MODEL NUMBER
1703VADA-36-201-901
1703VADA-36-201-925
1703VADA-36-201-926
36-IN VANITY WITH TOP
ITEM # 5071977; 5071978; 5071979
MODEL # 1703VADA-36-201-901; 1703VADA-36-201-925; 1703VADA-36-201-926
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
•
sophisticated
DESCRIPTION
AR 36-In White ADA Vanity with Eng White Top
AR 36-In White ADA Vanity with Eng Carrara Top
AR 36-In White ADA Vanity with Eng Calacatta Top
1
•
inspiring
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Allen + Roth 1703VADA-36-201-901
Summary of Contents for Allen + Roth 1703VADA-36-201-901
- Page 1 AR 36-In White ADA Vanity with Eng Calacatta Top 36-IN VANITY WITH TOP ITEM # 5071977; 5071978; 5071979 MODEL # 1703VADA-36-201-901; 1703VADA-36-201-925; 1703VADA-36-201-926 ATTACH YOUR RECEIPT HERE Serial Number__________________ Purchase Date__________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service...
- Page 2 TABLE OF CONTENTS Package Contents...........................3 Hardware Contents..........................3 Safety Instructions...........................3 Preparation............................4 Assembly or Installation Instructions ....................4 Care and Maintenance........................9 Warranty............................9 Replacement Parts List.........................10...
- Page 3 PACKAGE CONTENTS (Undermount Sink) PART DESCRIPTION QUANTITY CARTON Center Frame Box 2 of 3 Box 1 of 3 Backsplash Sink Box 3 of 3 Left Panel Right Panel Box 2 of 3 Back Stretcher Bar HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Short Bolt Lock Washer Washer...
- Page 4 PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 35 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit, measuring tape, level INSTALLATION INSTRUCTIONS...
- Page 5 INSTALLATION INSTRUCTIONS Note: Clean area where the vanity will be permanently located prior to beginning installation, ensuring the vanity will not interfere with any water supply and drain lines once mounted. 2. With two people, carefully place vanity against the wall in its final location. While holding the vanity base firmly against the wall, use the pre-assembled levelers on the bottom of each leg of the vanity to level the...
- Page 6 INSTALLATION INSTRUCTIONS 4. Apply silicone caulk (not included) to the top edge of sink (D). With the help of another adult, lower the sink onto the back side of the stone top. Make sure the sink over-flow hole is facing the front of stone top.
- Page 7 INSTALLATION INSTRUCTIONS 6. Lower the sink brackets (JJ) over the bolts (II) and allow to rest on the sink lip. Adjust location of bracket to firmly grasp sink lip. Lower lock washers (LL) over bolts (II) and secure with nuts (KK). Hand tighten nuts (KK) with included wrench (MM).
- Page 8 INSTALLATION INSTRUCTIONS 8. Apply silicone caulk (not included) to unpolished side and bottom of backsplash (C). Position backsplash (C) on top (B) and against wall. Clean any excess caulk before allowing to dry. Assembly is now complete. Install desired faucet and drain assemblies (neither included) per the manufacturers’...
- Page 9 CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •...
- Page 10 REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART# Center Frame 1703VADA-36-201-CENTER FRAME Complete Set 36" Engineered White Top 2550VT-36-901 Complete Set 36" Engineered Carrara Top 2550VT-36-925 Complete Set 36"...
