17.0 Short Parts List
Short Parts List
Key No. Description
302 Flue Thermostat
306 Burner (15/18/24)
Burner (28)
Burner (32)
311 Fan
315 Igniter Electrode
316 Sensing Electrode
415 Pump
419 Microswitch
420 Overheat Thermostat 5114729
421 NTC Sensor
422 Gas Valve
434 NTC Sensor (Return) 5114725
503 PCB IE 15
PCB IE 18
PCB IE24
PCB IE 28
PCB IE 32
PCB IE 24 LPG
PCB IE 28 LPG
504 Pressure Gauge
306
315
316
Manufacturers Part No.
5114747
5122149
5114697
5114698
5121447
720222801
720222901
248042
248067
5114725
5119647
5129831
5129832
720045501
720804801
5129835
720045801
720804901
248090
