Summary of Contents for National Instruments NI 9214
Page 1
NI NI TB-9214 Isothermal Terminal Block In Stock Used and in Excellent Condition Open Web Page https://www.artisantg.com/96818-3 A l l t r a d e m a r k s , b r a n d n a m e s , a n d b r a n d s a p p e a r i n g h e r e i n a r e t h e p r o p e r t y o f t h e i r r e s p e c t i v e o w n e r s . •...
Page 3
This document explains how to connect to the NI 9214. Before you begin, complete the software and Note hardware installation procedures in your chassis documentation. The guidelines in this document are specific to Note the NI 9214. The other components in the system might not meet the same safety ratings.
Page 5
This category refers to local-level electrical distribution, such as that provided by a standard wall outlet, for example, 115 V for U.S. or 230 V for Europe. Do not connect the NI 9214 to signals or use Caution for measurements within Measurement Categories III or IV.
Page 6
Safety Guidelines for Hazardous Locations The NI 9214 is suitable for use in Class I, Division 2, Groups A, B, C, D, T4 hazardous locations; Class I, Zone 2, AEx nA IIC T4 and Ex nA IIC T4 hazardous locations; and nonhazardous locations only.
Page 7
Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI 9214 in Gas Group IIC hazardous locations, you must use the device in an NI chassis that has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.
Page 9
In addition, take precautions when designing, selecting, and installing measurement probes 8 | ni.com | NI 9214 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
Page 10
EMC performance is attained. Preparing the Environment Ensure that the environment in which you are using the NI 9214 meets the following specifications. Operating temperature -40 °C to 70 °C (IEC 60068-2-1, IEC 60068-2-2)
Page 13
All thermocouples are referenced to the same common-mode voltage • One thermocouple is reference to a common-mode voltage and all other thermocouples are floating 12 | ni.com | NI 9214 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
Page 14
NI 9214 Connection Guidelines • Make sure that devices you connect to the NI 9214 are compatible with the module specifications. • The shield grounding methodology can vary depending on the application.
Page 15
Minimize adjacent heat sources and air flow across the terminals. • Keep the ambient temperature as stable as possible. • Make sure the NI 9214 terminals are facing forward or upward. • Keep the NI 9214 in a stable and consistent orientation. •...
Page 19
LabVIEW Help RELATED INFORMATION C Series Documentation Services & Resources ni.com/services ni.com/info cseriesdoc Located at ni.com/manuals Installs with the software 18 | ni.com | NI 9214 Getting Started Guide hnology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www...
