Smeg BG91CTX2 Manual

Smeg BG91CTX2 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
PRECAUTIONS
General safety instructions
Installation
Appliance purpose
This user manual
Manufacturer's liability
Identification plate
Disposal
Information for European Control Bodies
Energy efficiency technical data
To save energy
Information on power consumption in off/stand-by
mode
Light sources
How to read the user manual
DESCRIPTION
General description
Cooking hob
Control panel
Other parts
Accessories
USE
Preliminary operations
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• WARNING: During use the
appliance and its accessible
parts become very hot. Keep
children well away from the
appliance.
• Protect your hands by wearing
oven gloves when moving food
inside the oven.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
91477B566/A
35
Using the accessories
Using the hob
35
Using the storage compartment (where present) 45
39
Using the oven
40
Cooking advice
40
Digital programmer
40
Cooking information table
40
CLEANING AND MAINTENANCE
40
41
Cleaning the appliance
41
Cleaning the hob
41
Knobs
Cleaning the door
41
Cleaning the oven cavity
41
Vapor Clean (on some models only)
41
Extraordinary maintenance
42
INSTALLATION
42
Gas connection
42
Gas types and Countries
43
Burner and nozzle specifications tables
43
Positioning
43
Electrical connection
44
Instructions for the installer
44
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
44
45
45
46
47
49
50
50
50
51
51
52
54
54
55
55
58
59
60
62
63
PRECAUTIONS - 35

Advertisement

loading
Need help?

Need help?

Do you have a question about the BG91CTX2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Smeg BG91CTX2

