LTM4644/LTM4644-1
PIN FUNCTIONS
PACKAGE ROW AND COLUMN LABELING MAY VARY
AMONG µModule PRODUCTS. REVIEW EACH PACKAGE
LAYOUT CAREFULLY.
V (A1, A2, A3), V
OUT1 OUT2
G1, G2), V (J1, K1, K2): Power Output Pins of Each
OUT4
Switching Mode Regulator Channel. Apply output load
between these pins and GND pins. Recommend placing
output decoupling capacitance directly between these pins
and GND pins. See the Applications Information section
for paralleling outputs.
GND (A4-A5, B1-B2, C5, D3-D5, E1-E2, F5, G3-G5,
H1-H2, J5, K3-K4, L1-L2): Power Ground Pins for Both
Input and Output Returns. Use large PCB copper areas to
connect all GND together.
V (B3, B4), V (E3, E4), V
IN1 IN2
Power input pins connect to the drain of the internal top
MOSFET for each switching mode regulator channel.
Apply input voltages between these pins and GND pins.
Recommend placing input decoupling capacitance directly
between each of V pins and GND pins.
IN
PGOOD1, PGOOD2, PGOOD3, PGOOD4 (C3, C2, F2,
J2): Output Power Good with Open-Drain Logic of Each
Switching Mode Regulator Channel. PGOOD is pulled to
ground when the voltage on the FB pin is not within ±10%
of the internal 0.6V reference.
CLKOUT (J3): Output Clock Signal for PolyPhase
tion of the Module. The phase of CLKOUT with respect to
CLKIN is set to 180°. CLKOUT's peak-to-peak amplitude
is INTV to GND. See the Application Information section
CC
for details. Strictly output; do not drive this pin. CLKOUT
is only active when RUN4 is enabled.
INTV , INTV , INTV
CC1 CC2 CC3
Internal 3.3V Regulator Output of Each Switching Mode
Regulator Channel. The internal power drivers and con-
trol circuits are powered from this voltage. Each pin is
internally decoupled to GND with 1µF low ESR ceramic
capacitor already.
6
(C1, D1, D2), V (F1,
OUT3
(H3, H4), V (L3, L4):
IN3 IN4
Opera-
®
, INTV (C4, F4, J4, K5):
CC4
For more information
SV , SV , SV , SV
IN1 IN2 IN IN4
Filtered input voltage to the internal 3.3V regulator for
the control circuitry of each Switching mode Regulator
Channel. Tie this pin to the V
applications. Connect SV
of at least 4V which must also be greater than V
TRACK/SS1, TRACK/SS2, TRACK/SS3, TRACK/SS4 (A6,
D6, G6, K6): Output Tracking and Soft-Start Pin of Each
Switching Mode Regulator Channel. Allows the user to
control the rise time of the output voltage. Putting a volt-
age below 0.6V on this pin bypasses the internal reference
input to the error amplifier, instead it servos the FB pin
to match the TRACK voltage. Above 0.6V, the tracking
function stops and the internal reference resumes control
of the error amplifier. There's an internal 2.5µA pull-up
current from INTV on this pin, so putting a capacitor
CC
here provides soft-start function.
MODE1, MODE2, MODE3, MODE4 (B6, E6, H6, L6):
Operation Mode Select for Each Switching Mode Regula-
tor Channel. Tie this pin to INTV
synchronous operation at all output loads. Tying it to
SGND enables discontinuous current mode operation at
light loads. Do not leave floating.
RUN1, RUN2, RUN3, RUN4 (C6, F6, J6, K7): Run Control
Input of Each Switching Mode Regulator Channel. Enable
regulator operation by tying the specific RUN pin above
1.2V. Pulling it below 1.1V shuts down the respective
regulator channel. Do not leave floating.
FB1, FB2, FB3, FB4 (A7, D7, G7, J7): The Negative Input
of the Error Amplifier for Each Switching Mode Regulator
Channel. Internally, in LTM4644, this pin is connected to
V of each channel with a 60.4kΩ precision resistor.
OUT
Different output voltages can be programmed with an
additional resistor between the FB and GND pins for the
LTM4644, and two resistors between the V
GND pins for the LTM4644-1. In PolyPhase operation, tying
the FB pins together allows for parallel operation. See the
Applications Information section for details.
www.analog.com
(B5, E5, H5, L5): Signal V
pin respectively in most
IN
to an external voltage supply
IN
OUT
to force continuous
CC
, FB and
OUT
.
IN
.
