- Page 1 P/N: S00204 -HDMI- 2x1 Multi-Viewer with PIP User Manual VER 2.2 Stock Code 873117 en.rgble.com 400-1661-021...
- Page 2 P/N: S00204 Thank you for purchasing RGBLE product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
- Page 3 10W (max) Operating Temperature 0° C ~ 40° C / 32° F ~ 104° F Storage Temperature -20° C ~ 60° C / -4° F ~ 140° F Relative Humidity 20~90% RH (non-condensing) 5. product Images Stock Code 873117 en.rgble.com 400-1661-021...
- Page 4 . SIZE: Press the button to select the size of sub image when in PIP mode. ➓ RESOLUTION: Press the button to select the output resolution. RESOLUTION 1080P, Main image audio 720P, Main image audio 1080I, Main image audio 1024x768, Main image audio 1360x768, Main image audio Stock Code 873117 en.rgble.com 400-1661-021...
- Page 5 . DC 5V IN: Plug the 5V DC power supply into the unit. ※ Description 1 Mode Introduction: Mode 1: One-view mode Mode 2: PIP mode Mode 3: POP mode A Mode 4: POP mode B Stock Code 873117 en.rgble.com 400-1661-021...
- Page 6 5 . POSITION: Press these buttons to select the position of sub image when in PIP mode. ○ 6 . MODE: Press the button to select display mode. ○ 7 . RESO: Press the button to select the output resolution. Stock Code 873117 en.rgble.com 400-1661-021...
- Page 7 P/N: S00204 8. Application Example Stock Code 873117 en.rgble.com 400-1661-021...
