- Page 1 Washing Machine User Manual GWP89619WW 2820529836/ EN/ / 12/01/2022 10:21...
- Page 2 Auxiliary Function Selection.... 27 Table of Contents 6.8.1 Auxiliary Functions...... 28 6.8.2 Functions/Programmes Selec- 1 Safety Instructions ......ted by Pressing the Function Intended Use ........ Keys for 3 Seconds ....Safety of Children, Vulnerable Per- End Time ........30 sons and Pets ......
- Page 3 Please read this user manual first! Dear Customer, Thank you for choosing Grundig product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire user manual and all other accompanying documents care- fully before using the product.
- Page 4 1 Safety Instructions This section includes the safety • The product must only be instructions necessary to pre- used for washing and rinsing vent the risk of personal injury or of laundry that are marked ac- material damage. cordingly • This appliance is intended to Our company shall not be held be used in household and responsible for damages that...
- Page 5 ing use of the appliance in a • Cut the power cable and the product safe way and the break and deactivate the lock- hazards involved. ing mechanism of the loading • Children under the age of 3 door before disposing of the should be kept away unless product for children’s safety.
- Page 6 • When unplugging the appli- Installation Safety ance, don't hold the power • Check the information on the cord, but the plug. manual and installation in- • Make sure the plug is not wet, structions to prepare the dirty or dusty. product for installation and Handling Safety make sure the electrical...
- Page 7 • Place the product on a level be running from the tap in a and hard surface and balance minute in order for the product with the adjustable legs. to function properly. If the wa- • Connect the product to a ter pressure is above 1 MPa grounding plug protected by a (10 Bars), a pressure-reducing...
- Page 8 • Make sure pets do not climb Operational Safety inside the product. Check in- • When you are using the appli- side the product before use. ances, use only detergents, • Do not force open the locked softeners and supplements loading door.
- Page 9 charge hose is connected to • Do not use sharp or abrasive the tap. Do not touch the dis- tools to clean the product. Do charge water. not use household cleaners, • Take the following precautions soap, detergent, gas, gasol- to prevent formation of biofilm ine, thinner, alcohol, varnish, and malodours:...
- Page 10 2 Important Instructions for Environment 2.1 Compliance with WEEE Directive This product complies with EU WEEE Directive (2012/19/EU). This product bears a classifica- tion symbol for waste electrical and electronic equipment (WEEE). This product has been manu- factured with high quality parts and materials which can be reused and are suitable for re- cycling.
- Page 11 3 Technical Specifications Supplier’s name or commercial brand GRUNDIG GWP89619WW Model name 7177881800 Nominal Capacity (kg) Maximum spin speed (cycle/min) 1600 Built-In Height (cm) Width (cm) Depth (cm) Single Water inlet / Double Water inlet + / - Electrical input (V/Hz)
- Page 12 4 Installation • If you will install the product on a surface Please read the “Safety Instructions” with steps, never place it close to the section first! edge. • Please contact the nearest Authorised • Do not place the product on any platform. Service for the installation of the appliance.
- Page 13 NOTICE Remove the transportation safety bolts before operating the product. Otherwise, the product will get dam- aged. NOTICE Keep the transportation safety bolts in a safe place to reuse when the 4.5 Connecting the Drain Hose to product needs to be moved again in the Drain the future.
- Page 14 e. The end of the hose should not be bent, • Connection must comply with national it should not be stepped on and the hose regulations. must not be pinched between the drain • The electrical connection cable infrastruc- and the product. Otherwise, water dis- ture of the product must be adequate and charge issues may emerge.
- Page 15 5 Preparation cing into the product. Such dusts and Please read the “Safety Instructions” powders on the laundry may build up on section first the inner parts of the product in time and can cause damage. 5.1 Sorting the Laundry 5.3 Tips for Energy and Water Saving •...
