- Page 1 BT8385-BDB Bolt-Down Base Use With A BT8385 Column Installation Guide Item Description Base M6 x 35mm CSK Hex Screw 5AF Hex Key Designed to work in conjunction with B-Tech’s Model-AL range www.btechavmounts.com...
- Page 2 Installation Safety Instructions Caution: This mount is intended for use only with the maximum weights indicated. Use with equipment heavier than the maximum indicated may result in instability causing possible injury. B-Tech AV Mounts, it’s distributors and dealers are not responsible for damage or injury caused by improper installation, improper use, modifications, installations over the specified weight capacity and/or failure to observe these safety instructions.
- Page 3 Bolt Stand To The Floor Pre-drill holes in floor and using suitable ground anchor fixings (not supplied), fix stand to floor. Ground Anchors Ground Anchors (Not Supplied) Concrete Floor...
- Page 4 BT8385-BDB Bolt-Down Base Use With A BT8385 Column Dimensions Top View Bottom View [12.21in] 310mm [1.58in] [9.05in] [1.58in] 40mm 230mm 40mm [4.41in] 112mm [0.41in] 4 x 10.5mm [2.36in] 60mm Side View Contact: info@btechavmounts.com ©2024 B-Tech AV Mounts Corporation Ltd. All rights reserved.
