The SDI output will configure itself automatically according to the SDI format presented to SDI input
and replicate it. The output is compliant with SMPTE 259M-C, SMPTE 292M and SMPTE424M
standards.
10.6 USB Type A Out
Provides a 0.5A source of 5 VDC to power accessories such as CSCN CueNumber.
Monitor Connector type:
Mating (cable) connector:
EMC17SDI Monitor Manual
USB-A (Standard USB)
USB-A (USB) plug
Pin Description
1 +5 VDC
2 N/C
3 N/C
4 Ground