- Page 16 ) there is a liquid detergent apparatus for 5.5 Correct Load Capacity liquid detergent use in the main washing The maximum load capacity depends on the compartment. type of laundry, the degree of soiling and the Detergent, Softener And Other Cleaning desired washing programme.
- Page 17 Only detergents, softeners and ad- ditives suitable for washing ma- chines should be used. Do not use natural hand washing soap for the washing machine. Adjusting the Detergent Amount The amount of detergent depends on the amount of laundry, how soiled they are and Use of Gel and Tablet Detergents the water hardness.
- Page 18 • Do not pour bleach directly onto the laun- detergent, first place the detergent in com- dry. partment no. “2” in the detergent drawer • Do not use bleach for coloured clothes. and wait for the product to rinse away the •...
- Page 19 SPECIAL CASE: At programme start of Cot- the machine. And if the detected load is tons and Cotton Eco programmes, display higher than half load; washing programme shows the duration of half load. It is the most will be adjusted accordingly and programme common use case.
- Page 20 6.2 Symbols on the Display 1 Temperature Indicator 2 Wireless Connection Indicator 3 Remote Control Indicator 4 Programme follow-up indicator 5 Duration information 6 Programme Start Indicator 7 Delayed Start Enabled Indicator 8 Door Lock Engaged Indicator 9 Auxiliary Function Indicators 5 10 Child Lock Engaged Indicator 11 Auxiliary Function Indicators 4 12 No Water indicator...
- Page 21 6.3 Programme and Consumption Table Auxiliary Functions Programme Temperature °C 2,75 1600 • • • • • Cold - 90 Cottons 2,00 1600 • • • • • Cold - 90 1,10 1600 • • • • • Cold - 90 40 *** 9 55,0 0,690 1600...
- Page 22 Please read Installation section of You can see the washing duration the manual before first use. on the display of your machine while The auxiliary functions in the table selecting a programme. Depending may vary according to the model of on the amount of laundry you have your machine.
- Page 23 quick wash function button is pressed, pro- Programmes are limited to the gramme duration becomes notably shorter highest spin speed appropriate for but effective washing performance is en- that particular type of fabric. sured with intense washing movements. If When selecting a programme, al- the quick wash function is not selected, ef- ways consider the type of fabric, col- fective washing and rinsing performance is...
- Page 24 • Supreme Refresh Allergy UK is the brand of the British Use this programme to reduce the creases Allergy Association. Seal of Approval is created to guide people that re- and ironing times of a small amount of un- spotted cotton, synthetic or mixed laundry. quire recommendation about a product that the related product re- •...
- Page 25 shirts, there may be differences on the • Lingerie wrinkle levels and humidity on shirts at the You can use this programme to wash delic- end of cycle. ate garments that are suitable for hand wash and delicate women's underwear. Small •...
- Page 26 When “Quick” is selected; 6.6 Temperature Selection Tea, coffee, juice, ketchup, red wine, cola, jam, coal a. Select the stain programme. b. Select the stain you want to clean by loc- ating it in the groups above and selecting the related group with the Quick/Intense Whenever a new programme is selected, the auxiliary function button.
- Page 27 ded spin speed value is not the maximum Rinse Hold spin speed that can be selected for the cur- If you are not going to unload your clothes rent programme. immediately after the programme completes, Press the Spin Speed Adjustment button to you can use rinse hold function to keep your change the spin speed.
- Page 28 case. You may use Intense selection to When an auxiliary function button achieve a better washing performance while that cannot be selected with the cur- washing heavily soiled laundry. rent programme is pressed, the You may shorten the programme duration by washing machine will make a warn- using the Quick/Intense key for your lightly ing sound.
- Page 29 • Remote Control • Filter Changing You can use this auxiliary function key to When your microfibre filter is full and you re- connect your product to smart devices. For place with the new filter, press and hold the detailed information, see HomeWhiz Func- related auxiliary function button for 3 tion Feature and Remote Control Function.