Summary of Contents for Smeg BG91CTX2

  • Page 1 Instructions for the installer Preliminary operations We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com PRECAUTIONS General safety instructions • This appliance may only be...
  • Page 2 eight at a safe distance unless the flames, for example with a they are constantly supervised. lid or a blanket. • Keep children under the age of • The appliance becomes very 8 away from the appliance hot during use. Take care never when it is in use.
  • Page 3 COMPARTMENT (IF • If the power cable becomes AVAILABLE) OR NEAR THE damaged, contact technical APPLIANCE. support immediately to arrange • DO NOT USE AEROSOLS IN for it to be replaced in order to THE VICINITY OF THIS avoid possible hazards. APPLIANCE WHILST IT IS IN •...
  • Page 4 inserted as far as they will go model) by placing it on the into the side guides. The bottom as a support for mechanical safety locks that cooking. prevent them from being • If you wish to use greaseproof removed must face downwards paper, place it so that it will not and towards the back of the interfere with the hot air...
  • Page 5 dishwasher. of the appliance are • Never use the oven door to compatible. lever the appliance into place • This appliance is not connected when fitting. to a system for extracting • Avoid exerting too much combustion products. It should pressure on the door when be installed and connected in open.
  • Page 6 check for any leaks with a accommodation. soapy solution, never with a This user manual flame. • This user manual is an integral part of the • Have the electrical connection appliance and must therefore be kept in its entirety and within the user's reach for the performed by authorised whole working life of the appliance.
  • Page 7 Technical data on the appliance's power • Deliver the packing materials to the consumption in off/stand-by mode can be appropriate recycling centre. found at www.smeg.com under the page Plastic packaging corresponding to the product in question. Danger of suffocation Light sources •...
  • Page 8 DESCRIPTION General description 1 Upstand (on some models only) 6 Door 2 Cooking hob 7 Fan 3 Control panel 8 Storage compartment 4 Light Frame shelf 5 Gasket Cooking hob AUX = Auxiliary Burner SR = Semi-rapid Burner R = Rapid Burner UR-3c = Ultra-Rapid Burner 42 - DESCRIPTION 91477B566/A...
  • Page 9 Control panel 1 Programmer clock the appliance and which may continue for a brief period of time even after the appliance has For displaying the current time, setting been turned off. programmed cooking operations and the minute minder timer. Do not obstruct ventilation openings 2 Temperature knob and heat dispersal slots.
  • Page 10 Rack the rack above. Self-cleaning panels (on some models only) To be placed over the top of the oven tray; for cooking foods which may drip. Useful for absorbing small grease residues. Deep tray Useful for collecting fat from foods placed on Preliminary operations guides until they come to a complete stop.
  • Page 11 Tray rack burner caps. Make sure that the holes in the flame-spreader crowns are aligned with the igniters and thermocouples. Practical tips for using the hob For better burner efficiency, to minimise gas consumption and prevent damage to the cooking hob, use pans with lids and of suitable size for the burner, so that the flames do not reach up the sides of the pan.
  • Page 12 List of traditional cooking functions This function is particularly suitable for Not all functions are available on some cooking on a single shelf with low models. energy consumption. It is recommended for all types of food STATIC except those that may produce a large Traditional cooking, ideal for preparing amount of moisture (e.g.
  • Page 13 Digital programmer • We recommend placing the food at the centre of the rack. • With the Grill function, we recommend that you set the temperature to the maximum value to optimise cooking. Advice for cooking desserts/pastries and biscuits • Use dark metal moulds: They help to absorb the heat better.
  • Page 14 current time (for example, the cooking end appear, alternating with the time shown is 18:30). current time. 6. Press the key to set the cooking 3. Use the increase and decrease end time. (for example, 19:30). keys to set the required minutes of cooking. 4.
  • Page 15 2. Use the increase and decrease 2. Use the increase and decrease keys to set the required minutes. keys to set the required minutes. 3. Wait approx. 5 seconds without pressing Deleting the set data any key to finish setting the minute minder. 1.
  • Page 16 Weight Temp. Time Food Function Shelf (Kg) (°C) (minutes) Salmon trout TURBO/CIRCULAIRE 150 - 160 35 - 40 Monkfish TURBO/CIRCULAIRE 60 - 65 Turbot TURBO/CIRCULAIRE 45 - 50 Pizza TURBO/CIRCULAIRE 8 - 9 Bread CIRCULAIRE 190 - 200 25 - 30 Focaccia TURBO/CIRCULAIRE 180 - 190...
  • Page 17 remove the door and place it on a tea towel. them thoroughly and return them to the hob. To remove the door proceed as follows: The continuous contact between the 1. Open the door completely and insert two pan supports and the flame can cause pins into the holes on the hinges indicated in modifications to the enamel over time in the figure.
  • Page 18 1. Open the door and lock it with the 5. Clean the external glass pane and the appropriate pins. panes removed previously. 2. Remove the internal glass pane by pulling the rear part gently upwards, following the movement indicated by the arrows 1. 6.
  • Page 19 cavity, as this could damage the enamel. cavity to release it from its groove A. Then slide it out of the seats at the back B. The Take out all removable parts before cleaning. side self-cleaning panel is attached to the For easier cleaning, it is recommended to rack/tray support frame.
  • Page 20 Vapor Clean (on some models only) 3. Use a non-scratch sponge with brass filaments on hard to remove deposits. 4. In case of grease residues use specific oven See General safety instructions. cleaning products. 5. Remove the residual water inside the oven. The Vapor Clean function is an assisted 6.
  • Page 21 5. Replace the light bulb with one of the same Take care not to scratch the enamel of type (40 W). the oven cavity wall. 6. Refit the cover. Ensure the moulded part of the glass (A) is facing the door. 4.
  • Page 22 comply with the applicable standard. (serigraphed on the hose itself). Connection using a rubber hose complying with current standards is only permitted if the hose can be inspected along its entire length. The inside diameter of the hose must be 8 mm for LPG and 13 mm for Natural gas and Town gas.
  • Page 23 comply with the applicable standard. Extraction of the combustion products The combustion products may be extracted by means of hoods connected to a natural draught chimney whose efficiency is certain or via forced extraction. An efficient extraction system requires precision planning by a specialist qualified in this area and must comply with the positions and clearances indicated by the applicable standards.
  • Page 24 Replacing nozzles Light the burner and turn it to the minimum position. Extract the gas cock knob and turn the adjustment screw next to the gas cock spindle (depending on the model) until the correct minimum flame is achieved. Refit the knob and verify that the burner flame is stable.
  • Page 25 Gas types 5 LPG G30/31 28-30/37 mbar G30/31 • • • • • • 30/30 mbar G30/31 • • • 6 LPG G30/31 37 mbar G30/31 • 7 Town Gas G110 8 mbar • • G110 It is possible to identify the available gas types based on the country the appliance is to be installed in.
  • Page 26 7 Town gas G110 – 8 mbar UR-3c Rated heating capacity (kW) Nozzle diameter (1/100 mm) Pre-chamber (printed on nozzle) Reduced flow rate (W) 1400 The nozzles where not provided are available at Authorised Service Centres. WARNING: In the case of conversion to City GAS G110 - 8 mbar (category 1a) do not use the burners provided, but request the special G110 burners kit from our Technical Assistance Service.
  • Page 27 Appliance dimensions Assembling the upstand (on some models only) Position of gas connection The upstand must always be positioned and secured correctly on the appliance. Position of electrical connection 1. Unscrew the two nuts (B) on the back of the hob.
  • Page 28 1. Screw the wall fastening plate to the rear of 6. Consider a distance of 50 mm from the side the appliance. of the appliance to the bracket holes. 2. Adjust the height of the 4 legs. 3. Assemble the fastening bracket. 7.
  • Page 29 data, serial number and brand name is visibly valve, burner and ignition are working positioned on the appliance. properly. Do not remove this plate for any reason. • Turn the burner knobs to the minimum position and check that the flame is stable The appliance must be connected to ground for each individual burner and all the using a wire that is at least 20 mm longer than...
