARD Rear cover ( p.1 "Rear Cover") x 3, snap pin x 1) Main board [A] (All D579...
Page 962 Paper Feed Unit 1.3 PAPER FEED UNIT Stopper [A] ( x 1) Vertical transport guide [B] of the paper feed unit Right cover [A] ( x 2) Pull tray 3. Paper guide [A] Paper feed unit [B] x 2, x 1, x 2) D579...
Page 963 Rollers and Sensors 1.4 ROLLERS AND SENSORS 1.4.1 SEPARATION ROLLER, FEED ROLLER AND PICK-UP ROLLER Paper feed unit ( p.5 "Paper Feed Unit") Roller holder [A] ( x 1) Pick-up roller [B] ( x 1) Paper feed roller [C] Separation roller [D] ( x 1) D579...
Page 964 Rollers and Sensors 1.4.2 LIFT, PAPER END, AND RELAY SENSORS Paper feed unit ( p.5 "Paper Feed Unit") Vertical transport sensor bracket [A] ( x 1) Vertical transport sensor [B] ( x 1) Paper feed sensor bracket [C] ( x 1) Paper feed sensor [D] ( x 1) Paper end sensor feeler [E]...
Page 965 D631 RT3020 - 1200-SHEET LCT R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New None...
Page 967 RT3020 - 1200-SHEET LCT (D631) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 COVERS ......................1 1.1.1 REAR COVER ..................1 1.1.2 RIGHT DOOR ..................1 1.1.3 FRONT AND TOP COVERS ..............2 1.2 PAPER FEED ....................3 1.2.1 PICK-UP, PAPER FEED AND SEPARATION ROLLERS ....
Page 968 2.2.3 PAPER HEIGHT AND END DETECTION .......... 18 Paper Height ..................18 Paper End ....................18 D631...
Page 969 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the  replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...
Page 971 Covers 1. REPLACEMENT AND ADJUSTMENT 1.1 COVERS 1.1.1 REAR COVER 1. Cover [A] ( x 1) 2. Rear cover [B] ( x 3) 1.1.2 RIGHT DOOR 1. Right lower cover [A] ( x 2) 2. Right door [B] ( x 1) D631...
Page 972 Covers 1.1.3 FRONT AND TOP COVERS 1. Right door ( p.1 "Rear Cover") 2. Switch cover [A] ( x 2) 3. Front cover [B] ( x 4) 4. Top cover [C] ( x 2) D631...
Page 973 Paper Feed 1.2 PAPER FEED 1.2.1 PICK-UP, PAPER FEED AND SEPARATION ROLLERS 1. Open the right door. 2. Sensor bracket [A] ( x 2) 3. Rollers [B], [C], [D] ( x 1 each) [B]: Paper feed roller [C]: Pick-up roller [D]: Separation roller D631...
Page 974 Drive 1.3 DRIVE 1.3.1 PAPER FEED CLUTCH 1. Rear cover ( p.1 "Rear Cover") 2. Bracket [A] ( x 1,  x 2, bushing x 1) 3. Paper feed clutch [B] ( x 1,  x 1) 1.3.2 PAPER FEED MOTOR 1.
Page 975 Drive 1.3.3 TRAY LIFT MOTOR 1. Rear cover ( p.1 "Rear Cover") 2. Tray lift motor unit [A] ( x 4,  x 1) D631...
Page 976 Electrical Components 1.4 ELECTRICAL COMPONENTS 1.4.1 MAIN BOARD 1. Rear cover ( p.1 "Rear Cover") 2. Main board ( x 2, all 's) 1.4.2 LCT SET SWITCHES Rear 1. Rear cover ( p.1 "Rear Cover") 2. Switch bracket [A] ( x 3) 3.
Page 977 Electrical Components Front 1. Front cover ( p.2 "Front and Top Covers") 2. Front LCT set switch [A] ( x 1) 1.4.3 DOWN SWITCH 1. Front cover ( p.2 "Front and Top Covers") 2. Switch base [A] ( x 2,  x 1) 3.
