  • Page 1 User Manual ENABLING BRIGHT OUTCOMES...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium...

  • Page 3: Guarantee And Compensation

    Barco. If the purchaser or a third party carries out modifications or repairs on goods delivered by Barco, or if the goods are handled incorrectly, in particular if the systems are operated incorrectly or if, after the transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid.

  • Page 5: Table Of Contents

    Table of contents 1 Safety ........................................... 9 General considerations ................................10 Important safety instructions..............................11 Product safety labels..................................16 High Brightness precautions: Hazard Distance ......................17 HD for fully enclosed projection systems...........................19 HD calculation of multi-projector stacks..........................20 HD in function of modifying optics ............................20 Radio equipment ....................................21 Compliance ......................................21 1.10...
  • Page 6 Power On the projector................................42 Power Off the projector................................43 Power mode transitions................................44 6 Inputs & Communication ................................47 Control & Communication module ............................48 Pulse Quad Combo input Mk III..............................49 Pulse Quad DP 1.2 input ................................50 Pulse SFP input ....................................51 7 Projector maintenance ..................................53 Software update....................................54 Cleaning the lens ....................................55 Cleaning the exterior of the projector...........................56...
  • Page 7 Product compliance EU................................104 Product compliance UK................................105 Product compliance US................................105 Product compliance Canada ..............................106 Product compliance Turkey..............................107 Product compliance EAC ................................ 107 Product compliance China..............................107 E.10 Product compliance Taiwan ..............................109 E.11 Product compliance Korea ..............................110 E.12 Trademark notice ..................................111 E.13...
  • Page 8 R5917033 /00...

  • Page 9: Safety

    QDX product. Clarification of the term “QDX” used in this document When referring in this document to the term “QDX” means that the content is applicable for following Barco products: •...

  • Page 10: General Considerations

    • All warnings on the unit and in its documentation manuals must be adhered to. • Installation and preliminary adjustments must be performed by qualified Barco personnel or by authorized Barco service dealers. • This product contains no user serviceable parts. Attempts to modify/replace mechanics or electronics inside the housing or compartments will violate any warranties and may be hazardous.

  • Page 11: Important Safety Instructions

    Safety WARNING: No direct exposure to the projection beam within the hazard distance shall be permitted for RG3 (Risk Group 3) IEC EN 62471-5:2015. Do not stare into the beam for RG2 (Risk Group 2) IEC EN 62471-5:2015. CAUTION: Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure.

  • Page 12: To Prevent Personal Injury

    Safety • Use only the power cord supplied with your device. While appearing to be similar, other power cords have not been safety tested at the factory and may not be used to power the device. For a replacement power cord, contact your dealer.

  • Page 13: To Prevent Fire Hazard

    Do not place flammable or combustible materials near the projector! • Barco large screen projection products are designed and manufactured to meet the most stringent safety regulations. This projector radiates heat on its external surfaces and from ventilation ducts during normal operation, which is both normal and safe.
  • Page 14 Safety • Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since these will damage the cabinet. Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution.
  • Page 15 Safety Operation • Only use Barco projection lenses that are supported for the I600. Using other lenses will damage the internal optics. For suitable lenses contact Barco or see Barco website. • To ensure the highest optical performance and resolution, the projection lenses are specially treated with an anti-reflective coating, therefore, avoid touching the lens.

  • Page 16: Product Safety Labels

    Safety Safety Data Sheets for Hazardous Chemicals For safe handling information on chemical products, consult the Safety Data Sheet (SDS). SDSs are available upon request via safetydatasheets@barco.com. 1.3 Product safety labels Light beam related safety labels Safety labels explanation and location: Hazard RG3: Not for household use symbol.

  • Page 17: High Brightness Precautions: Hazard Distance

    Safety 1.4 High Brightness precautions: Hazard Distance Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the eye or on the skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the light source is less than the HD.
  • Page 18 The LIP shall be installed by Barco or by a trained and Barco-authorized installer or shall only be transferred to laser light show variance holders. This is applicable for dealers and distributors since they may need to install the LIP (demo install) and/or they transfer (sell, rent, lease) the LIP.

  • Page 19: Hd For Fully Enclosed Projection Systems

    Safety 1.5 HD for fully enclosed projection systems Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the eye or on the skin. The light beam is considered (to be) unsafe for exposure if the distance from a person to the light source is less than the HD.

