VTech A2310 User Manual
VTech A2310 User Manual

VTech A2310 User Manual

Analogue corded trimstyle hotel telephone
Hide thumbs Also See for A2310:

Advertisement

Quick Links

Analogue Contemporary Series
User's Guide
Model:
Analogue corded trimstyle hotel telephone - A2310

Advertisement

loading
Need help?

Need help?

Do you have a question about the A2310 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for VTech A2310

  • Page 1 Analogue Contemporary Series User’s Guide Model: Analogue corded trimstyle hotel telephone - A2310...
  • Page 2 Important safety instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: This product should be installed by a qualified technician. 2. This product should only be connected to the host equipment and never directly to the network such as Public Switch Telephone Network (PSTN) or Plain Old Telephone Services (POTS).
  • Page 3 For cETL compliance only Mesures de sécurité importantes Afin de réduire les risques d’incendie, de blessures corporelles ou d’électrocution, suivez toujours ces mesures préventives de base lorsque vous utilisez votre téléphone: 1. Cet appareil doit être installé par un technicien qualifié. 2.
  • Page 4 Telephone layout ���������������������������������������������������������������������������������������������������������������������������������������������������������������� 6 Installation �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 7 Set up ���������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 9 Operation �������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 10 Appendix ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������11 Troubleshooting ............................................11 VTech Hospitality limited warranty program ..................................12 Maintenance ..............................................13 Important note ...............................................14 Environmental notes ............................................14 Product disposal instructions ........................................14 Technical information..........................................14 European Directives .............................................14 Declaration of Conformance ........................................14...
  • Page 5 Parts checklist Items contained in the telephone package: Model name Model number Parts included Analogue corded A2310 trimstyle Telephone Telephone base with Corded Mounting line cord faceplate and overlay handset bracket...
  • Page 6 Telephone layout MESSAGE WAITING LED FAX/DATA port Switch hook Wall mount clip -/VOLUME/+ MUTE FLASH MUTE LED RINGER VOL...
  • Page 7 Installation Telephone base installation The telephone can be adapted to desktop use or mount on a standard telephone wall plate. Installation option - desktop position 1. Turn the telephone base over with the bottom side facing up. Connect the telephone line cord to the telephone base and route along the wire duct.
  • Page 8 Installation Installation option - converting from desktop to wall mount position To mount the telephone base on the wall: 1. Set aside the handset. On the telephone base cradle, place a coin in the slit of the wall mount clip and rotate a half turn (180 degrees).
  • Page 9 Set up Default settings are indicated by asterisks (*). Setting Options Adjustable by Handset earpiece volume 1, 2, 3*, 4, 5 User and administrator Ringer volume Low, Medium*, High User and administrator Ringer tone Tone 1*, Tone 2, Tone 3 Administrator only Disable voicemail voltage detection, Administrator only...
  • Page 10 Operation Receive a call When there is an incoming call, the telephone rings and the MESSAGE WAITING LED flashes. To answer a call: Lift the corded handset from the telephone base. Place a call Lift the corded handset from the telephone base. Listen for a dial tone and then dial the desired number. End a call Place the corded handset in the telephone base.
  • Page 11 Appendix Troubleshooting If you have difficulty with the telephones, please try the suggestions below. For customer service, visit our website at www. vtechhotelphones.com or contact your local distributor. For corded telephones: telephone does not work at all� • Make sure the telephone line is plugged into the TEL port of the telephone base. •...
  • Page 12 Product in transit. If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorise the cost of repair and return shipping costs for the repair of Products that not covered by this limited warranty.
  • Page 13 Appendix Maintenance Taking care of the telephone The telephone contains sophisticated electronic parts, so it must be treated with care. Avoid rough treatment Place the handset down gently. Save the original packing materials to protect the telephone if you ever need to ship it. Avoid water The telephone can be damaged if it gets wet.
  • Page 14 These equipments are compliant with directives 1999/5/EC (R&TTE), 2014/35/EU (LVD), 2014/30/EU (EMC) and 2011/65/EU (ROHS). Declaration of Conformance Hereby, VTech declares that cordless equipment are in compliance with the essential requirements of directive 1999/5/EC (R&TTE) The Declaration of Conformity may be obtained from: www�vtechhotelphones�com.
  • Page 15 Appendix Technical specifications Analogue corded trimstyle - A2310 Power requirement Line powered 24V or 48V Message waiting signal Steady/periodic high voltage pulse and periodic low voltage pulse Size Telephone base: 8.47 x 2.87 x 2.17 in (215 x 73 x 55 mm) Corded handset: 8.39 x 1.85 x 1.65 in (213 x 47 x 42 mm)
  • Page 16 VTECH TELECOMMUNICATIONS LTD. A member of THE VTECH GROUP OF COMPANIES. VTech is the registered trademark of VTech Holdings Limited. Copyright © 2023 for VTECH TELECOMMUNICATIONS LTD A2310_UG_V1_CEC_EU-UK_2023.05.29 All rights reserved. 05/23. Printed in China.
