Chamberlain SENTEX INFINITY Installation Instructions Manual page 2

INTRODUCTION
Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INSTALLATION
Mount the Cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
WIRING
Telephone Interface Board Connections . . . . . . . . . . . . . . . . . . . .5
Processor Board Signal Connections . . . . . . . . . . . . . . . . . . . .6-7
Optional Closed Circuit Television Connections (CCTV) . . . . . . . .8
Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Power On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
ADDITIONAL FEATURES
Postal Lock Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Auxiliary Opening/Request Access Devices . . . . . . . . . . . . . . . . .9
Door Position Sensing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Connect a Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Baud Rate for RS232 Communication . . . . . . . . . . . . . . . . . . . .11
Connect a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Connect an External Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Connect Remote Keypads/Keypad Lights . . . . . . . . . . . . . . . . . .13
Connect Card Readers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Connect Built-In Modem/Remote Programming/Multiple Entry . .15
Connect Optional Closed Circuit Television (CCTV) . . . . . . . . . . .15
IMPORTANT NOTES
The system is a powerful and flexible access control system, but
may be damaged by incorrect installation. In particular, it is
critical that the system be grounded properly. Each system
contains static sensitive components that can be destroyed by
static discharge if not grounded thoroughly.
WARNING:
• Incorrect installation invalidates the warranty.
• Please take the time to read these instructions carefully BEFORE
attempting installation.
T A B L E O F C O N T E N T S
ADJUSTMENTS
TESTING
LCD Display/Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Telephone Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Card Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Code Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Postal Lock/Request for Access/Door Position Monitoring . . . .19
Built-In Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Multiple Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Method of Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Optional Closed Circuit Television (CCTV) Monitoring . . . . . . . .19
FCC REQUIREMENTS
DOC REQUIREMENTS
OPERATOR NOTES
I N T R O D U C T I O N
PREPARATION
Your customer should have the telephone company install a
telephone line as close as possible to the system location.
• This line can use either tone or rotary dialing.
• Rotary lines are cheaper, but tone lines dial faster.
• The unit is factory-set to tone dial, but can be changed during
installation (see Adjustments).
• When ordering the telephone line, the phone company requires
the following information:
FCC REGISTRATION NUMBER:
RINGER EQUIVALENCE NUMBER (REN): 0.1B
TYPE OF CONNECTOR REQUIRED:
2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-17
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .22-23
DS83E7-1796-ALE
USOC RJ11C
