7.1.10. MIXING VALVE
The function allows you to view the values and status of individual parameters of the mixing valve. For a detailed description
of the function and operation of the valve, please refer to the L-12 controller manual.
7.1.11. VERSION
The function displays the software version number of the module. This information is necessary when contacting the service.
7.2. ADDITIONAL MODULES
It is possible to expand the number of supported zones by using additional ML-12 controllers (modules) (max. 4 in the system).
7.2.1. MODULE SELECTION
Each controller must be registered separately in the L-12 controller:
•
In the L-12 controller, select:
Menu → Fitter's menu → Additional Modules → Module 1..4 → Module Type → Wired/Wireless → Register
•
In the ML-12 controller, select:
Menu → Fitter's menu → Master Module → Module Type → Wired/Wireless → Register
The ML-12 add-on module can also be registered via the EU-M-12t panel:
•
In the panel, select:
Menu → Fitter's menu → Additional Modules → Module 1...4 → Module Selection → Wired/Wireless → Register
•
In the ML-12 controller, select:
Menu → Fitter's menu → Master Module → Module Type → Wired/Wireless → Register
7.2.2. INFO
The parameter allows you to preview which module is registered in the L-12 controller and which functions are enabled.
7.2.3. NAME
The option is used to name the registered module.
7.2.4. ZONES
The function is described in chapter 7.1.4. Zones.
7.2.5. ADDITIONAL CONTACTS
The parameter allows you to register additional contacts (max. 6 pcs.) and preview information about these contacts, e.g.
operation mode and range.
7.2.6. VOLTAGE-FREE CONTACT
The option allows you to switch on the remote operation of the voltage-free contact, i.e. start this contact from the EU-ML-
12 slave controller and set the delay time of the contact.
