4a
Position your Sound Bar
The ideal place to position the Sound Bar is
centered underneath your TV.
4b
Wall mount your Sound Bar
Required tools:
Place the supplied wall mount template on the
wall. Make sure the wall mount template is at
least 2 inches below the center of the TV.
Use a level to make sure the wall mount template
is positioned accurately
Use the tape to stick the wall mount template
firmly on the wall.
Mark on the wall using each marking on the
template through the mounting holes.
Take away the wall mount template.
Drill a screw hole at each marking on the wall.
TV
TV
3
1
4
30.7"
< 9.8'
T V
> 2"
5
6
2