  • Page 20: Hd Calculation Of Multi-Projector Stacks

    Safety 1.6 HD calculation of multi-projector stacks Sometimes two or more projectors are stacked (projecting on the same surface). In this case, because of the overlap of the images, possibly a system Hazard Distance needs to be applied instead of a single projector hazard distance.

  • Page 21: Radio Equipment

    UKNI Hereby, Barco NV declares that the radio equipment type “4G module for the Pulse Input & Communication unit” is in compliance with the Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.barco.com/en/support/docs/TDE12980...
  • Page 22 Safety R5917033 /00...

  • Page 23: Qdx Introduction

    The Pulse software has regular new releases due to continuous improvements. Hence, the Pulse OSD user guide is subject to updates. Download the latest version of the user guide from the Barco website using following link: https://www.barco.com/support.

  • Page 24: Projector Orientation

    QDX introduction 2.1 Projector orientation Orientation convention This manual refers to the left side of the projector as the side at your left hand when standing behind the projector and looking at the projection screen in front of the projector. Image 2–1 Right Left...

  • Page 25: Projector Airflow

    QDX introduction Image 2–3 IR receiver back Optional external cooler cooling connectors Optional external cooler power and data connection Optional WIFi module Optional rigging frame USB connector 2.3 Projector airflow Air inlets and outlets The projector has five air inlet channels and two air outlet channels. The air outlets are located at the rear side of the projector.

  • Page 26: Projector Status

    QDX introduction 2.4 Projector status Projector status indicator LEDs The Control & Communication module contains four status LEDs at the right side of the front panel. These LEDs allows a quick status analyses of the projector. For explanatory see table hereunder. Image 2–6 Location of projector status LEDs.
  • Page 27 The Pulse software has regular new releases due to continuous improvements. Hence, the Pulse Prospector user guide is subject to updates. Download the latest version of the user guide from the Barco website using following link: https://www.barco.com/support.
  • Page 28 QDX introduction R5917033 /00...

  • Page 29: Local Keypad

    Local keypad Local keypad functions........................30 Local keypad backlight........................30 LCD touch panel...........................31 R5917033 /00...

  • Page 30: Local Keypad Functions

    Refer to the Pulse OSD user guide for detailed guidance on all software features of the projector. The Pulse software has regular new releases due to continuous improvements. Hence, the Pulse OSD user guide is subject to updates. Download the latest version of the user guide from the Barco website using following link: https://www.barco.com/support.

  • Page 31: Lcd Touch Panel

    Local keypad 3.3 LCD touch panel Functionality The LCD touch panel has two main functions: 1. Showing the menus, adjustment information and if enabled a mirror of the OSD (On Screen Display). 2. Information regarding the status of the projector: •...
  • Page 32 Local keypad R5917033 /00...

  • Page 33: Pulse Remote Control Unit

    Pulse Remote Control Unit Pulse RCU functions........................34 Pulse RCU battery installation .......................34 Pulse RCU on/off button........................35 Pulse RCU “button pressed indicator” ....................36 Pulse RCU “RGB filter” button .......................36 Pulse RCU “Projector OSD on/off” button ..................37 Using the XLR connector of the RCU .....................37 Using the mini-jack connector of the RCU..................37 Pulse RCU silicone protection sleeve (optional) ................38 R5917033 /00...

  • Page 34: Pulse Rcu Functions

    Pulse Remote Control Unit 4.1 Pulse RCU functions Functions Image 4–1 Button pressed indicator Backspace (while entering values) Shutter open XLR connector Shutter close Decimal mark (while entering values) LCD/Touch panel on / off Macro button (Not in use) Projector OSD on / off Menu back Lens zoom Default value button...

  • Page 35: How To Install

    Pulse Remote Control Unit How to install Push the battery cover tab with the fingernail a little backwards (reference 1) and, at the same time, flip the cover outwards (reference 2). Image 4–2 Insert two AA size batteries into the battery compartment. making sure to match the polarities of the batteries to the + and - marks inside the battery compartment.

  • Page 36: Pulse Rcu "Button Pressed Indicator

    Pulse Remote Control Unit To activate the remote control, press the on/off button until the button pressed indicator will turn off (3-5 seconds). To deactivate the remote control, press the on/off button again. Default after (re)placing batteries, is “ON”. Image 4–6 4.4 Pulse RCU “button pressed indicator”...

