BT8390-VESA200T
Interface Arms With Tilt
Use with a BT8390 Mounting Rail
Parts List
1
3
A
B
C
I
K
L
Designed to work in conjunction with B-Tech's System X range
4
2
6
D
E
F
J
M
www.btechavmounts.com
Item
1
2
5
3
4
5
6
A
B
C
D
G
H
E
F
G
H
I
J
K
L
M
Description
Interface Arm - Left
Interface Arm - Right
M8 x 55mm Hex Screw
M6 x 8mm Hex Screw
5AF Long Hex Key
4AF Hex Key
Screen Fixings
M4 x 12mm Screw
M4 x 25mm Screw
M6 x 16mm Screw
M6 x 25mm Screw
M6 x 40mm Screw
M8 x 16mm Screw
M8 x 25mm Screw
M8 x 50mm Screw
M4 Washer
M6 Washer
5mm Spacer
15mm Spacer
25mm Spacer
Max
Max
Load
VESA
200
70kg
[154lbs]
Qty
1
1
4
2
1
1
4
4
4
4
4
4
4
4
4
4
4
4
4
Tilt
20
°
