- Page 1 Patio Heater 55000 BTU Owner’s Manual MODEL: UR55BN3 UR55GY2 UR55BK2 EASTOAK.COM OWNER’S MANUAL...
- Page 2 ( 9am-5pm PST/PDT ) installation video Unlock all the perks! Welcome to the East Oak family! Start the registration process now for a 3-year warranty. Stay updated with our latest news and exclusive discounts by following us on social media!
- Page 3 DANGER IMPORTANT INFORMATION DANGER indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Please check all parts and components to ensure no damage or missing items before starting the product’s construction. If you have any problems or discover any missing parts, please contact customer service at support@eastoak.com.
- Page 4 WARNING For Outdoor Use Only SAFETY INFORMATION CARBON MONOXIDE HAZARD • This appliance can produce carbon monoxide which has no odor. DANGER EXPLOSION - FIRE HAZARD • Using it in an enclosed space can kill you. • Never store propane near high heat, open flames, pilot lights, direct sunlight, •...
- Page 5 ASSEMBLY SUGGESTIONS SAFETY INFORMATION • Estimated Assembly Time: 60 minutes • Two adults required for a safe assembly WARNING • Cross-head screwdriver • This product is fueled by propane gas. Propane gas is invisible, odorless, and • Ladder flammable. An odorant is normally added to help detect leaks and can be described as a “rotten egg”...
- Page 6 PACKAGE CONTENTS PACKAGE CONTENTS PART DESCRIPTION QUANTITY Sand Box Wheel Kit Base Support Bracket Lower Post Upper Post Cylinder Housing Burner Assembly Reflector Panel Reflector Plate PATIO HEATER EASTOAK.COM OWNER’S MANUAL...
- Page 7 PARTS LIST PARTS LIST Sand Box Wheel Kit Base X 1 PC X 1 PC X 1 PC Burner Assembly Reflector Panel X 1 PC X 3 PCS Support Bracket Lower Post X 3 PCS X 1 PC Reflector Plate X 1 PC Upper Post Cylinder Housing...
- Page 8 PARTS LIST PARTS LIST Screw Bolt M8*16 M8 Washer Stud X 4 PCS X 3 PCS X 9 PCS + Spare X 1 X 3 PCS Bolt & M6 Flange Nut Washer Bolt Wing Nut Wrench X 6 PCS + Spare X 1 X 13 PCS + Spare X 1 X 3 PCS X 2 PCS...
- Page 9 ASSEMBLY INSTRUCTIONS Place the sand box flat on the ground, lift the base, and place it onto the sand box① (with the base covering). Attach the wheel kit② assembly to base③ using 2 M8 flange nuts and 2 M8*16 bolts. TIPS: The required screws (2 M8 flange nuts and 2 M8*16 bolts) are packaged with the wheel kit.
- Page 10 Screw 3 support brackets④ to the base with 3 M8x16 Attach lower post⑤ to support brackets using 6 bolts bolts(B). M6x30 and 6 M6 flange nuts(C). X 3 PCS X 6 PCS TIPS: Keep the bracket with the belt in the middle. TIPS: Secure bolts tightly.
- Page 11 Place the cylinder housing⑦ on top of the assembly. Put the burner assembly⑧ on a flat surface or on the ground first. Then insert the regulator from the top end of the upper post⑥. TIPS: The sticker is located on the same side as the ignition button.
- Page 12 Attach the burner assembly to upper post using the Connect the 3 pieces reflector⑨ panels together with 3 4 washer bolts(D). washer bolts(D) and 3 cap nuts(F). X 4 PCS X 3 PCS TIPS: If needed, loosen each TIPS: Secure bolts tightly. X 3 PCS screw prior to further assembly.
- Page 13 Attach the reflector plate to the installed 3 reflector Attach 3 reflector studs(H) and 3 M8 washers(G) to panels with 6 washer bolts(D) and 6 cap nuts(F). burner assembly firstly. Tighten the reflector studs. X 6 PCS X 3 PCS TIPS: Secure bolts tightly.
- Page 14 Insert the regulator from the top end of the lower post. Attach the reflector assembly made in step 10 to the top of the reflector studs on the burner assembly. Insert upper post to lower post, then tighten 2 posts Fasten with 6 M8 washers (G) and 3 wing nuts (I).
- Page 15 Unscrew the lid, add sand, and pour in water. Tighten the lid. Place the 20 lb gas cylinder (sold separately) in the center of the base and fasten it with the webbing. PATIO HEATER EASTOAK.COM OWNER’S MANUAL...
- Page 16 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS • Connect hose and regulator to cylinder. To Disconnect: Fully close the tank valve by turning clockwise. Turn the • The propane gas and cylinder are sold separately. coupling nut counterclockwise until the regulator assembly detaches. •...
- Page 17 OPERATION INSTRUCTIONS If bubbles appear at any connection, there is a leak. 1. Turn cylinder valve OFF. 2. If leak is at hose/regulator connection: tighten connection and perform another leak test. If bubbles continue appearing, the hose should be returned to the place LEAK CHECK of purchase.
- Page 18 OPERATION INSTRUCTIONS TURN MODE : ECO MODE Before Turning Gas Supply ON: 50,000 BTU, suitable for most situations. 1. Your heater was designed and approved for outdoor use only. Do NOT use it inside a building, garage, or any other enclosed area. BOOST MODE 2.
- Page 19 OPERATION INSTRUCTIONS 6. Unit will operate at reduced efficiency below 40°F. 7. Heater is outdoors (outside any enclosure). 8. There is adequate fresh air ventilation. 9. Heater is away from gasoline or other flammable liquids or vapors. WARNING FOR YOUR SAFETY 10.
- Page 20 CARE AND MAINTENANCE Note: In a salt-air environment (such as near an ocean) corrosion occurs more quickly than normal. Frequently check for corroded areas and repair them promptly. WARNING FOR YOUR SAFETY • Do NOT touch or move heater for at least 45 minutes after use. TIPS: Use high-quality automobile wax to help maintain the appearance of your •...
- Page 21 TROUBLE SHOOTING FEATURES • 55,000 BTU heat output provides a heating range of up to 20-foot diameter and up to 314 square feet of warmth. • 304 Stainless Steel heating mesh: compared with traditional patio heaters, our heaters are sturdier, and more durable. •...
- Page 22 • Damage caused by acts of nature (storm damage, wind damage, etc.). • Arbitrarily repair or modification by the customer. During the limited warranty period for the product, East Oak will provide parts, repair, or replace your product, at our discretion, due to any defect in materials or manufacturing defects.
- Page 23 support@eastoak.com eastoak.com 1-833-EAST-OAK (USA) PATIO HEATER...