  • Page 37: Pulse Rcu "Projector Osd On/Off" Button

    Pulse Remote Control Unit 4.6 Pulse RCU “Projector OSD on/off” button On-Screen Display (OSD) on/off While the light source is on, you can toggle the projection of the On-screen display on and off by pressing the projector OSD on/off button. Stealth mode on/off Stealth mode is a function where the backlight of the LCD, the backlight of the keypad buttons and the indication LEDs on the communication and input panels can be disabled.

  • Page 38: Pulse Rcu Silicone Protection Sleeve (Optional)

    4.9 Pulse RCU silicone protection sleeve (optional) Introduction Barco offers a silicone form fitting protection sleeve for the Pulse RCU. The silicone material keeps it comfortably, non-slip and soft to the touch. All buttons and openings remain accessible. The only thing that needs to be removed is the XLR cover.
  • Page 39 Pulse Remote Control Unit Image 4–12 R5917033 /00...
  • Page 40 Pulse Remote Control Unit R5917033 /00...

  • Page 41: Powering On / Off

    Powering on / off Power modes ..........................42 Power On the projector .........................42 Power Off the projector .........................43 Power mode transitions.........................44 R5917033 /00...

  • Page 42: Power Modes

    Powering on / off 5.1 Power modes Overview The QDX has 4 different power modes: Description Mode ECO STANDBY Light source is switched off and projector electronics are powered down. STANDBY Light source is switched off and Control & Communication module is active. READY Projector is booted up and the light source is switched off.

  • Page 43: Power Off The Projector

    CAUTION: Never switch off the projector by means of unplugging mains cord or by cut down of mains power. Barco advises to keep the projector always powered and use the ECO STANDBY mode for low power consumption. How to unplug the projector Follow the previous power off procedure to switch off the projector.

  • Page 44: Power Mode Transitions

    Powering on / off 5.4 Power mode transitions Power transition diagram READY STANDBY ECO STANDBY Image 5–3 Symbol Description Short pressing the Power on/off button on the local keypad or on the remote control unit. Long pressing the Power on/off button on the local keypad or on the remote control unit.
  • Page 45 Powering on / off Wake-On-LAN (WOL) The link speed of the projector network interface in ECO mode is reduced to 10Mbit/s. This is standard practice in the industry to not waste power. Hence, the network connected with the projector must support such a low link speed to enable the remote wake up of the projector. This implies that all peripherals (switchers, routers...) in the network path must support WOL and configured correctly to support WOL.
  • Page 46 Powering on / off R5917033 /00...

  • Page 47: Inputs & Communication

    Inputs & Communication Control & Communication module....................48 Pulse Quad Combo input Mk III .....................49 Pulse Quad DP 1.2 input .......................50 Pulse SFP input..........................51 R5917033 /00...

  • Page 48: Control & Communication Module

    Inputs & Communication 6.1 Control & Communication module Front panel Control & Communication module Image 6–1 12V DC HDMI™ TRIGGER WIRED REMOTE SYNC I/O Projector status LEDs IR receiver Functionality Description Name 12V DC 12 V DC output, maximum 1A available when projector is not in standby. TRIGGER Two 3.5 mm mini jack connectors (OUT1 &...

  • Page 49: Pulse Quad Combo Input Mk Iii

    Inputs & Communication LED behavior • The SEL LED lights up GREEN: input is selected. • The SEL LED blinks GREEN: input/output is selected and configured as output. • The SYNC LED lights up ORANGE: valid input sync is detected. •...

  • Page 50: Pulse Quad Dp 1.2 Input

    Inputs & Communication Description Earth Cold Return - (or not used) Return + (or not used) DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to lighting devices. Standardized by USITT. HDBaseT input Supports HDBaset 3.0 (up to 4k60 RGB 444). The HDBaseT port does not supports network connectivity.

  • Page 51: Pulse Sfp Input

    “Specifications”, page 6.4 Pulse SFP input The Barco SFP Input Board has been designed and tested to work alongside the Barco SFP Output Board. However, it is possible that the SFP Input board can also work with other third-party devices that support 12G over fiber.
  • Page 52 Inputs & Communication WARNING: Only by Barco trained and qualified technicians are allowed to install the SFP input. Optical Tranceiver to comply with Laser Class 1, IEC60825–1: 2014 R5917033 /00...

