AnyWireASLINK System Products Guide
ASLINKTERMINAL [ASLINK terminal]
BL296□B-08F□-20
The Products Guide describes individual products. Refer to the Guide as necessary.
■Function List
Model
ASLINKTERMINAL
NPN eight-point input/eight-point output
four-wire (isolated)
PNP eight-point input/eight-point output
small eight-point
NPN four-point input/four-point output (hybrid)
terminal
PNP four-point input/four-point output (hybrid)
■Notes on use ⇒
Setting of addresses and similar items requires "address writer ARW-04 (Ver.04-1.01 or
higher) or ARW-03 (Ver.2.10 or higher)." Please prepare it separately.
[Notes on Safety]
Precautions that must be observed in order to use this system safely are indicated as shown below.
You must observe these precautions.
A WARNING indicates a potentially hazardous
situation which, if not handled correctly, could
result in death or serious injury.
WARNING
○ System Safety
This system is intended for general industrial applications. It does not have functions for supporting applications requiring higher levels of
safety such as safety-related devices or accident prevention systems.
WARNING
○ Always turn off the system power before attempting to mount or replace.
○ Prolonged continuous ow of a rated load current or higher or a transit current due to load short-circuit or similar problem, in the hybrid unit
including the output unit and the output circuit may result in smoke generation or re. An external safety device such as a fuse must be installed.
○ System power supply
Use a stabilized 24V DC power supply. Use of a non-stabilized power supply may cause problems with the system.
○ Separately route high-voltage and power cables
CAUTION
Although the AnyWireASLINK has a high noise margin, lay the transmission lines and I/O cables so as to keep them away from high-voltage
and power cables.
○ Connectors and terminals
・ Pay careful attention to the length and installation of cable wiring to ensure that connectors and cables are neither overloaded nor disconnected.
・ Make sure to prevent any metal objects from getting inside the connectors or the terminal blocks.
・ Short-circuits caused by metal objects or mis-wiring are likely to damage the device.
○ Do not impose any external loads on the units. Doing so may cause a failure.
○ Do not disconnect or reconnect between the transmission line and slave units when a transmission line is operating. A malfunction may occur.
○ Use the AnyWireASLINK within the range of the speci cations and conditions shown below.
[Warranty]
■ Warranty period
The warranty on the delivered Product shall continue to be effective for one (1) year after the delivery thereof to a location as designated by the original owner.
■ Scope of warranty
Should a defect occur in any part of the Product during the foregoing warranty period when it is used normally in accordance with the speci cations described
in this User's Manual, the Company shall replace or repair the defect free of charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by cause other than the delivered Product;
[3] Unauthorized modi cation or repair of the Product by any party other than the Company;
[4] Any unusual force of nature, disaster, or other cause beyond the Company's control.
The term "warranty," as used herein, refers to the warranty applicable to the delivered product alone. The Company shall not be liable for any damages conse-
quential or incidental to a malfunction of the delivered product.
■ Repair at cost
After the expiration of the warranty period, any troubleshooting or repairs shall be done at the expense of the owner.
Even during the warranty term, any repairs and troubleshooting for defects arising from causes outside the scope of the warranty as speci ed above shall be
done at the owner's expense.
[Type]
BL296SB-08F-20
NPN input
BL296PB-08F-20
NPN output
BL296XB-08F-20
NPN input/output
Speci cations
Connection targets
General-purpose
sensors and
switches
General-purpose
output devices
Eight-point
Eight-point
Four-point/Four-point
-BL296*B08F*20 1/18-
Slave unit
Sensing
I/O
voltage
level
disconnection
drop
drop
×
×
A CAUTION indicates a potentially hazardous situation
which, if not handled correctly, may result in personal
injury or property damage.
CAUTION
BL296SB-08FS-20
PNP input
BL296PB-08FS-20
PNP output
BL296XB-08FS-20
PNP input/output
0
1
2
3
4
5
6
7
ADDRESS No.
BL296SB-
08F-20
R/W
Functions
I/O
I/O
Small-
power supply
short-
voltage
sized
circuit
drop
×
Eight-point
Eight-point
Four-point/Four-point
Water
proof
×

Advertisement

loading
Need help?

Need help?

Do you have a question about the ASLINKTERMINAL BL296 B-08F 20 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Anywire ASLINKTERMINAL BL296 B-08F 20 Series

