QUICK REFERENCE GUIDE
Please refer to the User Manual for
full instructions
ACTIVATE THE DEVICE -
DO NOT remove the pull
1.
tab until ready to deliver
therapy. Locate the red
pull tab at the base of the
battery cover.
Grip the pull tab firmly.
2.
Pull the tab to remove it
3.
and begin the 7-day timer
within the pump.
USING THE DEVICE
Confirm pump is
1.
connected to canister. To
connect the pump to the
canister, open the back of
the pump and insert canister
face down.
Confirm canister is
2.
connected to dome. To
connect the canister to
the dome, push the connectors
together and twist clockwise.
CLINICIAN ONLY
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DeRoyal PROSPERA FLEX
Summary of Contents for DeRoyal PROSPERA FLEX
- Page 1 QUICK REFERENCE GUIDE Please refer to the User Manual for full instructions ACTIVATE THE DEVICE - CLINICIAN ONLY DO NOT remove the pull tab until ready to deliver therapy. Locate the red pull tab at the base of the battery cover. Grip the pull tab firmly.
- Page 2 QUICK REFERENCE GUIDE USING THE DEVICE, CONT. Confirm wound dressing is applied properly and is securely connected to the canister and the Prospera Flex™ device. Confirm all tubing and tubing connections are open and free from kinks or other blockages. о...
- Page 3 QUICK REFERENCE GUIDE MONITORING THE SYSTEM OPERATION Check pump regularly. The pump is running when the green OK light is flashing. Check the dressing regularly. Monitor skin for redness and irritation. Contact clinician if skin condition deteriorates when the dressing is in use. The canister should be changed as soon as it is full.
- Page 4 QUICK REFERENCE GUIDE BATTERY STATUS Display Status Light/Audible Status Replace batteries soon. Low Battery Alert Turn pump ON or replace batteries. Pump Off Or Battery Dead BEFORE SHOWERING Turn the pump OFF. Disconnect the canister from the dome. Twist counter-clockwise. Remove the carrying bag holding the pump and canister.
- Page 5 QUICK REFERENCE GUIDE AFTER SHOWERING Put on the carrying bag holding the canister and pump. Reconnect the canister to the dome. Push and twist the connector clockwise. Route and fasten the tubing and straps to ensure they do not become kinked or entangled.
- Page 6 QUICK REFERENCE GUIDE DAILY ACTIVITIES Route and fasten the tubing and straps to avoid kinking or trapping. о Place tubing inside clothing whenever possible to avoid pulling or snagging. о When sitting at home or in the car, avoid sitting on the pump, canister, or tubing. о...
- Page 7 QUICK REFERENCE GUIDE BATTERY REPLACEMENT, CONT. Slide the pump battery cover closed until it snaps into place. Check the pump. о The pump is running normally when the green OK light is flashing. CHANGING THE CANISTER Check the canister fill status. EMPTY PARTIALLY о...
- Page 8 QUICK REFERENCE GUIDE CHANGING THE CANISTER, CONT. Replace the canister by inserting the bottom tab and rocking the clip of the new canister into the housing until it clicks. Close canister door. Reconnect the canister to the dome. Push and twist the connector clockwise.
- Page 9 QUICK REFERENCE GUIDE TROUBLESHOOTING Display Status Light/Audible Status Replace batteries within 24 hours. Low Battery Alert Check tubing and dressing for potential leak. Leak Alert Pump has completed 7 days of therapy and will no longer deliver Therapy NPWT. Complete Turn pump ON or replace batteries.
- Page 10 NOTES...
- Page 11 NOTES...
- Page 12 For product support, call: 1 (800) 524-3416 The DeRoyal logo and Prospera FLEX logo are trademarks or registered trademarks of DeRoyal Industries, Inc. Reprint # 0-1963 | Rev # 1/2024...
