- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS ICON-LINE ECLIPSE XL SERIES Icon-Line Eclipse SCA is exempt for use in smoke control areas when burning dry wood PENDING www.heta.dk DANISH DESIGN . DANISH QUALITY . DANISH PRODUCTION...
-
Page 2: Table Of Contents
Icon-Line Eclipse XL series have been approved according to the EN 13240, NS 3058, NS 3059. And the Icon-Line Eclipse XL series are modified so that they are also recommended as exempt for use within smoke control areas (SCA) throughout the UK (see clean air act Appendix A) of the air supply regulation so that it can`t be closed completely. -
Page 3: Before Installation
It is important that upon receipt check your Heta product completely and report any damage or defects to your dealer. The packaging must be disposed of as follows: Wood is untreated and able to burn in the stove. - Page 4 With your new wood stove you should find the following: CHR list Operating / Instruction manual Graphite spray for Heta glove lubrication Nr. 0023-9002 Nr. 0027-0130 Data plate Handle 8057 0000-DK Heta A/S Jupitervej 22 . DK-7620 Lemvig . Denmark 6000-026634 EN 13240:2001/A2:2004 - AEA - NS 3058/3059, Aus §15A...
-
Page 5: Operating Instructions
To comply, a permanent stop is fitted to ensure that the air control slider cannot be closed beyond 44% Icon-Line Eclipse XL series of its fully open position. A permanent amount of air will there- fore enter the firebox to feed the fire producing negli- gible amounts of smoke and unburnt hydrocarbons. -
Page 6: Refueling
Startup/Lighting Scan the code and select a language. Maximum 1.5 Refueling wood filling Refueling of your stove should be done while there is still a good layer of embers. You should therefore air well when using the stove for the first time. -
Page 7: Draft Conditions In The Chimney
(In excess of 90° C). Nominal fluegas temperature: 283° Children should avoid contact with the stove. Icon-Line Eclipse XL Series, relative to 20°C. Setting up a fence if you have small children may Flue gas flow is: 5,4 g/sec. -
Page 8: Fuel
Good draft occurs when: It is advised not to use oil-containing woods like teak tree and mahogany, as this can cau- • The difference in temperature in the chimney se damage to the glass. (warmer) and outside temperature (colder) • It is clear weather Heating value in wood •... -
Page 9: Maintenance
use of damp wood, close the door and the air 1.14 Cleaning the glass supply completely, to help slow/smother the fire. Incorrect firing, for example using wet wood, Call the fire department. The stove and chimi- can result in the viewing window becoming co- ney must be inspected before use again. -
Page 10: Diagram For Maintenance
1.16 Diagram for the maintenance Qualified Stove Owner Technicia Maintenance / Period Before 60-90 1st Year 2st Year Daily Autum week days days Cleaning the chimney (see. Chimney) Cleaning the chimney and stove Cleaning the stoves firebox Cleaning combustion air intake Cleaning of the firebox Checking / switch, gasket for door Checking / changing, gasket for glass... -
Page 11: Troubleshooting
1.18 Troubleshooting table - applies to all stove types Fault Cause Troubleshooting Solution Inadequate chimney draft. Lighting problems. When the You can test using a lighter whether Improve the chimney. The chimney only has stove is cold, smoke seeps flame is drawn into the combustion sufficient draft when it is hot. - Page 12 1.19 Icon-Line Eclipse XL Series. Cleaning after sweeping or before replacing vermiculite stones Note: it may be necessary to clean/vaccum the holes and air ducts behind the rear stone. Order of removing Fire bricks. Replace in reverse order. Starting with Fig. 5.
- Page 13 Therefore, the duration of the warranty is 5 years on this product, covering manufactu- rer’s defects, 1 year on paint adhesion defects from purchase date from Heta and a 3 months total warranty for seals, vermiculite and glass from the date of sale from the dealer.