  • Page 53: Projector Maintenance

    Projector maintenance Software update ...........................54 Cleaning the lens..........................55 Cleaning the exterior of the projector ....................56 Removing and replacing the dust filters ..................56 Vacuum cleaning of the dust filters ....................58 Washing and drying the dust filters....................59 R5917033 /00...

  • Page 54: Software Update

    CAUTION: Do not power off or unplug the projector while the software update is ongoing. Similarly, do not remove the USB flash drive while the software update is ongoing. Prerequisites First download the latest projector software package from the Barco's website, using the following link: https:// www.barco.com/support.

  • Page 55: Cleaning The Lens

    Always contact Barco if you want to make sure a downgrade will not hurt your device.

  • Page 56: Cleaning The Exterior Of The Projector

    Projector maintenance How to clean the lens? Blow off dust with clean compressed air (or pressurized air cans Clean with lens cleaner together with a clean lens cleaning cloth to remove the dust and contamination. Use big wipes in one single direction. Warning: Do not wipe back and forwards across the lens surface as this tends to grind dirt into the coating.
  • Page 57 Projector maintenance Image 7–5 Light processor dust filter (cellulose) Left LDM dust filter (foam) Prerequisites Remove the appropriate side or top cover before checking or removing a filter. For more info, see chapter“Projector covers”, page How to check and remove a filter Do one of the following, depending on the foam type: a) For a foam filter, grab and remove the filter from its holder.

  • Page 58: Vacuum Cleaning Of The Dust Filters

    Projector maintenance Image 7–10 Top dust cover b) For the light processor dust filter, click it out of its holders and remover it as illustrated. Image 7–11 Light processor dust filter Check the status of the filter. Do one of the following: a) If the filter is clean, place it back in its holder.

  • Page 59: Washing And Drying The Dust Filters

    7.6 Washing and drying the dust filters About filter washing and drying For environments where popcorn grease and such can contaminate the filters, Barco advises the client to purchase one extra set of filters to cover drying time, as well as taking following extra precautions and instructions pertaining to filter cleaning and drying.
  • Page 60 CAUTION: Do not install/use damaged dust filters. Replace damaged dust filters immediately with new dust filters of the same type. See https://my.barco.com for the correct replacement part. R5917033 /00...

  • Page 61: Projector Covers

    Projector covers Cover locks ..........................62 Removing a side, front or rear cover....................62 Installing a side, front or rear cover....................63 Removing the top covers.......................64 Installing the top covers.........................65 About this chapter Most maintenance and service procedures demand removing one or more of the projector covers to gain access to the parts to maintain or to service.

  • Page 62: Cover Locks

    Projector covers 8.1 Cover locks About the cover locks All the side covers are fastened with the same “easylock” type cover lock. Required tools Flat screwdriver 5 mm Opening a cover with cover locks Push down the inner side of the easylock with a screwdriver. Image 8–1 As a result the lock jumps loose.

  • Page 63: How To Remove

    Projector covers • For the left side cover: Power off the projector. Remove the mains power cord. • For the right side cover: Disconnect the motorized rigging frame connections (if installed) Disconnect the external cooler connections (if installed) Required tools Flat screwdriver 5 mm How to remove Unlock the cover locks.

  • Page 64: Removing The Top Covers

    Projector covers Image 8–9 Image 8–10 Lock the projectors in place, using the cover locks. For more info, see “Cover locks”, page 8.4 Removing the top covers Required tools Torx screwdriver T20 How to remove both top covers Loosen the four screws of the top cover. Use a T20 Torx screwdriver. Lift up and remove the cover.

  • Page 65: Installing The Top Covers

    Projector covers 8.5 Installing the top covers Required tools Torx screwdriver T20 How to install both top covers Place the rear top cover on the projector. Image 8–13 Lock the two cover locks at the rear top side of the projector. For more info, see “Cover locks”, page Place the front top cover on the pojector.
  • Page 66 Projector covers R5917033 /00...

