- Page 1 OPERATING INSTRUCTIONS Translation of the original instructions...
- Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
- Page 3 VERS.2016.01.12 CST 100/120/150_MAN_EN CST: OPERATING INSTRUCTIONS TABLE OF CONTENTS 1 BASIC SAFETY INSTRUCTIONS ....................6 1.1 Symbols ..........................6 1.2 Machine plate .......................... 7 1.3 Safety instructions for particular operating phases ............7 2 MACHINE DESCRIPTION ......................8 2.1 Short description ........................8 2.2 Purpose of use ........................
- Page 4 VERS.2016.01.12 CST 100/120/150_MAN_EN 1 BASIC SAFETY INSTRUCTIONS The CST is exclusively designed for the cutting of abrasive materials with NORTON diamond blades, mainly on construction sites. Uses other than the manufacturer's instructions shall be considered as contravening the regulations. The manufacturer shall not be held responsible for any resulting damage. Any risk shall be borne entirely by the user.
- Page 5 VERS.2016.01.12 CST 100/120/150_MAN_EN 1.2 Machine plate Important data can be found on the following plate located on the machine: Machine code Year of production Bore diameter Machine model Weight Max. blade diameter Serial number Machine type Safety standard Blade speed Power 1.3 Safety instructions for particular operating phases Before commencing work...
- Page 6 2 MACHINE DESCRIPTION Any modification, which could lead to a change in the original characteristics of the machine, may be done only by Saint-Gobain Abrasives who shall confirm that the machine is still in conformity with the safety regulations. 2.1 Short description CST type Masonry saw is a machine with fixed table and mobile head.
- Page 7 VERS.2016.01.12 CST 100/120/150_MAN_EN Frame (1) Jig-welded steel construction, the frame is robust and resistant. The side posts of the machine ensure that the rail is parallel to the table. The rails (4) assembly can also be tilted to 45º to make bevel cuts.
- Page 8 VERS.2016.01.12 CST 100/120/150_MAN_EN 2.4 Technical data Code CST100 CST120 CST150 Description 230V 230V 230V Power 2,2 kW Voltage 230V 1~ Motor protection IP 54 Sound pressure level 73,5 dB (A) (selon ISO EN 11201) Sound energy level 88,5 dB (A) (selon ISO EN 3744) Cutting length 1000 mm 1200 mm...
- Page 9 VERS.2016.01.12 CST 100/120/150_MAN_EN 2.5 Statement regarding the vibration emission Declared value of vibration emission following EN 12096. Machines Measured value of Uncertainty K Tool used Modèle / code vibration emission at Model / code CST 100 / 70184613977 Duo Granit CST 120 / 70184614032 <2.5 CST 150 / 70184614025...
- Page 10 VERS.2016.01.12 CST 100/120/150_MAN_EN Statement regarding noise emission Declared value of noise emission following EN ISO 11201 and NF EN ISO 3744. Machine Sound Uncertainty K Sound power level Uncertainty K Modèle / code Pressure (Sound (Sound power level level L Pressure level NF EN ISO 3744 EN ISO...
- Page 11 VERS.2016.01.12 CST 100/120/150_MAN_EN 3 ASSEMBLY ANDCOMMISSIONING The machine is delivered fully equipped. It is ready for operation when you mount the diamond blade, the handles and the conveyor cart and after you connect to the appropriate power supply. 3.1 Tool assembly Only NORTON blades should be used.
- Page 12 VERS.2016.01.12 CST 100/120/150_MAN_EN 3.5 Water cooling system Fill the water pan with clean water to approximately 1cm from top (ensure that bottom of pump is fully immersed in water). Open water-tap at blade guard (note that handle on water-tap should be in line with water-flow). ...
- Page 13 VERS.2016.01.12 CST 100/120/150_MAN_EN 4 TRANSPORT AND STOCKING 4.1 Securing for transport Before transporting or lifting the machine, always remove the blade and empty the water pan. Also lock the cutting head on the rail. To do so, move the head in the middle of the rail and tighten the knob screw until the cutting head is secured on the rail.
- Page 14 VERS.2016.01.12 CST 100/120/150_MAN_EN 5 OPERATING THE MACHINE In this part, you will find some safety tips to use the machine. 5.1 Site of work 5.1.1 Sitting the machine Remove from the site anything, which might hinder the working procedure! ...
- Page 15 VERS.2016.01.12 CST 100/120/150_MAN_EN 5.3 General advice for the cutting The CST is designed to cut materials with maximal dimensions of : Machine CST 100 CST 120 CST 150 Ø disc 350 mm 350 mm 350 mm 1000 1200 1500 Maximal dimensions x660 x660...
- Page 16 VERS.2016.01.12 CST 100/120/150_MAN_EN 6 MAINTENANCE AND SERVICING To ensure a long-term quality from the cutting with the CST, please follow the maintenance plan below: Visual control (general aspect, watertightness) Whole machine Clean Flange and blade fixing devices Clean Motor cooling fans Clean Water pump Clean...
- Page 17 VERS.2016.01.12 CST 100/120/150_MAN_EN 7 FAULTS: CAUSES AND CURES 7.1 Fault-finding procedures Should any fault occur during the use of the machine, turn it off, and isolate it from the electrical supply. Any works dealing with the electrical system or supply of the machine can only be carried out by a qualified electrician.
- Page 18 VERS.2016.01.12 CST 100/120/150_MAN_EN 7.3 Circuit diagram 230V Motor...
