Anywire BL296 B-F-4P-20 Series Product Manual

AnyWireASLINK System Products Guide
ASLINKTERMINAL
BL296□B-□□F-4P□-20
This Products Guide is a document that describes individual products. Read it carefully to understand the products.
■Function List
Model
4 NPN input points
ASLINKTERMINAL
2 each NPN input/output points (mixed)
4-wire (isolated) 8 NPN input points
cable type 4 each NPN input/output points (mixed)
× 2 24V pin type
16 NPN input points
8 each NPN input/output points (mixed)
■Notes on Use A separate Address Writer ARW-04 (Ver. 04-1.01 or later) or ARW-03 (Ver. 2.10 or later) is required to
⇒
set addresses and other data.
[Notes on Safety]
Precautions that must be observed in order to use this system safely are indicated as shown below.
You must observe these precautions.
A WARNING indicates a potentially hazardous
situation which, if not handled correctly, could
result in death or serious injury.
WARNING
System Safety
○
This system is intended for general industrial applications. It does not have functions for supporting applications requiring higher levels
of safety such as safety-related devices or accident prevention systems. The product must not be used for these purposes.
WARNING
Always turn off the power in installing or replacing the system.
○
Prolonged continuous ow of a rated load current or higher or a transit current due to load short-circuit, etc., in the hybrid unit including
○
the output unit and the output circuit may result in smoking or ring. An external safety device such as a fuse must be installed.
System power supply
○
Use a stable, 24V DC power supply. Use of an unstable power supply may cause problems with the system.
Separately route high-voltage and power cables
CAUTION ○
Although the AnyWireASLINK has a high noise margin, install the transmission line and I/O cables away from high-voltage and power
cables.
Connectors and terminals
○
- Pay careful attention to the length and installation of cable wiring to ensure that connectors and cables are neither overloaded nor disconnected.
- Make sure to prevent any metal objects from getting inside the connectors or the terminal blocks.
- Short-circuits caused by metal objects or mis-wiring are likely to damage the device.
Do not impose any external loads on the units. Doing so may cause a failure.
○
Do not disconnect or reconnect between the transmission line and slave units when the transmission line is active. A malfunction may occur.
○
Use the AnyWireASLINK within the range of the speci cations and conditions shown below.
○
[Warranty]
■ Warranty period
The warranty on the delivered Product shall continue to be effective for one (1) year after the delivery thereof to a location as designated by
the original owner.
■ Scope of warranty
Should a defect occur in any part of the Product during the foregoing warranty period when it is used normally in accordance with the
speci cations described in this Products Guide, the Company shall replace or repair the defect free of charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by other than the delivered Product;
[3] The unauthorized modi cation or repair of the Product by any person other than the Company's personnel;
[4] Any unusual force of nature, disaster or other cause beyond the Company's control.
The term "warranty," as used herein, refers to the warranty applicable to the delivered product alone. The Company shall not be liable for
consequential or incidental damages resulting from any malfunction.
Repair at cost
■
After the expiration of the warranty period, the owner shall be responsible for all costs and expenses incurred for the troubleshooting and
repair of the Product. Even during the warranty term, the Company shall repair any defects arising from causes other than within the scope
of the warranty as speci ed above, at the owner's cost.
[Type]
BL296SB-04F-4PA-20 NPN input
BL296XB-04F-4PA-20
[ ASLINK Integrated Compact Terminal ]
Speci cations
BL296SB-08F-4P-20
NPN input/output
BL296XB-08F-4P-20
-BL296*B**F4P*20 1/15-
Connection targets
Detection of
slave unit
General-purpose sensors,
voltage drop
switches General-purpose
output devices
A CAUTION indicates a potentially hazardous situation
which, if not handled correctly, may result in personal
CAUTION injury or property damage.
NPN input
NPN input/output
Functions
Detection of Detection of Detection of
sensing I/O
level drop disconnection
○ × ×
BL296SB-16F-4PA-20
BL296XB-16F-4PA-20
Detection of
I/O power
I/O short Compact
supply
circuit
voltage drop
× ○ ○
NPN input
NPN input/output