  • Page 67: A Specifications

    Specifications Specifications QDX 4K45 ......................68 Specifications QDX W45 .......................69 Specifications QDX 4K35 ......................71 Specifications QDX W35 .......................73 Specifications SDI inputs.......................75 Specifications HDMI inputs......................75 Specifications HDBaseT input......................76 Specifications DisplayPort 1.4 inputs....................77 Specifications DisplayPort 1.2 inputs....................79 A.10 Specifications SFP inputs......................80 R5917033 /00...

  • Page 68: Specifications Qdx 4K45

    Specifications A.1 Specifications QDX 4K45 Notes The specifications in this document are preliminary Projector type WUXGA 3-chip DLP digital projector Technology 0.96" DMD™ x3 Resolution 3840 x 2400 (4K UHD) Brightness 41000 center lumens Contrast ratio 2.200:1 Optical lens shift Vertical: up to -150% to +130% (motorized) Horizontal: up to +/- 50% (motorized) with lens memory on TLD+ lenses...

  • Page 69: Specifications Qdx W45

    Specifications Control DMX (optional), XLR wired (optional) + IR, RJ45, Wifi (optional), GSM (optional) Active eye wear 3D stereo formats: 1xHDMI™ 1xDP or Quad DP(optioN/Al) top/ bottomsequential multi pipe. 1920x1200 @ 120Hz 24/7 operation BTU per hour Max 11935 BTU/h Operating temperature 0-40°C / 32°-104°F (reduce power >...
  • Page 70 Specifications Horizontal: up to +/- 50% (motorized) with lens memory on TLD+ lenses Light source Blue+Red laser phosphor with inorganic phosphor wheel Brightness uniformity Light source lifetime 20000 hrs (100% power, DynaBlack® off) Color correction Optical dowser Laser switching /optional external Aspect ratio 16:10 Lens type...

  • Page 71: Specifications Qdx 4K35

    Specifications Storage temperature -10°C to 60°C Operating humidity 0-80% (no condense) Storage humidity 5 - 90% RH Network connection 10/100 base-T RJ-45 connection Wifi (opt) Dimensions (WxLxH) 660 x 830 x 350 mm / 25.98 x 32.67 x 13.77 inches Weight 79kg / 174 lbs Shipping weight...
  • Page 72 Specifications Lens range TLD+: 0.37:1 ; 0.65-0.85:1 ; 0.8-1.16:1 ; 1.25 -1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1 Color space REC 709 + Orientation 360° Sealed DLP™ core Standard Inputs HDMI™ 2.1 (HDCP2.2 - HDR10)/ DP1.2 (HDCP 1.3) RJ45 Ethernet / RS232 / USB(5v) / 12V out/ BNC 3D sync in-out Input resolutions Including and up to:...

  • Page 73: Specifications Qdx W35

    Specifications At 120v: 2200W typical/ 2300W max Noise level (typical at 25°C/ <52dB(A) 77°F) Shipping dimensions 800 x 1200 x 660 mm / 31.49 x 47.24 x 25.9 " incl. palet (WxLxH) Safety class Laser Safety Class: RG3 Class 2 Standard accessories Power cord wireless / XLR wired rugged remote control Certifications...
  • Page 74 Specifications 7680 × 4320 @ 60Hz Processing Pulse electronics Web browser Picture-by-picture Two sources simultaneously CLO (constant light output) DMX 512 Image processing Embedded warp & blend Keystone correction Standby power <0,5 W Software tools Pulse Toolset + Android app + iOS app + IMS Control DMX (optional), XLR wired (optional) + IR, RJ45, Wifi (optional), GSM (optional)

  • Page 75: Specifications Sdi Inputs

    Up to 1280 x 720 @60 Hz Up to 2048 x 1080 @50 Hz Single link 3G-SDI Level A Up to 2048 x 1080 @60 Hz Quad link 3G-SDI “Barco Single link 1920 x 1200 @50 Hz, @59.94 Hz and Link” @60 Hz Quad link...

  • Page 76: Specifications Hdbaset Input

    Specifications HDMI specifications Specification Value Pixel rate 25 – 600 MHz pixel clock HDCP support • HDCP 1.x • HDCP 2.2 • RGB 4:4:4 Color space • YCbCr 4:2:0 • YCbCr 4:2:2 • YCbCr 4:4:4 • RGB 4:4:4 Color depth •...

