- Page 1 Operating instructions Wood band saws HBS 351 HBS 430 HBS 431 HBS 433 HBS 533 HBS 433...
- Page 2 12.1 Spare parts orders ......... 22 12.2 Spare parts drawings........23 12.3 Spare parts drawing 1 HBS 533 ....25 12.4 Spare parts drawing 1 HBS 351 ....28 13 Wiring diagrams ..........30 14 EC Declaration of Conformity ......33 HBS series | Version 3.10...
- Page 3 All data in these operating instructions has been com- You have made an excellent choice in purchasing a piled on the basis of the state-of-the-art, valid standards HOLZKRAFT Wood band saw. and guidelines as well as our many years of expertise and experience.
- Page 4 Safety Operator's duties WARNING! If the wood band saw is used for commercial purposes, This combination of symbol and signal term indicates the operator of the wood band saw is subject to the legal potentially hazardous situations which may cause stipulations in terms of occupational safety.
- Page 5 Safety 2.3 Personnel requirements 2.4 Personal protective equipment Personal protective equipment is intended to protect the Qualifications health and safety of persons at work. Staff must wear the The different tasks described in these operating instruc- personal protective equipment indicated in individual tions require different levels of skills in terms of the quali- sections of these operating instructions when carrying fications of operating staff working with the machine.
- Page 6 Safety - Keep the machine and your work environment 2.5 General safety instructions clean at all times. Ensure sufficient illumination. - Always secure the workpiece when working with suitable clamping equipment. Ensure a sufficient NOTE! support surface. Observe the regulations applicable in the country of - The machine's design must not be changed;...
- Page 7 Safety 2.7 Special safety instructions for wood band 2.9 Safety data sheets saws Safety data sheets for hazardous materials can be ob- - When sawing round timber, clamp the workpiece to tained from your specialist dealer or by phone: +49 prevent it rotating.
- Page 8 Intended use Intended use The wood band saw is designed for sawing edged wood and wood substitute materials, as well as hard plastics to be processed. Round materials may only be cut with a suitable holding device.Intended use also includes compliance with all the information in these instructions.
- Page 9 Technical data Technical data Type HBS 351 HBS 430 HBS 431 HBS 433 HBS 533 Article number 5153501 5154300 5154301 5154303 5155303 (Cast) Work table 500 x 356 mm 610 x 431 mm 610 x 431 mm 610 x 431 mm...
- Page 10 Machine description Machine description Saw band clamping head Figures in these operating instructions may deviate from the original. Saw band height adjustment Saw band guide 5.1 Controls Swivel work table Extraction port Chassis Lower front door Rip fence with quick clamping Guide rail rip fence Emergency stop and ON/OFF switch Top front door...
- Page 11 Delivery, packaging and storage Delivery, packaging and storage 5.2 Accessories 6.1 Delivery and Transport Extraction units Check the wood band saw for visible transport damage To reduce the dust and wood particle emissions in your upon delivery. Immediately notify the haulage company work area, order one of our extraction units along with the or retailer if you identify damage to the device.
- Page 12 Assembly and setting up Assembled band saw Devices may only be transported by authorized and qua- lified persons. Act responsibly during transport and al- ways consider the consequences. Refrain from daring The band saw is delivered to you in almost fully-assem- bled condition.
- Page 13 Operation Machines with 400 V electric motor Operation Connecting the machine to the power supply: DANGER! - make sure that the power supply has the same characteristics (voltage, mains frequency, phase Risk of fatal injury through electric position) as the motor. shock! - Use 400 V line voltage (16A fuse) There is a risk of fatal injury on touching live compo-...
- Page 14 (1, Fig. 8). Use the effect of the machine are permitted to handle and handwheel B (Fig. 7 - not on model HBS 351) to adjust work on and with the machine. the angular position of the table after loosening the clam- ping lever A or the clamping screws 1 (Fig.
- Page 15 Operation Step 6: Now place the new saw blade in reverse order on 8.2.3 Cutting height adjustment both saw blade rollers and align it centrally on the rubber supports. Turn the upper wheel a IMPORTANT! few turns and check that the saw blade runs correctly.
- Page 16 Operation Fig. 11: Setting the band tension 8.2.6 Setting the saw band run NOTE! Before the saw band run setting can be adjusted, it is important to correctly adjust the blade tension. Fig. 12: Adjusting the saw band run Step 1: Slowly turn the upper saw band pulley (1) clock- wise by hand.
