Summary of Contents for Hoshizaki HRWE Series
- Page 1 COMMERCIAL REFRIGERATOR / FREEZER HRWE - Series HFWE - Series HRFWE - Series INSTRUCTION MANUAL (ORIGINAL INSTRUCTIONS) 1001545_A...
- Page 2 CONTENTS PAGE I. INSTALLATION INSTRUCTIONS----------------------------------------------------------1 1. SAFETY INFORMATION------------------------------------------------------------------1 2. CONSTRUCTION--------------------------------------------------------------------------2 3. PRODUCT NOMENCLATURE-----------------------------------------------------6 4. SPECIFICATION----------------------------------------------------------------------------7 5. ACCESSORIES----------------------------------------------------------------------------9 6. LOCATION-----------------------------------------------------------------------------------9 7. SETUP---------------------------------------------------------------------------------------10 8. DRAIN PAN---------------------------------------------------------------------------------11 9. SHELF AND SHELF CLIP---------------------------------------------------------------12 10. ELECTRICAL CONNECTIONS------------------------------------------------------13 II. OPERATING INSTRUCTIONS-----------------------------------------------------------17 1. START UP----------------------------------------------------------------------------------18 2. FRONT PANEL----------------------------------------------------------------------------18 3.
- Page 3 I. INSTALLATION INSTRUCTIONS 1. SAFETY INFORMATION WARNING: RISK OF FIRE / FLAMMABLE MATERIALS IMPORTANT NOTICE These appliances contains small quantity of flammable refrigerant. all machines are to be serviced only by trained technicians for handling of hydrocarbon refrigerant. all electric components in this cooler are spark free, while replacing please ensure these are replaced with genuine authenticated components.
- Page 4 ENGLISH WARNING 2. CONSTRUCTION Do not wet the product or use it in 2.1 (HRWE77/HFWE77) potentially wet conditions. This may cause electrical leakage, Refrigeration Unit Machine Keep Dry resulting in electric shock or fire. Compartment The refrigerated unit contains R-290 and Ÿ...
- Page 5 ENGLISH 2.5 (HRWH77L-LG) Machine Compartment Refrigeration Unit Front Canopy Panel Glass Door Shelf Castor Fig. 3 2.7 (HRWH127/147/HFWH127/147) Machine Compartment Refrigeration Unit Front Canopy Panel Solid Door Shelf Fig. 4 Castor...
- Page 6 ENGLISH 2.11 (HRWE127-LG) Refrigeration Unit Machine Compartment Front Canopy Panel Glass Door Shelf Castor Fig. 5 2.11 (HRWE/HFWE147-LDGN) Machine Compartment Refrigeration Unit Front Canopy Panel Solid Door Shelf Castor Fig. 6...
- Page 7 ENGLISH 2.10 (HRFWE127) 2.10 (HRFWE77) Refrigeration Unit Front Canopy Panel Solid Door Shelf Castor Fig. 7 Fig. 8 2.12 (HRFWE127-LD) Machine Compartment Refrigeration Unit Front Canopy Panel Solid Door Shelf Castor Fig. 9...
- Page 8 ENGLISH 3. PRODUCT NOMENCLATURE: HRWE77-MS4R-LDGN R: Right Side handle Door H: HOSHIZAKI R/F:REFRIGERATOR/ FREEZER S4: SS 430 HL NO 4 FINISH W: WESTERN S3: SS 304 HL NO 4 FINISH M: Standard Model (230V 50Hz) E: Energy Efficient L: LED Version (230V 50Hz)
- Page 9 ENGLISH 4. SPECIFICATIONS: Model HRWE77 HRWH77-LG HRWH127 HRWH127-LG HRWH147 Power Supply Single phase, 230V AC, 50Hz Rated Current 1.3 Amp 1.3 Amp 2.3 Amp 2.3 Amp 2.3 Amp Rated Power 280 Watt 280 Watt 520 Watt 520 Watt 520 Watt Power cord 10 Amps / 3 meter 1400 (W) x 881(D)
- Page 10 ENGLISH 4. SPECIFICATIONS: Model HRFWE127 HRFWE127-LD REFRIGERATOR REFRIGERATOR FREEZER SECTION FREEZER SECTION SECTION SECTION Power Supply Single phase, 230V AC, 50Hz Rated Current ** Amp ** Amp ** Amp ** Amp Rated Power *** Watt *** Watt *** Watt *** Watt Power cord 10 Amps / 3 meter Outside dimension with castor...
- Page 11 ENGLISH PRODUCT OUTSIDE DIMENSIONS IN MM (WITH 124 MM CASTORS): HALF DOOR MODELS: HRWE77LS4 700 (W) x 881 (D) x 2024 (H) HRWE127LS4 1200 (W) x 881 (D) x 2024 (H) HRWE147LS4 1400 (W) x 881 (D) x 2024 (H) HFWE77LS4 700 (W) x 881 (D) x 2024 (H) HFWE127LS4...
- Page 12 ENGLISH Avoid a site where dripping is not allowed. ¬ Especially, a side-by-side or back-to-back installation (possibly with other manufacturer's unit) may cause condensation between the two units, resulting in dripping onto the floor. Do not expose the unit to direct sunlight or higher ¬...
- Page 13 ENGLISH 8. DRAIN PAN IMPORTANT 1. The drain pan is at rear side of the body 2. Drain pan surface is hot, do not touch it Drain Pan Airvent valve Water overflow pipe Fig. 18 Fig. 17...
- Page 14 ENGLISH 8. ELECTRICAL CONNECTIONS CAUTION Do not move the unit in fully loaded condition. IMPORTANT It may cause human fatigue. This appliance has no power switch, earth Front caster must be locked while unit is in leakage circuit breaker or overcurrent use.
- Page 15 ENGLISH ELECTRICAL WIRING DIAGRAM...
- Page 16 ENGLISH ELECTRICAL WIRING DIAGRAM...
- Page 17 ENGLISH ELECTRICAL WIRING DIAGRAM...
- Page 18 ENGLISH ELECTRICAL WIRING DIAGRAM...
- Page 19 ENGLISH II. OPERATING INSTRUCTIONS II. OPERATING INSTRUCTIONS IMPORTANT 1.Use the appliance only at the specified 15. Make sure all items are snug on each voltage. (As specified in the name plate). shelf. 2. Use standard socket. Do not use multi- 16.
- Page 20 ENGLISH 3. CABINET TEMPERATURE SETTING 1. START UP IMPORTANT 1) Plug in the unit. The temperature range given below is only the adjustable range. The actual cabinet temperature depends on the ambient 2) The compressor and condenser fan motor will temperature and other conditions.
- Page 21 ENGLISH HRWE / HFWE / HRFWE (Common) 5. INDICATOR LIGHTS The compressor stops when the cabinet temperature Indicator Symbol Status Function reaches down to the set temperature or minimum Compressor running compressor ON time whichever comes later, and starts Off Compressor off...
- Page 22 Immediately contact an authorized Polishing powder, alcohol, thinner, benzine, HOSHIZAKI service company. acidic or alkaline detergent, hot water, petroleum, Defrost sensor Defrost termination temperature is soap powder, metal scourer or brush, etc. Especially invalid.
- Page 23 HOSHIZAKI warrants to the original owner/user that all Disposed with other household wastes throughout the HOSHIZAKI branded products shall be free of defects in European union. To prevent possible harm to the material and/or workmanship for the duration of the environment or human health from uncontrolled waste “warranty period”.
