Network Configuration
Device initialization and IP setting can be finished with the "IP Finder" or in web interface. For
more information, see the WEB Operation Manual.
Device initialization is available on select models, and it is required at first use and
after device is being reset.
Device initialization is available only when the IP addresses of the device
(192.168.1.250 by default) and the PC stays in the same network segment.
Planning useable network segment properly to connect the device to the network.
The following figures and interfaces are for reference only, and the actual product
shall prevail.
2.1 Initializing Device
Step 1 Double-click "IP Finder.exe" to open the tool.
Step 2 Click
The Modify IP interface is displayed. See Figure 2-1.
.
Figure 2-1 Modify IP interface