  • Page 1 AnyWireASLINK System Products Guide ASLINKTERMINAL [ASLINK terminal] ADDRESS No. BL296SB- BL296□B-08F□-20 08F-20 The Products Guide describes individual products. Refer to the Guide as necessary. ■Function List Model Speci cations Connection targets Functions General-purpose Slave unit Sensing ASLINKTERMINAL NPN eight-point input/eight-point output Small- Water power supply...
  • Page 2 [AnyWireASLINK Terminal] The AnyWireASLINK can employ a two-wire or four-wire terminal selectively depending on the load current. If the load current is small, using a two-wire (non-isolated) terminal allows for achieving simpli ed wiring without local power supply. In the case of prioritizing the sites of concentrated loads and/or the number of connections, hybridization with a four-wire (isolated) terminal, which supports local power supply, is also possible.
  • Page 3 MAX 5A/24V DC Filter of COSEL Co., Ltd. EAC-06-472 MAX 6A/24V DC ■AnyWire Type: ANF-01 Connection example (The gure is an explanatory schematic. Adjust the actual terminal layout to meet each device.) ①Power supply to the entire system Two-wire Four-wire...
  • Page 4 ■COSEL Co., Ltd. Type: EAC-06-472 Connection example (The gure is an explanatory schematic. Adjust the actual terminal layout to meet each device.) ①Power supply to the entire system Two-wire Four-wire Four-wire terminal terminal terminal AnyWireASLINK master LOAD LINE Terminator EAC-06-472 If any of the side-by-side lines of DP, DN, 24V, or 0V exceeds the total length of 50m General-purpose power supply filter...
  • Page 5 - The address number to be set for the terminal is for interacting with the input/output memory map of the controller. An AnyWire address number indicates the number of the terminal for the transmission frame, and the number of occupied points for the terminal are used from this number.
  • Page 6 [Indication Function] Normal state: LINK flashing, ALM off, I/O ON on/OFF off LED display LED symbol Indication status Details Transmission signal error LINK Transmission signal reception Flashing No transmission signal (including DP, DN disconnections and reverse connections) I/O power supply voltage drop Slave unit voltage drop Flashing ADDRESS No.
  • Page 7 0V (3,4) [Example] 0V (white) Use 0V in common. Four-wire (isolated) ASLINKTERMINAL Load controlled by an external (AnyWire system power supply) system power supply Four-wire (isolated) NPN Output BL296PB-08F-20 <Circuit requirements> Withstand voltage: 30V DC Add a surge killer if using...
  • Page 8 (black) 0V (3,4) [Example] 0V (white) Use 0V in common. Four-wire (isolated) ASLINKTERMINAL Load controlled by an external (AnyWire system power supply) system power supply Four-wire (isolated) PNP output BL296PB-08FS-20 <Circuit requirements> 24V (green) Withstand voltage: 30V DC DP (red)
  • Page 9 DN (black) 0V (3,4) [Example] 0V (white) Use 0V in common. Four-wire (isolated) ASLINKTERMINAL Load controlled by an external (AnyWire system power supply) system power supply Four-wire (isolated) NPN output BL296XB-08F-20 (Output side) 24V (1,2) <Circuit requirements> 24V (green) Add a surge killer if using Withstand voltage: 30V DC an inductive load.
  • Page 10 DN (black) 0V (3,4) [Example] 0V (white) Use 0V in common. Four-wire (isolated) ASLINKTERMINAL Load controlled by an external (AnyWire system power supply) system power supply Four-wire (isolated) PNP output BL296XB-08FS-20 (Output side) <Circuit requirements> 24V (green) Withstand voltage: 30V DC...
  • Page 11 [Specifications] ■Individual speci cations ■General Specifications 0 to +55°C Number of Ambient temperature for use BL296SB-08F-20 NPN eight-point input BL296PB-08F-20 NPN eight-point output occupied 10 to 90%RH No condensation Ambient humidity for use BL296XB-08F-20 NPN four-point input/four-point output data items -25 to +75°C Storage temperature BL296SB-08FS-20...
  • Page 12 [Outside Dimensions] Unit: mm UL style 20276 Four cores of 38.4 No.11 pole No.12 pole R2.3 No. 23 AWG (gray) φ4.6 Indication Indication Black: DN Red: DP White: 0V Green: 24V (200) No.1 pole No.2 pole Indication Indication Core covering outside diameter φ1.4 +...
  • Page 13 [Extension] For the small eight-point terminal, an optional connection cable and connection terminal are available. Combining these allows for development as a small connector-type terminal. [Standard structure] ■Connection terminal ■Small eight-point terminal ■Connection cable * This figure shows an e-CON. * Combination has no limitation.
  • Page 14 [Connection terminal connection example e-CON] ■BL296S-08-4...(e-CON installed) – Two-wire sensor NPN input BL296SB-08F-20 (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) BL296XB-08F-20 Three-wire – sensor (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) ■BL296P-08-4...(e-CON installed) Load NPN output –...
  • Page 15 [Connection terminal connection example JST XH series] ■BL296S-08-9...(JST XH series installed) – Two-wire sensor NPN input BL296SB-08F-20 (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) BL296XB-08F-20 – Three-wire sensor (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) ■BL296S-08-9...(JST XH series installed) –...
  • Page 16 [Connection terminal connection example MOLEX 5045 series] ■BL296S-08-10...(MOLEX 5045 series installed) – Two-wire sensor NPN input BL296SB-08F-20 (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) BL296XB-08F-20 – Three-wire sensor (IN 0, 1, 2, 3, OUT 0, 1, 2, 3) ■BL296P-08-10...(MOLEX 5045 series installed) –...
  • Page 17 [Connection terminal outside dimensions] Unit: mm 43.6 39.4 2-Φ3.5 26.3 26.3 (44) ■ADP-T96 (Mounting DIN Rail Adapter) Dimensions With the mounting DIN rail adapter attached With the mounting DIN rail adapter attached and fixed to the DIN rail in a right-angle direction and fixed to the DIN rail in the same direction 19.75 19.75...
  • Page 18 [Address] Anywire Corporation Headquarters :1 Babazusho, Nagaokakyo-shi, Kyoto 617-8550 JAPAN Contact :Contact by mail info_e@anywire.jp :Contact by website http://www.anywire.jp Printed in Japan 2016, 2017,2018 UMA-15278AE-EN -BL296*B08F*20 18/18-...
