Rielta Pyrone-7i Installation Manual

SECURITY COMBINED PIR +
nstallation Guide
I
1 General Information
1.1 Security combined detector «Pyrone-7i» (hereinafter, the Detector) is
designed for application as a component of security systems.
The Detector has the following two independent detection channels:
- glass break channel (hereinafter, GB channel);
- passive infrared channel (hereinafter, PIR channel).
GB channel is intended for detecting destruction of engineering structures
made of plate glasses as well as glass bricks with further «Alarm» message
generation by GB channel relay contacts opening (hereinafter, «ALARM1»).
1.2 PIR channel is assigned for detecting intrusion into protected area of
closed premises (movement within protected area) with further «Alarm» message
generation by PIR channel relay contacts opening (hereinafter, «ALARM2»).
1.3 PIR channel provides wide-angle detection zone and pet immunity to
animals up to 20 kg with thermal contrast t = 8 °C.
1.4 Power supply of the Detector is ensured from DC-current power supply
(V = 12 V with ripple amplitude not more than 0,1 V).
1.5 The Detector is resistant to to the impacts of ambient light, radio noise,
as well as disturbance from small animals: mice, rats, birds in cages.
1.6 The Detector is designed to operate continuously around the clock.
1.7 The Detector provides:
a) Discrete sensitivity adjustment of GB channel;
b) Discrete sensitivity adjustment of PIR channel;
c) LED indication of both detection channels state;
d) Indication of high level of interference for GB channel.
1.8 The Detector is constructed in the shape of mono-block. The Detector
design provides possibility to mount it direct to the wall or in the corner of a room,
as well as on the wall or in the corner of a room by means of swivel bracket.
1.9 PIR channel provides wide-angle detection zone.
2 Features
- Microprocessor-based signal processing;
- Self-test mode;
- Possibility of GB channel sensitivity adjustment;
- Pet immunity;
- Ensures case tamper protection;
- Temperature compensation of a detection sensitivity.
3 LED Indication
Indication of messages is fulfilled in accordance with the Table 1.
Table 1
LED Indicator
State
red yellow
Norm OFF OFF
Switching ON
-
ON 50 s
GB
channel ON ON
alarm
PIR channel
ON -
alarm
Supply Blinking Blinking
voltage at 1 Hz at 1 Hz
drop frequency frequency
First
frequency - ON
interference
Second
frequency - -
interference
Tamper - -
4 Specifications
Table 2
Parameter
PIR channel detection zone
Maximum detection range:
Maximal commutated current, under the voltage not more
than 42 V
GLASS BREAK DETECTOR
«Pyrone-7i»
Contacts
green ALARM1 ALARM2
OFF Closed Closed
Opened Opened
ON for not for not
3 s less than less than
2 s 50 s
Opened
for not
ON -
less than
2 s
Opened
for not
- -
less than
2 s
Opened Opened
Blinking
for not for not
at 1 Hz
less than less than
frequency
2 s 2 s
- - -
ON - -
- - -
Value
10 х 10 m
- GB channel 6/10 m
- PIR channel 8/10 m
30 mA
Sensitivity:
Pet Immunity
Warm-up time after switching on
Alarm message duration
Detection angle of PIR channel in horizontal plane
Consumption current, not more than
Minimal area of protected glass
Operating voltage
Operating temperature
Relative humidity at +25 °C without moisture condensation
IP rating
Dimensions
Weight, not more
Average service life
The Detector ensures safe operation under the impact of:
- sinusoidal vibration with acceleration of 0,981 m/s
frequency range 10 – 55 Hz.
- aluminum alloy hammer (AlCu
with impact energy (1,9 ± 0,1) J.
5 Scope of Delivery
5.1 Each Detector unit package contains the items listed in Table 3.
Table 3
Security combined detector «Pyrone-7i»
Swivel bracket
Security combined detector «Pyrone-7i». Installation Guide
6 Field of Application
The Detector can be installed in flats, shops, offices, museums and other
confined areas.
7 Choosing Place of Installation
When choosing the Detector installation place, it is advisable to take note
of the fact that the detection zone may be limited by non-transparent objects
(curtains, houseplants, cabinets, bookcases, etc.), as well as by glass and mesh
partitions. There must be no windows, air conditioners, space heaters or heating
radiators in the PIR detection zone.
Distance between the Detector and the farthest point of the monitored glass
should not exceed 6 m. The Detector microphone should be oriented strictly
towards the protected surface of a glass construction.
In case of 1 m
increased up to 10 m. Recommended installation height is (2,3 ± 0,1) m
The Detector wires should be laid at a distance not less than 0,5 m from
power supply cables.
To exclude false alarms it is recommended to install the detector vertically.
PIR channel detection zone pattern is shown in Figure 1.
TAMPER
Closed
90
0
0
Closed
-
-
2,3 m
0
-
-
Figure 1 – PIR channel detection
zone pattern
-
8 Installation of the Detector
- Put off access hole of the Detector (2);
- Remove cover with the printed circuit board (PCB) (4,3) from the base (1)
Opened
by pulling towards yourself and downward;
- Open holes in the base for the Detector wiring and fastening the base;
- Choose the place of installation, mark the places for mounting holes with
regard to the openings on the detector base, drill holes in the place of installation;
- Pass the wire through the mounting holes in the base, leaving enough length
of the wire for hooking up to the Detector terminals;
- Fix the base of the detector on the chosen place;
In case of mounting on swivel bracket, align the square protrusion of the
sphere with the corresponding recess in the upper part of the detector base.
Insert the screw into the hole in the upper part of the base, rotate the base to
the desired position, tighten the screw;
- Install cover with PCB to the base.
- GB channel
- PIR channel
SiMg) blow at a speed (1,500 ± 0,125) m/s,
4
Name
area monitoring maximal distance to the Detector should be
2
Top view
10 m
Side view
10 m
Figure 2 – GB channel detection
Сhoоse:
minimum/+12 dB
high/normal
10/20 kg
60 s
2 s
90 0
-2
35 mA
0,1 m
2
9 ... 17 V
from minus 20 up to +55° С
98 %
IP30
110 х 58 х 45 mm
0,1 kg
8 years
(0,1 g) within the
2
QNT
1 pc.
1 pc.
1 copy
180
о
6 m
R
Reliable-
detection
area
Microphone
orientation
6 m
90 о
R
zone pattern
