- Page 1 Alto 8211 Series 2.1 Dolby Atmos Sound Bar with Built-in Subwoofers Quick Start Guide...
-
Page 3: Register Your Product
Register Your Product Register your TCL Sound Bar to receive the latest news on product releases, promotional offers, and more!* Text to Register Text a photo of the camera icon to 71403 Or register online at register.tcl.com Need help? Visit photoregister.com/help... -
Page 4: What's In The Box
What's in the box Make sure you read all the safety information before you use this product. Sound Bar main unit AC power cord * Power cord plug type vary region. Optical cable HDMI cable Remote control AAA battery x 2 Wall mount bracket x 2 Wall anchor x 2 Wall mounting screw x 2... - Page 5 Overview Sound Bar main unit Source button: Volume buttons: Press to switch the audio source Press to increase or decrease the among HDMI ARC/HDMI IN/ /BT/AUX/USB modes. volume level. Power button: Bluetooth button: Press to select the Bluetooth source. Press to enter SLEEP Press and hold to enter pairing mode.
- Page 6 HDMI IN connector AC IN AC IN...
-
Page 7: Wall Mount Your Sound Bar
Place your Sound Bar The ideal place to position the Sound Bar is centered underneath your TV. Wall mount your Sound Bar Required tools: > 2" • Place the supplied wall mount template on the wall. Make sure the wall mount template is at least 2 inches below the center of the TV. - Page 8 Wall mount your Sound Bar Required tools: • Insert the wall anchors in the holes on the wall. • Insert the supplied screws with the sleeves into the hole of the wall anchors. • Fix and tighten the wall bracket screws on the wall.
- Page 9 Wall mount your Sound Bar Required tools: • Unscrew the rubber cushions from the bottom of the sound bar and set them aside for potential use in the future. • Attach the included wall bracket mounts to the sound bar in the same holes the rubber cushions were removed from.
-
Page 10: Connect To Your Tv
Connect to your TV There are 3 ways to connect your sound bar to the TV HDMI CEC (listed in order that we recommend): HDMI ARC (refer to 5a), Optical (refer to 5b), and AUX (refer to 5c) For USA only: If you have a Roku TV , simply plug in the HDMI cable and follow the Roku TV Ready on-screen instructions. - Page 11 Connect HDMI cable to HDMI (ARC) interface on both TV and sound bar. Connect power cord. Enable the T-Link function in the settings of the TCL TV. Note: CEC function naming may differ by TV manuafacturer. This feature may be called T-Link, Anynet+, SimpLink, BRAVIA Link, EasyLink or VIERA Link.
- Page 12 Optical Connect the Sound Bar with your TV through the supplied Optical cable. Connect the Sound Bar to the power supply with the supplied power cord. AC IN AC IN...
- Page 13 Connect the Sound Bar with your TV through AUX cable (not supplied). Connect the Sound Bar to the power supply with the supplied power cord. AC IN AC IN...
-
Page 14: Using The Remote
Install or replace the remote batteries Battery type: 1.5V AAA Alkaline battery x 2 Using the Remote Press to switch the audio source to Bluetooth mode. Press and hold to enter pairing mode. Press to switch the audio source to AUX mode. Press to select the equalizer (EQ) effect when you are watching TV, Press to enter Sleep mode. - Page 15 > The Sound Bar is ready to pair. 4. Power on your Bluetooth device and activate its Bluetooth function. 5. Select TCL 8211 Sound Bar. > You hear a sound signal. > Pairing is successful. 6. If you want to re-pair with another device, please repeat step 3.
- Page 16 3b. For the Airplay 2, in Settings > Wi-Fi, look for Media Settings "TCL 8211 Sound Bar" under "SETUP AS NEW AIRPLAY SPEAKER" and complete the setup process. 4. Once setup is complete via either 3a or 3b,...
- Page 17 Remote Control LED Indications Remarks Sound Bar LED Display *Power on/off HELLO START READY SLEEP STDBY The LED display on the Sound Bar gives HDMI IN HDMI ARC *Input source you information about the status of the BT PAIR CONNECTED *Connect your Blu-ray player via HDMI IN to use PASS THRU Sound Bar.
- Page 18 Works with Apple AirPlay Trademarks To control this AirPlay 2–enabled speaker, iOS 11.4 or later is required. Apple, AirPlay, Apple TV, Apple Watch, iPad, iPad Air, iPad Pro, iPhone, and Lightning are trademarks of Apple Inc., registered in the U.S. and other countries. Chromecast built-in Google and Chromecast built-in are trademarks of Google LLC.
- Page 19 Does this Sound Bar work with any TV? What’s PASS THRU? (TBC) Yes, the Sound Bar is compatible with any TV that has one of the ports below: 1. HDMI supporting ARC (preferred) 2. Optical audio output (TOSLink) 3. Headphone output When the Sound Bar and TV are both on, there is an echo effect.
- Page 20 Copyright © 2021 TCL. All rights reserved. 72-TS82NA-QSGB1 TS8211_NA_USA_QSG_V0.1...