- Page 30 Programme duration may differ from • Wireless Connection the values in section "Programme You can match your machine and your and consumption table" depending smart devices with the wireless connection. on the water pressure, water hard- This way, you can use your smart device to ness and temperature, ambient tem- get information about your machine and perature, amount and the type of...
- Page 31 When you have activated the End If no programme is started or no Time function, do not add liquid de- button is pressed within 10 minutes tergent in the powder detergent during programme selection pro- compartment no 2. There is the risk cess, the product will automatically of staining of the clothes turn off.
- Page 32 If the water level in the machine is not suit- able when you press Start/Pause button, the door lock cannot be deactivated and the door lock icon on the display remains on. If the temperature of the water inside the machine is above 50°C, you cannot deactivate the door lock for safety reasons, even if the water level is suitable.
- Page 33 Filtering process is carried out automatically 6.13 Cancelling the Programme during the program. Filtering is carried out When the machine is turn on and off the pro- before discharge steps in the program in gramme gets cancelled. Press and hold On/ your washing machine.
- Page 34 Control Function button simultaneously In order to use the HomeWhiz func- for 3 seconds to switch your machine to tion, the application must be in- HomeWhiz setup mode. stalled on your smart appliance, and your washing machine must be paired with your smart appliance via Bluetooth.
- Page 35 You need internet connection on Since the HomeWhiz Feature and your smart device to proceed with Remote Control function on your ap- HomeWhiz setup. Otherwise, the pliance is operated via pairing using HomeWhiz application will not let Bluetooth technology only one you finish the setup procedure suc- Homewhiz application can operate it cessfully.
- Page 36 turn off. For this reason, you will need to turn You can follow whether the Remote Control on the bluetooth again if you want to use the function is On or Off through the function in- Remote Control function. dicator on the button. You can check the bluetooth symbol on the If the Remote Control function is Off, all the display to track your connection status.
- Page 37 7 Maintenance and Cleaning a. Press the marked part of the syphon Please read the “Safety Instructions” within the softener compartment and section first! then pull the drawer towards yourself to take it out. Service life of your product extends and fre- quently experienced problems will be re- duced if it is cleaned at regular intervals.
- Page 38 a. Close the taps. After every washing make sure that no for- eign substance is left in the product. b. Remove the nuts of the water intake If the holes on the door gasket shown in the hoses to access the filters on the water figure is blocked, open the holes using a intake valves and clean them with an ap- toothpick.
- Page 39 c. Follow the below procedures in order to NOTICE: drain water. Foreign substances left in the pump filter may damage your product or If the product has an emergency water may cause noise problem. draining hose, in order to drain the In regions where freezing is possible, water: the tap must be closed, system...
- Page 40 Water inside the product. Product stopped shortly after the programme started. • Some water has remained in the product due to the quality control processes in the • Machine has stopped temporarily due to production. >>> This is not a failure; water low voltage.
- Page 41 • Input temperature of water is low. >>> Re- • Excessive foam has occurred and auto- quired time to heat up the water extends matic foam absorption system has been in cold seasons. Also, washing time can activated due to too much detergent us- be lengthened to avoid poor washing res- age.
- Page 42 • Excessive amount of detergent is used. • Pump filter is clogged. >>> Check the fil- >>> Put the detergent in the correct com- ter. partment. Do not mix the bleaching agent • Draining hose is folded. >>> Check the and the detergent with each other.
- Page 43 • The detergent in the main wash compart- Foam is overflowing from the detergent ment got wet while taking in the prewash drawer. water. Holes of the detergent compart- • Too much detergent is used. >>> Mix 1 ment are blocked. >>> Check the holes tablespoonful softener and ½...
- Page 44 The spare part availability of the washing repairs by professional repairers (who machine or washer-dryer that you purchased are not authorized by Grundig ) shall void is 10 years. During this period, original spare the guarantee. parts will be available to operate the washing machine or washer-dryer properly.