- Page 14 1.22 Icon-Line Eclipse XL Series Parts - Inside fire chamber Pos. Name Qty. 1 0023-025614 Vermiculite, rear 2 0023-025626 Baffle 3 0023-025627 Vermiculite, rear, right 4 0023-025628 Vermiculite right side - front 5 0023-025642 Bottom stone in the middle 6 0023-026677...
- Page 15 Parts - Door Pos. Name Qty. 1 0008-0021 M5x10 Hexagon socket button head screw with flange 2 0008-1002 M6x6 Hexagon socket set screw 3 0008-2304 M4x6 Hexalobular socket pan head 4 0008-3503 M6/12x1,6 Washer BN 560, Brass 5 0008-9082 6x35 Round head rivet 6 0021-025531 Glass 7 0023-3013 Textile glass 8x3 mm with adhesive...
- Page 16 Parts - Baking oven door Pos. Name Qty. 1 0050-0301 Rails for baking racks 2 0050-0325 Baking racks 462 x 243 3 1013-027110 Stainless tray 4 1500-026487 Oven door 5 0008-026041 M4x6 Hexalobular socket flat head cap screw INOX A2 BN 20146 6 6000-026634 Handle, completet 7 0021-026603...
- Page 17 Installation Instructions Contents Installation instructions ..............18 Distance requirements ..............18 Floor ....................18 Chimney connection ................. 18 Combustion air and ventilation ............19 Stovedrawings/measurments ............. 19-20 Assembling the thermal stones ............21 Connecting direct air below or behind ..........22 Clearances for installation EN 13 240 ..........
-
Page 18: Installation Instructions
flue gas pipe ve or on page 13 of this manual. must be sealed with fireproof material and / or beading. Heta A/S stresses that it is of utmost 2.2 Floor importance that this is done correctly with very tight joints. -
Page 19: Combustion Air And Ventilation
2.4 Combustion air and stalled to an outside air supply. Ventilation The Icon-Line Eclipse XL Series (7,1 kW) re- quires the additional ventilation, when not con- The stove is approved as a room air dependent nected to direct air, because it has a greater stove in accordance with EN 13240. - Page 20 Icon-Line Eclipse XL S Series 1351 ø100 101Center fresh air from bottom Icon-Line Eclipse XL B Series 1350 1304 1170 ø100 101 Center fresh air from bottom...
-
Page 21: Assembling The Thermal Stones
2.6 Assembling the thermal stones This room may only be used for Heta’s thermal Stone 0023-026810 - - 0023-026924... -
Page 22: Connecting Direct Air Below Or Behind
ø100 mm, the draught in the flue depends on this air for optimal combu- stion. Heta recommends max. 4 meters of direct air pipe, with max. 3, 90° bends and a min. of ø100 Flexi-pipe to the floor... -
Page 23: Clearances For Installation En 13 240
2.8 Clearances for installation EN 13 240 Combustible material - Non-flammable substrate Furnitures The dimensions are the minimum dimensions, unless otherwise stated. Clearances Oventype Distance from oven to combustible material Stove Rear the At the Over Corner Minimum stove side oven furnitures distance... -
Page 24: Changing To A Back Flue Outlet
2.9 Changing to a back outlet Accessory 0030-2410... -
Page 25: Installation Of Purchased Bottom Door
2.10 Installation of purchased bottom door Bottom door Nr. 6000-026787... - Page 26 3. Appendix A The Clean Air Act 1993 and Smoke Control Areas. Under the Clean Air Act local authorities may gulatory Reform (Scotland) Act 2014. In Wales declare the whole or part of the district of the and Northern Ireland these are authorized by authority to be a smoke control area.
-
Page 27: Eu Declaration Of Conformity
Certifikat no. 2620 Manufacturer Heta A/S Ecodesign Adress Jupitervej 22, DK 7620 Lemvig EU Declaration of Conformity E-mail heta@heta.dk Website www.heta.dk DoC Icon-Line Eclipse XL 2620-2022 Telephone +45 9663 0600 Product fiche Model identifier Icon-Line Eclipse XL, Eclipse XL B, Eclipse XL S serie The identified product described above is in...
