Page 2
OH&S requirements This appliance must be installed, maintained and removed only by an Authorised Person. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. Rinnai ORH(WF) OIM – Issue 1...
Page 3
Clearances ������������������������������������������������������������������������������������������������������������������������������������������������������� 14 Installation Method ������������������������������������������������������������������������������������������������������������������������������������������� 15 Electrical Connections �������������������������������������������������������������������������������������������������������������������������������������� 17 Location of Electrical Connection ��������������������������������������������������������������������������������������������������������������������� 17 Multiple Installations ����������������������������������������������������������������������������������������������������������������������������������������� 17 Care & Maintenance Maintenance ����������������������������������������������������������������������������������������������������������������������������������������������������� 18 Cleaning ����������������������������������������������������������������������������������������������������������������������������������������������������������� 18 Save a Service Call ������������������������������������������������������������������������������������������������������������������������������������������ 18 When to Call for Service ����������������������������������������������������������������������������������������������������������������������������������� 19 Warranty Contacts Rinnai ORH(WF) OIM – Issue 1...
Page 4
The installation MUST BE equipped with an all-pole disconnection mechanism in accordance with wiring rules. When installed outdoors this appliance is suitable for under cover use ONLY. DO NOT install this appliance in the bathroom. Rinnai ORH(WF) OIM – Issue 1...
Page 5
DO NOT allow young children or the infirm to remain unsupervised or sleep directly in front of or below the appliance while in operation. Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present. Rinnai ORH(WF) OIM – Issue 1...
Page 6
A NOTE ON ILLUSTRATIONS The illustrations used in this manual are for explanatory purposes only and the shape of your unit may NOTE vary slightly from that which is shown in this manual. Rinnai ORH(WF) OIM – Issue 1...
Page 7
Water ingress protection allows for safe cleaning of the external heater casing using a typical low pressure garden hose or by using a wet sponge. Remote Control Remote control is supplied with appliance. SPECIFICATIONS Model ORH15WF ORH18WF ORH24WF ORH32WF Max. Rated power 1500W 1800W 2400W...
Page 8
WIFI CARTON CONTENTS / ITEM CHECKLIST The following table lists the components for the Rinnai outdoor radiant heater. Ensure that all the relevant components for the model being installed are present before proceeding. Do not install any damaged items. Check all components have been supplied.
Page 9
Wi-Fi activation or reset. For further details refer to the Wi-Fi Operation Manual, a copy of the manual may be downloaded from the Rinnai web site: https://www.rinnai.com.au/lifestyle The Remote Control allows for convenient operation of the appliance within a 5 metre range.
Page 11
The diagram shown of the Remote Controller is an example only. The image contains almost all of the function buttons. Remote Controllers may be slightly different from illustrated diagram NOTE depending on which model purchased. Rinnai ORH(WF) OIM – Issue 1...
Page 12
The images show that the maximum heat output is found directly under the heater, and the temperature decreases as the user moves away from the heater. APPROXIMATE HEATING AREA Indoor Area Spot Heating Dimension ORH15WF ORH18WF ORH24WF ORH32WF 1040 1220 1500...
Page 13
CEILING CEILING CEILING The heater must never be installed in the upwards or inwards facing position, the heating surface must always be positioned to direct the heat in a downwards or outwards direction. WARNING Rinnai ORH(WF) OIM – Issue 1...
Page 14
110 Min. MUST NOT 600 Min. be below heater 1500 Min. 1000 Min. to surfaces (ie table tops, etc) 2100 Min. from floor 3000 Max. from floor (recommended) 600 Min. Same both ends Rinnai ORH(WF) OIM – Issue 1...
Page 15
30° 45° Mark the position of the two brackets, using the following minimum recommended bracket spacing below to determine the correct location. Dimension (mm) ORH15WF ORH18WF ORH24WF ORH32XWF 530 ± 50 710 ± 50 990 ± 50 1400 ± 50...
Page 16
Depending on material and design of ceiling structural elements, the heater must be secured with the correct fasteners. Refer to table below for weight of the heater. The installation location MUST NOTE be able to hold 5 times the weight of the heater. Model ORH15WF ORH18WF ORH24WF ORH32WF Power (W) 1500 1800...
Page 17
For connection of more than one heater to a common "ON/OFF" isolation switch refer to your authorised electrical installer. Ensure that the power switch on the right hand side of the appliance is set in the ‘I’ position when installing. IMPORTANT Rinnai ORH(WF) OIM – Issue 1...
Page 18
Exposure to extreme ambient conditions such as high winds / excessively cold temperatures can lower the heating performance of an outdoor installation. Unit is not installed in correct position, possibly too high or heater is too small for recommended area. Rinnai ORH(WF) OIM – Issue 1...
Page 19
Poor heating performance. Incorrectly sized installation, contact your authorised electrical installer. Faulty heater element, turn off the heater, and contact Rinnai. Will not heat / No operation indicator Check that power is connected and switched on, if still faulty, turn off the heater, and contact Rinnai.
Page 20
WARRANTY TERMS OF WARRANTY – AUSTRALIA Rinnai Australia Pty. Ltd. ABN 74 005 138 769, 100 Atlantic Drive, Keysborough VIC 3173. DEFINITIONS The terms listed below shall have the following meanings: “Authorised Service Representative” means an independent service contractor authorised by Rinnai or Rinnai service personnel.
Page 21
Normal Business Hours by an Authorised Service Representative. Repair by persons other than an Authorised Service Representatives may void the Warranty. 2.4 Alternatively to clause 2.3 above, Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product.
Page 22
7 “Purchaser’s Responsibilities” on page 23; c) notifies Rinnai within 30 days of a defect occurring or, in the case of a latent defect, becoming apparent, that a claim is being made under this Warranty; and d) provides, in support of the claim made under this Warranty, a Proof of Purchase.
Page 23
Rinnai to enquire about alternative arrangements. If you wish to make a warranty claim in respect of any fixed Product, please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product.
Page 24
Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call may be higher from a mobile phone. (National calls from public phones in Australia are free.) For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with...