- Page 17 Fig. 13: Adjusting the saw blade guideHBS 351 8.2.8 Adjusting the saw band speed 8.2.9 HBS 351 Fig. 16: Tighten clamping screw and motor Step 1: Disconnect the wood band saw from the power supply.
- Page 18 Operation Step 3: Now place the V-belt in the desired groove of the V-belt pulley. Fig. 18: V-belt pulley Step 4: Lower the motor again and tighten the lever. Then move the bolt down. Fig. 14: Chip brush 8.2.12 Extraction port For connection to an extraction system, your band saw is equipped with one or two extraction ports (2) with a di- ameter of 120 mm depending on the type.
- Page 19 Operation Always guide the workpiece with both hands and keep it 8.2.13 Use and assembly of the laser flat on the band saw table to avoid the saw blade jam- Mount the bracket on the machine. ming. Insert the batteries into the laser, paying attention to the Always use the rip fence or the mitre stop for all cutting correct polarity.
- Page 20 Maintenance and repairs Saw band parameters: Hold the workpiece firmly against the fence on the cross- cutting gauge and flat against the table. Pay attention to your fingers, particularly at the end of the cut; keep a Softwood, as- Hardwood safe distance to the saw band.
- Page 21 Troubleshooting NOTE! NOTE! Do not remove the chips with your bare hands. There Never use aggressive cleaning agents for cleaning is a risk of injuries through sharp edged or pointed work. This may cause damage or destroy the ma- chips! chine.
- Page 22 Disposal, reusing used machines 11 Disposal, reusing used machines 12 Spare parts In your own interest and to protect the environment make DANGER! sure that all machine components are exclusively dis- Risk of injury caused by the use of posed of in as intended and permitted. incorrect spare parts! The use of incorrect or faulty spare parts may cause 11.1 Decommissioning...
- Page 23 Spare parts 12.2 Spare parts drawings The following drawings of the HBS series are intended to identify the required spare parts in the event of service. When ordering, send a copy of the parts drawing including the highlighted components to your authorised retailer. Spare parts drawing 1 (HBS 430 / HBS 431 / HBS 433 ) Fig.
- Page 24 Spare parts Spare parts drawing 2 (HBS 430 / HBS 431 / HBS 433 ) Fig. 19: Spare parts drawing 2 HBS 430 / HBS 431 / HBS 433 HBS series | Version 3.10...
- Page 25 Spare parts 12.3 Spare parts drawing 1 HBS 533 Fig. 20: Spare parts drawing 1 HBS 533 HBS series | Version 3.10...
- Page 26 Spare parts Spare parts drawing 2 HBS 533 Fig. 21: Spare parts drawing 2 HBS 533 HBS series | Version 3.10...
- Page 27 Spare parts Spare parts drawing 3 HBS 533 Fig. 22: Spare parts drawing 3 HBS 533 HBS series | Version 3.10...
- Page 28 Spare parts 12.4 Spare parts drawing 1 HBS 351 Fig. 23: Spare parts drawing 1 HBS 351 HBS series | Version 3.10...
- Page 29 Spare parts Spare parts Drawing 2 HBS 351 Fig. 24: Spare parts drawing 2 HBS 351 Spare parts Drawing 3 HBS 351 Fig. 25: Spare parts drawing 3 HBS 351 HBS series | Version 3.10...
- Page 30 Wiring diagrams 13 Wiring diagrams Wiring diagram HBS 351 Fig. 26: Wiring diagram for HBS 351 HBS series | Version 3.10...
- Page 31 Wiring diagrams Wiring diagram HBS 431 Fig. 27: Wiring diagram for HBS 431 HBS series | Version 3.10...
- Page 32 Wiring diagrams Wiring diagram HBS 433 and HBS 533 Fig. 28: Wiring diagram for HBS 433 and HBS 533 HBS series | Version 3.10...
- Page 33 Dr.-Robert-Pfleger-Str. 26 D-96103 Hallstadt Germany hereby declares that the following product ® Product group: Holzkraft Woodworking machines Designation of the machine*: Item number*: HBS 351 5153501 HBS 430 5154300 HBS 431 5154301 HBS 433 5154303 HBS 533 5155303 Machine type:...