  • Page 77: Specifications Displayport 1.4 Inputs

    Specifications Specification Value Network support No longer supported For future release • 3D support • Interlaced support Not supported • Audio • Power over HDBaseT Video timings Layout mode Supported formats progressive Standard layout (1x1 • Up to 4096 x 2160 @24 Hz layout) •...
  • Page 78 Specifications 3D support • Field sequential 3D (Active 3D) • Passive stereoscopic 3D (Passive stereo) converted to active 3D Video timings 2D / 3D Layout Mode Supported formats progressive Standard layout (1x1 • Up to 4096 x 2160 @24 Hz layout) •...

  • Page 79: Specifications Displayport 1.2 Inputs

    Specifications CAUTION: In order to display high resolution images (e.g.: 3840 x 2160 @60 Hz or higher) via the DP 2.1 input, the quality of the cable must be adequate, in addition the length of the cable can also influence the performance (recommended maximum ~1.2 meter);. In case there is an issue with one of these criteria the automatic link-training initiated by the DP-standard may decide to switch to a lower resolution.

  • Page 80: Specifications Sfp Inputs

    Specifications • 2048 x 1080 @120 Hz 4 column mode (4x1 • 960 x 2160 @120 Hz layout) • 960 x 2400 @120 Hz • 1024 x 2160 @60 Hz Active 3D Standard layout (1x1 • 1600 x 1200 @120 Hz layout) •...
  • Page 81 Specifications • Up to 1280 x 720 @25 Hz 3G-SDI Single link 1920 x 1080 @50 Hz and @60 Hz 1920 x 1200 @50 Hz, @59.94 Hz and @60 Hz. 2048 x 1080 @50 Hz and @60 Hz 12G-SDI Single link 3840 x 2160 @50 Hz and @60 Hz 4096 x 2160 @50 Hz and @60 Hz 3840 x 2400 @50 Hz, @59.94 and @60...
  • Page 82 Specifications R5917033 /00...

  • Page 83: B Video Timing Tables

    Video timing tables Overview video timings .........................84 Overview video timings SDI Inputs ....................85 Overview video timings HDMI 2.0 inputs..................86 Overview video timings DisplayPort 1.2 inputs ................87 Overview video timings HDBaseT inputs ..................90 About this chapter This chapter contains the tables with video timings for video interfaces. R5917033 /00...

  • Page 84: Overview Video Timings

    B.1 Overview video timings List of compatible signals The following table specifies the video signals that the projector can project. Barco Events projectors supports the signal with “X” in the Compatible signals column. Note: Support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates.

  • Page 85: Overview Video Timings Sdi Inputs

    3G-SDI Single Link & Quad Link 1920 x 1080 3G-SDI Single Link & Quad Link 1920 x 1200 3G-SDI “Barco Link” Single Link & Quad Link 1920 x 1200 59.94 3G-SDI “Barco Link” Single Link & Quad Link 1920 x 1200 3G-SDI “Barco Link”...

  • Page 86: Overview Video Timings Hdmi 2.0 Inputs

    3G-SDI Single Link & Quad Link 3840 x 2160 12G-SDI Single Link 3840 x 2160 12G-SDI Single Link 3840 x 2400 12G-SDI “Barco Link Single Link Ultra” 3840 x 2400 59.94 12G-SDI “Barco Link Single Link Ultra” 3840 x 2400 12G-SDI “Barco Link...

  • Page 87: Overview Video Timings Displayport 1.2 Inputs

    Video timing tables Video timing Vertical refresh rate (Hz) 3D support? (active pixels x active lines) 1920 x 1080 1920 x 1080 1920 x 1080 Side by Side (SbS) progressive 1920 x 1080 Side by Side (SbS) progressive 1920 x 1200 1920 x 1200 2048 x 1080 2048 x 1080...
  • Page 88 Video timing tables Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 640 x 480 800 x 600 960 x 1080 4 Quadrant mode (2 x 2 Active 3D layout) 960 x 1200...
  • Page 89 Video timing tables Video timing Available layout modes, Vertical refresh rate other than standard Support for 3D? (active pixels x active (Hz) layout (1 x 1 layout) lines) 1920 x 1200 4 Quadrant mode (2 x 2 Active 3D layout) 1920 x 2160 2 Column mode (2 x 1 Passive stereo...