Page 978 Electrical Components 1.4.4 PAPER FEED, PAPER END, TRAY LIFT AND RELAY SENSORS 1. Front cover ( p.2 "Front and Top Covers") 2. Top Cover ( Front and Top Covers) 3. Rear ground plate [A] ( x 1) 4. Front ground plate [B] ( x 1) 5.
Page 979 Electrical Components 7. Sensors [E], [F], [G], [H] ( x 1, hooks each) [E]: Tray lift sensor [F]: Relay sensor [G]: Paper feed sensor [H]: Paper end sensor 1.4.5 STACK SENSOR 1. Open the right door 2. Paper feed unit ( p.8 "Paper Feed, Paper End, Tray Lift and Relay Sensors") 3.
Page 980 Side Fence Position Change 1.5 SIDE FENCE POSITION CHANGE 1. Open the right door of the LCT. 2. Push the down switch to lower the tray bottom plate until it reaches its lowest position. 3. Remove the front and rear side fences [A, B] ( x 1 each). 4.
Page 981 Component Layout 2. DETAILS 2.1 COMPONENT LAYOUT 2.1.1 COMPONENT LAYOUT 1. Rear LCT Set Switch 12. Sub Paper Height Sensor 2. Pick-up Roller Solenoid 13. Tray Down Switch 3. Tray Lift Sensor 14. Paper Height Sensor 3 4. Paper Feed Roller 15.
Page 982 Component Layout 2.1.2 ELECTRICAL COMPONENT LAYOUT 1. Front LCT Set Switch 11. Pick-up Roller Solenoid 2. Rear LCT Set Switch 12. Paper Feed Sensor 3. Paper Feed Clutch 13. Paper End Sensor 4. Paper Feed Motor 14. Paper Height Sensor 1 5.
Page 983 Component Layout 2.1.3 ELECTRICAL COMPONENT DESCRIPTIONS Symbol Name Function Index No. Motors Paper Feed Drives all rollers. Tray Lift Drives the paper tray up or down. Sensors Detects whether the paper is jammed at Paper Feed the LCT. Detects the copy paper coming to the Relay relay roller and checks for misfeeds.
Page 984 Component Layout Symbol Name Function Index No. Detects a) when the tray has moved down to the paper supply position after paper end, to stop the tray lift motor or b) Stack when the top of the paper stack has moved down to the paper supply position, to stop the tray lift motor after the down switch has been pressed.
Page 985 Component Layout 2.1.4 DRIVE LAYOUT 1. Tray Lift Motor 5. Relay Roller 2. Paper Feed Motor 6. Separation Roller 3. Pick-up Roller 7. Tray Drive Belt 4. Paper Feed Clutch D631...
Page 986 Paper Feed 2.2 PAPER FEED 2.2.1 PAPER FEED MECHANISM This machine uses the FRR paper feed system (paper feed roller [E], separation roller [H], pick-up roller [G]). When the right door is closed, the tray lift motor raises the tray to the position where the top of the paper stack in the tray interrupts the tray lift sensor [D].
Page 987 Paper Feed 2.2.2 TRAY LIFT MECHANISM The lift motor [A] controls the vertical position of the tray through the timing belts [B]. Tray lifting conditions When the tray lift sensor [C] turns off in the following conditions, the tray lift motor raises the tray bottom plate until the tray lift sensor [C] turns on again.
Page 988 Paper Feed 2.2.3 PAPER HEIGHT AND END DETECTION Paper Height The amount of the paper in the tray is detected by combination of high (1)/low (0) outputs from three sensors (paper height sensor 1 [A], 2 [B], 3 [D] and sub paper height sensor [C]). Indicator on the Amount of paper PH S-1...
Page 989 Paper Feed D631...
Page 990 BOOKLET FINISHER SR3020 (B803)/ SR3110 (D637)/SR4020 (D373) FINISHER SR3030 (B805)/ SR3120 (D636)/SR4010 (D374) R E V I S I O N H I S T O RY P ag e Dat e Ad d ed/ Upd at ed/ New None...
