Anywire ASLINK BL296 B-08F V50 Series Product Manual

Terminal with compact terminal block

Advertisement

Quick Links

AnyWireASLINK System Products Guide
ASLINKTERMINAL
BL296□B-08F□□□□-V50
■ Note on use ⇒A separate Address Writer is required to set addresses and other data.
*
For more information, refer to [Various Settings] on page 12.
[Type]
BL296SB-08F-V50
BL296XB-08F-V50
BL296PB-08F-V50
BL296SB-08F-3-V50
BL296XB-08F-3-V50
BL296PB-08F-3-V50
BL296SB-08F-11-V50
BL296XB-08F-11-V50
BL296PB-08F-11-V50
[Notes on Safety]
Precautions that must be observed in order to use this system safely are indicated as shown below.
You must observe these precautions.
A WARNING indicates a potentially hazardous
WARNING
situation which, if not handled correctly, could
result in death or serious injury.
○ System Safety
WARNING
This system is intended for general industrial applications. It does not have functions for supporting applications requiring higher
levels of safety such as safety-related devices or accident prevention systems. The product must not be used for these purposes.
○ Always turn off the power in installing or replacing the system.
○ Prolonged continuous ow of a rated load current or higher or a transit current due to load short-circuit, etc., in the hybrid unit including
the output unit and the output circuit may result in smoking or ring. An external safety device such as a fuse must be installed.
○ System power supply
CAUTION
Use a stable, 24V DC power supply. Use of an unstable power supply may cause problems with the system.
○ Separately route high-voltage and power cables
Although the AnyWireASLINK has a high noise margin, install the transmission line and I/O cables away from high-voltage and power cables.
○ Connectors and terminals
- Pay careful attention to the length and installation of cable wiring to ensure that connectors and cables are neither overloaded nor disconnected.
- Make sure to prevent any metal objects from getting inside the connectors or the terminal blocks.
- Short-circuits caused by metal objects or mis-wiring are likely to damage the device.
○ Do not impose any external loads on the units. Doing so may cause a failure.
○ Do not disconnect or reconnect between the transmission line and slave units when the transmission line is active. A malfunction may occur.
○ Use the AnyWireASLINK within the range of the speci cations and conditions shown below.
[Warranty]
■ Warranty period
The warranty on the delivered Product shall continue to be effective for one (1)
year after the delivery thereof to a location as designated by the original owner.
■ Scope of warranty
Should a defect occur in any part of the Product during the foregoing warranty
period when it is used normally in accordance with the speci cations described
in this Products Guide, the Company shall replace or repair the defect free of
charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by other than the delivered Product;
[3] The unauthorized modi cation or repair of the Product by any person other
than the Company's personnel;
[4] Any unusual force of nature, disaster or other cause beyond the Company's control.
The term "warranty," as used herein, refers to the warranty applicable to the
delivered product alone. The Company shall not be liable for consequential or
incidental damages resulting from any malfunction.
■ Repair at cost
After the expiration of the warranty period, the owner shall be responsible for all
[ ASLINK Terminal with Compact Terminal Block ]
NPN input
Standard
NPN input/NPN output
terminal block
NPN output
NPN input
Spring
NPN input/NPN output
terminal block
NPN output
NPN input
Euro
NPN input/NPN output
terminal block
NPN output
-BL296*B08F****V50 1/22-
BL296SB-08FS-V50
BL296XB-08FS-V50
BL296PB-08FS-V50
BL296SB-08FS-3-V50
BL296XB-08FS-3-V50
BL296PB-08FS-3-V50
BL296SB-08FS-11-V50
BL296XB-08FS-11-V50
BL296PB-08FS-11-V50
A CAUTION indicates a potentially hazardous situation
CAUTION
which, if not handled correctly, may result in personal
injury or property damage.
costs and expenses incurred for the troubleshooting and repair of the Product. Even
during the warranty term, the Company shall repair any defects arising from causes
other than within the scope of the warranty as speci ed above, at the owner's cost.
■ Changes in the product speci cations and the descriptions in the manual
The descriptions in this manual may be subject to change without notice.
[About Pictogram *
Ver. 1.0*
*
1 The pictogram may not be marked (or stuck) depending on the product.
*
2 AnyWireASLINK device not compatible with Ver. 1.1 (word transmission and
single unit simplified replacement functions)
Some products, not marked with the Ver. 1.1 pictogram, are compatible with
the functions included in Ver. 1.1. Refer to the lot No. and the product guide
for ultimate confirmation.
*
3 For details of Ver. 1.1, refer to the subsequent pages.
PNP input
Standard
PNP input/PNP output
terminal block
PNP output
PNP input
Spring
PNP input/PNP output
terminal block
PNP output
PNP input
Euro
PNP input/PNP output
terminal block
PNP output
]
1
Compatible with
2
Ver. 1.1*
Ver.1.1
Euro terminal
block type
3