  • Page 90: Overview Video Timings Hdbaset Inputs

    Video timing tables B.5 Overview video timings HDBaseT inputs Overview The following standard video formats are available for the projector. Note: support for refresh rates 24.00, 30.00, 60.00 Hz automatically includes support of 1/1.001 x those refresh rates. Video timing Vertical refresh rate (Hz) (active pixels x active lines) 640 x 480...
  • Page 91 Video timing tables Video timing Vertical refresh rate (Hz) (active pixels x active lines) 3840 x 2160 3840 x 2160 4096 x 2160 4096 x 2160 4096 x 2160 R5917033 /00...
  • Page 92 Video timing tables R5917033 /00...

  • Page 93: C Dmx Chart

    DMX chart DMX chart input board positioning ....................94 DMX chart, Basic..........................94 DMX chart, Extended........................95 R5917033 /00...

  • Page 94: Dmx Chart Input Board Positioning

    DMX chart C.1 DMX chart input board positioning About the input boards 6 Input selection ranges are reserved in the DMX chart per input board location (named L1 and L2). With the current version of DMX support, it is important to take into account to keep the input boards in their original slots.

  • Page 95: Dmx Chart, Extended

    DMX chart Function Value Default Action 152 - 159 Select input 9: Quad DP board Input C (if held for 1 second) 160 - 167 Select input 10: Quad DP board Input D (if held for 1 second) 168 - 175 Select input 11: Quad DP board Inputs A-B (if held for 1 second) 176 - 183...
  • Page 96 DMX chart Function Value Default Actions 152 - 159 Select input 9: Quad DP board Input C (if held for 1 second) 160 - 167 Select input 10: Quad DP board Input D (if held for 1 second) 168 - 175 Select input 11: Quad DP board Inputs A-B (if held for 1 second) 176 - 183...
  • Page 97 DMX chart Function Value Default Actions 80 - 87 Power on / Light source on (If held for 5 seconds) 88- 95 Power down / Light source off (if held for 5 seconds) 96 - 255 Reserved for future functionality Various 0 - 7 Reserved for future functionality...
  • Page 98 DMX chart Function Value Default Actions 168 - 175 Select input 11: Quad DP board Inputs A-B (if held for 1 second) 176 - 183 Select input 12: Quad DP board quad column mode (if held for 1 second) 184 - 255 Reserved for future functionality Focus (MSB) 0 - 255...

  • Page 99: D Pjlink Commands

    PJLink commands PJLink Command list ........................100 R5917033 /00...

  • Page 100: Pjlink Command List

    ON or READY mode. Remark for PJLink Class 1 only: The PJLink 1.0 specification only defines 9 digital inputs. Barco projectors can have more than 9 digital inputs. For this reason, the storage and network categories are used to host the remaining digital sources.
  • Page 101 Get list of input sources NAME ? Get projector name The result is the projector Hostname INF1 ? Get manufacturer of The result is: “Barco” the projector INF2 ? Get product name Identification property of the DeviceIdentification file INFO ?
  • Page 102 PJLink commands R5917033 /00...

  • Page 103: E Regulatory

    Regulatory Contact information........................104 Production information ........................ 104 Product compliance EU....................... 104 Product compliance UK....................... 105 Product compliance US....................... 105 Product compliance Canada......................106 Product compliance Turkey ......................107 Product compliance EAC ......................107 Product compliance China......................107 E.10 Product compliance Taiwan ......................109 E.11 Product compliance Korea ......................

  • Page 104: Contact Information

    Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com Importers contact information To find your local importer, contact Barco directly or one of Barco's regional offices via the contact information given on Barco's web site, www.barco.com. Manufacturer Registered office: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Registered office: Barco (Wuxi) Technology Co., Ltd.

  • Page 105: Product Compliance Uk

    Warning : This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. E.4 Product compliance UK UK Compliance This product is fit for use in the UK. Authorised Representative: Barco UK Ltd Address: Building 329, Doncastle Road Bracknell RG12 8PE, Berkshire, United Kingdom E.5 Product compliance US Regulatory information for US and Canada can be accessed in the OSD of the projector.

  • Page 106: Product Compliance Canada

    Regulatory radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...

  • Page 107: Product Compliance Turkey

    According to the “Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Products” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. R5917033 /00...
  • Page 108 Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environment-friendly use period of electronic information products”...

