If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
Coffee Table
Stock # PW1425004710030
# PW1425004710031
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
www.whalenstyle.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2024-04-22
1-866-942-5362
Rev. 0001-A
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Related Manuals for Pioneer Woman Helen PW1425004710030
Summary of Contents for Pioneer Woman Helen PW1425004710030
- Page 1 LOT NUMBER: DATE PURCHASED: Coffee Table Stock # PW1425004710030 # PW1425004710031 ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 Pacific Standard Time: 8:30 a.m.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: Coffee Table MODEL: PW1425004710030 / PW1425004710031 MAXIMUM LOAD 90.7 kg / 200 lb MAXIMUM LOAD 22.7 kg / 50 lb WARNING...
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Table Top (Qty. 1) B- Bottom Panel (Qty. 1) C- Leg (Qty. 4) (1) 5/16” x 51 mm Bolt (Qty. 4+1 extra) (2) Hex Nut (Qty.
- Page 4 Assembly Instructions 2 3 4 Pre-attached ④ x 8 ③ x 8 ② x 8 WARNING DO NOT fully tighten the bolts or nuts initially until all the bolts or nuts are ready to assemble. To avoid causing damages to the thread, DO NOT over-tighten the bolts or nuts. 1.
- Page 5 Assembly Instructions 1 3 4 ④ x 4 ③ x 4 ① x 4 4. Align and attach the Bottom Panel (B) to the Legs (C) by inserting four 51 mm Bolts (1) with the Lock Washers (3) and Flat Washers (4) through the side cleat and screw into place. Tighten the bolts with the Ratchet Wrench provided.
- Page 6 Assembly Instructions 5. Ask for assistance to lift the unit upright and position it at the desired location. 6. If necessary, adjust the pre-attached floor levelers at the bottom of Legs (C) to level the unit.
- Page 7 Care and Maintenance Use a soft, clean cloth that will not scratch the surface when dusting. Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area. Using solvents of any kind on your furniture may damage the finish. ...
- Page 9 LOTE NUMERO FECHA DE COMPRA: Mesa de Centro Serie # PW1425004710030 # PW1425004710031 ENSAMBLE POR ADULTO REQUERIDO Si tienen alguna pregunta acerca del ensamble o si alguna parte está faltante, no retorne esté producto a la tienda donde lo compro. Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el número de fábrica: 1-866-942-5362 Hora estándar del Pacífico: 8:30 a.m.
- Page 10 M Á X I M O P E S O R E C O M E N D A D O FABRICANTE: Whalen Furniture Manufacturing CATALOGO: Mesa de Centro SERIE: PW1425004710030 / PW1425004710031 CARGA MÁXIMA 90.7 kg / 200 lb. CARGA MÁXIMA 22.7 kg / 50 lb.
- Page 11 Lista de partes y material de ferretería Por favor lea completamente las instrucciones y verifique que estén todas las partes y partes de ferretería antes de iniciar el ensamblado A- Tapa superior (Cant. 1) B- Panel inferior (Cant. 1) C- Pata (Cant. 4) (1) 5/16”...
- Page 12 Instructivo de Ensamble 2 3 4 Pre- instalado ④ x 8 ③ x 8 ② x 8 ADVERTENCIA NO apriete los pernos hasta que todos los pernos estén listos para el ensamble. Para evitar daños a la rosca. NO sobre apriete los pernos. 1.
- Page 13 Instructivo de Ensamble 1 3 4 ④ x 4 ③ x 4 ① x 4 4. Alinee y fije el panel inferior (B) a las patas (C) insertando cuatro pernos de 51 mm (1) con las arandelas de presión (3) y las arandelas planas (4) a través del listón lateral y atorníllelos en su lugar. Apriete los pernos con la llave de trinquete proporcionada.
- Page 14 Instructivo de Ensamble 5. Pida ayuda para levantar la unidad en posición vertical y colocarla en la ubicación deseada. 6. Si es necesario, ajuste los niveladores de piso preinstalados en la parte inferior de las Patas (C) para nivelar la unidad.
- Page 15 Mantenimiento y Cuidados Use una toalla suave y limpia para evitar daños y rayaduras. Uso de cera para pulir muebles no es necesario. Si desea usar cera, pruébela en un área que no sea visible para revisar su funcionamiento. ...
