OSD MENU
FUNCTION
SDI & HDMI & CVBS : Power Save, Zoom Mode, Aspect, Image Flip, Image Mirror, Auto Source, 3DNR
Power Save
Zoom Mode
Aspect
Image Flip
Image Mirror
Auto Source
3DNR
Advanced (VGA / RGB only)
(UNUSED)
EMC17SDI Monitor Manual
Description
Adjust the Power Save time. (0 ~ 120Min) [0.5, 1, 2, 5, 10, 30, 60, 120]
Select the zoom mode. (Normal, OverScan, Zoom).
[Note]:
"OverScan" mode: this is the factory default condition in general, most of target video sizes
on the LCD screen mean this mode (5% zoom and cropped). Traditional CVBS input signal
requires OverScan mode for general usage.
"Normal": Displays all available pixels into screen without cropping and zooming.
"Zoom": Magnifies centre of screen by 25% .
Auto / 16 : 9 / 4 : 3 / Fill
Image is reversed by vertical. (On, Off)
Image is reversed by horizontal. (On, Off)
Detect the valid input source automatically. (On, Off)
Select NR mode. (Off, Strong, Standard, Weak)
H-Pos: 0 ~ 100
V-Pos: 0 ~ 100
Clock: 0 ~ 100
Phase: 0 ~ 100
Auto: Auto Adjust