  • Page 109: Product Compliance Taiwan

    Regulatory EMC notices China GB/T 9254.1 A级ITE(信息技术设备) 警告：在居住环境中，运行此设备可能会造成无线电干扰。 E.10 Product compliance Taiwan EMC notices Taiwan BSMI Taiwan Class A statement 警告使用者 : 此為甲類資訊技術設備，於居住環境中使用 ，可能會造成射頻擾動，在此情況下，使用者會被要 求採取某些適當的對策。 BSMI Reporting Obligor Information / 報驗義務人資訊 一、 商品在國內產製時，為商品之產製者或輸出者。 但商品委託他人產製，並以在國內有住所或營業所之委託者名義，於國內銷售或輸出時，為委託者。 二、 商品在國外產製時，為商品之輸入者。 但商品委託他人輸入，並以在國內有住所或營業所之委託者名義，於國內銷售時，為委託者。 三、 商品之產製者、輸出入者、委託產製或委託輸出入者不明或無法追查時，為銷售者。 前項所稱產製者，包括具有下列情形之一者： 一、組裝者：商品由個別零組件以組裝銷售。...

  • Page 110: Product Compliance Korea

    기기명칭: 특정소출력무선기기(무선랜을 포함한 무선접속시스템용 무선기기) 인증자상호: Barco N.V. 모델명: eBox Pulse 인증번호: R-C-BVY-eBoxPulse 모듈 ID: KCC-CRM-TCS-HE910-D 제조연월: 2019. 제조자/제조국: Barco NV/벨기에와 중국 EMC 경고: 이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서 가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. R5917033 /00...

  • Page 111: Trademark Notice

    Users feature, or via a factory reset executed as administrator. Logs may contain user names and IP addresses and are subject to the retention policy, but can’t be deleted by the user. The user can send a request to dataprotection@barco.com. R5917033 /00...
  • Page 112 Regulatory R5917033 /00...

  • Page 113: Glossary

    Glossary DMX-512 Lighting protocol over RS-485 interface. Carries information of 512 channels from a lighting controller to lighting devices. Standardized by USITT. Hazard Distance (HD) is the distance measured from the projection lens at which the intensity or the energy per surface unit becomes lower than the applicable exposure limit on the eye or on the skin.
  • Page 114 Glossary R5917033 /00...

  • Page 115: List Of Tools

    List of tools Bucket with hot water Clean cotton cloth Clean micro fiber lens cleaning cloth (e.g. Toraysee® cloth(s)) Compressed air Flat screwdriver 5 mm Lens cleaner (e.g. Zeiss lens cleaner, Purosol® or any water based lens cleaner) Scissors or knife cutter Sodium carbonate, 30 gram (handful) per liter hot water Torx screwdriver T20 USB flash drive...
  • Page 116 List of tools R5917033 /00...

  • Page 117: Index

    Index Install 61 Numbers/Symbols Remove 61 DisplayPort 1.2 inputs Address Specifications 79 Prodcution 104 DisplayPort 1.4 inputs Specifications 77 Disposal 103–104 Battery 105 Backlight 30 DMX chart 93 Battery Basic 94 Disposal 105 Extended 95 DMX Chart Input mapping 94 DMX input 49 DMX interface 49 CE Certification 21...
  • Page 118 Index remove 62 Function Orientation Button pressed indicator 36 Projector 24 OSD 31 Overview video timings 84 General considerations 10 PJLink Command List 100 Hazard Distance 17, 19 Commands 99 Modifying optics 20 Power Multi-projector 20 Modes 42 Projector stacks 20 Power mode Hazardous Chemicals 16, 111 Transition 44...
  • Page 119 Index Safety 9 Vacuum Battery explosion 13 Filters 58 Cooling liquid circuit 13 Video timings Electrical shock 11 DisplayPort Inputs 87 Fire hazard 13 HDBaseT Inputs 90 Hazard Distance 17, 19 HDMI Inputs 86 Hazardous Chemicals 16, 111 Video Timings Important instructions 11 SDI Inputs 85 Personal injury 12...
  • Page 120 Index R5917033 /00...
  • Page 122 R5917033 /00 | 2024-09-24 www.barco.com...

This manual is also suitable for:

Qdx w35Qdx 4k35Qdx w45Qdx 4k45Qdx w/4k laphQdx n4k laph

Table of Contents
