Rielta Udar-A Installation Manual

ADDRESSABLE
COMBINED SECURITY
DETECTOR
«Udar-А»
Installation Guide
1 General Information
1.1 The addressable combined security detector «Udar-A» (hereinafter referred
to as the Detector) allows to counteract to any attempts to break into and/or steal
ATMs, safes and other banking security units by transmitting notifications via an
addressable loop (hereinafter referred to as the ADL) in accordance with the
«Rielta-Contact-ADR» protocol to a Control Panel (hereinafter referred to as CP).
1.2 The Detector has two independent detection channels: a burglary detection
channel and the angle of inclination change detection channel.
1.3 The Detector is resistant to electromagnetic interference, single impacts
on the protected structure and acoustic noise.
1.4 The Detector provides the ability to select an operating mode depending
on the material of the protected structure and the ability to gradually adjust the
sensitivity on the burglary detection channel.
1.5 The Detector is powered from the ADL.
1.6 The Detector generates and ensures transmission of the following
notifications via the ADL:
- «Normal» – in the absence of influences in the detection channels;
- «Opening» – when the case is open or removed from the place on mounting.
- «Destruction» – when attempts to break into, destroy and (or) steal a
protected structure are detected.
- «Tilt» – when changing of the angle of inclination of the protected structure
is detected;
- «Power failure» – when the supply voltage in the ADL is low.
1.7 The Detector can report the current value of the supply voltage in the ADL
in response to a corresponding request from the CP.
1.8 The Detector is designed for continuous 24-hour operation.
1.9 The Detector is resistant to electromagnetic interference.
2 Technical specification
Table 1
Parameters
Controlled area, not less than:
- solid concrete, brick or wood structure
- metal cabinet, door, upper ATM cabinet
- safe, lower ATM cabinet
Tilt change detection
Average power consumption
Technical readiness time
Protection class
Dimensions
Weight
Average service life
Operational conditions
Operating temperature range
Permissible relative humidity at a temperature of +25°C
3 Scope of Delivery
Table 2
Name
Addressable combined security detector «Udar-A»
Accessories set:
Screw A.M4-6gx40.48.016
Washer 4.65G.029
Cyanoacrylate glue
Instructions for the Addressable combined security detector «Udar-A»
Serial interface matching device «US-PI»
* Supplied upon special request
3 Design
The Detector consists of a case cover and a case base (1) with an installed
printed circuit board (2).
The base of the case with a printed circuit board is shown in Picture 1.
The base of the case contains:
- case cover hook (3);
- printed circuit board latch (5);
- openable holes for the passage of cables (7);
- case cover latch (8);
- pin of the detector removal control sensor (11);
- sensitive element (12).
The printed circuit board contains:
- dip switch (4);
- terminal blocks (6) for connecting to ADL;
- indicators (9);
- tamper switch (10).
а) top view (no case cover)
10
9
5 Indication
The Detector generates the following types of indication:
- indication of successful registration/deletion of the Detector in the CP;
- «Identification» indication turns on after receiving the corresponding command
from the CP and remains active for 15 minutes;
- «Initialization» indication turns on immediately after power is applied for 10 s.
- indication of the status of the detection channels turns on after power is
supplied and after initialization or upon receipt of the corresponding command from
the CP and stays active for 15 minutes in the absence of other types of indication.
The modes of the indicator's operation are presented in Table 3.
Table 3
Detector status
«Initialization»
Values
Successful
registration/
12 m 2
6 m
2
3 m
2
5° and more
«Identification»
8 mA
10 s
«Destruction»
IP30
101х43х34 mm
«Inclination»
150 g
8 years
-30...+55 °С
до 90 % 6 Registration
6.1 Connect the Detector to the ADL (up to 20 detectors can be connected).
6.2 Prepare the CP for Detector registration in accordance with the instructions
for the CP.
6.3 Register the Detector in the CP.
QNT
7 Installation of the Detector
1 pc.
Installation of the Detector and adjustment of its sensitivity is done with the
removed cover. To remove the cover, you need to release the latch by pressing
2 pcs.
it through the rectangular hole in the cover (Picture 2).
2 pcs.
Depending on the type and material of the secured structure, the Detector is
1 pcs.
fastened with screws through holes in the base of the case (the distance between
1 copy the holes is 35 mm) or using glue. Make sure the installed Detector has direct
mechanical contact with the surface of the secured structure.
*
To mount the Detector on metal structures, it is recommended to use M4
screws through holes or M4 screws through blind holes with pre-cut threads.
It is recommended to install the Detector inside of a safe, including the lower
cabinet of an ATM, using M4 screws or cyanoacrylate glue, in accordance with
the instructions for using the glue given in its accompanying documentation or
on the packaging. Adhesive connection of the Detector is also allowed on other
metal structures if it is not possible to use a screw fastening.
1 2 3
S1
S2
4 S3
M1
M2
5
6
+LINE- -LINE+
+
АШ
–
7 8 7
Picture 1 – Case base with PCB
Indication
Alternating short switching of red,
green and yellow indicators
Simultaneous short switching on of
the red, green and yellow indicators
deletion for 3 s
Alternating short switching of yellow
and green indicators
Frequent short flashing of the red
indicator
Frequent short flashings of the
yellow indicator
Frequent short flashing of the
Vibration
green indicator
«Norm»
Picture 2
b) bottom view
5
4
3
2
11
1
12
+
АШ
–
Notes
After power is
supplied
The corresponding
command has
been received
from the CP
Status indication is
ON and
«Initialization» and
«Identification»
indications are
OFF
Off
Press