Page 992 BOOKLET FINISHER SR3020 (B803)/ SR3110 (D637)/SR4020 (D373) FINISHER SR3030 (B805)/ SR3120 (D636)/SR4010 (D374) TABLE OF CONTENTS 1. REPLACEMENT AND ADJUSTMENT ........... 1 1.1 COVERS ......................1 1.1.1 EXTERIOR COVERS ................1 1.1.2 UPPER TRAY, END FENCE ..............2 1.2 MAIN UNIT ..................... 3 1.2.1 UPPER TRAY LIMIT SENSOR, LIMIT SWITCH ........
Page 993 2. DETAILED SECTION DESCRIPTIONS ........24 2.1 COMPONENT LAYOUT ................24 2.1.1 GENERAL LAYOUT ................24 Paper direction ..................24 Proof tray ....................25 Upper tray ....................25 Pre-stack tray ..................25 Lower tray ....................25 2.1.2 ELECTRICAL COMPONENTS ............26 Upper Area B804/B805 ................
Page 994 Skew Correction before Punching ............66 Punch Unit Position Correction .............. 67 2.8.2 PUNCH MECHANISMS ..............69 Paper Position Detection ................ 69 Punch Unit Movement ................70 Punch Selection and Firing ..............71 2.8.3 PUNCH HOPPER MECHANISM ............72 2.9 FINISHER JAM DETECTION ..............73 B803/B805/D373/D374/D636/D637...
Page 996 Read This First Safety and Symbols Replacement Procedure Safety Turn off the main power switch and unplug the machine before beginning any of the  replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. : See or Refer to : Screws : Connector...
Page 998 Covers 1. REPLACEMENT AND ADJUSTMENT 1.1 COVERS 1.1.1 EXTERIOR COVERS 1. Open the front door [D]. 2. Small upper cover [A] ( x1) 3. Upper cover [B] ( x2) 4. Front door bracket [C] ( x1) 5. Front door [D] 6.
Page 999 Covers 1.1.2 UPPER TRAY, END FENCE 1. Remove the rear cover. ( "Exterior Covers") 1. Support the tray [A] with your right hand. 2. Pull gear [B] toward you  to release. 3. Slowly lower the tray  until it stops. 4.
Page 1000 Main Unit 1.2 MAIN UNIT 1.2.1 UPPER TRAY LIMIT SENSOR, LIMIT SWITCH 1. Front door, front left side cover, rear cover, upper cover ( "Exterior Cover") 2. End fence ( "Upper Tray, End Fence") 3. Upper tray exit mechanism [A] ( x4,  x3) 4.
Page 1001 Main Unit 1.2.2 POSITIONING ROLLER 1. Open the front door [A]. 2. Pull out the stapling unit [B]. 3. Positioning roller [C] ( x1, timing belt x1) B803/B805/D373/D374/D636/D637...
Page 1002 Main Unit 1.2.3 PROOF TRAY EXIT SENSOR 1. Small upper cover ( "Exterior Cover") 2. Proof tray exit sensor bracket [A] ( x1) 3. Proof tray exit sensor [B] ( x1) 1.2.4 UPPER TRAY HEIGHT SENSORS 1, 2 1. Small upper cover, upper cover ( "Exterior Cover") 2.
Page 1003 Main Unit 1.2.5 EXIT GUIDE PLATE, UPPER TRAY EXIT SENSOR 1. Rear cover, Upper covers, Front door, Cover, Paper exit cover ( "Exterior Cover") 2. Inner cover [A] ( x2) 3. Exit guide plate [B] ( x1, Link and spring,  x1,  x1) 4.
Page 1004 Main Unit 1.2.6 PROOF TRAY FULL SENSOR 1. Exit guide plate. ( "Exit Guide Plate, Upper Tray Exit Sensor") 2. Guide plate [A] (hook x 2) 3. Sensor bracket [B] ( x1) 4. Proof tray full sensor [C] (S11) ( x1) 1.2.7 FINISHER ENTRANCE SENSOR 1.
Page 1005 Main Unit 1.2.8 PRE-STACK TRAY EXIT SENSOR 1. Disconnect the finisher if it is connected to the copier. 2. Sensor bracket [A] 3. Pre-stack tray exit sensor [B] (S2) B803/B805/D373/D374/D636/D637...
