Installation Instructions
Suitable for:
•
all Rinnai Super Ray W-Series (WMA, WEA and WFA) radiant heaters
Not suitable for Outdoor Super Ray models as these already have an
in-built heat shield.
Heat shield must be fitted to the Super Ray heater prior to installation.
Must be installed, commissioned and serviced by a licensed tradesperson in accordance
with all applicable local rules and regulations.
Installer, please leave this manual with the customer.
Rinnai New Zealand
Super Ray Heat Shield
Heat Shield
Super Ray Heat Shield Installation: 450-A
0-09
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rinnai Super Ray WMA 16
Summary of Contents for Rinnai Super Ray WMA 16
-
Page 1: Installation Instructions
Heat Shield Suitable for: • all Rinnai Super Ray W-Series (WMA, WEA and WFA) radiant heaters Not suitable for Outdoor Super Ray models as these already have an in-built heat shield. Heat shield must be fitted to the Super Ray heater prior to installation. - Page 2 3. this warranty commences from the date of purchase and subject to clauses and 3 below, purchase. Proof of purchase is required at the Rinnai New Zealand Limited (“Rinnai”) will, at time of any warranty claim. its own discretion, either replace or repair any defective product at no charge to the customer.
- Page 3 Contents Limited Warranty About the Super Ray Heat Shield Before Installation Kit Contents Assembling the Heat Shield Fitting the Heat Shield to the Heater Customer Contacts Rinnai New Zealand Super Ray Heat Shield Installation: 450-A 0-09...
- Page 4 Super Ray heater can be positioned. For example: the ceiling clearance for a Rinnai Super Ray WMA 6 reduces from m to 0.5 m with a heat shield installed. Constructed from stainless steel and heat resistant insulator board.
-
Page 5: Before Installation
Check all components have been supplied, refer kit components below. Read these instructions to get an overview of the steps required before starting. Kit Contents Rivets Rivets Insulator Heat Shield Brackets Rinnai New Zealand Super Ray Heat Shield Installation: 450-A 0-09... - Page 6 Replace the insulator panel to its original position. Bend the retainer tabs down to hold the insulator in place. Bending Rear Retainer Tabs - Open to Closed Rinnai New Zealand Super Ray Heat Shield Installation: 450-A 0-09...
- Page 7 Secure the assembled heat shield to the heater using the original mounting bolts and top side screw. Screw and Bolt Locations top side screw Mounting bolts Front View of Fitted Heat Shield Brackets are fixed in a 90 ° position (can not be altered) Rinnai New Zealand Super Ray Heat Shield Installation: 450-A 0-09...
- Page 8 Consumers: 0800 RINNAI (746 64) Installers: 0800 tO RINNAI (86 746 64) Address: 05 Pavilion drive, Airport Oaks, Mangere, Manukau PO Box 5377, Auckland Airport, Manukau 50 Phone: (09) 57 3800 Fax: (09) 57 3899 Email: info@rinnai.co.nz Websites: www.rinnai.co.nz and www.rinnai-tradesmart.co.nz...
