Power Connections
The only method of powering a VE4090AL Network
Interface is via a Power over Ethernet (PoE) switch
or power injector meeting the 802.3af specification.
Make all required signal connections before
connecting to Ethernet switch or power injector
meeting the 802.3af specification.
Network Connection
The VE4090AL Network Interface has one RJ-45
network connector and one RJ-45 horn connector.
Use a standard Ethernet patch cable to connect
the NETWORK connector of the VE4090AL
Network Interface to a PoE Ethernet switch.
Signal Connections
Connect RJ-45 using EIA/TIA 568B Standard to
the horn connector of the VE4080AL Network
Interface then to VM-186 RJ-45 connector.
Connect as shown in Figure 1.
If required, a normally open call button may be
connected to the white blue pair (pins 4 and 5) of
the HORN RJ-45 connector.
Status Indicator Lights
The VE4090AL has 2 status indication lights on the
front panel:
Green LED: (Link) Indicates Ethernet connection
when illuminated.
Valcom, Inc. warrants its products only to the original purchaser, for its own use, to be free from defects in materials and workmanship under conditions of
normal use and service for a period of one year from the date of shipment. This Limited Warranty obligation shall be limited to the replacement, repair or
refund of any such defective device within the warranty period, provided that:
1. inspection by Valcom, Inc. indicates the validity of the claim;
2. the defect is not the result of damage, misuse or negligence after the original shipment;
3. the product has not been altered in any way or repaired by others and that factory sealed units are unopened (a service charge plus parts
and labor will be applied to units defaced or physically damaged);
4. freight charges for the return of products to Valcom are prepaid;
5. all units 'out of warranty' are subject to a service charge. The service charge will cover minor repairs (major repairs will be subject to
additional charges for parts and labor).
This Limited Warranty is in lieu of and excludes all other warranties, expressed or implied and in no event shall Valcom, Inc. be liable for any
anticipated profits, consequential damages, loss of time or other losses incurred by the buyer in connection with the purchase, operation,
maintenance, installation, removal or use of the product. The maximum liability of Valcom under this warranty is limited to the purchase price of
the specific Product covered by the warranty.
Disclaimer. Except for the Limited Warranty provided herein, the product is provided "as-is" without any warranty of any kind whatsoever including, without
limitation, any WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT.
This warranty specifically excludes damage incurred in shipment. In the event a product is received in damaged condition, the carrier should be notified
immediately. Claims for such damage should be filed with the carrier involved in accordance with the F.O.B. point.
Yellow LED: (Activity) Indicator flashes to indicate
network activity.
Setup
Information specific to your application will need to
be programmed into the VE4090AL using a
computer. The PC used for programming should
be connected to the same subnet as the
VE4090AL. Setup will be done using the VIP-102B
IP Solutions Setup Tool. The IP Solutions Setup
Tool is available for download on the Valcom
website.
TECHNICAL ASSISTANCE
Assistance in troubleshooting is available from the
factory. When requesting assistance, you should
call from the job site Call (877) 427-2166 and ask
for Valcom Engineered Solutions Technical
Support, or visit our website at
www.ValcomES.com.
Class Connection equipment is not field repairable.
Valcom, Inc. maintains service facilities in
Roanoke, VA.
Should repairs be necessary, attach a tag to the
unit clearly stating your company name, address,
phone number, contact person and the nature of
the problem. Send the unit to:
Information is subject to change
VALCOM LIMITED WARRANTY
Headquarters:
Valcom, Inc.
5614 Hollins Road Roanoke, VA 24019-5056
Phone: (540) 563-2000 FAX: (540) 362-9800
3
Valcom, Inc.
Repair & Return Dept.
5614 Hollins Road
Roanoke, Va. 24019-5056
947771