Page 1006 Stapler Unit 1.3 STAPLER UNIT 1.3.1 CORNER STAPLER 1. Open the front door. 2. Pull out the stapler unit. 3. Inner cover [A] ( x3) 4. Stapler unit holder [B] ( x1) 5. Corner stapler [C] (M20) ( x1) B803/B805/D373/D374/D636/D637...
Page 1007 Stapler Unit 1.3.2 POSITIONING ROLLER 1. Open the front door [A]. 2. Pull out the stapling unit [B]. 3. Positioning roller [C] ( x1, timing belt x1) B803/B805/D373/D374/D636/D637...
Page 1008 Fold Unit 1.4 FOLD UNIT 1.4.1 FOLD UNIT 1. Remove the back cover ( "Exterior Covers"). 2. Open the front door. The stapler unit is heavy.  3. Ground cable [A] ( x1) 4. Harness [B] ( x6,  x6) 5.
Page 1009 Fold Unit Support the fold unit with your hand to prevent it from falling.  The fold unit is heavy.  6. Folding unit [D] ( x4,  x2,  x6) If you have replaced the folding unit: 1. Read the DIP SW settings on the decal [A] attached to the back of the new folding unit. 2.
Page 1010 Fold Unit 1.4.2 FOLD UNIT ENTRANCE SENSOR 1. Pull out the stapler unit ( "Positioning Roller"). 2. Fold unit entrance sensor bracket [A] ( x2) 3. Fold unit entrance sensor [B] (S26) ( x1,  x1) B803/B805/D373/D374/D636/D637...
Page 1011 Fold Unit 1.4.3 FOLD UNIT EXIT SENSOR 1. Open the front door. 2. Pull out the stapler unit ( "Positioning Roller"). 3. Fold unit vertical guide plate [A] 4. Fold unit inner cover [B] ( x2, Spring pin x1) 5. Fold unit upper cover [C] ( x1) 6.
Page 1012 Fold Unit 1.4.4 STACK PRESENT SENSOR If you intend to correct the horizontal and vertical skew for the fold unit at the same time,  do those adjustments first, then replace the sensor. ( "Folding Horizontal Skew Adjustment" or "Fold Vertical Skew Adjustment") 1.
Page 1013 Fold Unit 1.4.5 FOLDING HORIZONTAL SKEW ADJUSTMENT (FOR B804 ONLY) The fold unit is adjusted for optimum performance before the finisher is shipped from the  factory. Do this adjustment only if the edges of folded booklets are not even. 1.
Page 1014 Fold Unit 10. Push the stapler unit into the finisher and close the front door. 11. Do a folding test. Switch the copier on.  Put one page of A3 or DLT paper in the ARDF.  On the copier operation panel, select booklet stapling. ...
Page 1015 Fold Unit For – skew [G], turn the adjustment screw to the left (counter-clockwise).  Every click in the +/– direction adjusts the fold position by 0.1 mm by moving the bottom  fence [K]. 18. Raise the tip of the adjustment screw [J] and allow it to lower under its own weight. 19.
Page 1016 Fold Unit 1.4.6 FOLD VERTICAL SKEW ADJUSTMENT (FOR B804 ONLY) The fold unit is adjusted for optimum performance before the finisher is shipped from the  factory. Do this adjustment only if the edges of folded booklets are not even. 1.
Page 1017 Fold Unit The range for measurement is –3.0 mm to +3.0 mm in 0.2 mm steps for every notch  adjustment. 8. Exit the SP mode and do the test again (steps 2 to 5). 9. Repeat this procedure until the skew is corrected. The illustration below shows the effects of +/- adjustment with SP6113.
Page 1018 Booklet Stapler Unit 1.5 BOOKLET STAPLER UNIT 1.5.1 BOOKLET STAPLER 1. Open the front door. 2. Pull out the stapler unit ( "Positioning Roller"). 3. Harness cover [A] ( x2) 4. Booklet stapler support stay [B] ( x4,  x2,  x4) 5.
