CTEK CHARGESTORM CONNECTED 3 Getting Started page 5

TECHNICAL SPECIFICATION
POWER
Power input TN/TT: 230 V ~/400 V 3N~ AC
50Hz Max
Power output AC
Connected to AC supply network Yes
Permanently connected to the mains Yes
Charging current Up to 32 A per outlet
Supply Connection TN/TT: L1,L2,L3,N,PE
Fuses C-Characteristics.
Breaking capacity 6kA
Mode 3: 32A
Rated frequency, f 50 Hz
n
Rated diversity factor, RDF 1
Rated insulation voltage, U 250/400 V
i
Rated impulse withstand voltage, U 4 kV
imp
Rated conditional short-circuit current, I 6 kA
cc
Rated conditional residual short-circuit 6 kA
current, I
∆c
Max prospective short-circuit current, I 6 kA
cp
Overvoltage category III
MECHANICS
Weight Up to 24 kg (depending on model)
Dimension H x W x D 449 x 282 x 160 mm
Material Front and back cover in ABS
plastic. Colored zinc oxide metal
box for electronics.
Ingress Protection IP54
Ambient operation temperature -30°C to +50°C
Altitude < 2000 m
Relative humidity Up to 100 % at +25°C
Storage temperature -30°C to +50°C
External mechanical impact IK10
© CTEK SWEDEN AB
INTERFACES
EV connector
64 A
(depends on model)
Display
Enclosure lock
Energy meter
RFID tag standard
Connectivity
RF Exposure
COMPATIBILITY
Compliance
Approval
Charging method
Electric shock protection
Communication protocol
Pollution degree
SAFETY
Ground fault detection
Rated making and breaking capacity,
I
m
One or two Type 2 outlets or Type 2
fixed cables
LED symbols
Mechanical lock with key.
MID-approved
Milfare 1k, Milfare 1k+, Milfare
Classic. 13,5 MHz.
4G: Frequency band: LTE Cat-1,
B3 B8 B20 power class: 23 dBm.
Fallback GSM/GPRS/EDGE 900 MHz
(Max: 2W) 1800 MHz (Max: 1W).
WiFi 2402-2482MHz, max output
power 100mW (+23dBm)
Dual Ethernet ports
Users recommended to remain
20cm away from the device during
operation.
EN 61851-1, EN 62196-2, EN 61439-
7, CE
Download the Declaration of
Conformity from
www.ctek.com
Mode 3
Class I equipment
OCPP 1.6
3
Built-in modular RCD Type B (EN
60947-2), AC 30 mA, DC 6mA
200 A contactor
WWW.CTEK.COM
OVERCURRENT AND SHORT-CIRCUIT PROTECTION
Rated current, I See Part specific data
n
Characteristic C
Rated short-circuit capacity, I 6 kA
cn
Rated service short-circuit breaking 7.5 kA
capacity, I
cs
Let-through energy, I t 36000 A s
2 2
CONFORMITY
Hereby, CTEK Sweden AB declares that the radio equipment type,
CHARGESTORM CONNECTED 3 model 3010, is in compliance with Directive
2014/53/EU (Radio Equipment Directive - RED).
The full text of the EU declaration of conformity is available at the following
Internet address: https://www.ctek.com/uk/quality/doc
PART SPECIFIC DATA
PART.NO RATED RATED LEFT
INPUT, U INPUT, I OUTLET
n nA
88-645** 400 V 32 A -
88-647** 400 V 64 A Outlet, 3 ph,
230/400 V,
32 A*
40-645 230/400 V 32 A -
40-647 230/400 V 64 A Outlet, 3 ph,
230/400 V,
32 A*
40-646 230/400 V 32 A -
40-648 230/400 V 64 A Cable, 3 ph,
230/400 V,
32 A*
*Expected minimum output current at 20 C ambient is 19A per outlet when
o
both outlets are in use. In ambient temperature of 50
is limited to 11A.
** Single-phase power input not supported.
CHARGESTORM® CONNECTED 3 | GETTING STARTED | 5
EN
RIGHT
OUTLET
Outlet, 3 ph,
230/400 V,
32 A
Outlet, 3 ph,
230/400 V,
32 A*
Outlet, 3 ph,
230/400 V,
32 A
Outlet, 3 ph,
230/400 V,
32 A*
Cable, 3 ph,
230/400 V,
32 A
Cable, 3 ph,
230/400 V,
32 A*
C, the output per outlet
o
