- Page 1 2.0 heta aUtomatiC CombUstion Door sensor LED-indicator Temperature sensor Bluetooth air controler www.heta.dk Danish DesiGn . Danish QUality . Danish ProDUCtion...
- Page 2 For UsinG oUr ProDUCt Thank you for purchasing our product, the HAC 2.0 Automatic Regulation of com- bustion. This product is the result of our many years of experience with burn control systems. We trust the product will fulfill your expectations.
- Page 3 Heta’s HAC 2.0 technology can be easy to control using Heta’s app for Android/ iOS via Bluetooth. HAC 2.0 is, first and foremost, a convenient aid in getting the highest possible heating value out of the firewood and, thus, the best possible value for money compared to manual operation.
- Page 4 • Provides information on heating system 1 DeViCe DesCriPtion performance 1.1 basic Description The HAC 2.0 is an automatic burn control device for wood stoves. This product offers unique features representing the cutting edge in burn control technology for an enhanced user experience.
- Page 5 Connect 220V Power to haC 2.0 scan-line 900 series 220 V Important, the stoves air must be fully open at all times, when using HAC 2.0. Power 5 V DC...
- Page 6 910 - 920 series Important, the stoves air must be fully open at all times, when using HAC 2.0. Power 5 V DC 220 V icon-line moderna series Important, the stoves air must be fully open at all times, when using HAC 2.0.
- Page 7 6. The mobile app is now paired with the HAC 2.0 device. Note: The HAC 2.0 can only be paired with a single mobile device at a time. If you wish to connect another mobile device, you will need to disconnect...
- Page 8 4 mobile aPP DoCUmentation 4.1 menu Open the menu by tapping *** at top right of the screen. Indication amount of refueled wood Shows the adequacy of the current fuel load. Only shows once the “Burning phase” circle reaches position A. Sound signalization Turns the control unit’s sound alerts on or off –...
- Page 9 Combustion control mode Turn the automatic burn control process on or off. When set to off, automatic burning regulation is inactive. The EAI shutter can then be moved manually using its attached handle, or the stove’s own shutter handle can be used. (See page 101 When automatic control is off, the Main Screen shows MAN, for “manual mode”.
- Page 10 Unit Settings Here you can configure the control unit for your stove and perform some maintenance tasks. The Settings menu is password-protected; the default password is 1234. • Program setting - Allows you to select one of a number of pre-set control curves, each of which maps exhaust temperature to shutter position in a different way.
- Page 11 5 Control Unit soUnD alerts The control unit can signal certain states and requests using an internal beeper module mounted on the unit’s circuit board. Beeper signals: • Unit power-on o 3 short beeps • New burn start (stove refueled, EAI shutter open to 100%) o 3 short beeps •...
- Page 12 7 saFety instrUCtions Once electric power has been restored, no 7.1 What to Do in Case of Power outage further manual changes to the combustion con- In the event of mains power failure to the auto- trol system are required. matic regulation process, there is no need to re- duce or stop heating, regardless of which phase 7.1.1 manually opening the eai shutter...
- Page 13 Manual handle Green close open Icon-Line Moderna series 8 heatinG With aUtomatiC reGUlation 8.1 starting Fire and refueling Whenever refueling, a new automatic burn con- As the temperature decreases, the app back- trol cycle must be started. This may be done ground will return to yellow.
- Page 14 9 Common errors anD solUtions • If “- - -“ continues to show even when the fi- In case of error • First try restarting the device by unplugging it rebox is hot, check the thermal sensor for bad for 10 seconds. wiring and / or damage.
- Page 15 • Disconnect all electrical connections before care and maintenance. performing any maintenance on the device! • In the event of malfunction, contact Heta. 11 teChniCal Data • Control unit input power 5V/DC, 50Hz 0,3A •...