Page 1019 Booklet Stapler Unit 1.5.2 BOOKLET STAPLER MOTOR 1. Open the front door. 2. Remove the stapler unit. ( "Fold Unit") 3. Stay [A] ( x4). 4. Left plate [B] ( x4) 5. Harness cover [C] ( x2) 6. Booklet stapler support stay [D] ( x4,  x2,  x4) 7.
Page 1020 Booklet Stapler Unit To Reattach the Booklet Stapler Motor 1. Reattach the booklet stapler motor. Do not tighten the screws.  2. Attach the special tool [A] and reattach the booklet stapler stay. This tool is included with the stapler spare part. ...
Page 1021 Component Layout 2. DETAILED SECTION DESCRIPTIONS 2.1 COMPONENT LAYOUT 2.1.1 GENERAL LAYOUT 1. Proof Tray Junction Gate 7. Lower Tray (Booklet)* 2. Punch Unit 8. Folder Rollers* 3. Stapler Junction Gate 9. Folder Plate* 4. Pre-Stack Junction Gate 10. Booklet Stapler* 5.
Page 1022 Component Layout the finisher: Proof Junction Gate Stapler Junction Gate Paper Feeds Closed Closed Paper feeds straight through Closed Paper feeds to the proof tray Open Closed Paper feds to the staple tray Open Proof tray Copies are sent to the proof tray (12) when neither sorting nor stapling are selected for the job. Upper tray The upper tray (11) receives copies that are sorted and shifted and also receives copies that have been corner stapled.
Page 1023 Component Layout 2.1.2 ELECTRICAL COMPONENTS Upper Area B804/B805 1. Upper/Proof Exit Motor (M4) 10. Upper Tray Limit Switch (SW2) 2. Stapling Tray Junction Gate Solenoid 11. Stacking Roller HP Sensor (S13) (SOL2) 12. Stacking Sponge Roller Motor (M10) 3. Upper Transport Motor (M2) 13.
Page 1024 Component Layout Lower Area B804/B805 8. Positioning Roller Motor (M14) 1. Upper Tray Lift Motor (M21) 9. Lower Tray Full Sensor – Front (S34)* 2. Lower Transport Motor (M3) 10. Lower Tray Full Sensor – Rear (S33)* 3. Entrance Motor (M1) 11.
Page 1025 Component Layout Punch Unit B702 1. Punch Encoder Sensor (S24) 6. Paper Position Slide HP Sensor (S22) 2. Punch Drive Motor (M24) 7. Paper Position Sensor (S3) 3. Punch HP Sensor (S24) 8. Punch Hopper Full Sensor (S4) 4. Punch Unit Board (PCB3) 9.
Page 1026 Component Layout Stacker/Stapler - B804/B805 7. Jogger Fence Motor (M15) 1. Stack Present Sensor (S32)* 8. Jogger Fence HP Sensor (S15) 2. Stack Junction Gate HP Sensor (S27)* 9. Corner Stapler Movement Motor (M6) 3. Stack Feed Out Belt HP Sensor (S16) 10.
Page 1027 Component Layout B804 Fold unit 1. Clamp Roller HP Sensor (S25) 6. Fold Cam HP Sensor (S30) 2. Fold Roller Motor (M12) 7. Fold Bottom Fence HP Sensor (S28) 3. Fold Plate Motor (M11) 8. Fold Unit Entrance Sensor (S26) 4.
Page 1028 Component Layout 2.1.3 SUMMARY OF ELECTRICAL COMPONENTS Here is a general summary of all the electrical components of the B804/B805 finishers. In the table below a number that appears in bold text (M8, etc.) denotes a component that  is on the 2000/3000 Sheet Finisher B804 only. Component Function Boards (PCB)
Page 1029 Component Layout Component Function Drives the movement of the paper position slide that Paper Position Sensor holds the paper position sensor (S3) that detects the Slide Motor position of the paper. Drives a large cam that alternately clamps and unclamps the clamp retraction roller, the idle roller of the clamp roller pair.

This manual is also suitable for:

M125
