- Page 1 Instruction Manual Circular saw TKS-Z 400 TKS-Z 400...
-
Page 2: Table Of Contents
Passing on as well as copying of this document, the use 15 EC-Declaration of Conformity.... 24 and distribution of its content are prohibited if not explic- itly permitted. Contraventions are liable to compensa- 16 Notes ............ 25 tion. Subject to technical modifications and error. TKS-Z 400 | Version 1.01... -
Page 3: Introduction
We are always interested in valuable experience and tes a directly dangerous situation which may cause knowledge gained from using the application, whichthen death or serious injury if not averted. could be shared and be valuable to develop our products even further. TKS-Z 400 | Version 1.01... -
Page 4: Obligations Of The Operating Company
The operator is the person who operates the table saw for commercial or commercial purposes or gives it to a third party for use or application and bears legal product responsibility for the protection of the user, personnel or third parties during operation. TKS-Z 400 | Version 1.01... -
Page 5: Requirements To Staff
Protective work clothing means tight-fitting clothing sonnel of the manufacturer. Other personnel is not au- with low tear resistance. thorized to perform these works. Please contact our cus- tomer service for the execution of all arising work. TKS-Z 400 | Version 1.01... -
Page 6: Safety Labels On The Circular Saw
Always use sharp saw blades. terial. Persons under the age of 18 may use the ta- ble saw only as part of a vocational training and un- der the supervision of a trainer. TKS-Z 400 | Version 1.01... -
Page 7: Safety Devices
The chip hood (Fig. 2, b) protects against accidental con- tact with the saw blade and flying chips. The chipbreaker The Circular saw TKS-Z 400 is designed exclusively for must always be mounted during operation. cutting wooden materials (solid, chipboard, veneered, etc.). -
Page 8: Residual Risks
Width / Depth 1100 mm Height 1180 mm Weight 131 kg Supply voltage 400 V Fig. 5: Type plate TKS-Z 400 Max. cutting width with rip 640 mm fence Max. cross cut width left 410 mm from saw blade Saw blade angle 90°... -
Page 9: Transport, Packaging, Storage
Cover the ma- chine with a protective tarpaulin. Fig. 6: Transport with a forklift TKS-Z 400 | Version 1.01... -
Page 10: Description Of The Device
Ensure that there is sufficient freedom of move- ment for working. The installation location should meet the following criteria: Fig. 8: Circular saw TKS-Z 400 1 Blade safe guard - The substrate must be level, firm and vibration- 2 Blade safe guard holding bracket free. -
Page 11: Set Up The Circular Saw
Fig. 10: Assembly of the retaining clip • 1 Wrench 17 mm • 1 Wrench 8 mm • 1 Wrench 12mm • 1 Wrench 10mm • 1 Wrench 15 mm • 1 Wrench 19 mm TKS-Z 400 | Version 1.01... -
Page 12: Settings
Step 3: Measure the distance between rip fence and main knife, set the rip fence slightly to make sure L1 = L2, and then tighten the locking screws (C). Fig. 14: Set miter cutting angle TKS-Z 400 | Version 1.01... - Page 13 (B) and tighten the left nut (A). Step 1: Turn off the saw, disconnect it from the mains, and lower the saw blade completely. Step 2: Open the cover of the saw blade. Fig. 18: Installation saw blade TKS-Z 400 | Version 1.01...
-
Page 14: Electrical Connection
- Protect the power cord from heat, aggressive li- not actuate the limit switch. Therefore push the stop quids and sharp edges. plate slightly towards the limit switch. TKS-Z 400 | Version 1.01... -
Page 15: Operation Of The Circular Saw
Ensure a secure footing and maintain balance at all times. - After sawing, drive the saw blade until the chip hood rests on the saw table. - Use gloves when changing the saw blade. TKS-Z 400 | Version 1.01... -
Page 16: Saws With Longitudinal Stop
Step 1: Set the cutting height of the saw blade according to how the slitting works. Step 2: Check the vertical of the rip fence with the saw Fig. 21: ON-OFF switch TKS-Z 400 blade. In the event of a power failure or unplugging the power... -
Page 17: Lift Cutting
NOTE! When slitting, the width of the piece of wood is less than 120mm, please turn the rip fence to use the bot- tom to guide the workpiece. TKS-Z 400 | Version 1.01... -
Page 18: Care After Work
Step 6: Check the machine regularly and replace if necessary: - Loose screws and nuts - Worn or damaged switches - Worn or damaged saw blade - Worn or damaged blade guard TKS-Z 400 | Version 1.01... -
Page 19: Troubleshooting
If necessary, request product-spe- Step 2: If necessary, dismantle the machine into mana- cific data sheets. geable and usable assemblies and compo- nents. Step 3: Guide the machine components and operating materials to the appropriate disposal routes. TKS-Z 400 | Version 1.01... -
Page 20: Spare Parts
Spare parts 13 Spare parts Example The saw blade for the Circular saw TKS-Z 400 must be DANGER! ordered. The saw blade has the number 66 in the spare parts drawing 1. Risk of injury by using wrong spare parts! -
Page 21: Spare Parts Drawing 1
The following spare parts drawings are intended to help identify the necessary spare parts. To order, please send a copy of the list of spare parts with the marked components to your dealer. Spare parts drawing 1 Fig. 27: Spare parts drawing 1 Circular saw TKS-Z 400 TKS-Z 400 | Version 1.01... - Page 22 Spare parts Spare parts drawing 2 Fig. 28: Spare parts drawing 2 - Circular saw TKS-Z 400 TKS-Z 400 | Version 1.01...
-
Page 23: Electrical Circuit Diagram
Electrical circuit diagram 14 Electrical circuit diagram Fig. 29: Electrical circuit diagram TKS-Z 400 TKS-Z 400 | Version 1.01... -
Page 24: Ec-Declaration Of Conformity
<= 16 A per phase and not subject to conditional connection Kilian Stürmer, Stürmer Maschinen GmbH, Responsible for documentation: Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 18.07.2019 ______________________ Kilian Stürmer Manager TKS-Z 400 | Version 1.01... -
Page 25: Notes
Notes 16 Notes TKS-Z 400 | Version 1.01... - Page 26 www.holzkraft.de...
