Clarke MGH3 User Instructions
Clarke MGH3 User Instructions

Clarke MGH3 User Instructions

Folding mobile gas heater

Advertisement

Quick Links

This product is not suitable for primary heating purposes
FOLDING MOBILE GAS HEATER
MODEL NO: MGH3
PART NO: 6920029
USER INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC05/24

Advertisement

loading
Need help?

Need help?

Do you have a question about the MGH3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clarke MGH3

  • Page 1 This product is not suitable for primary heating purposes FOLDING MOBILE GAS HEATER MODEL NO: MGH3 PART NO: 6920029 USER INSTRUCTIONS ORIGINAL INSTRUCTIONS GC05/24...
  • Page 2 INTRODUCTION Thank you for purchasing this CLARKE Mobile Gas Heater. This portable gas heater is designed to give safe, efficient and reliable operation and is for use with LPG/Butane gas only. Gas bottles are not supplied with the unit but are readily available from builders merchants or gas suppliers.
  • Page 3 THE FOLLOWING TABLE ADDRESSES THE INFORMATION REQUIREMENTS OF REG.2015/1188 & ERP COMPLIANCE Item Symbol Value Unit Fuel LPG butane Gaseous G30 Space Heating Emission(*) 114.32 mg/kWh Indirect heating fuctionality: [yes/no] Heat Output At nominal heat output Pnom At minimum heat output (indicative) 1.66 Pnom Auxiliary electricity consumption...
  • Page 4 3. ALWAYS keep children and animals well away from heater at all times. 4. NEVER carry out any modifications to this product. If experiencing difficulty of any kind consult your local CLARKE dealer. 5. NEVER move the heater when it is lit.
  • Page 5 CARBON MONOXIDE HAZARDS WARNING: LACK OF VENTILATION CAN CAUSE CARBON MONOXIDE POISONING WHICH CAN BE FATAL. Carbon Monoxide is a highly toxic, odourless, colourless and tasteless gas, created by the incomplete combustion of carbon compounds due to a lack of available oxygen in an enclosed space. The signs of carbon monoxide poisoning are, headaches, dizziness and/or nausea.
  • Page 6 FEATURES OF THE MGH3 HEATER The MGH3 gas heater comprises three groups of components: GAS SUPPLY COMPONENTS The gas supply to the machine is by means of a high pressure hose, connected to a gas cylinder via a pressure regulator.
  • Page 7 PREPARATION When unpacking, check the heater for any damage that may have occurred in transit and notify your CLARKE dealer immediately should any be apparent. The following items are supplied • 500mm Gas hose • 2 x Jubilee clips • 21mm snap-fit regulator •...
  • Page 8 Contact your CLARKE dealer or gas supplier for assistance. CAUTION: DO NOT USE IF A LEAK IS FOUND. DO NOT USE A NAKED FLAME FOR TESTING.
  • Page 9 POSITIONING THE HEATER The heater must be located on a hard, level surface to minimise the risk of accidental tipping with the gas bottle held by the bottle retainer. DO NOT operate this heater with the gas bottle in any other than the upright position. The heater must be located such that it will not be exposed directly to sources of water.
  • Page 10 If the hose shows evidence of damage or if the hose is cut, it must be replaced prior to the heater being put into operation. The replacement hose shall be that specified by CLARKE International.
  • Page 11 CHANGING THE SETTING 1. To select the desired heating level, press the control knob down and rotate until the knob locks at the desired position (Low / High). DO NOT operate between the locked positions. TURNING THE HEATER OFF 1. Set the control knob to the START position. 2.
  • Page 12 2. Regularly check the flexible tubing between the regulator and heater and replace if cracked. In the event of damage or broken components, replacements should only be obtained from CLARKE Parts & Service. 3. Have the heater inspected yearly by a qualified service agent.
  • Page 13 TROUBLESHOOTING PROBLEM CAUSE REMEDY Pilot light will not light No spark across Request service technician to automatically. electrode gap. check the piezo-electric switch is functioning correctly. Check the electrical lead to the pilot light is not damaged. Pilot light will not light Incorrect position of Request service technician to re- automatically but...
  • Page 14 5kg to 15kg (max 32cm dia x 55cm high) Please note that the details and specifications contained herein are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the heater’s data plate.
  • Page 15 COMPONENT PARTS Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 16 COMPONENT PARTS Description No Description Front panel Control Knob Safeguard Anti-tilt device Lower thermal baffle ODS gas pipe Burner assembly Gas pipe Nozzle Castor wheel Top thermal baffle Spindle Side panel - left Thumbscrew Side panel - right Cylinder holder Ignition cable Top panel Thermocouple cable...
  • Page 17 DECLARATION OF CONFORMITY - UKCA Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 18 DECLARATION OF CONFORMITY - CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
  • Page 19 OTHER PRODUCTS FROM THE CLARKE RANGE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
